Manufactory Wholesale EPON ONU 1GE 1FE Wifi CATV for FTTH FTTO FTTD Broadband Access
Looking for a reliable and versatile solution for broadband access and CATV services? The EPON ONU 1GE 1FE Wifi CATV combines GPON and Gigabit EPON technologies to deliver high performance, stability, and cost-effectiveness. Designed for FTTH, FTTO, and FTTD applications, it supports triple-play services, including data, VoIP, and CATV, with an RF bandwidth of 45~1000MHz. With dual-mode capability, it automatically detects and switches between GPON and EPON, ensuring seamless integration. Key features include 300Mbps WiFi, 20KM transmission distance, and robust firewall functionality, making it ideal for offices, homes, and video surveillance systems.
• Dual-mode GPON/EPON compatibility | • 300Mbps WiFi with 2T2R antennas | • 20KM optical transmission | • Triple-play support (data, VoIP, CATV) | • Robust firewall and NAT functionality
This 1GE 1FE Wifi EPON ONU is widely used in FTTO (office), FTTD (desk), FTTH (home) broadband access and CATV, video surveillance and other requirements.
This Epon onu 1ge 1fe wifi catv is based on mature GPON and Gigabit EPON technology, and has high ratio of performance to price, stable, cost-effective, high reliability, easy management, configuration flexibility and good quality of service (QoS) guarantees.Dual mode ONU can automatically detect OLT and switch PON mode, it can be used as GPON or EPON. It can also be applied to a wide temperature environment, and also has a firewall function.
ONU-2GF-RFW is a 1GE+1FE+WIFI+CATV XPON(GPON and EPON dual mode) HGU ONU. It is designed for meeting the triple-play service needs of fixed network operators or cable operators.
Features
HGU ONU, bridging and routing modes can be set
Dual mode ONU compatible with popular EPON and EPON OLT
Support loop detection, IGMP, IGMP snooping
802.1Q VLAN, QinQ, Cos, DSCP, QoS for priority of service
Support port speed, support for storm suppression
Support 802.11n 2T2R speed up to 300Mbps
Support No-auth, WEP, WPA-PSK and WPA2-PSK
Triple Solution Data, Voip and Cable TV(RF bandwidth:45~1000MHz, AGC function)
It supports Telnet, CLI, OMCI/OAM and Web management.
Contact:Tomleequan Email：
It supports NAT, Firewall function.
It supports remote software upgrade.
Technical parameters of Epon Onu 1ge 1fe Wifi Catv
Items Unit
PON standard.
Optical interface
Speed Gbps
EPON IEEE802.3ah, GPON ITU-T G.984.x
SC/PC connector,1 GPON/EPON interface(EPON PX20+ and GPON Class B+) Receiving sensitivity: ≤-28dBm Transmitting optical power:
0～+4dBm Transmission distance: 20KM
GPON: uplink 1.25Gbps, downlink 2.5Gbps; EPON: symmetric 1.25Gbps
Wavelength nm Tx1310, Rx 1490, CATV 1550
Interface data
1FE 10/100Mbps 1GE 10/100/1000Mbps
Auto adaptive Ethernet interfaces, Full/Half Duplex, RJ45 connectors
Wireless Compliant with IEEE802.11b/g/n, 300Mbps, 2T2R 2 external antenna
Indicator LED PWR, PON, LOS, WiFi, GE, FE, CATV
CATV
Optical Connector Type
Input
Contact:Tomleequan Email：sales@fmuser.com whatsapp: +8613922702227
RF Output Connector
