SJD Homes | Haven Booklet

Say

hello to home

BY

Say

hello to

Built for first home buyers and investors, Haven combines smart design, quality construction and a simplified process to create homes that are practical, stylish and ready for real life.

With thoughtfully considered floorplans, curated colour palettes and clear inclusions, Haven removes the overwhelm that often comes with building, while still delivering the quality, experience and trusted reputation SJD Homes is known for.

simple

Five steps to your new home STEP 1

Choose your floorplan Select from our collection of floorplans designed specifically with First Home Buyers and Investors in mind.

STEP 2

Choose your style Select your home’s internal & external colours from the Haven designer colour palettes, your facade, and any upgrade packs.

STEP 3

Finalise your documents Sign your Preliminary Building Agreement, pay your deposit, receive your quote, and get your working drawings!

STEP 4

Sign your contracts It’s time for contract signing! Our pre-construction team will work behind the scenes to prepare for your build.

STEP 5

Make it happen!

It’s all in the

details

Thoughtfully selected inclusions come standard in every Haven home build. Explore the stylish fittings, fixtures and finishes waiting for you.

Internal

External

•

Choice of Four Haven Designer Colour Palettes

•

Choice of Four Haven Designer Colour Palettes

•

2440mm Ceilings

•

Concrete Roof Tiles

•

Flooring Throughout

•

•

Tiled Kitchen Splashback

Aluminium double glazed awning windows including firbreglass flyscreens

•

900mm Appliances

•

•

Laminate Kitchen Benchtops

Colorbond Fascia and Gutter

•

Soft close to kitchen doors and drawers

•

Timber Infill above Garage Door

•

Flush Tiled Shower Bases

•

Colorbond Panel Lift Garage Door

•

Semi Frameless Pivot Shower Screens

•

3.5kw Solar System

•

R5.0 Insulaton Batts to Ceiling

•

Double glazed sliding doors to meals and laundry area

•

3kW Solar System and Electric Heat Pump Hot Water System

Inclusions

Inclusions

Let the journey

begin

step 1. choose your

floorplan

min. lot width

min. lot depth

Page

zest 130

8.5

21

8

noosa 160

8.5

25

9

amalfi 146

10.5

24

10

malibu 144

10.5

21

11

monaco 164

10.5

25

12

monaco 190

10.5

28

13

rio 172

12.5

21

14

cove 172

12.5

22

15

bellini 199

12.5

25

16

savanna 223

12.5

28

17

maldive 223

12.5

28

18

aruba 236

12.5

30

19

maldive 242

12.5

30

20

savanna 242

12.5

30

21

maldive 251

12.5

32

22

savanna 253

12.5

32

23

colada 186

14

21

24

capri 222

14

25

25

capri 243

14

27

26

capri 253

14

28

27

laguna 164

16

16

28

cosmo 193

16

20

29

sanctuary 248

16

28

30

santorini 251 Double Storey

12.5

22

31

PORCH GRAND TOTAL:

4.53 m² 121.12 m²

0.49 13.04

H O US E L EN G T H : 1 6 . 8 m H O US E W I D T H: 8. 5 m

zest 130 SUITS 8.5 m x 21m BLOCK

8500

BE D 3 2.8 x 3.0

ME AL S 2.5 x 3.7

F A MI L Y

K I T CH EN

2.9 x 4.2

16800

BE D 2 2.8 x 3.2

EN TR Y

GAR A GE 6.8 x 3.6 L'DRY

B AT H WI R

M ASTE R S UI T E 3.1 x 3.2

P O RCH

3

8.5m+ Frontage

ZEST 130 1 : 125

1

1

Total Size

13.04 Sq | 121.12 m2

Exterior Width

8.50m

Exterior Length

16.80m

Min Lot Size

8.5m x 21m

PORCH GRAND TOTAL:

4.49 m² 148.80 m²

either in whole or part is strictly forbidden.

0.48 16.02

H O US E L EN G T H : 1 9 m H O US E W I D T H: 8. 5 m

noosa 160 SUITS 8.5 m x 25 m BLOCK

8500

F A MI L Y

KIT

3.9 x 5.3

ME AL S L D RY

2.6 x 3.5

BA TH

B ED 3 3.0 x 3.0

19000

WC

BE D 2 3.1 x 3.1

EN TR Y

G AR A G E 6.8 x 3.6

W I R EN S

M ASTE R S UI T E 3.5 x 3.1

P O RCH

3

NOOSA 160 8.5m+ Frontage 1 : 125

2

1

Total Size

16.02 Sq | 148.80 m2

Exterior Width

8.50m

Exterior Length

19.00m

Min Lot Size

8.5m x 25m

HOUS E LENGTH: 16 .1 0m HOUS E W IDTH: 9 .1 1m SUITS 10.5m x 24 m BLOCK

amalfi 146 9110

3.0 x 3.0

3.0 x 4.3

ME A L S

L D RY

3.0 x 3.7

KI T CH EN

16100

B ED 2 3.0 x 3.0

B ATH

G ARAG E

WI R

6.0 x 3.5

ENT RY

MAS T E R S UITE 3.7 x 3.6

PO RCH

3

1

10.5m+ Frontage

AMALFI 146 - LH

: 125

BE D 3

F A MI L Y

1

Total Size

14.62 Sq | 135.84 m2

Exterior Width

9.11m

Exterior Length

16.10m

Min Lot Size

10.5m x 24m

OUS E LENGTH: 15.00m O U S E W ID T H : 9 . 3 0 m

U I T S 1 0 . 5 m x 2 1 m B L O CK

malibu 144

ME A L S

F A MI L Y

4.4 x 2.5

3.4 x 3.8

KIT CH EN BE D 3 1525 BATH

2.8 x 3.4

BAT H 15000

L 'D R Y

LIBU 144 - LH

9300

BE D 2 2.8 x 3.2

G ARA G E 6.0 x 3.5

WI R

ENS

ENT RY

MA S T E R SU I TE 3.2 x 3.7

P O RCH

3

2

10.5m+ Frontage

1

Total Size

14.40 Sq | 133.80 m2

Exterior Width

9.30m

Exterior Length

15.00m

Min Lot Size

10.5m x 21m

GROUND FLOOR GARAGE PORCH OUTDOOR LIVING GRAND TOTAL:

112.91 m² 36.22 m² 3.18 m² 0.00 m² 152.31 m²

12.15 3.90 0.34 0.00 16.39

C opy ri gh t: T h is w or k is ow n e d by SJ D Home s.

C opie s , u pl oadi n g t o th e i n t e r ne t, or re pr oduction in a n y f o r m e i t h e r in w h ol e o r p a r t i s s t r ic t ly f o r b i d d e n .

monaco 164 HO U S E L EN G T H: 1 9 .0 0 m H O U S E W ID T H : 9 . 3 0 m

SUITS 10.5m x 25m BLOCK

9300

ME A L S 2.6 x 3.5

F A MI L Y 3.2 x 4.1

KI T CH EN BE D 3 2.9 x 2.8

WI R ENS

BE D 2 2.9 x 2.8 3.1 x 3.0

WC

19000

MA S T E R S U I T E

BAT H

G ARA G E 6.0 x 5.5

L 'D R Y ENT RY

S TU D Y P O RCH

3

2

10.5m+ Frontage

MONACO 164 1 : 125

2

3.1 x 1.9

Total Size

16.39 Sq | 152.31 m2

Exterior Width

9.30m

Exterior Length

19.00 m

Min Lot Size

10.5m x 25m

AREA GROUND FLOOR GARAGE PORCH GRAND TOTAL:

m2 137.21 m² 36.22 m² 3.18 m² 176.61 m²

SQ 14.77 3.90 0.34 19.01

C opy ri gh t: T h is w or k is ow n e d by SJ D Home s.

C opie s , u pl oadi n g t o th e i n t e r ne t, or re pr oduction in a n y f o r m e i t h e r in w h ol e o r p a r t i s s t r ic t ly f o r b i d d e n .

monaco 190 HOUS E LENGTH: 21 .50m H O U S E W ID T H : 9 . 3 0 m

S U I T S 1 0 .5 m x 2 8 m BL O C K

9300

ME A L S 2.8 x 4.5

K IT C H EN

WI P

F A MI L Y 3.2 x 4.5

BE D 4 2.8 x 3.0

BE D 3 3.0 x 2.8

ENS

WI R 21500

BE D 2 3.0 x 2.8

MA S T E R S U I T E 3.3 x 3.0

WC

BAT H

G ARA G E 6.0 x 5.5

L 'D R Y ENT RY

S TU D Y P O RCH

4

2

2

2.6 x 1.9

Total Size

19.01 Sq | 176.61 m2

Exterior Width

9.30m

MONACO 190

Exterior Length

21.50m

1 : 125

Min Lot Size

10.5m x 28m

10.5m+ Frontage

HOUS E LENGTH: 15.0 0m H O U S E W ID T H : 1 1 . 3 0 m

rio 172

S U I T S 1 2 . 5 m x 2 1 m B L O CK

11300

F A MI L Y

L 'D R Y

BAT H

3.8 x 4.9

WC

BE D 3

ME A L S W IP

KIT CH EN

3.0 x 3.0

3.4 x 4.0

2.9 x 3.2

G ARA G E 6.0 x 5.5

ENS WI R ENT RY

MA S T E R SU I TE 3.1 x 3.8

P O RCH

3

2

12.5m+ Frontage

RIO 172 - LH 1 : 125

2

Total Size

17.24 Sq | 160.20 m2

Exterior Width

11.30m

Exterior Length

15.00m

Min Lot Size

12.5m x 21m

15000

BE D 2

HOUS E LENGTH: 15.50m H O U S E W ID T H : 1 1 . 3 0 m SUITS 12 .5m x 22 m BLOCK

cove 172

11300

F A MI L Y

BAT H

BE D 3

3.0 x 4.2

3.1 x 3.2

WC ME A L S 2.5 x 5.2

BE D 2

WI P

3.0 x 3.2

K IT C H EN 15500

L 'D R Y

G ARA G E

W IR

6.0 x 5.5

E NS

E NT R Y

MAS T ER S U ITE 3.3 x 3.8

P O RCH

3

2

12.5m+ Frontage

COVE 172 - RH 1 : 125

2

Total Size

17.17 Sq | 159.49 m2

Exterior Width

11.30m

Exterior Length

15.50m

Min Lot Size

12.5m x 22m

PORCH GRAND TOTAL:

4.01 m² 184.74 m²

0.43 19.89

HOUS E LENGTH: 18.00m H O U S E W ID T H : 1 1 . 3 0 m

bellini 199

SUITS 12 .5m x 25m BLOCK

11300

O U TD O O R L I VI N G

BAT H

2.4 x 3.4

W IR

BE D 4 3.0 x 3.2

F A MI L Y 3.0 x 4.2

WC

BE D 3 3.0 x 3.2

ME A L S 2.6 x 5.2

18000

WI P

BE D 2 3.1 x 3.2

K IT C H EN

L 'D R Y

G ARA G E

W IR

6.0 x 5.5

E NS E NT R Y

MAS TE R S U ITE 3.3 x 3.8

P O RCH

4

2

12.5m+ Frontage

BELLINI 199 - RH 1 : 125

2

Total Size

19.89 Sq | 184.74 m2

Exterior Width

11.30m

Exterior Length

18.00m

Min Lot Size

12.5m x 25m

AREA GROUND FLOOR GARAGE OUTDOOR LIVING PORCH GRAND TOTAL:

m2 158.98 m² 36.22 m² 8.30 m² 4.01 m² 207.51 m²

SQ 17.11 3.90 0.89 0.43 22.34

C o p y r ig h t : T h i s w o r k is o w n e d b y S J D H o m e s .

C o p i e s , u p l o a d i n g t o t h e i n t e r n e t , o r r e p r o d u c t io n i n a n y f o r m e i t h e r i n w h o l e o r p a r t i s s t r ic t ly f o r b id d e n .

savanna 223 H O U S E L E N G T H : 2 0 .6 5 m H O U S E W I D T H : 1 1 . 00 m

S U I T S 1 2. 5 m x 2 8 m B LO C K

On display at Meridian Estate, Clyde North and Lillifield Estate, Warragul 11100

BE D 3

BE D 4

2.9 x 3.0

2.9 x 3.0

O U T D O OR L I VI N G 3.0 x 2.7

L'D RY WC

BAT H

F A MI L Y 4.1 x 4.3

BE D 2

ME A L S

2.9 x 3.2

2.8 x 4.3

20650

WIP K IT CH E N

T H E A TR E 3.7 x 3.6

WI L E NS

WIR

ENT RY

G ARA G E 6.0 x 5.5

MAS T ER S U I T E 3.7 x 3.6

P O RCH

4

2

12.5m+ Frontage

SAVANNA 223 - RH 1 : 125

2

Total Size

22.34Sq | 207.51 m2

Exterior Width

11.00m

Exterior Length

20.65m

Min Lot Size

12.5m x 28m

maldive 223 AREA TABLE

AREA GROUND FLOOR GARAGE OUTDOOR LIVING PORCH GRAND TOTAL:

m2 158.56 m² 36.22 m² 8.44 m² 4.07 m² 207.29 m²

SQ 17.07 3.90 0.91 0.44 22.31

Copyright: This work is owned by SJD Homes. Copies, uploading to the internet, or reproduction in any form either in whole or part is strictly forbidden.

On display at Wonthaggi Display Home Super Centre H O U S E L E N G T H : 2 0 .6 5 m H O U S E W I D T H : 1 1 . 00 m S U I T S 1 2. 5 m x 2 8 m B LO C K

11100

O U T D O OR L I VI N G 3.0 x 2.7

BE D 4

BE D 3

3.0 x 3.0

3.0 x3.0

WC BAT H F A MI L Y 3.0 x 4.6

ME A L S

BE D 2

2.7 x 4.6

3.0 x 3.0

20650

WIP K IT CH E N T H E A TR E 3.4 x 3.6

L'D RY WI L

ENS

WIR

ENT RY

G ARA G E 6.0 x 5.5

MAS T ER S U I T E 3.7 x 3.4

PORCH

MALDIVE 223 - RH 1 : 125

4

2

12.5m+ Frontage

2

Total Size

22.31 Sq | 207.29 m2

Exterior Width

11.10m

Exterior Length

20.65m

Min Lot Size

12.5m x 28m

aruba 236 AREA TABLE AREA GROUND FLOOR GARAGE OUTDOOR LIVING PORCH GRAND TOTAL:

m2 166.68 m² 36.25 m² 11.56 m² 4.57 m² 219.06 m²

SQ 17.94 3.90 1.24 0.49 23.58

C opy ri gh t: T h is w or k is ow n e d by SJ D Home s.

C opie s , u pl oadi n g t o th e i n t e r ne t, or re pr oduction in a n y f o r m e i t h e r in w h ol e o r p a r t i s s t r ic t ly f o r b i d d e n .

HOUSE LEN GTH: 2 2.76 m H O U S E W ID T H : 1 1 . 0 0 m S U I T S 1 2 . 5 m x 3 0 m B L O CK 11000

O U T D O O R L I V ING 3.0 x 3.8

ME A L S 3.2 x 3.1

L 'D R Y

WI P F A MI L Y 5.0 x 4.0

KIT CH EN

BE D 4 3.0 x 3.0

BE D 3 3.0 x 3.3

22760

WC

BAT H

BE D 2 3.0 x 3.3

WI R E NS

MAS T ER S U I T E

G ARA G E

3.6 x 3.6

6.0 x 5.5

ENT RY L O U NG E 3.5 x 3.4

P OR CH

ARUBA 236 - LH 1 : 125

4

2

12.5m+ Frontage

2

Total Size

23.58 Sq | 219.06 m2

Exterior Width

11m

Exterior Length

22.76m

Min Lot Size

12.5m x 30m

AREA TABLE AREA GROUND FLOOR GARAGE OUTDOOR LIVING PORCH GRAND TOTAL:

m2 174.52 m² 36.22 m² 9.80 m² 4.07 m² 224.62 m²

SQ 18.79 3.90 1.06 0.44 24.18

Copyright: This work is owned by SJD Homes. Copies, uploading to the internet, or reproduction in any form either in whole or part is strictly forbidden.

maldive 242 H O U S E L E N G T H : 2 2 .4 0m H O U S E W I D T H : 1 1 . 10 m S U I T S 1 2. 5 m x 3 0 m B LO C K

11100

BE D 3

BE D 4

3.5 x 3.0

3.5 x 3.0

O U TD O O R L I VI N G 3.6 x 2.7

WC BAT H F A MI L Y 3.7 x 4.6

BE D 2

ME A L S

3.5 x 3.0

3.2 x 4.6

22400

WIP

KI T CH E N

T H E A TR E 4.1 x 3.6

L'D RY WI L

G ARA G E

ENT RY

WIR

EN S

6.0 x 5.5

MAS T ER S U I T E 4.0 x 3.4

P O RCH

4

2

12.5m+ Frontage

MALDIVE 242 - RH 1 : 125

2

Total Size

24.18 Sq | 224.62 m2

Exterior Width

11.10m

Exterior Length

22.76m

Min Lot Size

12.5m x 30m

AREA GROUND FLOOR GARAGE OUTDOOR LIVING PORCH GRAND TOTAL:

m2 175.49 m² 36.22 m² 9.12 m² 4.01 m² 224.84 m²

SQ 18.89 3.90 0.98 0.43 24.20

C o p y r ig h t : T h i s w o r k is o w n e d b y S J D H o m e s .

C o p i e s , u p l o a d i n g t o t h e i n t e r n e t , o r r e p r o d u c t io n i n a n y f o r m e i t h e r i n w h o l e o r p a r t i s s t r ic t ly f o r b id d e n .

savanna 242 H O U S E L E N G T H : 2 2 .4 0m H O U S E W I D T H : 1 1 . 10 m S U I T S 1 2. 5 m x 3 0 m B LO C K 11100

BE D 3

BE D 4

3.5 x 3.0

3.5 x 3.0

O U TD O O R L I VI N G 3.6 x 2.7

L'D RY

WC BAT H F A MI L Y 4.6 x 4.3

BE D 2

ME A L S

3.5 x 3.3

3.5 x 4.3

22400

WIP KI T CH E N

T H E A TR E 4.0 x 3.3

WI L ENS

WIR

ENT RY

G ARA G E 6.0 x 5.5

MAS T ER S U I T E 4.0 x 3.6

P O RC H

4

2

SAVANNA 12.5m+ 242 - RH Frontage 1 : 125

2

Total Size

23.58 Sq | 219.06 m2

Exterior Width

11m

Exterior Length

22.76m

Min Lot Size

12.5m x 30m

AREA TABLE AREA GROUND FLOOR GARAGE OUTDOOR LIVING PORCH GRAND TOTAL:

m2 182.14 m² 36.22 m² 10.07 m² 4.92 m² 233.36 m²

SQ 19.61 3.90 1.08 0.53 25.12

Copyright: This work is owned by SJD Homes. Copies, uploading to the internet, or reproduction in any form either in whole or part is strictly forbidden.

maldive 251 HO U S E L EN G TH : 2 3 . 5 0 m H O U S E W I D T H : 1 1 . 10 m 11100

S U I T S 1 2. 5 m x 3 2 m B LO C K

BE D 3

O U TD O O R L I VI N G

BE D 4

3.6 x 3.0

3.6 x 3.0

3.7 x 2.7

WC BAT H F A MI L Y 3.8 x 4.6

BE D 2

ME A L S

3.6 x 3.0

3.0 x 4.6

23500

WIP

KI T CH E N

T H E A TR E 4.5 x 3.6

L'D RY WI L

G ARA G E

ENT RY

WIR

EN S

6.0 x 5.5

MAS T ER S U I T E 4.5 x 3.4

P O RCH

4

2

2

Total Size

25.12 Sq | 233.36 m2

Exterior Width

11.10m

MALDIVE 242 - RH

Exterior Length

23.50m

1 : 125

Min Lot Size

12.5m x 32m

12.5m+ Frontage

AREA TABLE AREA GROUND FLOOR GARAGE OUTDOOR LIVING PORCH GRAND TOTAL:

m2 182.66 m² 36.22 m² 11.85 m² 4.01 m² 234.74 m²

SQ 19.66 3.90 1.28 0.43 25.27

C o p y r ig h t : T h i s w o r k is o w n e d b y S J D H o m e s .

C o p i e s , u p l o a d i n g t o t h e i n t e r n e t , o r r e p r o d u c t io n i n a n y f o r m e i t h e r i n w h o l e o r p a r t i s s t r ic t ly f o r b id d e n .

savanna 253 HO U S E L EN G T H : 2 3 . 40 m H O U S E W I D T H : 1 1 . 10 m S U I T S 1 2. 5 m x 3 2 m B LO C K

11100

BE D 3

BE D 4

3.6 x 3.0

3.6 x 3.0

O U TD O O R L I VI N G 3.7 x 2.7

L'D RY F A MI L Y

WC

5.0 x 4.3

BAT H

WI L

BE D 2 3.0 x 3.8

ME A L S 4.0 x 4.3

23400

WIP

T H E A TR E

KI T CH E N

4.2 x 3.3

ENS

WIR ENT RY

G ARA G E 6.0 x 5.5

MAS T ER S U I T E 4.5 x 3.6

P O RC H

4

2

12.5m+ Frontage

SAVANNA 253 - RH 1 : 125

2

Total Size

25.27 Sq | 234.74 m2

Exterior Width

11.10m

Exterior Length

23.40m

Min Lot Size

12.5m x 32m

ND TOTAL:

172.68 m²

18.59

HOUS E LENGTH: 15.00m H O U S E W ID T H : 1 2 . 8 0 m

colada 186

S U I T S 1 4 m x 2 1 m BL O C K

12800

BE D 3

3.0 x 4.8

3.1 x 3.0

KI T CH EN L 'D R Y WI P F A MI L Y 3.4 x 5.5

WC

BE D 2 3.1 x 3.0

G ARA G E 6.0 x 5.5

WI L WI R ENT RY MA S T E R SU IT E

ENS

3.8 x 3.2

P O RCH

3

14m+ Frontage

2

2

Total Size

18.59 Sq | 172.68 m2

Exterior Width

12.80m

Exterior Length

15.00m

Min Lot Size

14m x 21m

15000

BAT H

COLADA 186 - LH

: 125

ME A L S

PORCH GRAND TOTAL:

4.00 m² 206.06 m²

0.43 22.18

H O U S E L EN G T H : 1 8. 0 0 m H O U S E W I D T H : 1 2 .6 0 m

capri 222

S U I T S 14 m x 2 5m BL O C K

On display at Averley, Nar Nar Goon North 12600

BED 3

OUTDOO R L I VIN G

BED 4 3.0 x 3.0

3.0 x 3.0

3.0 x 3.6

BATH W IR

ME A L S

F AMIL Y

WC

4.2 x 2.8

4.2 x 3.9

BED 2

RA

3.0 x 3.0

18000

K IT CH EN L 'D R Y WI P RU MP U S STUDY NOOK

3.1 x 4.1

G ARA G E

W IR

6.0 x 5.5

ENTRY

ENS

MA S T E R SU IT E 3.8 x 3.2

PO RCH

4

14m+ Frontage

CAPRI 222 - RH 1 : 125

2

2

Total Size

22.18 Sq | 206.06 m2

Exterior Width

12.60m

Exterior Length

18.0m

Min Lot Size

14m x 25m

AREA GROUND FLOOR GARAGE OUTDOOR LIVING PORCH GRAND TOTAL:

m2 172.93 m² 36.22 m² 13.03 m² 3.70 m² 225.88 m²

SQ 18.61 3.90 1.40 0.40 24.31

C o p y r ig h t : T h i s w o r k is o w n e d b y S J D H o m e s .

C o p i e s , u p l o a d i n g t o t h e i n t e r n e t , o r r e p r o d u c t io n i n a n y f o r m e i t h e r i n w h o l e o r p a r t i s s t r ic t ly f o r b id d e n .

capri 243 HO U S E L EN G T H: 1 9. 80 m HO U S E W ID T H: 1 2 . 6 0 m

S U I T S 1 4 m x 2 7 m B L O CK

12600

BE D 3

BE D 4

OUTDOO R L I VI N G

3.5 x 3.0

3.5 x 3.0

3.6 x 3.6

F A MI L Y

ME A L S

5.3 x 3.6

5.3 x 3.0

BAT H WIR

WC

BE D 2 3.5 x 3.0

19800

RA

KI T CH E N

WIP

L'D RY

T H E A TR E 3.6 x 4.2

WIR

ENT RY

G ARA G E 6.0 x 5.5

EN S MA S T E R S UITE 4.1 x 3.1

P O RCH

4

14m+ Frontage

CAPRI 243 - RH 1 : 125

2

2

Total Size

24.31 Sq | 225.88 m2

Exterior Width

12.60m

Exterior Length

19.80m

Min Lot Size

14m x 27m

AREA GROUND FLOOR GARAGE OUTDOOR LIVING PORCH GRAND TOTAL:

m2 181.66 m² 36.22 m² 13.03 m² 3.70 m² 234.61 m²

SQ 19.55 3.90 1.40 0.40 25.25

C o p y r ig h t : T h i s w o r k is o w n e d b y S J D H o m e s .

C o p i e s , u p l o a d i n g t o t h e i n t e r n e t , o r r e p r o d u c t io n i n a n y f o r m e i t h e r i n w h o l e o r p a r t i s s t r ic t ly f o r b id d e n .

capri 253 H O U S E L E N G T H : 2 0 . 6 0m HO U S E W ID T H: 1 2 . 6 0 m

SUITS 14m x 28m BLOCK

12600

BE D 3

BE D 4

3.5 x 3.0

3.5 x 3.0

OUTDOO R L I VI N G 3.6 x 3.6

BAT H WIR

WC

ME A L S 5.3 x 3.0

F A MI L Y 6.1 x 3.6

BE D 2 3.5 x 3.0 RA

20600

KI T CH E N

WIP

L'D RY

T H E A TR E 4.2 x 4.2

WIR

ENT RY

G ARA G E 6.0 x 5.5

EN S MA S T E R S UITE 4.3 x 3.1

P O RCH

4

14m+ Frontage

CAPRI 253 - RH 1 : 125

2

2

Total Size

25.25 Sq | 234.61 m2

Exterior Width

12.60m

Exterior Length

20.60m

Min Lot Size

14m x 28m

OUS E LENGTH: 11.8m OUS E W IDTH:14 .8m

U I TS 1 6 m x 1 6 m B LO C K

laguna 164

14800

L 'D R Y

3.2 x 3.0

ME A L S

F A MI L Y

2.7 x 4.6

11800

3.4 x 4.0

G ARA G E 6.0 x 5.5

WI R BAT H

EN S ENT RY

MA S T E R S UITE

WC BE D 2 3.0 x 3.1

3.5 x 3.2

WI R

P O RCH

3

16m+ Frontage

GUNA 164 - LH

5

KIT CH EN

BE D 3

2

2

Total Size

16.38 Sq | 152.17 m2

Exterior Width

14.80m

Exterior Length

11.80m

Min Lot Size

16m x 16m

HOUS E LENGTH: 13.0m HOUS E W IDTH:14 .8m SUITS 16 m x 20m BLOCK

cosmo 193

14800

K IT C H EN L' D RY

BE D 4

F A MI L Y

3.0 x 3.4

3.5 x 4.3

WI P BE D 3

ME A L S

13000

3.1 x 3.0

2.8 x 4.5

WC

WI R

WI R

G ARA G E 6.0 x 5.5

BAT H

EN S

ENT RY

MA S T E R S UITE

BE D 2

3.8 x 3.2

3.0 x 3.4

P O RCH

3

16m+ Frontage

COSMO 193 - LH 1 : 125

2

2

Total Size

19.33 Sq | 179.62 m2

Exterior Width

14.8m

Exterior Length

13.0m

Min Lot Size

16m x 20m

GROUND FLOOR GARAGE OUTDOOR LIVING PORCH GRAND TOTAL:

180.89 m² 37.06 m² 8.30 m² 4.01 m² 230.26 m²

19.47 3.99 0.89 0.43 24.79

C opy ri gh t: T h is w or k is ow n e d by SJ D Home s.

C opie s , u pl oadi n g t o th e i n t e r ne t, or re pr oduction in a n y f o r m e i t h e r in w h ol e o r p a r t i s s t r ic t ly f o r b i d d e n .

sanctuary 248

HO U S E L EN G TH : 2 0 .6 5 m HOUS E W IDTH: 14 .60m SUITS 16m x 28m BLOCK

14600

OUTDO OR L IV I NG 3.0 x 2.7

BE D 4

BE D 3

2.9 x 3.0

2.9 x 3.0

L 'D R Y WC

BAT H

F A MI L Y 4.1 x 4.3

BE D 2

ME A L S

2.9 x 3.2

2.8 x 4.3

20650

WI P K IT C H EN

T H E A TR E 3.9 x 3.6

MU D WI L E NS G ARA G E

ENT RY

6.0 x 5.5

W IR

LO U NGE 4.3 x 3.4

MAS T ER S U IT E 3.7 x 3.6

P O RC H

4

16m+ Frontage

SAVANNA 248 1 : 125

2

2

Total Size

24.79Sq | 230.26m2

Exterior Width

14.60m

Exterior Length

20.65m

Min Lot Size

16m x 28m

GROUND FLOOR FIRST FLOOR GARAGE PORCH GRAND TOTAL:

99.22 m² 97.26 m² 36.49 m² 3.50 m² 236.47 m²

10.68 10.47 3.93 0.38 25.45

Copyright: This work is owned by SJD Homes. Copies, uploading to the internet, or reproduction in any form either in whole or part is strictly forbidden.

santorini 255 H O US E L EN G T H : 1 4. 3 7 m H O US E W I D TH: 1 0 . 7 0 m

S U I T S 1 2 . 5 m x 2 2 m B L O CK

10700

8750

WIR 2

BE D 2

WC BE D 3

3.0 x 3.1

3.0 x 3.1

ME A L S 4.9 x 2.6

F A MI L Y 4.5 x 3.0

K IT CH EN

BA TH

R U MP U S 3.0 x 4.8

WIP WI L 14220

14370

L ' D RY E NS

WIL

PDR

WIR 1

G AR A GE 6.0 x 5.5

E NTR Y M A S TE R S U IT E

B ED 4 3.1 x 3.1

3.7 x 4.6

P O RCH

4

3

12.5m+ Frontage

SANTORINI 255 1 : 125

2

Total Size

25.45 Sq | 236.47 m2

Exterior Width

10.70m

Exterior Length

14.37m

Min Lot Size

12.5m x 22m

step 2. choose your colour

style

Haven by SJD Homes’ four colour palettes and facade options have been designed to embrace your personal style to truly make your home your own.

Choose from five facade options and our Oasis, Urban, Hampton, and Adriatic colour palettes for your external and internal colour style.

Life

Say

hello

to the standard

Villa facade

3.5kw Solar System

Your facade is the face of your home and can create a beautiful street presence for your new Haven.

The Villa facade is your standard facade and is right on balance between style and impact.

Painted front door Flatline Profile Colorbond panel lift garage door

Infill over garage Optional upgrade to brickwork over garage

Roof tiles Optional upgrade to Colorbond Roof

450mm eaves to porch Colorbond fascia and gutter

Aluminium full sash Armadale Awning windows

Two brick piers Optional upgrade to render

Brickwork with natural mortar Optional upgrade to render

More than just a

prettyfacade

Personalise your Villa facade to suit your style, as easy as choosing from Alto, Soho, Port, or Bliss!

Alto Render to facade piers

Port Render to facade piers, James Hardie Axon Cladding to front projection and brickwork under windows.

Soho Render to facade piers and front projection

Bliss Render to facade piers, Weatherboard Cladding to front projection and rendered brickwork under windows.

oasis external palette Light, fresh and energising. Oasis creates a stunning seaside abode.

Images are for illustration purposes only and may show items not included as standard. While we strive to provide accurate representations, there may be slight variations in colour and texture that occur in real life. We recommend that you view Haven sample boards in person to ensure you are satisfied before choosing your colour scheme.

urban external palette Urban brings a chic, bold, and industrial style to your home.

Images are for illustration purposes only and may show items not included as standard. While we strive to provide accurate representations, there may be slight variations in colour and texture that occur in real life. We recommend that you view Haven sample boards in person to ensure you are satisfied before choosing your colour scheme.

hampton external palette Cool, classic and sophisticated, the Hampton palette is laid back luxury at it’s finest.

Images are for illustration purposes only and may show items not included as standard. While we strive to provide accurate representations, there may be slight variations in colour and texture that occur in real life. We recommend that you view Haven sample boards in person to ensure you are satisfied before choosing your colour scheme.

adriatic external palette Take a trip to the Mediterranean with cool, organic, and earthy tones

Images are for illustration purposes only and may show items not included as standard. While we strive to provide accurate representations, there may be slight variations in colour and texture that occur in real life. We recommend that you view Haven sample boards in person to ensure you are satisfied before choosing your colour scheme.

Say

hello

to your

Kitchen

900mm canopy rangehood

Life happens in the kitchen! So it’s only fitting that we’ve packed it full with inclusions that make living a breeze.

Tiled splashback

Chrome tapware

67mm half splayed skirting boards and architraves

75mm Cove Cornice Optional upgrade to overhead cabinetry with finger grips

900mm upright oven & cooktop

Chrome cabinetry handles

Soft close to doors and drawers

Laminate benchtop with tight form edge Optional upgrade to 20mm stone 1 3/4 chrome double bowl with drainboard

Say

hello

to your

Bathroom

Large mirrors over vanity with polished edge

Relax and unwind in a space you love. Create a functional yet luxurious workspace with Haven’s bathroom inclusions.

Chrome cabinetry handles

Ceramic bath

75mm Cove Cornice

Semi frameless pivot shower screens Optional upgrade to Shower Niche

Optional upgrade to Shower Rail

Stainless steel flickmixer taps

450mm x 450mm tiles

Ceramic basin

Laminate benchtop Optional upgrade to 20mm stone Flush tiled shower bases

oasis internal palette Light, fresh and energising. Oasis creates a stunning seaside abode.

Images are for illustration purposes only and may show items not included as standard. While we strive to provide accurate representations, there may be slight variations in colour and texture that occur in real life. We recommend that you view Haven sample boards in person to ensure you are satisfied before choosing your colour scheme.

urban internal palette Urban brings a chic, bold, and industrial style to your home.

Images are for illustration purposes only and may show items not included as standard. While we strive to provide accurate representations, there may be slight variations in colour and texture that occur in real life. We recommend that you view Haven sample boards in person to ensure you are satisfied before choosing your colour scheme.

hampton internal palette Cool, classic and sophisticated, the Hampton palette is laid back luxury at it’s finest.

Images are for illustration purposes only and may show items not included as standard. While we strive to provide accurate representations, there may be slight variations in colour and texture that occur in real life. We recommend that you view Haven sample boards in person to ensure you are satisfied before choosing your colour scheme.

adriatic internal palette Take a trip to the Mediterranean with cool, organic, and earthy tones

Images are for illustration purposes only and may show items not included as standard. While we strive to provide accurate representations, there may be slight variations in colour and texture that occur in real life. We recommend that you view Haven sample boards in person to ensure you are satisfied before choosing your colour scheme.

step 3 & 4. finalise your documents and sign your contracts!

Congratulations, we’re almost there! It’s time to finalise your floorplan, facade, and style and pay your deposit.

We’ll get busy preparing your contracts and working drawings!

Once your contract is signed, we are ready for your finance approval and building permit.

Key

Pre-Build Stages

Prelimary Building Agreement Sign your PBA and pay your inital deposit to lock in your Haven home.

Working Drawings Our drafting team will draw up your new home plans, including your detailed floorplan, elevations, electrical and flooring plans.

Final Documentation Your Building Consultant will work behind the scenes to prepare all documentation, final plans, developer approval, and your final contact

Contract We’re almost there! Once we have received your finance approval and your land has settled, it’s time to sign your contract.

Pre-Construction Your Building Consultant will obtain your building permit. Your home file will then be submitted to our Pre-Construction team where material orders will be placed with suppliers and your Site Supervisor will be allocated.

Step by

step

step 5. make it happen!

It’s go time! Your home is now ready to commence construction. Once your building permit has been issued, construction will begin and your home will progress through the following stages:

commence!

Let the build

Key

Build Stages

Base Site works commence and the slab is poured

Frame Framing is completed and roof trusses are erected

Lock Up Brickwork is completed, roof tiles are laid, and external doors, and windows are installed

Fixing Plaster is installed to the internal walls and celings, and cabinetry, internal doors, skirting boards and architraves are installed.

Completion All works are completed and your new home is ready for handover!

Maintenance Your build includes a 3-month maintenace period after which SJD Homes will conduct a maintenance inspection to attend to all maintenance items and to ensure your home is completed to the highest standard.

Welcome Home

03 9095 8000 www.sjdhomes.com.au

BY
