Manufactory Wholesale SR1002 CATV Optical Node with Wide Range Receiving Power
and
High Output Level for NGB Networks
Struggling with inconsistent signal quality and high power consumption in your CATV network? The SR1002 CATV Optical Node is a high-performance solution designed for NGB networks, featuring a wide receiving optical power range (-9 to +2dBm), high output level (up to 106 dBμV), and low power consumption. Built with GaAs MMIC amplification and optimized circuit design, it ensures stable performance with adjustable AGC control and 1 GHz downlink frequency. Ideal for FTTB CATV networks, it supports remote management and offers compact, easy installation.
• Wide optical power range (-9 to +2dBm) | • High output level (up to 106 dBμV) | • GaAs MMIC amplification | • 1 GHz downlink frequency | • Compact design for FTTB networks
CATV Optical Node
SR1002 is our latest high-class CATV network optical receiver, with wide range receiving optical power, high output level and low power consumption. It is an ideal equipment to build the high performance NGB network.
This catv optical node adopts GaAs MMIC amplify module. Optimization circuit design, coupled with the company 10 years professional design experience, makes the equipment achieve high performance index. The parameters will be displayed by single-chip to make engineering debug be more convenient. It is the best choice for CATV network
Features of Catv Optical Node
1.When the input optical power range is -9~+ 2dBm, the output lever, CTB and CSO is basically unchanged. The AGC control range is adjustable.
2. The downlink working frequency is extended to 1 GHz. RF amplifier part adopts the high performance and low power consumption GaAs chip. The highest output level is up to 106 dBuv.
3. EQ and ATT both use the professional electric control circuit, which makes the control more accurate and the operation more convenient.
4. It is built in national standard class II network management transponder. And it supports remote network management (optional).
5. With compact structure and convenient installation, it is the first choice of FTTB CATV network equipment.
Parameters
Link performance
RF Parameters Frequency
Output Level
