Raceway [Standing] Rev 3 Eng

Raceway [Standing] Installation guidelines

©2025 All rights reserved

Eng

Please read these instructions carefully before starting installation. Failure to follow these instructions may result in damage to the product or property.

Installation should be carried out by qualified personnel only. If you are not confident with any part of the installation process, please contact a professional installer for assistance.

The manufacturer is not responsible for any damage caused by incorrect installation or misuse of the product.

Please check all parts and tools are included before installation.

Ensure the parts and tools are suitable for the product’s weight and size.

Ensure the mounting surface is suitable for the product’s weight and size.

Always use appropriate safety equipment and take necessary precautions when working with tools and electricity.

These instructions are provided as a guide only. Actual installation may vary depending on specific circumstances and site conditions.

Required Tools • • • • • • •

Drill With Drill Bit Threaded Rods & Bolts Pencil Hammer Spanner Wrench Mounting Glue Vacuum Cleaner

E-mail: support@signage-group.com Phone: +49 (0)30 863280590 Opening hours: Mon. - Fri., 9:00 - 17:00 Uhr Office address:Bogen 45, Holzmarktstr. 15-18 10179 Berlin Germany

2

The appearance of the standing structure may vary depending on the design.

Step 1

Step 2

Step 3

Place the product in the installation location and mark the mounting points on the floor using a pencil.

Move the product aside and drill holes at the marked points.

Clean the holes from dust using a vacuum cleaner.

Step 4

Step 5

Pour mounting glue into the drilled holes and insert the threaded rods, making sure they stick out higher than the construction. Glue must come out at the top of hole to avoid moisture damage in the future

Wait for the glue to harden. Place the product onto the exposed threaded rods and secure it with bolts using a wrench.
