Marker Lights, Low Level Lights

MARKER LIGHTS

38

SOFIA

pg 39-41

MIA SQUARE

pg 42-43

MIA ROUND

pg 44

LOLA

pg 46-48

ELLA

pg 49-53

CHLOE

pg 54-56

CLARA

pg 57-59

MAYA

pg 60-61

TRIMLESS MAYA

pg 62-63

DIMMABLE DRIVERS

pg 64-66

SOFIA

39

Ideal For Low Level Lighting

Driver Supplied Fits Through Cutout

Embedded Box ( Sold Separately )

SOFIA 3W LOW LEVEL MARKER LIGHT 3W

30K LIFESPAN (HRS)

CRI 90

AC200-240V

IP44

OSRAM CHIP

FEATURES & BENEFITS

CLASS II

2 YEAR WARRANTY

DIMENSIONS

• 3W Low Level Wash Light

• Finish - Matt White, Matt Black & Matt Gold

• 50 Lumens

• Available in Warm White 3000K

• IP44 Rated

• An ideal indirect lighting effect in circulation areas, walkways, stairs etc

• Anti Glare • LED CHIP – Osram

• Aids individuals to navigate their way around when overhead lights are switched off

• Slim profile • Supplied with a inline non dimmable driver fits through cutout • Dimmable driver option available

• Can be used as decorative feature marker light • 2 year warranty

• Available Aluminium Embedded Box – required when installed into brick or solid walls SPECIFICATIONS

40

Product Code

Finish

Power

Colour

Lumens

Dimension

Cutout

SOFIA-3W-3KWHT

Matt White

3W

3000K

50lm

80 x 40 x 31

35

SOFIA-3W-4KBLK

Matt Black

3W

4000K

50lm

80 x 40 x 31

35

Product Code

Description

SOFIA-BOX

Polycarbonate Embedded Box

Product Code

Description

Input Voltage

Output Voltage

Dimension

CHLOE-DIM

Chloe Dimmable Driver

200-250V

3-8VDC 700mA

48 x 30 x 21

Product Code

Description

Output Voltage

Dimension

ML-DIM-DVR-20W

20W Dimmable Driver

3-22V

140 x 45 x 28

Dimension 70 x 70 x 40

FEATURES IP44 RATED

ANTI GLARE

SLIM PROFILE

OSRAM CHIP

MATT WHITE PRODUCT CODE: SOFIA-3W-3KWHT

FROSTED GLASS FOR OPTIMUM LIGHT DISTRIBUTION

MATT BLACK PRODUCT CODE: SOFIA-3W-3KBLK

MATT GOLD PRODUCT CODE: SOFIA-3W-3KMGOLD

DARK BRONZE PRODUCT CODE: SOFIA-3W-3KBRZ

ONLY SUITABLE FOR INDOOR & BATHROOM USAGE

Ideal For Low Level Lighting

Embedded Box ( Sold Separately ) Required when installed into brick or solid walls 41

MIA 42

Ideal For Low Level Lighting

Driver Supplied Fits Through Cutout

Embedded Sleeve ( Sold Separately )

MIA LOW LEVEL MARKER LIGHT 3W

30K LIFESPAN (HRS)

CRI 90

AC200-240V

IP44

FEATURES & BENEFITS

OSRAM CHIP

CLASS II

2 YEAR WARRANTY

DIMENSIONS • Finish - Matt White, Matt Black & Matt Gold

• 3W Low Level Wash Light • 50 Lumens

• Available in Warm White 3000K • IP44 Rated • An ideal indirect lighting effect in circulation areas, walkways, stairs etc

• Anti Glare • LED CHIP – Osram • Slim profile • Supplied with a inline non dimmable driver fits through cutout • Dimmable driver option available • Available Embedded Sleeve – required when installed into brick or solid walls (Sold Separately)

• Aids individuals to navigate their way around when overhead lights are switched off • Can be used as an architectural feature maker light within an area • 2 year warranty

SPECIFICATIONS Product Code

Finish

Power

Colour

Lumens

Dimension

Cutout

MIA-3W-3KWHT

Matt White

3W

3000K

50lm

45 x 45 x 26

35

MIA-3W-4KWHT

Matt Black

3W

4000K

50lm

45 x 45 x 26

35

Product Code

Description

MIA-SLEEVE

Polycarbonate Embedded Sleeve

Product Code

Description

Input Voltage

Output Voltage

Dimension

CHLOE-DIM

Chloe Dimmable Driver

200-250V

3-8VDC 700mA

48 x 30 x 21

Product Code

Description

Output Voltage

Dimension

ML-DIM-DVR-20W

20W Dimmable Driver

3-22V

140 x 45 x 28

Dimension 50 x 40

43

Ideal For Low Level Lighting

Driver Supplied Fits Embedded Sleeve Through Cutout ( Sold Separately )

MIA ROUND LOW LEVEL MARKER LIGHT 3W

30K LIFESPAN (HRS)

CRI 90

AC200-240V

IP44

FEATURES & BENEFITS

OSRAM CHIP

CLASS II

2 YEAR WARRANTY

DIMENSIONS • Finish - Matt White, Matt Black & Matt Gold

• 3W Low Level Wash Light • 50 Lumens

• Available in Warm White 3000K • IP44 Rated • An ideal indirect lighting effect in circulation areas, walkways, stairs etc

• Anti Glare • LED CHIP – Osram • Slim profile • Supplied with a inline non dimmable driver fits through cutout • Dimmable driver option available • Available Embedded Sleeve – required when installed into brick or solid walls (Sold Separately)

• Aids individuals to navigate their way around when overhead lights are switched off • Can be used as an architectural feature maker light within an area • 2 year warranty

SPECIFICATIONS

44

Product Code

Finish

Power

Colour

Lumens

Dimension

Cutout

MIA-RD-3KWHT

Matt White

3W

3000K

50lm

45 x 45 x 26

35

MIA-RD-4KWHT

Matt Black

3W

4000K

50lm

45 x 45 x 26

Product Code

Description

MIA-SLEEVE

Polycarbonate Embedded Sleeve

Product Code

Description

Input Voltage

Output Voltage

Dimension

CHLOE-DIM

Chloe Dimmable Driver

200-250V

3-8VDC 700mA

48 x 30 x 21

Product Code

Description

Output Voltage

Dimension

ML-DIM-DVR-20W

20W Dimmable Driver

3-22V

140 x 45 x 28

35 Dimension 50 x 40

FEATURES IP44 RATED

ANTI GLARE

SLIM PROFILE

FROSTED GLASS FOR OPTIMUM LIGHT DISTRIBUTION

OSRAM CHIP

MATT WHITE

MATT BLACK

MATT GOLD

MATT GOLD

PRODUCT CODE: MIA-3W-3K-WHT

PRODUCT CODE: MIA-3W-3K-BLK

PRODUCT CODE: MIA-3W-3K-MGOLD

PRODUCT CODE: MIA-3W-3K-MGOLD

ONLY SUITABLE FOR INDOOR & BATHROOM USAGE

Ideal For Low Level Lighting

Round Option PRODUCT CODE： MIA-RD-3KWHT

Embedded Box ( Sold Separately ) Required when installed into brick & solid walls 45

LOLA 46

Supplied with In-Ground Sleeve

LOLA IN GROUND LIGHT 2.5W

50K LIFESPAN (HRS)

CE & ROHS

CRI 90

30°

BEAM ANGLE

2 YEAR WARRANTY

AC220-240V

IP67

FEATURES & BENEFITS

OSRAM CHIP

DIMENSIONS

• lntegrated Recessed Downlight

• Made from 316 Stainless Steel for maximum durability

• 240 Lumens • LED Chip - Osram

• Stainless Steel, Matt White, Eyelid & Up/Down Bezels available

• Beam Angle 30°

• Available in 3000K & 4000K

• IP Rating - IP67

• 24V Constant Voltage Wired in parallel

• Anti-Glare

• 2 Metres rubberised cable

• Faceted Lens

• Ideal walk over light when used mounting sleeve

• Waterproof gland • 2 waterproof gasket

Size 36×30mm Opening size 32×40mm

• Suitable as a walkover light

• Flush toughened glass

• 2 year warranty

SPECIFICATIONS Product Code

Finish

Power

Colour

Lumens

Cutout

Dimension

LOLA-3K

MATT WHITE

2.5W

3000k

240lm

32mm

36 × 30

LOLA-4K

MATT WHITE

2.5W

4000K

240lm

32mm

36 × 30 47

3000K & 4000K Options IP67 Rated

Faceted Lens

Beam Angel 30°

240 Lumens

Waterproof Gland

In Ground Sleeve

48

2 Waterproof Gaskats

49

35

Driver Supplied Fits Through Cutout

In-Ground Polycarbonate Sleeve (Sold Separately)

3W ELLA IP65 MARKER LIGHT 3W

50K LIFESPAN (HRS)

CE & ROHS

CRI 90

30°

BEAM ANGLE

2 YEAR WARRANTY

OSRAM CHIP

AC100-240V

IP65

3V 600ma

FEATURES & BENEFITS

DIMENSIONS

• 3W Low Glare Marker Light / Downlight

• Polycarbonate Embedded Sleeve available

• High Powered version of our 1W Ella Range

• Included Brushed Nickel & Matt White Bezel

• 200 Lumens

• Variety of bezel options available

• LED Chip - Osram

• Improved driver IP rating, with waterproof heat shrink

• Beam Angle 30° • Indoor & outdoor usage • IP Rating – IP65 •

Available in 2700K, 3000K & 4000K

• Anti-Glare • 2 year warranty • Faceted Lens • Flush toughened glass SPECIFICATIONS

50

Product Code

Finish

Power

Colour

Lumens

Dimension

Cutouts

ELLA3W-27K-BN/WHT

Brushed Nickel / Matt White

3W

2700K

200lm

42 x 27

37mm

ELLA3W-3K-BN/WHT

Brushed Nickel / Matt White

3W

3000K

200lm

42 x 27

37mm

ELLA3W-4K-BN/WHT

Brushed Nickel / Matt White

3W

4000K

200lm

42 x 27

37mm

Product Code

Description

Dimension

ELLA3W-SLEEVE

Polycarbonate Embedded Sleeve

35 x 50

Product Code

Description

Output Voltage

Dimension

ML-DIM-DVR-20W

20W Dimmable Driver

3-22V

140 x 45 x 28

Driver Supplied Fits Through Cutout

In-Ground Polycarbonate Sleeve (Sold Separately)

1W ELLA IP65 MARKER LIGHT 1W

50K LIFESPAN (HRS)

CE & ROHS

CRI 90

30°

BEAM ANGLE

2 YEAR WARRANTY

OSRAM CHIP

AC100-240V

IP65

3V 350ma

FEATURES & BENEFITS

DIMENSIONS

• 1W Low Glare Marker Light / Downlight

• Polycarbonate Embedded Sleeve available

• 100 Lumens

• Included Brushed Nickel & Matt White Bezel

• LED Chip - Osram • Variety of bezel options available • Beam Angle 30° • IP Rating – IP65

• Ideal walk over light when used mounting sleeve

• Anti-Glare

• Suitable as a walkover light

• Faceted Lens

•

• Flush toughened glass

• 2 year warranty

Available in 2700K, 3000K & 4000K

SPECIFICATIONS Product Code

Finish

Power

Colour

Lumens

Dimension

Cutouts

ELLA-27K-BN/WHT

Brushed Nickel / Matt White

1W

2700K

100lm

26 x 30

25

ELLA-3K-BN/WHT

Brushed Nickel / Matt White

1W

3000K

100lm

26 x 30

25

ELLA-4K-BN/WHT

Brushed Nickel / Matt White

1W

4000K

100lm

26 x 30

25

Product Code

Description

Dimension

ELLA-SLEEVE

Polycarbonate Embedded Sleeve

35 x 50

Product Code

Description

Output Voltage

Dimension

ML-DIM-DVR-20W

20W Dimmable Driver

3-22V

140 x 45 x 28 51

Powered By

MATT WHITE BEZEL INCLUDED (PAINTABLE BEZEL)

BRUSHED NICKEL BEZEL INCLUDED

MATT BLACK BEZEL (SOLD SEPARATELY) PRODUCT CODE: ELLA-BLK-BZL

FOLLOWING BEZEL RANGE IS ONLY SUITABLE FOR INDOOR & BATHROOM USAGE ( SOLD SEPARATELY )

52

BRONZE PRODUCT CODE: ELLA-BZL-BRZ

MATT ANTHRACITE GREY PRODUCT CODE: ELLA-BZL-GREY

MATT GOLD PRODUCT CODE: ELLA-BZL-MGOLD

POLISHED BRASS PRODUCT CODE: ELLA-BZL-PB

POLISHED COPPER PRODUCT CODE: ELLA-BZL-PC

ANTIQUE BRASS PRODUCT CODE: ELLA-BZL-AB

WALKOVER LIGHT

IP65 SUITABLE FOR OUTDOORS

Ella Eyelid Bezel

MATT WHITE PRODUCT CODE: ELLA-EYE-BZL-WHT

DARK BRONZE PRODUCT CODE: ELLA-EYE-BZL-BRZ

BRUSHED NICKEL PRODUCT CODE: ELLA-EYE-BZL-BN

ANTIQUE BRASS PRODUCT CODE: ELLA-EYE-BZL-AB

POLISH BRASS PRODUCT CODE: ELLA-EYE-BZL-PB

MATT BLACK PRODUCT CODE: ELLA-EYE-BZL-BLK

POLISHED COPPER PRODUCT CODE: ELLA-EYE-BZL-PC

Ella Up & Down Bezel

MATT WHITE PRODUCT CODE: ELLA-UD-BZL-WHT

DARK BRONZE PRODUCT CODE: ELLA-UD-BZL-BRZ

BRUSHED NICKEL PRODUCT CODE: ELLA-UD-BZL-BN

ANTIQUE BRASS PRODUCT CODE: ELLA-UD-BZL-AB

POLISH BRASS PRODUCT CODE: ELLA-UD-BZL-PB

MATT BLACK PRODUCT CODE: ELLA-UD-BZL-BLK

POLISHED COPPER PRODUCT CODE: ELLA-UD-BZL-PC

53

54

Driver Supplied Fits Through Cutout

Dimmable Driver Chloe-Dim ( Sold Separately )

INLINE COLOUR SWITCHABLE CONNECTOR

6000K

4000K

2800K

3W CHLOE CCT MARKER LIGHT / MINI DOWNLIGHT 3W

50K LIFESPAN (HRS)

IP44

OSRAM CHIP

30°

BEAM ANGLE

2 YEAR WARRANTY

220-240V

CRI 90

FEATURES & BENEFITS

DIMENSIONS

• 3W Low Glare Marker Light / Downlight

• Great MR11 Alternative • Variety of bezel options available including Matt White & Brushed Nickel

• 300 Lumens • LED Chip - Osram

• Colour Switchable 2800K, 4000K 6000K

• Beam Angle 30° • IP Rating - IP44

• Ideal for kitchens (as plinth lights) receptions, meeting rooms, entrance foyers

• Fluted, Anti-Glare Bezel • Faceted Lens

• 2 year warranty

SPECIFICATIONS Product Code

Finish

Power

Colour

Lumens

Dimension

Cutout

CHLOE-3W-CCT

Matt White

3W

2800K/4000K/6000K

300lm

34 × 45mm

37mm

Product Code

Description

Input Voltage

Output Voltage

Dimension

CHLOE-CCT-DIM

Chloe Dimmable Driver

200-250V

2-6VDC 350mA

67 × 21 × 21 55

POWERED BY

MATT WHITE (PAINTABLE BEZEL)

BRUSHED NICKEL

MATT BLACK PRODUCT CODE: CHLOE-BZL-BLK

FOLLOWING BEZEL RANGE IS ONLY SUITABLE FOR INDOOR & BATHROOM USAGE ( SOLD SEPARATELY )

56

BRONZE PRODUCT CODE: CHLOE-BZL-BRZ

MATT GOLD PRODUCT CODE: CHLOE-BZL-MG

MATT ANTHRACITE GREY PRODUCT CODE: CHLOE-BZL-GREY

POLISHED BRASS PRODUCT CODE: CHLOE-BZL-PB

ANTIQUE BRASS PRODUCT CODE: CHLOE-BZL-AB

POLISHED COPPER PRODUCT CODE: CHLOE-BZL-PC

SOFFIT LIGHTING

ALCOVE / NICHE LIGHTING

CABINET LIGHTING

ACCENT/ WALL WASH

57

Driver Supplied Fits Through Cutout

CLARA 1W ADJUSTABLE MARKER LIGHT 1W

50K LIFESPAN (HRS)

CE & ROHS

CRI 90

30°

BEAM ANGLE

2 YEAR WARRANTY

OSRAM CHIP

AC100-240V

IP44

3V 350ma

FEATURES & BENEFITS

DIMENSIONS

• 1W Adjustable Marker Light / Downlight

• Anti-Glare • Faceted Lens

• 100 Lumens • Available in Matt White Finish • LED Chip - Osram • Paintable Bezel • Beam Angle 30° • Available in 3000K & 4000K • IP Rating – IP44 • 2 year warranty

SPECIFICATIONS

58

Product Code

Finish

Power

Colour

Lumens

Dimension

Cutouts

CLARA-3KWHT

MATT WHITE

1W

3000K

100lm

22 x 42

35

CLARA-4KWHT

MATT WHITE

1W

4000K

100lm

22 x 42

35

Product Code

Description

Output Voltage

Dimension

ML-DIM-DVR-20W

20W Dimmable Driver

3-22V

140 x 45 x 28

FEATURES

PAINTABLE BEZEL

IP44 RATED

OSRAM LED CHIP ADJUSTABLE MARKER LIGHT

180 degree rotate

FACETED LOW GLARE LENS

POWERED BY

59

Driver Supplied Fits Through Cutout

MAYA INTERCHANGEABLE BEZEL MARKER LIGHT 30°

1W

50K LIFESPAN (HRS)

IP44

2 YEAR WARRANTY

BEAM ANGLE

OSRAM CHIP CRI 90

100-240V

FEATURES & BENEFITS

DIMENSIONS

• 1W Marker Light / Downlight

• Faceted Lens

• 100 Lumens

• Round, Square, Pin Spot, Wash Bezels options available

• LED Chip - Osram • Beam Angle 30°

• Available Round & Square Eyelid Bezels

• IP44 Rated

• 2 Year Warranty

• Finish - Matt White

SPECIFICATIONS

60

Product Code

Power

Colour

Lumens

Output

Dimension

MAYA-3KWHT

1W

3000K

100lm

3V 350ma

26 x 25

22mm

MAYA-4KWHT

1W

4000K

100lm

3V 350ma

26 x 25

22mm

Product Code

Description

Dimension

MAYA-SLOT-RD

Round Eyelid Bezel

230 x 230 x 150

MAYA-SLOT-SQ

Square Eyelid Bezel

230 x 230 x 150

Cutouts

IP44

MATT WHITE PAINTABLE BEZEL

100LM INTERCHANGEABLE BEZEL POWERED BY

ROUND BEZEL SUPPLIED WITH FITTING

SQUARE BEZEL SUPPLIED WITH FITTING

BLACK PRODUCT CODE: MAYA-BZL-BLK

PIN SPOT SUPPLIED WITH FITTING

WASH BEZEL SUPPLIED WITH FITTING

FOLLOWING BEZEL RANGE IS ONLY SUITABLE FOR INDOOR & BATHROOM USAGE ( SOLD SEPARATELY )

61

TRIMLESS MAYA 62

TRIMLESS MAYA BEZEL

SUITABLE FOR MAYA ROUND BEZEL

IDEAL FOR PLASTER BOARDS

PIN SCREW ACCESSORIES ALLOWS FOR EASY REMOVEL AND REPLACMENT OF FITTING

PRODUCT CODE: TRIMLESS-BZL

PRODUCT CODE: PIN-SCRW

63

THROUGH-HOLE DIMMABLE DRIVERS FOR MARKER LIGHTS 3W CONSTANT CURRENT DIMMABLE DRIVER COMPATIBLE WITH

MIA

SOFIA

CHLOE

1W CONSTANT CURRENT DIMMABLE DRIVER COMPATIBLE WITH

CLARA

ELLA

FEATURES & BENEFITS • Protections: Short Circuit/ Over load/ Over Current • Full protection plastic housing easy installation • IP20 rated • Powers one per fittings • Dimming Function: Triac Dimmable

SPECIFICATIONS

64

Product Code

Watts

Input Voltage

Output Voltage

Cutout

Dimensions

1W-DIM

1W

200-250V

2-12.5VDC 500mA

25mm

84 x 20 x 20

CHLOE-DIM

3W

200-250V

35mm

48 x 30 x 21

Product Code

Description

Input Voltage

Output Voltage

Dimension

CHLOE-DIM-DVR

Chloe Dimmable Driver

200-250V

2-6VDC 350mA

67 x 21 x 21

3-8VDC 700mA

COMPATIBLE WITH:

SOFIA

MIA

MIA ROUND

MAYA

CHLOE

ELLA

20W DIMMABLE DRIVER 20W CONSTANT CURRENT DIMMABLE DRIVER IP20

CE & ROHS

2 YEAR WARRANTY

FEATURES & BENEFITS • Constant current mode output with multiple levels selectable by dip switch

• IP20 design for indoor installation • Cooling by free air convection

• Protections: Short Circuit/ Over load/ Over Current • Dimming function: Triac dimmable • Full protection plastic housing easy installation • 2 year warranty DIP MULTIPLE CURRENT FORM

DIMENSIONS

SPECIFICATIONS Product Code

Power

Input Voltage Range

Output Voltage

Output Range

Dimension

ML-DIM-DVR-20

20W

180-240 VAC

3-22V

700ma

140 x 45 x 27 65

COMPATIBLE WITH:

SOFIA

MIA

MIA ROUND

MAYA

CHLOE

ELLA

40W DIMMABLE DRIVER 40W CONSTANT CURRENT DIMMABLE DRIVER 40W

IP20

CE & ROHS

FEATURES & BENEFITS

2 YEAR WARRANTY DIMENSIONS

• Constant current mode output with multiple levels selectable by dip switch • Protections: Short Circuit/ Over load/ Over Current • Full protection plastic housing easy installation • IP20 design for indoor installation • Cooling by free air convection • Dimming function: Triac dimmable • 2 year warranty

DIP MULTIPLE CURRENT FORM

SPECIFICATIONS

66

Product Code

Power

Input Voltage Range

Output Voltage

Output Range

Dimension

ML-DIM-DVR-40

40W

180-240 VAC

3-22V

700ma

140 x 45 x 27
