News Britain is importing more power from overseas than ever before Britain is becoming increasingly reliant on power from overseas, as it saw a record day for electricity imports on August 20.

Over the last few years, the UK has seen a number of new interconnector cables either approved or come online, with the country now seeing the fruits of those new cables.

On August 20 at 12:20pm, a test on the new North Sea Link interconnector helped propel electricity imports into the UK to a brand-new high, peaking at 5,847 MW. It’s likely that we could see further peaks in the future, with the interconnector set to go live on October 1.

Government exploring ban on China’s involvement in UK nuclear power The UK Government could be about to axe China’s involvement from UK nuclear power projects, with state-owned China General Nuclear Power Group set to be kicked off the Sizewell project.

Speaking to the Financial Times, a source noted, “There isn’t a chance in hell that CGN builds Bradwell.

“Given the approach we’ve seen to Huawei, [Downing Street] aren’t going to be letting a Chinese company build a new nuclear power station.”

EDF have reportedly already been approached to see if it could find new partners to goahead with Sizewell C without any involvement from CGN, although there’s no word on whether a partner has yet been found.

There are worries within the sector that Hinkley Point C may not be viable without involvement from CGN. That’s because it utilises European Pressurised Reactor technology, which was first successfully installed at a CGN facility in Southern China.

In fact, more than 100 CGN engineers have already been involved on-site at Hinkley Point C, and removing them from the project could cause a significant brain drain that will impact the development of the new nuclear power station. Meanwhile, in Somerset, CGN is said to have 50 engineers.

6 Electrical Review | September / October 2021

Electric vehicles to increase electricity demand by 25% by 2040

Demand for electricity is set to rise a whopping 25% by 2040 as a result of the uptake in electric vehicles, according to the latest research from Cornwall Insight.

The latest figures from Cornwall Insight’s Benchmark power curve forecasts that by 2040 electric vehicles will contribute an additional 71.6TWh, this is a massive 31 times higher than the current level of demand for electricity from electrified transport and 25% of current annual demand, which stands at 299TWh (excluding losses).

According to the report, electrification of the economy (electric vehicles and heat pumps) and use of green hydrogen as an energy carrier, all increase demand from 298TWh in 2021-22 to 628.4TWh in the Central Scenario by 2040 and up to 668.2TWh in the High Scenario.

NEWS

Siemens Gamesa first to commercialise recyclable wind turbine blades

Siemens Gamesa has become the first company to debut a commercially-available wind turbine blade that can be recycled at the end of its lifecycle.

Dubbed the RecylableBlade, this is the first time that the components of a wind turbine blade could see a new lease of life after they reach their natural end atop a wind turbine. That’s because these blades are developed from a combination of materials cast together with a resin that can be easily separated from the other components.

Previously it’s been difficult to recycle wind turbine blades as there was no way to separate all these components.

The Siemens Gamesa RecylableBlade means that the materials that make up these components can be reused in new applications after separating.

Day-ahead power prices hit record high, following highs in balancing market Great Britain continues to see high day-ahead power prices, with no signs of a slowdown as prices hit a record high.

On September 14, the day-ahead auction cleared at new records across the board, with prices peaking at £1,675.30 per MWh for EPEX and £1,750 per MWh for Nordpool. That is a significant increase on the previous record price, with EPEX peaking at £1,500 per MWh on January 14, 2021, and Nordpool peaking a day earlier at £1,499.62 per MWh. Volume weighted baseload prices also set new records at £461.17 per MWh for EPEX and £379.82 per MWh for Nordpool. This follows

record pricing set just last week, where it was £281.11 per MWh for EPEX and £285.99 per MWh for Nordpool.

Phil Hewitt, Director at EnAppSys, commented, “These high prices are being set by some generators sitting out of the wholesale market to get higher prices in the balancing mechanism.”

It’s unsurprising to see some generators want to take advantage of higher prices in the balancing mechanism, which hit a record high of £4,037.80 per MWh on September 9. However, all these high prices are also having an impact on interconnector capacity prices.

UK forced to rely on coal power due to reduction in wind generation

Waste luminaires achieve 83% recyclability rating in Recolight study The National Audit Office has released a scathing review of the Green Homes Grant, noting that it was over ambitious and not executed to an acceptable standard.

The Green Homes Grant was designed to help kick start the UK’s so-called Green Revolution, with the Government offering to cover up to two-thirds of the cost of installing green home upgrades.

Unfortunately between announcement and launch, the scheme was watered down, with improvements such as energy efficient lighting upgrades removed altogether. This was the first warning sign that the scheme may not live up to its promise, but according to the National Audit Office, the scheme was unlikely to ever be a success.

Meg Hillier MP, Chair of the Committee of Public Accounts, commented, “The Green Homes Grant scheme was set up to fail, with an undeliverable timetable and overly complex design which took little account of supplier and homeowners’ needs.

“Government now expects the scheme to deliver only a small fraction of its targets for jobs supported and homes upgraded.

“Meanwhile, the Government expects to spend over £50 million administering the scheme – an astonishing cost of over £1,000 per home upgraded.

“The Government cannot hope to achieve its net zero ambitions if it doesn’t learn the lessons from this botched scheme.”

The UK has been forced to rely on coal power to keep the lights on, as there has been a reduction in electricity generated by wind farms.

National Grid ESO has confirmed that in recent weeks coal has been providing 3% of the total electricity needed.

This is largely due to unusually calm and warm weather, meaning wind turbines haven’t been turning at the normal rate we may expect at the end of August.

www.electricalreview.co.uk 7

Gossage Gossip Hot air on heat pumps

Bouncing Yeo-Yeo

All gas and gaiters

I have warned about the problem ahead if the UK Government continues to promote heat pumps as the preferred replacement for gas central heating, which is present in 86% of British homes. However, it continues to persist, despite the difference in capital cost between gas boilers and heat pumps being at least 4:1.

As part of a lengthy feature querying the need for new nuclear power stations, how magnanimous it is of The Sunday Times to quote Tim Yeo, the former Tory environment minister. He said, “We need a significant nuclear element in the energy mix if we’re going to get to net zero in the timeframe that is necessary — and that means having these new plants built.” He was cited as the current chairman of an entity called New Nuclear Watch Institute, which is funded by the nuclear industry.

Are the days numbered for electricity produced by natural gas? Judging by an inspection of the European Union’s Transparency Register, that is certainly the fear of the gas industry across Europe.

This Register provides details of the number of formal meetings between EU officials and lobbyists of all kinds each month.

Right now the official reassurance line is that all technologies reduce in price as their marketplace grows in size. Just look at offshore wind electricity. There is one big difference, however. The UK was amongst the first countries in the world to adopt offshore wind power stations. In contrast, in 2019 there were 29,000 heat pumps installed in Britain, while the worldwide market for heat pumps is almost 20 million. In other words, heat pumps are an already established technology, with an acknowledged worldwide pricing structure.

Even if the British marketplace does increase 20-fold by 2028, as is the official target, the cost of each installation will only marginally decrease. Certainly nothing likely to approach removing that 4:1 differential.

So the question is, will homeowners ever be prepared to cough up the extra cash needed to install a heat pump? Or will any Chancellor ever be prepared to bridge that funding gap?

I have a nasty feeling that the Government’s long-awaited buildings and heating policy statement, now due out in September, may dodge answering that question. Even so, it is effectively the real $64 billion question required to be addressed if we are ever to have a credible net zero strategy.

But how reliable is Tim Yeo? Back in 2015, Yeo was described by a judge when he lost a libel case as “unreliable,” “dishonest,” “untruthful,” “untrue,” and “unworthy of belief.”

He has also recently been found guilty of deliberately misusing his “fiduciary powers” as Chair of TMO Renewables, and repeatedly offering misleading evidence in court. He was accused of a “dishonest strategy for maintaining control of the board,” a strategy that included “misleading existing shareholders” into thinking the company had just received a substantial cash investment, when in reality the ‘new friendly shareholders’ he had cited had not invested a penny. Amongst the latest judge’s conclusions were that Yeo was motivated by an “improper purpose,” and that his tendency to “speechify” gave his evidence a “contrived, evasive and rather selfserving quality.”

I am sure it is a coincidence that the libel case he lost back in 2015 was against The Sunday Times.

Nowhere to dump it Five Swedish nuclear reactors may need to close between 2024 and 2028, simply because a temporary site for storing spent fuel will soon be full. And the Swedish government has yet to approve a final waste repository, The timetable is that the Forsmark 4 reactor risks closure in 2024, followed in 2025 by Forsmark 3, Ringhals 3 and 4 and finally Forsmark 1 in 2028. Ringhals is owned by a consortium comprising Vattenfall and Uniper, while Forsmark is owned by the same two companies plus Fortum and Skelleftea Kraft.

A Swedish government decision on used nuclear fuel storage must by law be made no later than September 30 this year, so as to avoid exceeding the official permit at the interim storage site at Oskarshamn. Precisely where nuclear waste is to be stored long-term remains a dilemma which effectively faces every single government that permits nuclear power. And the more such plants are built, the more the problem grows.

8 Electrical Review | September / October 2021

And it seems that the number of meetings with those from the gas industry has more than doubled over recent months.

From an average of 9.5 meetings per month back in 2018, up to an average of 19 per month over the past year. All this despite Covid restrictions. Meanwhile, the number of EU-registered lobbyists operating on behalf of the gas industry has risen to 776 between January 2020 and May 2021, from 759 in the prior period.

Why this frenzy of activity? I suspect that the reason may well be to do with the impending finalisation of the EU’s taxonomy categories.

Back in 2016, it was agreed that in response to many fears regarding false greenwashing claims, the EU would produce a detailed list regarding precisely which activities and which technologies would be deemed to be climate friendly. The definition is intended to be “doing no significant harm” to the environment.

Subsequently a group of expert advisers to the EU has concluded that gas-fired power can only be included if it meets stringent emissions rules. These are rules with which no gas plant in Europe currently complies. Whilst excluding gas from the coveted label would not prevent gas producers from raising money via debt or equity, some companies fear it would make the option of gas-fired electricity far more expensive.

Some Governments, noticeably in eastern Europe, still see gas as a necessary bridging fuel as they move from coal to renewables.

The European Commission has repeatedly delayed making a final decision, but that decision is now due this autumn. All of which is concentrating the minds of those in the natural gas industry very, very hard.

SPONSORED FEATURE

Are you using the right micro-ohmmeter?

Choosing the right micro-ohmmeter is critical for ensuring the continued safe operation of high- and medium-voltage circuit breakers, but which is the right one? Well, Megger may be able to help. ne of the most common uses for micro-ohmmeters is to check the contact resistance in high- and medium-voltage circuit breakers. Circuit breakers come under a great deal of stress, as they are required to break high-voltage circuits, often under load. The arc generated by the switching action can damage the face of the contacts, and this can lead to catastrophic failure of the breaker or other downstream substation equipment.

Circuit breakers are critical items of substation infrastructure. They are used to switch parts of the network in and out to provide isolation for purposes such as planned maintenance and, as part of the protection system, to remove the power in the event of a fault. If they fail to operate there can be serious consequences for the rest of the network.

Arcing at the contacts creates carbonised layers on the contact faces.

Over time, these layers will build up and the live contact area will be reduced or become pitted, leading to an increase in contact resistance and heating. This reduces the efficiency of the circuit breaker and can lead to failures that in an active transmission or distribution system could result in the loss of a substation.

One effective way of guarding against such problems is to regularly check circuit breaker contact resistance. However, this resistance should be very low, typically of the order of tens of micro ohms, which means that it can only be reliably measured with a very accurate micro-ohmmeter that has good resolution.

The accuracy and resolution of the micro-ohmmeter are especially important as the carbonised layers may only increase the contact resistance by a small amount, but the consequences of this small change can make a huge difference to the performance of the breaker. The excessive heat produced as a result of the increase in resistance can actually weld the contacts together and this may result in the circuit breaker not operating at all when called upon to do so.

O

Test at 10A or 100A? Contact resistance testing is clearly desirable, but the next thing to decide is the test current to use. Is 10A enough, or does it need to be more?

Let’s be honest, the simplest option is to take a battery-powered micro-ohmmeter to site. There’s no messing around with power supplies and long leads or dragging heavy generators into inaccessible substations. So for years, many engineers have been using battery-powered 10A micro-ohmmeters, such as the DLRO10, for measuring circuit breaker contact resistance because these instruments are convenient and they appear to do what’s needed. But do they really?

10 Electrical Review | September / October 2021

High-voltage circuit breakers operate at currents much higher than the 10A produced by one of these micro-ohmmeters. This means that they may not react in the same way as they would if they were tested with a current closer to their normal operating level.

For example, the carbonised layers may resist an injection of 10A but pass a higher test current, leading to differences in the readings. This might result in the circuit breaker failing the test unnecessarily. It is a definite fact that the stability and reliability of the micro-ohmmeter readings increase at higher currents as the very small voltages being measured are captured more reliably.

This issue is recognised in IEC and ANSI standards, which both recommend higher test currents for testing circuit breaker contact resistance: 100A is the minimum for ANSI/IEEE standard C37.09, while IEC62271-100 stipulates that any test current between 50A and the rated current of the circuit breaker may be used.

Inconveniently, most high-current micro-ohmmeters are 100A, 200A or even 600A mains-powered units, which need the associated power supplies or generators to power them while they are in use. It is partly this time-consuming set up that has limited the adoption of high-current circuit breaker testing.

There are, however, now two solutions to this problem. If you want the smallest possible instrument, Megger has a handheld battery-powered 200A micro-ohmmeter specifically designed for circuit breaker applications. Offering class-leading performance, it uses a supercapacitor to inject a high current for a short duration to give highly accurate readings.

On the other hand, if you are looking for more flexibility, the Megger battery-powered DLRO100 is designed to suit a wide range of applications including circuit breaker contact resistance measurement. It provides a test current of up to 100A and is capable of supplying a steady current for tests of a longer duration than those possible with the supercapacitor instrument.

Either way, there is now absolutely no excuse for measuring circuit breaker contact resistance with low test currents. Megger’s instruments offer circuit breaker testing that meets international standards, while having the convenience and portability of go-anywhere battery power.
