High-capacity PVC rainwater system popular for agricultural and industrial applications
XtraFlo guttering is engineered to handle large volumes of water, making it ideal for large roof areas and heavy rainfall conditions. Boasting a gutter width of 170mm and depth of 108mm and a downpipe diameter of 110mm, it provides superior water management compared to standard systems.
Manufactured from high-quality, UV-resistant PVC, XtraFlo gutters are built to withstand extreme weather conditions, including heavy rain, snow, and prolonged sun exposure, ensuring long-term durability.
Available from stock at our Hill Place Farm depot in Sussex or to order for collection from our Midlands depot.
KEY BENEFITS INCLUDE:
• Easy to install
• Will withstand average ladder weight
• Accommodates thermal expansion without leaking
• Suitable for commercial and industrial buildings
• 10-year guarantee
• National delivery
*Please visit floplast.co.uk for guarantee Terms and Conditions
visit www.southernsheeting.co.uk for our full range or call to speak to our friendly sales team
FloPlast XtraFlo Rainwater System
FloPlast XtraFlo is the ultimate PVC guttering solution for handling large volumes of rainwater, engineered specifically for demanding environments like commercial and agricultural buildings as well as residential properties. Its innovative semi-elliptical design allows for significantly higher water capacity than standard guttering systems, ensuring peak performance during heavy downpours and extreme weather conditions.
Constructed from durable, UV-resistant PVC, XtraFlo combines robust strength with low-maintenance convenience, making it the go-to choice for new builds and renovation projects. Its user-friendly clip-in system allows for quick, secure installation while ensuring optimal water flow and reducing the risk of leaks. With its ability to withstand extreme weather conditions, XtraFlo offers reliable, long-lasting performance, providing peace of mind in even the most demanding environments. Whether protecting a large industrial building or managing drainage for a sizeable roof area, FloPlast XtraFlo offers high-capacity, dependable performance to protect your property from water damage.
Technical spec
Gutter Dimensions
• Width: 170mm (external)
• Depth: 108mm (external)
• Larger profile handles more water than standard gutters (112 - 115mm wide).
• Supplied in 4m lengths, easily joined with the clip-in system for different building sizes.
Flow Capacity
• The maximum flow rate is 11 litres per second (l/s) with a 110mm round downpipe, ideal for large roofs or high rainfall.
• Drains roof areas up to 254m² at a 1:600 slope, offering higher capacity than standard systems.
Water Volume Capacity
• It carries approximately 7.5 litres per metre of gutter, ideal for large-scale roof drainage.
Downpipe Compatibility
• Compatible with 110mm downpipes, allowing faster water evacuation and reducing overflow risk.
Recommended Installation Slope/Fall
• Recommended slope: 1:600 for optimal water flow and drainage.
Material and Durability
• Made from UV-resistant PVC, it withstands sunlight, rain, snow, and frost without warping or fading.
• Temperature-resistant, ensuring reliable performance in any climate.
FloPlast XtraFlo system components
RF1GU170**-4.0 170mm 4.0m long half-round gutter
RF1SUP170** 170mm Fascia support bracket
RF1UN170** 170mm Joiner/Union bracket
RF1RO170** 170mm Running outlet to 110mm downpipe
170mm External stop end
170mm Internal stop end
170mm 90 degree gutter angle
PRODUCT DIAMETER DESCRIPTION FLOPLAST COLOUR CODE CODE * add single letter colour code (*) to complete FloPlast Product Code ** add two letter colour code to complete Product Code
Technical spec
110mm 4.0m long pipe socket
Key features
FloPlast XtraFlo Rainwater System
FloPlast XtraFlo 170mm/110mm Rainwater System Diagram
Width: 170mm (external)
Depth: 108mm (external)
Stopend - Internal
90° Angle
Stopend - External
Running Outlet
135° Offset Bend (top)
110mm Pipes - Plain Ended
135° Offset Bend (bottom)
Pipe Clip
Single Socket Pipes
DIMENSIONS
All FloPlast XtraFlo system components are covered by a manufacturer’s 10-year performance and product guarantee. This provides protection against issues such as cracking, warping, and colour fading due to weather exposure, provided the system is installed in adherence with FloPlast’s guidelines.
