Manufactory Wholesale IP to 32/48/64CHs Analog Agile Modulator for DVB-T ISDB-T Systems with HDMI H264 Support
Are you struggling to efficiently manage and convert multiple IP streams into analog RF signals for your broadcasting needs? The SKD1709B IP to Analog Modulator is here to revolutionize your headend system. This high-density platform supports up to 32/48/64 channels in a compact 2U design, ensuring optimal space utilization and energy efficiency. With its browser-based user interface, system setup and maintenance become seamless, significantly reducing operational costs and extending the lifecycle of your equipment. The SKD1709B excels in handling up to 256 IP streams, outputting in both NTSC and PAL standards, making it a versatile solution for various broadcasting environments. Its advanced features include BISS decryption, teletext, and overlay options, catering to complex broadcasting requirements. Whether you're in the broadcasting, hotel, or medical industry, this modulator ensures high-quality signal transmission with minimal power consumption. Key performance metrics include an output frequency range of 48 ~ 860 MHz, out-band rejection of ≥ 60dB, and a differential gain of ≤ 5%. The SKD1709B is a reliable, cost-effective solution for modern broadcasting challenges.
• 4 GE ports for MPTS and SPTS video streams
• Compact 2RU design with 5 cooling fans
• Supports up to 256 IP streams and 64 channels
• Easy configuration via built-in Web UI
• Optional BISS decryption and teletext functions
SKD1709B is a high-density IP to analog RF platform that carry 32/48/64 any
Contact:Tomleequan Email：
whatsapp: +8613922702227
Contact:Tomleequan Email：
channels in a 2U box. Browser based user interface facilitate system setup and maintenance efficiency. This outstanding headend system consumes much less power than other competitors, eventually reduce operating cost and extend life cycle.
SKD1709B
IP to 32/48/64CHs Analog Agile Modulator
FEATURES
1. System provides 4 GE ports for both MPTS and SPTS video streams
2. Compact 2RU design with 5 cooling fans and dustproof screen
3. Receive up to 256 IP streams and output up to 32/48/64 channels in NTSC or PAL standard
4. Easy configuration and software upgrade by built-in Web UI
5. Optional function on teletext and overlay
6. Support BISS decryption as an option
SPECIFICATION
GE INPUT
Input Connector 4x RJ45
Transport Protocol UDP, RTP
Addressing Unicast, Multicast
MPEG Transport SPTS, MPTS
TS DECODING
Video Resolutions Up to 1080P
Video Form
Audio Form
MPEG1/2/4; H.264; H.265; AVS; AVS+; VC1
MPEG-1 Layer I/II/III; WMA, AAC,AC3
MAX decoding stream 32/48/64 channels
Additional capabilities Teletext; BISS decrypt
Aspect Ratio Control 4:3(Letter & Box); 16:9
Contact:Tomleequan Email：sales@fmuser.com whatsapp: +8613922702227
RF OUTPUT
Connector F female connector
Number of RF channels Max 64,Fully agile modulated channels
Supported Standard NTSC, PAL BG/DI/DK
STD,HRC and IRC Supported
Output Frequency 48 ~ 860 MHz
Out-band
Rejection ≥ 60dB
Flatness -2dB per carrier
Return Loss 12 dB (min)
Differential Gain ≤ 5%
Group Delay Response ≤ 100nS
2K Factor ≤ 2%
Output Level ≥ 53dBmV combined*
20dB Per 32CHs
Adjust Range
10dB Per CH
Audio Output Format MONO
Audio Level Adjust Range 0 ~ 100 %
RF Test Point -20 dB Relative to output
GENERAL Management NMS
Language English, Spanish
Power Supply AC 90 ~ 264 V
