Manufactory Wholesale SK-8860 8 IN 1 Agile TV Modulator for DVB-T ISDB-T Cable TV Systems with HDMI H264 Encoding
Are you struggling to manage multiple audio/video inputs in your hotel or cable TV system? The SK-8860 8 IN 1 Agile TV Modulator is your ultimate solution. This cost-saving RF agile modulator features 8 Audio/Video inputs and a single RF combiner output, ensuring seamless integration and superior performance. With H.F processing and one-conversion technology, it guarantees low outband interference, while MCU control ensures precise frequency accuracy. Designed for hotel cable TV systems, this modulator delivers excellent video and audio linearity, providing crystal-clear picture quality. Key performance metrics include an output frequency range of 45~550MHz or 550~860MHz, output level of 85 dBµV, and frequency stability of ±10KHz. Trusted by industry professionals, the SK-8860 is factory-tested and balanced for optimal performance.
• Eight Video & Audio Inputs, One RF Output
• H.F Processed with One-Conversion Technology
• MCU Control for Frequency Accuracy
• Double Side Band Modulator (Skip Channel Modulator)
• LED Display with Frequency Control
The SK-8860 8 Audio/Video Input and 1 RF output TV Modulator is a cost-saving RF agile modulator for hotel cable TV system. It has 8 Audio/Video input and only one RF combiner output. Each output level is well balanced at factory and tested perfectly before shipping.
SK-8860
8 IN 1 SKIP CHANNEL AGILE MODULATOR
FEATURES:
1. Eight Video & Audio input, one RF output
2. H.F processed with one-conversion ensures low outband interfere
3. MCU control for frequency control and accuracy
4. Excellent video and audio linearity for superior picture quality
5. LED Display. Four indictor lights for each channel, using UP and DOWN to control output Frequency.
6. Double Side Band Modulator (Skip Channel Modulator) SPECIFICATION:
OUTPUT
RF
INPUT
VIDEO
AUDIO
GENERAL
POWER AND SIZE
Output Frequency 45~550MHz or 550~860MHz
Output Connector F Connector
Output Level 85 dBµV (Adj.)
Test Point -20 dB ±3dB
A / V Ratio -11 ~ -18 dB (Adj.)
Frequency Stability ±10KHz
Output Impedance 75 Ohms
Video Input Level
0.6-1.5Vp-p (87.5% Modulation)
Input Connector Yellow RCA Jack
Video C/N 60dB
Input Level 0.8Vp-p(25KHz Peak Deviation)
Input Connector White RCA Jack
Voltage
AC 110 ~ 220V
Power Consumption 10W
Dimension 19” x 1.75” x 6.6”
