Manufactory Wholesale 4GE CATV GPON ONT with WiFi for FTTH/FTTO Broadband Access
Looking for a reliable solution for high-speed broadband and CATV services? The 4GE CATV GPON ONT is designed to meet the demands of modern FTTH/FTTO networks, offering seamless data and video transmission. With four auto-adapting GE Ethernet ports and 802.11n/b/g WiFi, it ensures high-performance forwarding for HD video and internet services. Compatible with third-party OLTs like Huawei, ZTE, and Alcatel-Lucent, this device supports remote management via OMCI and local management via Web. Ideal for residential and commercial deployments, it delivers 2.488Gbps downstream and 1.244Gbps upstream speeds with a 30KM transmission range.
• 4 GE Ethernet ports & 802.11n/b/g WiFi | • GPON network with 2.488Gbps downstream | • OMCI & Web management | • Third-party OLT compatibility | • 30KM transmission range
ONT-4GE-W HGU GPON ONT is one of the GPON optical network unit design to meet the requirement of the broadband access network. It apply in FTTH/FTTO to provide the data, video service based on the GPON network.
ONT-4GE-W HGU GPON ONT is one of the GPON optical network units designed to meet the requirement of the broadband access network. It apply in FTTH/FTTO to provide the data, video service based on the GPON network.
4GE CATV GPON ONT provides four GE auto-adapting Ethernet ports and one 802.11 n/b/g WiFi port. The features high-performance forwarding capabilities to ensure excellent experience with Internet and HD video services. Therefore, it provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment. It has good third-party compatibility to work with the third party OLT, such as Huawei/ZTE/Fiberhome/Alcatel-Lucen.
Features
Full compatible with ITU-T G.984
Support fourGEauto-adapting Ethernet ports
Support one 802.11 n/b/g Wi-Fi port
Support OMCI for remote management
Support Web for local management
Support Auto-negotiation and MDI/MDIX
Support the Ethernet interface rate, working mode and flows control
Support loop-back at UNI
Support packet filtering and anti-illegal message attack protection
Support performance statistics of Ethernet lines
Support VLAN tagged label processing, traffic classification and packet filtering, STP/RSTP etc.
Support IGMP Snooping
Support AES-128
Specifications
Item Parameters
Interface
PON Port
Ethernet Port(LAN)
Power Supply Port
Network Management
Management
4GE CATV GPON ONT
1*GPON port, FSAN G.984.2 standard, Class B+
Downstream Data Rate: 2.488Gbps
Upstream Data Rate: 1.244Gbps
SC/PC single mode fiber 28dB Link loss and 30KM distance with 1:128
4*10/100/1000M Auto-negotiation RJ45 ports Full Duplex / Half-Duplex
RJ45, Auto-MDI/MDI-X
Transmission Distance 100 Meter
12V DC input
Standard compliant OMCI interface as defined by ITU-T G.984.4
Support WEB management
Management Function Status monitor, Configuration management, Alarm management, Log management
Shell
Power
Dimensions
Environmental Specifications
CATV Service Functions
Environment
Turn on/off RF output remotely
Plastic casing
External 12V 1A AC/DC power supply adapter
Power consumption:<6W
170mm(L)*130mm(W)*30mm(H) 0.3kg
Operating Temperature: 0～50℃
StorageTemperature: -40～85℃
Operating Humidity: 10%～90%(Non-condensing)
StorageHumidity: 5%～95%(Non-condensing)
Wavelength：1550 +/- 10nm
Optical return loss：>45dB
Input optical power：-8dBm～+2dBm
RF frequency：47MHz~875MHz
RF output lever：75～80dBuV
CNR：>46dB，CSO: >58dBc，CTB: >58dBc
RF output return loss： >14dB
RF impedance： 75Ohm
AGC function optional
