The Stanton Street decorative commercial concept originates from Stanton Carpet’s roots. Early on, our company’s founder resided in the Lower East Side of Manhattan, near Stanton Street. Influenced by the energy and style of New York City, Stanton Street exudes that inspiration into its decorative commercial carpet with a dramatic and edgy assortment of styles.
STANTON STREET
DECORATIVE COMMERCIAL
The Stanton Street display features broadloom, carpet tile, plank tile, and decorative vinyl plank flooring for application in spaces ranging from medium to heavy commercial. These high-style commercial products are rated Class I . The 25-pin display also holds coordinating architectural folders.
● DIMENSIONS: 68”W X 64”H X 22”D
● PRODUCT SAMPLES: HOLDS 25 - 21”W X 24”L DISPLAY BOARDS
4
Carpet Tile & Carpet Plank
FLATIRON TILE
BROADWAY TILE
INSTALLATION METHODS
Content: SD Nylon
Carpet Tile Size: 20” x 20” (19.7” x 19.7”)
Carton: 20 Tiles= 6 sq yards= 5 m²
Face/Pile Weight: 17 oz/sy
Gauge: 1/10”
Density: 5564
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662 Flaming & Non-Flaming)
Static Propensity: < 4.1 KV (AATCC 134)
6
METAL
TAUPE CHARCOAL INDIGO JET BLACK
Heavy Commercial
QUARTER TURN
BRICK
BRICK QUARTER TURN
CENTRAL PARK TILE
QUARTER TURN
METHODS
QUARTER TURN
Content: SD Royaltron® Polypropylene
Carpet Tile Size: 20” x 20” (19.7” x 19.7”)
Carton: 20 Tiles= 6 sq yards= 5 m²
Face/Pile Weight: 18 oz/sy
Gauge: 1/12”
Density: 5500
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662 Flaming & Non-Flaming)
Static Propensity: < 2.0 KV (AATCC 134)
7 BRICK QUARTER TURN
INSTALLATION
BUFF DENIM SILVERFOX JET FLINT
Heavy Commercial
CROSBY PLANK TILE
INSTALLATION METHODS
Content: SD Nylon
Carpet Tile Size: 13” x 39” (13.1” x 39.3”)
Carton: 15 Tiles= 6 sq yards= 5 m²
Face/Pile Weight: 20 oz/sy
Gauge: 1/12”
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662 Flaming & Non-Flaming)
Static Propensity: < 2.0 KV (AATCC 134)
8
BRICK QUARTER TURN
TAUPE SHADOW
COAL
EBONY LAPIS
Heavy Commercial
BRICK
HERRINGBONE END BLOCK MONOLITHIC REGULAR ASHLAR BASKETWEAVE BRICK NEW FOR 2024
BASKETWEAVE
FLATIRON TILE
QUARTER TURN
FOG
LET THE SUNSHINE
NIGHTFALL
FALL INTO DAY
SEASIDE
SNOWY SEA
Content: SD Royaltron® Polypropylene
Carpet Tile Size: 20” x 20” (19.7” x 19.7”)
Carton: 20 Tiles= 6 sq yards= 5 m²
Face/Pile Weight: 18 oz/sy
Gauge: 1/12”
Density: 5500
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662 Flaming & Non-Flaming)
Static Propensity: < 2.0 KV (AATCC 134)
Heavy Commercial
9
BRICK
BRICK – COLOR ZONED
GRAND AVENUE TILE
INSTALLATION METHODS
Content: SD Royaltron® Polypropylene
Carpet Tile Size: 20” x 20” (19.7” x 19.7”)
Carton: 20 Tiles= 6 sq yards= 5 m²
Face/Pile Weight: 18 oz/sy
Gauge: 1/12”
Density: 5500
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662 Flaming & Non-Flaming)
Static Propensity: < 2.0 KV (AATCC 134)
10
BRICK QUARTER TURN ASHLAR
ASH ICE BLUE
WARM FOSSIL DENIM MIDNIGHT
Heavy Commercial
ASHLAR
NEW FOR 2024
BRICK
GRAND CENTRAL TILE
INSTALLATION METHODS
Content: SD Royaltron® Polypropylene
Carpet Tile Size: 20” x 20” (19.7” x 19.7”)
Carton: 20 Tiles= 6 sq yards= 5 m²
Face/Pile Weight: 18 oz/sy
Gauge: 1/12”
Density: 5500
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662 Flaming & Non-Flaming)
Static Propensity: < 2.0 KV (AATCC 134)
11
BRICK QUARTER TURN
Heavy Commercial
SLATE GREY BUFF MARINE JET FLINT
QUARTER TURN
BRICK
GRAND LUXE PLANK TILE
INSTALLATION METHODS
Content: SD Royaltron® Polypropylene
Carpet Tile Size: 13” x 39”
Carton: 20 Tiles= 6 sq yards= 5 m²
Face/Pile Weight: 18 oz/sy
Gauge: 1/12”
Density: 5500
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662 Flaming & Non-Flaming)
Static Propensity: < 2.0 KV (AATCC 134)
12
BRICK QUARTER TURN
RANDOM ASHLAR
Heavy Commercial
HERRINGBONE END BLOCK MONOLITHIC REGULAR ASHLAR RANDOM ASHLAR BASKETWEAVE BRICK ASH GREY ICE BLUE WARM FOSSIL DENIM MIDNIGHT NEW FOR 2024
HERRINGBONE
HEADQUARTERS PLANK TILE
INSTALLATION METHODS
Content: SD Nylon 6
Carpet Tile Size: 13” x 39” (13.1” x 39.3”)
Carton: 15 Tiles= 6 sq yards= 5 m²
Face/Pile Weight: 18 oz/sy
Gauge: 1/12”
Density: 5500
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662 Flaming & Non-Flaming)
Static Propensity: < 2.0 KV (AATCC 134)
13
Heavy
Commercial
ASHLAR
HERRINGBONE END BLOCK MONOLITHIC REGULAR ASHLAR BASKETWEAVE BRICK
BLACK GREIGE DARK HARBOR CHARCOAL BUFF
HERRINGBONE
JET
PROSPECT PLANK TILE
INSTALLATION METHODS
BRICK QUARTER TURN
Content: SD Nylon 6
Carpet Tile Size: 13” x 39” (13.1” x 39.3”)
Carton: 15 Tiles= 6 sq yards= 5 m²
Face/Pile Weight: 18 oz/sy
Gauge: 1/12”
Density: 5500
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662 Flaming & Non-Flaming)
Static Propensity: < 2.0 KV (AATCC 134)
14
Heavy Commercial
FOG SANDSTONE SHADOW SMOKE INDIGO STEEL HERRINGBONE END BLOCK HERRINGBONE END BLOCK MONOLITHIC REGULAR ASHLAR RANDOM ASHLAR BASKETWEAVE BRICK
WALL STREET TILE
TAUPE
INSTALLATION METHODS
Content: SD Nylon
Carpet Tile Size: 20” x 20” (19.7” x 19.7”)
Carton: 20 Tiles= 6 sq yards= 5 m²
Face/Pile Weight: 17 oz/sy
Gauge: 1/10”
Density: 5564
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662 Flaming & Non-Flaming)
Static Propensity: < 4.1 KV (AATCC 134)
15
BRICK QUARTER TURN
METAL
CHARCOAL
INDIGO JET BLACK
Heavy Commercial
QUARTER TURN
BRICK
STANTON STREET
CARPET TILE FEATURES & BENEFITS
DEALER BENEFITS
• Tile and plank options are simple to measure and install
• Products are easy to transport in branded sturdy boxes that stack and ship well
• Less waste
CONSUMER BENEFITS
• Tiles and planks are easy to swap
• Installation is not disruptive to business
LAYOUT OPTIONS
• Flexible layout choices offer a modular, modern, and custom look that appeal to style-conscious consumers
• Easy to install to fit corners and cubicles
NYLON HIGHLIGHTS
• Durable, excellent wear performance, and can be spot cleaned
• Solution dyed for longevity of coloring
POLYPROPYLENE HIGHLIGHTS
• Strong resilience and wear performance
• Solution dyed and resistant to water-based stains, mildew, pilling, and electrostatic build-up
FLAMMABILITY
• All products are Class I
ADA COMPLIANT
ADA compliant tiles and planks are a great option for the elderly and children. Due to low-pile height and sturdy backing, a safe, firm, and slip resistant surface is provided.
BACKING BENEFITS
• Bitumen is PVC free and can be recycled.
• Bitumen is traditionally used in commercial carpet backing. It is comprised of hydrocarbons and often used in materials for road surfacing.
• Dimensionally stable and can withstand temperature and humidity fluctuations.
Our Carpet Tile is Backed with Four Layers
Hex-embossed scrim to provide reliable adhesion
Modified stable Bitumen core
Advanced polymer pre-coat for clean edges
Non-woven primary layer that will not fray
Resilient pile
INSTALLATION METHOD
Installation instructions will be provided in each shipment. Stanton recommends using a premium releasable carpet tile adhesive.
GREEN LABEL PLUS (GLP)
Green label plus is a program of the Carpet & Rug Institute based in Dalton, GA. Emissions (VOC’s/ off-gassing) are certified to be below certain very low thresholds. This gives consumers confidence regarding safety and air quality.
17
Broadloom
DIFFUSE
DIFFUSE
Content: Nylon 6 (Printed)
Face/Pile Weight: : 36 oz/sy
Pattern Repeat: 19 ¾" W X 12 ¼"L
Carpet Width: 13'2"
Backing: Action Back
Gauge: 1/10”
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662
Flaming & Non-Flaming)
Static Propensity: < 5.0 KV (AATCC 134)
Residential to Heavy Commercial
19 SADDLE MARINE MIDNIGHT STEEL
BLUESTONE
PEBBLE
FLUIDITY
Content: Nylon 6 (Printed)
Face/Pile Weight: : 36 oz/sy
Pattern Repeat: 1” W X 1/2”L
Carpet Width: 13'2"
Backing: Action Back
Gauge: 1/10”
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662
Flaming & Non-Flaming)
Static Propensity: < 5.0 KV (AATCC 134)
Residential to Heavy Commercial
20 MARINE
PEBBLE
STEEL
BLUESTONE
SADDLE SAND IRON
LASER FOCUS
Content: SD Nylon
Face/Pile Weight: : 21 oz/sy
Pattern Repeat: 11 3/4” W x 12 1/2” L
Carpet Width: 13'2"
Backing: Action Back
Gauge: 1/10”
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662
Flaming & Non-Flaming)
Static Propensity: < 3.5 KV (AATCC 134)
Residential to Medium Commercial
21
STEEL
FOG
BEACH
BLACKSTONE RAVEN
DENIM
Content: SD Nylon
Face/Pile Weight: : 21 oz/sy
Pattern Repeat: 11 3/4” W x 33 1/2” L
Carpet Width: 13'2"
Backing: Action Back
Gauge: 1/10”
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662
Flaming & Non-Flaming)
Static Propensity: < 3.5 KV (AATCC 134)
Residential to Medium Commercial
22 NAVY SABLE CINDER METAL FOG
SANDSTONE
LONGITUDE
MADISON AVE.
Content: SD Nylon 6
Face/Pile Weight: : 15 oz/sy
Pattern Repeat: N/A
Carpet Width: 13'2"
Backing: Action Back
Gauge: 5/64”
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662
Flaming & Non-Flaming)
Static Propensity: < 4.0 KV (AATCC 134)
Residential to Medium Commercial
23
STONE SHADOW
BLACKSTONE FLINT JET
PEBBLE
OPERA
Content: Nylon 6 (Printed)
Face/Pile Weight: : 36 oz/sy
Pattern Repeat: 11 1/4" W x 14"L HALF DROP
Carpet Width: 13'2"
Backing: Action Back
Gauge: 1/10”
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662 Flaming & Non-Flaming)
Static Propensity: < 5.0 KV (AATCC 134)
24
Heavy Commercial NAVY RUBY
STORM CLOUD BLUESTONE
Content: Nylon 6 (Printed)
Face/Pile Weight: : 36 oz/sy
Pattern Repeat: 39 1/2" W x 18 1/2" L
Carpet Width: 13'2"
Backing: Action Back
Gauge: 1/10”
Surface Flammability: Passes (FF 1-70)
Radiant Panel: CLASS 1 (ASTM E 648)
Smoke Density: < 450 (ASTM E 662
Flaming & Non-Flaming)
Static Propensity: < 5.0 KV (AATCC 134)
25 MARINE RUBY
ASH FOG
BLUESTONE
Heavy Commercial THEATRE
STANTON ®
26
■ BROADLOOM CARPET WITH COMMERCIAL RATING Adventure ...................................................... 27 Ambition 27 Apex ................................................................ 28 Bravo ............................................................... 28 Circuit ............................................................. 29 Meridian 29 Rapture ........................................................... 30 Rejoice ............................................................ 30 Vigor ............................................................... 31 Zenith 31 AMBITION
ADVENTURE
Residential to Medium Commercial
Content: Scotchgard 3M™ SD Nylon
Pattern Repeat : 16 ¼” W x 28 ¾” L HALF DROP
Carpet Width: 13'6"
Rating: Class 1
Commercial Wear Warranty: 10 Years
Stain Warranty: Scotchgard® 10-Year Warranty
AMBITION
Residential to Medium Commercial
Content: Scotchgard 3M™ SD Nylon
Pattern Repeat : 32 1/2” W x 35 1/2” L
Carpet Width: 13'6"
Rating: Class 1
Commercial Wear Warranty: 10 Years
Stain Warranty: Scotchgard® 10-Year Warranty
27
OYSTER PLATINUM MARINE WEDGEWOOD TAUPE CHROME
GOLDEN
OYSTER PLATINUM TAUPE WEDGEWOOD CHROME MARINE
GOLDEN
APEX
Residential to Medium Commercial
Content: Scotchgard 3M™ SD Nylon
Pattern Repeat : 3” W x 2 3/4” L
Carpet Width: 12'
Rating: Class 1
Commercial Wear Warranty: 10 Years
Stain Warranty: Scotchgard® 10-Year Warranty
BRAVO
Residential to Medium Commercial
Content: Scotchgard 3M™ SD Nylon Type 6
Pattern Repeat : 12” W x 1” L
Carpet Width: 13'6"
Rating: Class 1
Commercial Wear Warranty: 10 Years
Stain Warranty: Scotchgard® 10-Year Warranty
28 BONE OYSTER PUTTY WAVE SKY FLINT
STRAW KHAKI FLANNEL METAL MERCURY
VANILLA
CIRCUIT
Residential to Light Commercial
Content: Scotchgard 3M™ SD Nylon Type 6,6
Pattern Repeat : 18” W x 12 1/2” L
Carpet Width: 12'
Commercial Wear Warranty: 5 Years
Stain Warranty: Scotchgard® 10-Year Warranty
MERIDIAN
Residential to Medium Commercial
Content: Scotchgard 3M™ SD Nylon
Pattern Repeat : 6” W x 9 1/2” L
Carpet Width: 12'
Rating: Class 1
Commercial Wear Warranty: 10 Years
Stain Warranty: Scotchgard® 10-Year Warranty
29 BONE OYSTER PUTTY WAVE SKY FLINT
VANILLA STRAW KHAKI
PEWTER METAL
MERCURY
RAPTURE
Residential to Medium Commercial
Content: Scotchgard 3M™ SD Nylon
Pattern Repeat : 2” W x 5” L HALF DROP
Carpet Width: 13'6"
Rating: Class 1
Commercial Wear Warranty: 10 Years
Stain Warranty: Scotchgard® 10-Year Warranty
REJOICE
Residential to Medium Commercial
Content: Scotchgard 3M™ 6,6 Nylon
Pattern Repeat : 6” W x 6” L
Carpet Width: 13'6"
Rating: Class 1
Commercial Wear Warranty: 10 Years
Stain Warranty: Scotchgard® 10-Year Warranty
30
PLATINUM CHAMPAGNE METAL PLATINUM SANDSTONE SANDSTONE CHAMPAGNE METAL BRONZE BRONZE DEEP SEA DEEP SEA
VIGOR
Residential to Medium Commercial
Content: Scotchgard 3M™ SD Nylon
Pattern Repeat : 18” W x 24” L HALF DROP
Carpet Width: 13'6"
Rating: Class 1
Commercial Wear Warranty: 10 Years
Stain Warranty: Scotchgard® 10-Year Warranty
ZENITH
Residential to Medium Commercial
Content: Scotchgard 3M™ SD Nylon
Pattern Repeat : 18” W x 23 1/2” L
Carpet Width: 12'
Rating: Class 1
Commercial Wear Warranty: 10 Years
Stain Warranty: Scotchgard® 10-Year Warranty
31
GOLDEN OYSTER PLATINUM
MARINE WEDGEWOOD TAUPE CHROME
BONE OYSTER PUTTY WAVE SKY FLINT
Customer Service Hours 8:30AM - 6:00PM EST • 706.624.9385 • stantonB2B.com
COMMERCIAL
st
DECORATIVE
STANTON
