BASKET TRAY INTRODUCTION

BASKET TRAY FITTINGS

Basket tray is a wire mesh style cable tray system designed for sensitive cable applications in the data and communications industry. It utilizes high mechanical strength steel wire that is welded into a 2″ x 2″ grid system. This grid system is then formed into channels which support and carry cables. By using Basket Tray’s welded mesh, sensitive cables and fiber optics receive additional support and are safe from any damage due to sharp edges.

HORIZONTAL 90° CONNECTOR KIT (SSP-90-2)

This kit uses our unique 90° splice connectors that maximize cable support while field cutting is minimized by overlapping and clamping into place. Each Kit has 2 back plates, one “L” shaped plate, nuts and bolts.

T CONNECTOR KIT

TECHNICAL DATA Depth:

2″, 4″ and 6″ or 50mm, 100mm & 150mm.

Length:

10 feet (120″) or 3 meter standard.

Width (inside):

2″, 4″, 6″, 10″, 12″, 16″, 18″, 20″, and 24″.

Materials:

Welded steel wire, mill galvanized; other materials available by request. The 2″ x 2″ grid size provides support for cables every 2″ instead of every 4″ like other mesh trays on the market.

Basket Tray T Connectors require 2 Horizontal 90° Connector Kits.

X CONNECTOR KIT

CATALOG NUMBER

WB24–24–120 Wire Basket Grid Depth Size

Tray Series WB22-12 WB22-24 WB24-12 WB24-24 WB26-12 WB26-24

Width

Tray Size inch mm 2X12 50X300 2X24 50X600 4X12 100X300 4X24 100X600 6X12 150X300 6X24 150X600

Length

1.52m/5ft kg/ft lb/ft 35.8 79 42.6 102 42.6 102 42.6 102 52.6 115 52.6 115

Basket Tray X Connectors require 4 Horizontal 90° Connector Kits to make a Cross. Remove a section of each Tray side wall, overlap and connect.

1.82m/6ft kg/ft lb/ft 24.9 55 32.2 71 32.2 71 32.2 71 36.2 80 36.2 80

2.13m/7ft kg/ft lb/ft 18.1 40 23.6 52 23.6 52 23.6 52 26.8 59 26.8 59

2.43m/8ft kg/ft lb/ft 14.1 31 18.1 40 18.1 40 18.1 40 20.4 45 20.4 45

Maximum # of Cables * 315 651 608 1260 936 1540

* This chart is based on 50% fill of 4 UTP Category 5 cable (O.D. of 0.21″ 0.026lbs/ft) For more information, please call 604.572.4419 or visit www.superiortray.com

page 32

Saving you Time, Saving you Money, Putting you First!

BASKET TRAY BASKET TRAY SPLICES

VERTICAL ADJUSTABLE SPLICE CONNECTOR (SFS-VWB2)

SPLICE CONNECTOR (SSP-WB2) Splice connectors are used to clamp two Basket Tray sections together effortlessly. The inner ridged plate clamps the vertical side wires to the outer L-formed plate leveling and supporting the horizontal wire.

Vertical Adjustable Splices are used when modifying the elevation of the cable tray routing.

ACCESSORIES

CENTER HANGER CLAMP

HOLD DOWN CLAMP

2 Hold Down Clamps are fastened to sustain Tray from 1/4″ threaded rod. 2 pieces are required per hanger rod.

(WBHDC) Hold Down Clamps allow Basket Tray sections to be securely fastened into place.

For 1/4″ rod: WBHDC

For 3/8″ rod: WBHDC-3/8

SIDE HANGER CLAMP For trapeze type supports, this clamp attaches threaded rod to the side of the cable tray. For 1/4″ rod: WBVHC

For 3/8″ rod: WBVHC-3/8

For more information, please call 604.572.4419 or visit www.superiortray.com

page 33

Saving you Time, Saving you Money, Putting you First!

BASKET TRAY SUPPORTS AND CONNECTORS UNDER FLOOR BRACKET

UNDER FLOOR PAN SUPPORT

Superior Tray provides an “L” bracket support for 2″ to 24″ wide Basket Tray that includes a clamp, 3/8″ x 1″ square bolt and 1 WBHDC hold down clamp to attach to bracket.

We provide a 6″ Floor Pan Support that includes a WBHDC hold down clamp to attach the tray to floor pan.

Part No. WBUFB-( )

Part No. WBUFB-6

( ) = Width

BOX CONNECTOR

DROP OUTS

A Box Connector is used to terminate a Basket Tray run to an enclosure, wall or some other junction to a flat perpendicular surface. Includes all mounting hardware.

Drop Outs are provided for both ends of Basket Tray runs and for exiting the side of Basket Tray. They include mounting hardware.

Part No. WBBC-(W)

Part No. WBD-(W)

W = Width

2 1/16"

5 1/2"

W 2 1/16"

END PLATE

WALL BRACKET

End Plates are available for Basket Tray and are furnished with mounting hardware.

Wall Brackets are to be used for mounting Basket Tray from walls or other structures. Hold down clamps WBHDC and cap screws are not included.

Part No. WEP-(W)-(D) W = Width D = Depth

Part No. WBVBK-( )

( ) = Tray width

W 2"

For more information, please call 604.572.4419 or visit www.superiortray.com

page 34

Saving you Time, Saving you Money, Putting you First!

BASKET TRAY SEPARATORS / BARRIERS

CENTER HANGER CLIP

Separators are available in 2″-6″ Heights and come slotted at regular intervals to facilitate installation. Drilling is not required.

For 1/4″ rod Part No. WBCHC For 3/8″ rod Part No. WBCHC-3/8

Part No. S( )S-120-WB

( ) = Height

6 1/4"

2 7/8"

With our Center Hanger Clips, all of our Basket Trays are installed in a true center hung position.

FLANGED COVERS

Z BRACKETS

Flanged Covers are available for all Basket Tray widths. The WBCC cover clamp is available for all depths.

The Z Bracket is recommended to be used when attaching a Basket Tray to a wall, an enclosure or to the floor.

Part No. WBCF2-( )-120 ( ) = Width

Part No. WBBC-( ) ( ) = Depth

3/8 "

Part No. WB-Z

1 1/4"

120 "

1 1/4"

CENTER SUPPORT CHANNEL

TRAPEZE HANGER SUPPORT Hanger Rod (1/4" or 3/8")

1/4" Hanger rod

3/4" W

3/4"

1 1/2"

Part # WBCS-28 WBCS-24 WBCS-22 WBCS-20 WBCS-18 WBCS-16

W 28 24 22 20 18 16

″ ″ ″ ″ ″ ″

Part # WBCS-12 WBCS-8 WBCS-6 WBCS-4 WBCS-2

W 12 8 6 4 2

″ ″ ″ ″ ″

Part #

WBTHS-28 WBTHS-24 WBTHS-22 WBTHS-20 WBTHS-18 WBTHS-16

32″ 28″ 26″ 24″ 22″ 20″

WBTHS-12 WBTHS-8 WBTHS-6 WBTHS-4 WBTHS-2

16″ 12″ 10″ 8″ 6″

Note: Hanger Rod is supplied seperately.

For more information, please call 604.572.4419 or visit www.superiortray.com

page 35
