Manufactory Wholesale HD DVB-C Set Top Box with MPEG2 MPEG4 H.264 AVS+ and Dexin CAS Support

Page 1


Manufactory Wholesale HD DVB-C Set Top Box with MPEG2

MPEG4 H.264 AVS+ and Dexin CAS Support

Looking for a reliable HD TV set-top box that delivers seamless performance? The HD DVB-C Set Top Box is designed to meet the demands of modern broadcasting with support for MPEG2, MPEG4 H.264, and AVS+ standards. Equipped with an HDMI connector, it ensures compatibility with HDTV channels, while features like EPG, DVB Teletext, and DVB Subtitles enhance user experience. Ideal for home entertainment and hospitality setups, this device offers auto search, blind search, and network search functionalities, along with Dexin CAS support for secure content delivery.

• MPEG2, MPEG4 H.264, AVS+ support | • HDMI & RCA connectivity | • EPG, DVB

Teletext, Subtitles | • Auto, Blind, Network search | • Dexin CAS compatibility

HD DVB-C Set Top Box MPEG2 and MPEG4 H.264 and AVS+ Support Dexin CAS

HD TV Set Top Box

Contact:Tomleequan Email:

DVB-C HD TV set top box compliant with MPEG2 and MPEG4 H.264 and AVS+

Compatible with HDTV channels and equipped with HDMI connector

EPG & DVB Teletext & DVB Subtitles

Auto search & Blind search & network search function

Support Media Player

Support Dexin CAS

Technical Specifications of HD TV Set Top Box

Core System

●Processor : M88CC6000 (#1 CPU: MIPS 24KEf TM and #2 CPU: MIPS 24KEcTM)

●Broadcast tuners: 1 DVB-C

●Memory: 8MB Flash; 128MB RAM DDR3

●STB upgrade: Through OTA or USB Disk Connectivity

●Video: HDMI v1.4 ● RCA out (CVBS, Audio L/R) ●USB: 1xUSB2.0 host device

Tuner & Demodulator

●Input Frequency: 110MHz-860MHz

●Demodulator: 256,128,64,32 and 16QAM; demodulation supported

●Symbol rates: 0.45~8.5MBauds

Front panel

●Display: 3 LED Indicator; Power Red LED; Lock Green LED

●Button: Standby, VOL+, VOL-, CH+, CH-, Menu, OK

Video Decoding

●H.264 BP (with no ASO/FMO), MP& HP@L3/L4.1

●MPEG-2 MP@ML/HL

Contact:Tomleequan Email:sales@fmuser.com whatsapp: +8613922702227

●AVS Jizhun profile@L6.0/L4.0

●AVS Broadcast profile@L6.0/L4.0

●MPEG-4 SP Profile, Advanced Simple Profile@ Level 5 without GMC/Data Partitioning/Reversible VLC ●Xvid 1.3.2 without GMC and DivX without GMC

●H.263 baseline profile

Setup environment

●Function temperature:0-40 degree Celsius ●Power consumption: Max 10W

●Voltage:90V~250V AC (50/60Hz)

Proposed Accessories

●Remote control unit ●RCA Connect Cable

●HDMI Cable ●2*7# Batteries

Audio Decoding

●MPEG-1/2 Layer I/II/III

●MPEG-2/4 LC-AAC, MPEG-4 HE-AAC@Level 4

●Dolby AC3/AC3+ (for M88CC6000-1MD only)

●DRA 2 CH/5.1 CH

Dimensions

●W x H x D(mm):240*165*40 ●Weight(kg):1.0

●Packaging dimension(mm):275*255*48 ●Weight include packaging(kg):1.1
