Manufactory Wholesale Dual Mode XPON ONT
1GE+1FE+CATV+WIFI
ONU for FTTH FTTB Solutions
Looking for a reliable and versatile optical network terminal? The Dual Mode XPON ONT combines EPON and GPON compatibility, offering seamless integration for FTTH and FTTB applications. With a PON interface, 1GE+1FE+CATV+WIFI connectivity, and carrier-grade reliability, it ensures high-speed broadband access for residential and corporate users. Key features include 2.5Gbps downlink, 20km transmission distance, and WPA2-PSK encryption, making it a robust solution for modern optical networks.
• Dual Mode EPON/GPON support | • 1GE+1FE+CATV+WIFI interfaces | • 2.5Gbps downlink speed | • 20km transmission distance | • WPA2-PSK encryption
Contact:Tomleequan Email：
The uplink of this Dual Mode XPON ONT provides one PON interface, while downlink provides two Ethernet and one RF interfaces. It can realize optical access solutions such as FTTH (Fiber To The Home) and FTTB (Fiber To The Building). It fully integrates the reliability, maintainability and security design of carrier-grade equipment, and provides customers with the last kilometer of broadband access to residential and corporate customers.
This ONT-2GF-RFW, 1GE+1FE+CATV+WIFI ONU, is a residential gateway device can be used for both EPON and GPON.
Specifications of Dual Mode XPON ONT
User-Side Interface 1*10/100BASE-T;1*10/100/1000BASE-T; 1*RF interface
Size (Mm) 167(L)×118(W)×30(H)
Maximum Power Consumption <8W
Weight 200g
Temperature: -10°C ~ 55°C
Operating Environment
Power Supply
Humidity: 5% ~ 95% （no condensation）
External Power Adapter 12V/1A
Power Adapter Input 100-240V AC, 50/60Hz
Power Interface Size metal inner diameter: φ2.1±0.1mmouter diameter : φ5.5±0.1mm; length: 9.0±0.1mm
WLAN Module
Internal and external dual antenna, antenna gain 5db, antenna power 16~21dbm
Support 2.4GHz, 300M transmission rate
Software Characteristic(GPON)
Comply with ITU-T G.984/G.988
Standard Compliance
Comply with IEEE802.11b/g/n
Comply with China Telecom/China Unicom GPON Interoperability Standard
Contact:Tomleequan Email：sales@fmuser.com whatsapp: +8613922702227
GPON
Support for the ONT registration mechanism
Support DBA
Support FEC
Support link encryption
Supports the maximum effective transmission distance of 20 km
Support long illuminating detection and optical power detection
Multicast IGMP V2 Proxy/Snooping
Support WPA2-PSK/WPA-PSK encryption
Support client isolation
WLAN
Support for 4 * SSID
Support for 802.11 BGN mode
Support maximum rate of 300M
Support web management
Management & Maintenance
Compatibility
Support CLI/Telnet management
Support port loopback detection
Support the connection with the business competitor's OLT and its proprietary protocols, including Huawei, H3C, ZTE, BDCOM, RAISECOM, and so forth.
Software Characteristic(EPON)
Comply with IEE802.3ah EPON
Standard Compliance
EPON
Comply with China Telecom/China Unicom EPON Interoperability Standard
Support for the ONT registration mechanism
Support DBA
Support FEC
Support link encryption
Supports the maximum effective transmission distance of 20 km
Support long illuminating detection and optical power detection
Multicast IGMP V2 Proxy/Snooping
Support WPA2-PSK/WPA-PSK encryption
Support client isolation
WLAN
Support for 4 * SSID
Support for 802.11 BGN mode
Support maximum rate of 300M
Contact:Tomleequan
Management & Maintenance
Compatibility
Support web management
Support CLI/Telnet management
Support port loopback detection
Support the connection with the business competitor's OLT and its proprietary protocols, including Huawei, H3C, ZTE, BDCOM, RAISECOM, and so forth.
