Manufactory Wholesale 1GE 1FE Wifi ONU for FTTH
Networking with EPON Technology and 802.11n WiFi
Looking for a reliable and high-performance solution for FTTH and networking services? The 1GE 1FE Wifi ONU combines Gigabit EPON technology with 802.11n WiFi to deliver seamless connectivity and multi-service QoS guarantees. Designed for service providers, it features plug-and-play functionality, flexible QinQ VLAN support, and compatibility with major OLTs like Huawei and ZTE. With a throughput of up to 900Mbps and dual-stack IPv4/IPv6 support, this device ensures stability and ease of maintenance, fully compliant with IEEE802.3ah and China Telecom standards.
• 1GE + 1FE + 1WIFI ports | • Plug-and-play with auto-configuration | • 802.11n WiFi (300Mbps) | • Dual-stack IPv4/IPv6 support | • Compatible with Huawei, ZTE, Fiberhome OLTs
This 1GE 1FE Wifi ONU is designed for FTTH and networking service providers. It is based on the Gigabit EPON technology and has a high performance.
EPON ONU/HGUis designedfor FTTH and networkingservice providers. ONU-2GF-WFis developedbySOFTEL based on the Gigabit EPON technology, has a high performance. It supports the 802.11n wireless networking technology(T/R). This 1GE 1FE WIFI ONU is high stability and easy to maintain, has multi-service QoS quality guarantee. And It is fully compliant with technical regulations such as IEEE802.3ah and technical requirement of EPON Equipment from China Telecom, China Unicom.
Characteristics
Main service: 1GE+1FE+1WIFI
Plug and play, integrate auto detection, auto configuration and auto firmware upgrading
Support flexible QinQ VLAN,DHCP server/relay and IGMP/ MLD multicast monitoring function
Support diagnostic monitoring and remote disabling of fiber optical
Compatible with Huawei,ZTE and Fiberhome OLT
Support 802.11n WiFi（T/R）function
Support NAT and firewall function
Support IPv4 and IPv6 dual stack
WAN support networking bridge, route and bridge/route mixed mode
Specifications of 1GE 1FE WIFI ONU
Technical items
Descriptions
Fiber port 1 EPON interface, SC single-mode/single-fiber, Downstream rate 1.25Gbps,
Contact:Tomleequan
Contact:Tomleequan Email：
Upstream rate 1.25Gbps
Wavelength Tx 1310nm, Rx 1490nm
Fiber interface SC/PC
RX sensitivity <-27dBm （1490nm）
WLAN
LAN
Throughput
DC power
IEEE802.11b/g/n，300Mbps, a built-in antenna
1*10/100/1000Mbps+1*10/100Mbp adaptive Ethernet ports, full/halfduplex, RJ45 interface
Throughput can reach 900Mbps or more
12V 1A, external AC-DC power adapter
Button Reset, power, WIFI
Power ≤10W
Operation Working temperature: -5〜+55℃ working humidity:10〜90％(non-condensation)
Storage
Dimension
Storage temperature: -30℃〜+60℃ storage humidity: 10〜90％ (non-condensation)
130*107*31mm(length*width*height)
Net weight ≤0.2Kg
Data Service Functions
Full speed 1G non-blocking switching
2048 MAC address table
Support VLAN QinQ, transparent, tag, translation, trunk, etc.
Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc
Support auto polarity detection of Ethernet ports (AUTO MDIX)
Integrated IEEE802.1p QoS with four level priority queues
Support IPv4/ IPv6 IGMP snooping and MLD snooping
Contact:Tomleequan Email：sales@fmuser.com whatsapp: +8613922702227
Contact:Tomleequan Email：
Support bridge, route and bridge/route mixed mode
Wi-Fi service
Support Integrated 802.11b/g/n, 300Mbps
Support 16 connections
Support WEP and WPA/WPA2 security protocols.
Ordering Information
Model Description
ONU-2GF-WF (1GE 1FE WIFI ONU) 1PON(SC),1GE+1FE(ETH), 1WIFI
