Manufactory Wholesale Optical Fiber Fast Connector for FTTH
Projects with High Tensile Strength and Low Insertion Loss
Looking for a reliable and efficient solution for fiber optic connections? The Optical Fiber Fast Connector eliminates the need for fusion splicing machines, offering quick assembly with standard tools like cable strippers and fiber cleavers. Designed for drop cables and indoor cables, it features a fasten strength of over 5 kg and is widely used in FTTH projects. With an insertion loss of ≤0.2dB, return loss of ≤-50dB, and a success rate of >98%, this connector ensures robust performance in FTTx and data room transformations.
• No fusion splicing required | • Fast assembly with standard tools | • Insertion loss ≤ 0.2dB | • Tensile strength >40N | • Ideal for FTTH and data room projects
* Optical Fiber Fast Connector is designed to simplify the connection without fusion splicing machine. It is quick assembly which requires only normal fiber preparation tools such as cable stripping tool and fiber cleaver.
*Optical Fiber Fast Connector could be applied to drop cable and indoor cable. The connector can be directly used in ONU, also with fasten strength more than 5 kg, it is widely used in FTTH project of network revolution.
Application
FTTx, Data Room Transformation
Specifications
fiber Scope 0.9mm tight buffer
Size: 43.5 mm
Fiber Diameter 125μm ( 652 & 657 )
Coating Diameter 250μm
Mode SM
Operation Time about 60s(exclude fiber presetting)
Insertion Loss ≤ 0.2dB(1310nm & 1550nm)
Return Loss ≤ -50dB
Success Rate >98%
Reusable Times unlimited
Tighten Strength of Naked Fiber >5 N
Tensile Strength >40 N
Temperature -40 ~ +85 C
On-line Tensile Strength Test (20 N) IL ≤ 0.3dB
Mechanical Durability(500 times) IL ≤ 0.3dB
Drop Test(4m concrete floor, once each direction, three times total) IL ≤ 0.3dB
