Manufactory Wholesale 1550 External Modulation Optical
Transmitter for Long-Distance FTTH and PON Networks
Need reliable long-distance optical transmission? The 1550 External Modulation Optical Transmitter delivers exceptional performance with ITU-T standard wavelength adjustability (±0.05nm) and DFB continuous wave laser technology. Ideal for FTTH and PON networks, it ensures low noise, narrow bandwidth (1MHz), and superior CNR, CTB, CSO, and SBS metrics. With optional AGC/MGC mode, SNMP management, and 1+1 backup power, this transmitter is perfect for network upgrades and WDM system expansions.
• ITU-T wavelength adjustability (±0.05nm) | • DFB laser with ≤1MHz bandwidth | • Excellent CNR, CTB, CSO, SBS | • Optional AGC/MGC mode & SNMP management | • Ideal for FTTH, PON, and WDM systems
ST1550E Optic transmitter is usually used for long-distance transmission. By ITU-T wavelength, access to a broadband PON Network is easily implemented, or applying to the FTTH Solution by WDM Technologies.
ST1550E Optic transmitter is usually used for long-distance transmission. By ITU-T wavelength, access to a broadband PON Network is easily implemented, or applying to the FTTH Solution by WDM Technologies.
Feature
◆Narrow bandwidth (Typ=1MHz), Lower noise, DFB continuous wave laser.
◆Unique innovation technology; Providing excellent CNR, CTB, CSO, SBS.
◆ITU standard wavelength is adjustable. Users can adjust and set the laser wavelength on the front-panel with ±0.05nm stepping in the range of ±200GHz (±1.6nm), while executing network upgrading and WDM System Expansion.
◆AGC/MGC Mode is optional at spot; OMI can be optimized at spot.
◆Perfect RS232 communications interface.
◆SNMP network management optional.
◆1+1 backup power supply optional.
◆Excellent P/P ratio.
Parameter
Performance
Opticfeature Laser
CSO dB ≤-65
SBS restrain dBm ≥16.0 13、16、18 fixed or adjustableoptional
Network interface por t RJ45,R232 Support I.E. & SNMP
Power supply V 90~265 city power -48VDCoptional
Power Consume W ≤50 Singlepowerworks
General feature
Worktemp. ℃ -5~65
Storage temp. ℃ -40~85
Machine temp. control automatically
Work relative temp. % 5~95 Size “ 19×14.5×1.75 WxDxH
