Manufactory Wholesale 8 HDMI Encoder with
H.264/H.265
Encoding for IP Output, RTSP, RTMP, and SRT Support
Need a reliable solution for multi-channel HDMI encoding? The 8 HDMI Encoder supports up to 24 HDMI inputs with H.264, MPEG-4, and H.265 video encoding, delivering high-quality IP output via UDP, RTSP, RTMP, and SRT. Ideal for broadcasting, live streaming, and IPTV applications, it features audio encoding in MPEG-1 Layer II, LC-AAC, and HE-AAC, with AC3 pass-through. With web-based management, QR code insertion, and multi-language caption support, this encoder ensures seamless integration and control.
• 24 HDMI inputs | • H.264/H.265 encoding | • RTSP, RTMP, SRT support | • Web-based management | • Multi-language caption insertion
8 channel HDMI input encoder supports H264/MPEG-4/H265 （DUP/RTP/RTSP/RTMP/HLS/M3U8/SRT/etc.
Products Description 8 Hdmi Encoder
Features:
1. Support 2/4/8//16/24 HDMI inputs, with2/4/ 8/16/24 SPTS output (each encoder module, only support STPS, NO MPTS), max 24 HDMI inputs.
2.MPEG4 AVC/H.264/H265 video encoding format.
3.MPEG1 Layer II, LC-AAC，HE-AAC audio encoding format and AC3 Pass Through, and audio gain adjustment.
4.This 8 Hdmi Encoder supports IP Output over UDP(Unicast/Multicast), SRT, RTSP, RTP, RTMP, HTTP, HLS, M3U8.
5. Support QR code, LOGO, caption insertion (Language Supported: 中文, English, ةيبرعلا, ไไไ, ไไไไไी, руская, ودرا for more languages please consult us…)
6.Support “Null PKT Filter” function
7. Control via web management, and easy updates via web
Hdmi
Contact:Tomleequan Email：
1280*720_60p, 1280*720_59.94
1280*720_50P
Chroma 4:2:0
Bitrate 1Mbps~15Mbps
Rate Control CBR/VBR
GOP Structure IP
Encoding Format
Audio
MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2; AC3 Pass-through
Sample rate 32KHz,44.1KHz,48KHz
Bit-rate 48~384Kbps
Stream output IP out over UDP (Unicast/Multicast),SRT, RTP,RTSP, RTMP, HTTP, HLS (RJ45, 1000M ) (8 HDMI inputs with 8 SPTS for each encoder board)
Network management(WEB)
System function
Miscella neous
Chinese and English language
Ethernet software upgrade
Dimension (W×L×H) 482mm×328mm×44mm
Environment 0~45℃(work)；-20~80℃（Storage）
Power requirements AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz
Contact:Tomleequan Email：sales@fmuser.com whatsapp: +8613922702227
Hangzhou Softel Optic Co ., Ltd co. was established in 2005, which is located in Hangzhou Hi - Tech Development Zone . Taking advantage of the modern broadcast and optic fiber communication technology , we are specializing in R & D of CATV , xPON , and IPTV system equipment . As a leading manufacturer of HFC broadband and optic transmission equipment , Softel has strong R & D capability in this field .
