Editorial Direction

Trey Bell – Editor in Chief trey@indmacdig.com

Q1 just wrapped up, and by the time you are reading this we will be well beyond the starting line for Q2.

The shininess from the new year has probably become a bit less reflective. Now is the time though to double down and refocus on leveraging your assets - in terms of people and technology and knowledge. We hope to provide you with some insight that will get you rolling again.

Our 1Q23 Quarterly issue focused on Robotics has hit the digital racks, and we are accelerating toward more Industry 4.0 insight with this edition for April.

In Business 4.0 this month we discuss our Industrial Machinery Digest Industry X Blueprinting Workshop. These Workshops enable IMD to bring to your location our perspectives on the Industry 4.0 evolution, trends in advanced manufacturing and machinery, access to our network of experts, facilitated examination of current state of operations, and next generation visioning for change in the form of a Workshop intended to yield actionable strategies for a digital operations transformation program.

Talking Shop is a bit different in format this month. We highlight a Digitalization and Modernization Workshop in Michigan conducted by Executives from Schuler Group and Schuler North America in which they take a deep dive into their Smart Press Shop. From VDP to lasers this is a working example of Industry 4.0 in action. The backplane is Schuler’s Digital Suite for what they coin Forming Technology 4.0.

In Safety and Maintenance, our guest contributor Chris Kolb is Vice-President of Sales for Aerobotix, an innovative leader in robotic solutions for the aerospace and defense industries headquartered in Huntsville, AL. Chris looks at how robots can be used for handling toxic materials such as hexavalent chromium.

We feature some of the advances being made by Siemens in our News and Industry Insight sections. These include the new Intralogistics vertical, as well as the Siemens Xcelerator platform.

Lasers are seemingly underutilized, but expanding rapidly due to their lower maintenance costs and high effectiveness in areas like cutting, marking, welding, and for instance cleaning. In our Schuler overview, lasers play a role. However, we also feature a contributed piece on how lasers can be used to clean surfaces in our Industrial Automation section this month. We take a deeper dive on laser technology - how lasers work, a timeline on discoveries and the differences between fiber lasers and CO2 lasers, and some ideas on capabilities in our article from Process called “The Laser - our Modern Lightsaber.”

Our Workforce Development section features The Smart Factory @ Wichita, in which industry leaders such as Deloitte, Amazon Web Services, Infor, SAP, Dragos, Siemens, and Wichita State University have come together to build a working factory that features operating Industry 4.0 use cases. This isn’t an idea on a wipe board, but rather a brick and mortar (well, really a metal and concrete and wind power and solar power and glass and digital and robotic and advanced net zero emissions) masterpiece. The factory provides among other things, a place for Wichita State students to experience first hand the impact of Industry 4.0 on manufacturing.

Other industry news and several product showcases that have been curated by our staff will round out this edition. Hope you made it to ProMat 2023 - ping me (trey@indmacdig.com) with your Workshop questions.

Keep building.
