Forms surfaces surfaces

surfaces VIVIDGLASS, STAInLESS STEEL, FuSED METAL, BOnDED METAL, BOnDED QuARTZ

1 | FORMS+ SURFACES

shaping life in public spaces

FORMS+SURFACES | 2

contents surfaces............................................................................................................. 3 vividglass.......................................................................................................... 7 About VividGlass................................................................................................... 9 ViviChrome Chromis.............................................................................................11 Applications.....................................................................................................14 ViviChrome Scribe................................................................................................17 Accessories.....................................................................................................18 Applications.................................................................................................... 20 ViviGraphix Elements........................................................................................... 23 Applications.................................................................................................... 28 ViviGraphix Graphica........................................................................................... 31 Applications.................................................................................................... 36 ViviGraphix Gradiance.......................................................................................... 39 Applications.................................................................................................... 44 ViviGraphix Spectra Zoom Images......................................................................... 47 Applications.................................................................................................... 48 ViviGraphix Spectra Custom Artwork......................................................................51 Applications.................................................................................................... 52 ViviStone........................................................................................................... 55 Applications.................................................................................................... 58 VividGlass Finishes.............................................................................................. 60 VividGlass LumiLevel Options............................................................................... 61 ViviForm............................................................................................................ 63 Applications.................................................................................................... 64

stainless steel & fused metal........................................................................ 67 Stainless Steel Finishes........................................................................................ 69 Fused Metal Colors & Finishes.............................................................................. 73 Impression Patterns............................................................................................. 79 Eco-Etch Patterns............................................................................................... 83 Fusion Patterns................................................................................................... 91 Screen Patterns.................................................................................................. 95 Applications....................................................................................................... 98

bonded metal................................................................................................103.

Colors & Patinas................................................................................................105.

Patterns............................................................................................................106.

Applications......................................................................................................116

bonded quartz...............................................................................................119.

Colors..............................................................................................................121 Patterns............................................................................................................122.

Applications......................................................................................................128

systems............................................................................................................131 LEVELe Wall Cladding System.............................................................................132.

LightPlane Panels..............................................................................................134 Elevator Interiors................................................................................................136.

Elevator Doors...................................................................................................138.

Columns & Column Covers.................................................................................140 Doors...............................................................................................................142 Silhouette Railing System....................................................................................144 interactive Design Tools............................................................................147.

Zoom Digital Darkroom.......................................................................................148.

ViviStone Virtual Quarry......................................................................................152.

Elevator Design Studio........................................................................................154.

Augmented Reality.............................................................................................156 Comprehensive support..............................................................................158 Augmented Reality Marker........................................................................159 Additional Resources..................................................................................161

Š2014 Forms+Surfaces | All dimensions are nominal. Specifications subject to change without notice.

1 | FORMS+ SURFACES

FORMS+SURFACES | 2

Partition wall in ViviGraphix Gradiance glass, Switchgrass pattern interlayer, Standard finish. Kaiser Permanente, Carmel Valley Medical Offices, San Diego, California.

surfaces VividGlass. Stainless Steel. Fused Metal. Bonded Metal. Bonded Quartz. Our Surfaces are the basis for unlimited creative expression. Beautiful on their own, they provide a robust visual vocabulary for walls, columns, elevator interiors and more. They are as diverse as the applications for which they are used. And, highly configurable like our Systems, they offer a sophisticated breadth of choices that can be tailored to meet the real-world challenges of today's public spaces.

Shown on the following pages are just some of the hundreds of options. To see more, visit www.forms-surfaces.com.

3 | FORMS+ SURFACES

ViviGraphix Graphica glass, Reflect configuration, Cairo pattern interlayer in White, Pearlex finish | VIviGraphix Elements glass, Reflect configuration, Sage pattern interlayer, Standard finish | Stainless Steel, Sandstone finish, Denver Impression pattern

FORMS+SURFACES | 4

Fused Graphite, Seastone finish, Reeds Eco-Etch pattern | Bonded Aluminum, Dark Patina, Talus pattern | Bonded Quartz, White, Grass pattern

5 | FORMS+ SURFACES

FORMS+SURFACES | 6

LEVELe Wall Cladding System: insets in ViviGraphix Spectra glass, custom pattern interlayer, Standard finish. Nationwide Children's Hospital - Research Building III, Columbus, Ohio.

vividglass Reflecting 15 years of product innovation and the ongoing development of sophisticated in-house technologies, our specialty architectural glass offers unrivaled creative freedom. The four families within this group are broadly defined by their visual characteristics: ViviChrome emphasizes solid color; ViviGraphix adds a diversity of graphic elements; ViviStone unites the beauty of stone with the convenience of glass; and ViviForm lends a dimensional aspect.

7 | FORMS+ SURFACES

FORMS+SURFACES | 8

Partition walls in ViviGraphix Graphica glass, custom pattern interlayer, Standard finish. University Health System - University Hospital, San Antonio, Texas.

About VividGlass Our three laminated glass families – ViviChrome, ViviGraphix and ViviStone – are highly configurable and allow you to combine different visual elements to achieve the end results you desire. Whether drawing on our standard options or incorporating your own custom variations, our glass gives you the flexibility you need to transform indoor and outdoor settings of all kinds.

While details for each family are described on the following pages, it will help to understand some of the basic parameters that will inform your glass specification: Configurations, Interlayers, Finishes and LumiLevels.

Configuration refers to the amount of light transmitted— or not—through the glass. To a large extent, the glass application will determine which configuration to use.

LEVELe Wall Cladding System with ViviChrome Chromis glass, Mirror Mist color interlayer, Opalex finish. Herb Chambers, Boston, Massachusetts.

View is a single-sided or double-sided configuration with interlayer(s) laminated between two transparent lites of glass.

• Double-sided View is for use when the glass will be seen from both sides; it is ideal for doors, partitions, and other applications where semi-privacy is desired • Single-sided View can be used in backlit configurations.

Reflect is a single-sided configuration with interlayer(s) laminated between a transparent lite of glass and a reflective glass backer. Reflect is intended for one-sided applications where the glass will be used against another surface—for example, on walls, columns or in elevator interiors.

LightPlane Panels with ViviGraphix Spectra glass, custom graphic interlayer, Pearlex finish. Rosetta Resources, Houston, Texas.

Interlayers bring the visual excitement to our laminated glass. Choose from the standard colors, patterns and photography outlined on the following pages.

Or personalize a look with custom colors, graphics or project-specific artwork. The options and design possibilities are virtually endless.

Finishes define the surface appearance of all of our laminated glass; learn more and see our three standard options on page 60.

LumiLevels indicate the light diffusion level of View glass; learn more and see all six standard options on page 61.

Backlit wall in ViviStone Abalone Onyx glass, custom interlayer, Standard finish.

Royal Sonesta, Houston, Texas.

9 | FORMS+ SURFACES

FORMS+SURFACES | 10

ViviChrome Chromis glass, Reflect configuration, Taupe color interlayer, Opalex finish.

ViviChrome Chromis Cava, Reflect

Ice Grey, Reflect

Cava, View

Ice Grey, View

Mirror Mist, Reflect (available in Reflect only)

Bringing solid colors to life, ViviChrome Chromis invites you to choose from the standard interlayer colors shown here, or let us match your Pantone, Benjamin Moore or Sherwin Williams color specification. Chromis is available in View and Reflect configurations, all LumiLevel options, and in Pearlex, Opalex and Standard finishes.

11 | FORMS+ SURFACES

ViviChrome chromis continued Persimmon, Reflect

Plum, Reflect

Seaglass, Reflect

Persimmon, View

Plum, View

Seaglass, View

FORMS+SURFACES | 12

Slate Blue, Reflect

Taupe, Reflect

White, Reflect

Slate Blue, View

Taupe, View

White, View

13 | FORMS+ SURFACES

Vivichrome Chromis applications

Partition wall in ViviChrome Chromis glass, custom color interlayer, Standard finish. M. Moser Associates, New York, New York. | LEVELe-103 Elevator Interior with customized panel layout: insets in ViviChrome Chromis glass, White color interlayer, Opalex finish; Bonded Aluminum, Dark Patina, Charleston pattern; and Stainless Steel, Seastone finish. 1600 Market Street, Philadelphia, Pennsylvania.

FORMS+SURFACES | 14

LEVELe-105 Elevator Interior and LEVELe Wall Cladding System: insets in ViviChrome Chromis glass, custom color interlayer, Opalex finish; and Fused Graphite, Sandstone finish. Mission City Corporate Center, San Diego, California. | LEVELe Wall Cladding System: insets in ViviChrome Chromis glass, custom color interlayer, Opalex finish. Baylor College of Medicine Medical Center, Houston, Texas.

15 | FORMS+ SURFACES

FORMS+SURFACES | 16

ViviChrome Scribe glass, grid pattern interlayer in White, Standard finish.

ViviChrome scribe White

Ultra White

Blackboard

White, Magnetic

Ultra White, Magnetic

Blackboard, Magnetic

ViviChrome Scribe offers spectacular performance as a writing board or creative wall; it can be used with dry or wet erase markers and/or magnets. Scribe can be specified in the standard colors shown here, or in any Pantone, Benjamin Moore or Sherwin Williams color. Custom interlayer graphics are also an option. Scribe is available in opaque single-sided and double-sided configurations. Finishes include Pearlex and Standard.

17 | FORMS+ SURFACES

ViviChrome SCRIBE ACCESSORIES

0.125" (3.175 mm)

Cylinder Magnet .4375" d x .375" h

Cube Magnet .4375" x .4375" x .4375"

3.08" (78.1 mm)

Marker trays are designed to integrate seamlessly with standard configurations of ViviChrome Scribe glass up to 0.4 inches (10 mm) thick. The marker trays can be used with our slim profile mounting cleat (see next page).

FORMS+SURFACES | 18

Nickel-plated Rare Earth magnets with the strength of N42 will hold a maximum of 9 sheets of paper.

clamp Profile configuration one 0.28" (7.1 mm)

0.53 in (13.4 mm) - 0.63 in (16.0 mm)* 0.25 in (6.35 mm)

0.42" (10.7 mm)

*Dimension range indicates the variance in glass thickness for singled-sided Scribe glass based on magnetic and color configuration chosen.

ViviChrome Scribe Glass

Structural Glazing Tape

0.86" (21.8 mm)

Mounting Cleat

1.0" (25.4 mm)

clamp Profile configuration two 0.45" (11.5 mm)

1.03" (26.2 mm)

0.625" (15.9 mm)

1.21" (30.7mm)

Mounting clamps are constructed of solid stainless steel with a Satin finish, and a Neoprene cushion lines the inside surfaces of each clamp. The front of each clamp is visible from the front of the glass. Two different adjustable clamp sizes accommodate varying glass thicknesses. Configuration one accommodates total glass thicknesses ranging from 0.281" to 0.421". Configuration two accommodates total glass thicknesses ranging from 0.451" to 0.625".

Slim profile mounting cleat is extruded aluminum and attaches to the back of the glass and wall. There is no visible profile from the front of the glass.

19 | FORMS+ SURFACES

vivichrome scribe applications

LEVELe Wall Cladding System: insets in ViviChrome Scribe glass, White color interlayer, Pearlex finish. Florida International University - Ryder School of Business, Media Labs, Miami, Florida. | Partition walls in ViviChrome Scribe glass, White color Interlayer, Standard finish. Ammirati, New York, New York.

FORMS+SURFACES | 20

LEVELe Wall Cladding System: insets in ViviChrome Scribe glass, White color interlayer, Standard finish; Fused Graphite, Seastone finish. Private location. | ViviChrome Scribe glass, White color interlayer, Standard finish. Northwestern University, Evanston, Illinois.

21 | FORMS+ SURFACES

FORMS+SURFACES | 22

ViviGraphix Elements glass, Reflect configuration, Sage pattern interlayer, Standard finish.

ViviGraphix Elements Arctic, Reflect

Black Fig, Reflect

Hale, Reflect (available in Reflect only)

Arctic, View

Black Fig, View

Highlight, Reflect (available in Reflect only)

Capturing the rhythms of nature in glass, ViviGraphix Elements subtly brings the outdoors in with a series of patterns sourced from wood, stone and other natural themes.

Incorporating continuous tone color imagery, Elements patterns are generally available in both View and Reflect configurations. Finish options include Pearlex and Standard.

23 | FORMS+ SURFACES

vivigraphix elements continued Timber, Reflect

Tali, Reflect

Chevron, Reflect

Timber, View

Tali, View

Chevron, View

FORMS+SURFACES | 24

Strata, Reflect

Sage, Reflect

Acero, Reflect

Strata, View

Sage, View

Acero, View

25 | FORMS+ SURFACES

Yucca, Reflect

Yucca Blue, Reflect

Yucca Smoke, Reflect

Yucca, View

Yucca Blue, View

Yucca Smoke, View

FORMS+SURFACES | 26

ViviGraphix Elements glass, Reflect configuration, Arctic pattern interlayer, Standard finish.

vivigraphix elements continued

27 | FORMS+ SURFACES

ViviGraphix Elements Applications

LEVELe-106 Elevator Interior: insets in Stainless Steel, Seastone finish, and ViviChrome Chromis glass, Taupe color interlayer, Pearlex finish; LightPlane Panels with ViviGraphix Elements glass, Chevron pattern interlayer, Pearlex finish. Representative location. | ViviGraphix Elements glass, View configuration, Black Fig pattern interlayer, Standard finish. | LEVELe-107 Elevator Interior: insets in Wenge wood veneer, and Stainless Steel, Linen finish; LightPlane Panels with ViviGraphix Elements glass, Yucca pattern interlayer, Pearlex finish. Representative location.

FORMS+SURFACES | 28

ViviGraphix Elements glass, Reflect configuration, Strata pattern interlayer, Pearlex finish. | LEVELe-103 Elevator Interior: insets in Fused Graphite, Seastone finish; and ViviGraphix Elements glass, Acero pattern interlayer, Standard finish. Representative location.

29 | FORMS+ SURFACES

FORMS+SURFACES | 30

ViviGraphix Graphica glass, Reflect configuration, Centene pattern interlayer, Standard finish.

ViviGraphix Graphica Colors Cairo, White, Reflect

Cairo, Taupe, Reflect

Cairo, Slate Blue, Reflect

Cairo, White, View

Cairo, Taupe, View

Cairo, Slate Blue, View

ViviGraphix Graphica features color graphic patterns, in single or multiple interlayers. Pattern options include the designs shown here or virtually any custom graphic. Colors can be our standard Chromis colors (three examples above; see more on pages 11-13) or any Pantone, Benjamin Moore, or Sherwin Williams color. Graphica is available in View and Reflect configurations, Pearlex and Standard finishes, and all LumiLevel options.

31 | FORMS+ SURFACES

ViviGraphix Graphica Patterns Centene, Reflect

Current, Reflect

Dot Medium, Reflect

Centene, View

Current, View

Dot Medium, View

FORMS+SURFACES | 32

Drift, Reflect

Frost, Reflect

Glacier, Reflect

Drift, View

Frost, View

Glacier, View

33 | FORMS+ SURFACES

Seagrass, Reflect

Silkworm, Reflect

Vertical 116, Reflect

Seagrass, View

Silkworm, View

Vertical 116, View

FORMS+SURFACES | 34

ViviGraphix Graphica glass, Reflect configuration, Cairo pattern interlayer in White, Standard finish.

ViviGraphiX grAphica Patterns continued

35 | FORMS+SURFACES

ViviGraphix Graphica Applications

Kiosk roof in ViviGraphix Graphica glass, Silkworm pattern interlayer, Standard finish. Lloyd Center Tower, Portland, Oregon. | LEVELe-105 Elevator Interior: insets in Stainless Steel, Sandstone finish; LightPlane Panels in VIviGraphix Graphica glass, Cairo pattern interlayer, Standard finish. Private location. | Silhouette Railing with infill in ViviGraphix Graphica glass, Centene pattern interlayer, Standard finish. 821 5th Avenue South, Naples, Florida.

FORMS+SURFACES | 36

LEVLEe-102 Elevator Interior with customized panel layout: insets in ViviGraphix Graphica glass, Cairo pattern interlayer; and American Cherry with Dark Mahogany Stain wood veneer. Sallie Mae, Newark, Delaware. | Wall panels and doors in ViviGraphix Graphica glass, custom pattern interlayer, Standard finish. Citibank's Innovation Lab, New York, New York.

37 | FORMS+ SURFACES

FORMS+SURFACES | 38

Wall in ViviGraphix Gradiance glass, View configuration, Scatter pattern interlayer in White, Standard finish. Florida International University - Ryder School of Business, Media Labs, Miami, Florida.

ViviGraphix Gradiance patterns Switchgrass, View

6" x 10" section shown

detail

Full Panel layout (60" x 120")

ViviGraphix Gradiance patterns can fade from opaque to clear in numerous ways. Ideal for any application where semi-privacy is desired, the rate and degree of fade can be tailored to meet individual project needs. Gradiance is available with one or more color graphic interlayers in a double-sided View configuration. Patterns include the standard designs shown here, or virtually any custom graphic. Patterns can be specified in White (shown) or in any Pantone, Benjamin Moore, or Sherwin Williams color. Finishes include Pearlex and Standard, and all LumiLevel options are available 39 | FORMS+ SURFACES

ViviGraphiX gradiance Patterns continued Montane, View

6" x 10" section shown

detail

FORMS+SURFACES | 40

1:1 ETAIL D

Full Panel layout (60" x 120") PANEL VARIATIONS (L-R: #1, 2, 3)

Dot Mini Fade, View

6" x 10" section shown

detail

Full Panel layout (60" x 120")

41 | FORMS+ SURFACES

ViviGraphiX gradiance Patterns continued Scatter, View

6" x 10" section shown

detail

FORMS+SURFACES | 42

Full Panel layout (60" x 120")

Vapor, View

6" x 10" section shown

detail

Full Panel layout (60" x 120")

43 | FORMS+ SURFACES

ViviGraphix Gradiance Applications

Partition wall in ViviGraphix Gradiance glass, Scatter pattern interlayer, Standard finish. Florida International University - Ryder School of Business, Media Labs, Miami, Florida. | Partition wall in ViviGraphix Gradiance glass, Switchgrass pattern interlayer, Pearlex finish. Kaiser Permanente, Carmel Valley Medical Offices, San Diego, California.

FORMS+SURFACES | 44

Doors in ViviGraphix Gradiance glass, Scatter pattern interlayer, Standard finish. The Elinor Bunin Munroe Film Center, New York, New York. | Railing infill in ViviGraphix Gradiance glass, Scatter pattern interlayer, Standard finish. HSBC Bank, New York, New York.

45 | FORMS+ SURFACES

FORMS+SURFACES | 46

LightPlane panels with ViviGraphix Spectra glass, Zoom Sacramento Mountains graphic interlayer, Standard finish. Representative location.

ViviGraphix Spectra Zoom images Zoom Rice Field, Reflect

Zoom Woven Grass, Reflect

Zoom Rice Field, View

Zoom Woven Grass, View

ViviGraphix Spectra interlayers incorporate photographs, digital files, and other continuous tone imagery. Spectra images fall into two categories: Zoom Images and Custom Artwork.

Zoom Images are an ideal solution when you want to incorporate photographic imagery into your design, but don’t have, or can’t use, your own photography. With Zoom, you can select from our growing library of large-scale, super-high-resolution photos created using sophisticated gigapixel image capturing equipment. Accessible through the Zoom Digital Darkroom (see page 148), Zoom images range from sweeping panoramic vistas to intriguing close-ups of the world around us.

47 | FORMS+ SURFACES

ViviGraphix spectra Zoom Image Applications

LightPlane Panel with ViviGraphix Spectra glass, Zoom Garnet Schist Crossed Polarized graphic interlayer, Standard finish. Representative location. | Reception desk with LightPlane Panels in ViviGraphix Spectra glass, Zoom Adiauntum Fern graphic interlayer, Standard finish. Representative location.

FORMS+SURFACES | 48

Wall panels in ViviGraphix Spectra glass, Zoom Norite graphic interlayer, Standard finish; and Bonded Quartz, White, Carbon pattern. Representative location. | LEVELe-106 Elevator Interior: insets in ViviGraphix Spectra glass, Zoom Rice Field graphic interlayer, Standard finish; Stainless Steel, Seastone finish; and ViviChrome Chromis glass, White color interlayer, Opalex finish. Representative location.

49 | FORMS+ SURFACES

FORMS+SURFACES | 50

ViviGraphix Spectra glass, custom graphic interlayer, Standard finish. University Health System - University Hospital, San Antonio, Texas.

ViviGraphix Spectra Custom Artwork Custom Photography

Custom Digital Art

Custom Logo Art

Custom Digital Art

Custom artwork is a great way to go if you have the imagery you want to use, and the file is large enough to fit your application (supplied imagery must be a minimum of 300 dpi at scale). Photographs, digital files, and other continuous tone color imagery that ties to a project’s design theme, features logos or branding graphics, or displays wayfinding elements are just some of the ways our customers have incorporated their own artwork into Spectra glass.

Regardless of interlayer imagery, all Spectra glass is available in View and Reflect configurations, Pearlex and Standard finishes, and all LumiLevel options.

51 | FORMS+ SURFACES

ViviGraphix spectra Custom Artwork Applications

Wall in ViviGraphix Spectra glass, custom graphic interlayer, Pearlex finish. University Health System - Robert B. Green Campus, San Antonio, Texas. | LightPlane Panels with ViviGraphix Spectra glass, custom graphic interlayer, Pearlex finish.

Rosetta Resources, Houston, Texas.

FORMS+SURFACES | 52

LEVELe Wall Cladding System: insets in VivGraphix Spectra glass, custom graphic interlayer, Standard finish. Nationwide Children's Hospital - Research Building III, Columbus, Ohio. | LightPlane Panels with ViviGraphix Spectra glass, custom graphic interlayer, Standard finish. The Beach Club Athletics, Summerland, California.

53 | FORMS+ SURFACES

FORMS+SURFACES | 54

ViviStone Opal Onyx glass, Reflect configuration, Pearlex finish.

ViviSTONE Abalone Onyx, Reflect

Cream Onyx, Reflect

Honey Onyx, Reflect

Abalone Onyx, View

Cream Onyx, View

Honey Onyx, View

Uniting the beauty of stone with the convenience of glass, ViviStone is nearly indistinguishable from real stone. The graphic interlayers of this revolutionary product are ultra-sharp, full-scale representations of stones from around the world. Each stone family consists of a library of slabs that offer beautiful variations in color and veining. Individual slabs can be used in their entirety. Or, within a slab, you can define sections to size, mirror and repeat to create highly original layouts – configuration is easy with our online Virtual Quarry (see page 152). ViviStone is available in View and Reflect configurations, and Pearlex and Standard finishes.

55 | FORMS+ SURFACES

ViVistone continued Opal Onyx, Reflect

Pearl Onyx, Reflect

White Onyx, Reflect

Opal Onyx, View

Pearl Onyx, View

White Onyx, View

FORMS+SURFACES | 56

ViviStone Slabs

slab a-1

slab a-2

Slab A-3

slab A-4

Because ViviStone slabs are glass, not real stone, they afford size, weight, and design flexibility simply not found in nature. Slabs can be used in their entirety, or smaller sections can be defined, mirrored, rotated, and repeated to create highly original layouts. Each ViviStone family consists of a library of slabs that range from 40" to 65" (1m to 1.6m) wide x 80" to 117" (2m to 2.9m) high, depending on family selected. Library size varies per stone family, and individual slabs within each library have their own unique pattern. To illustrate the slab concept: The Opal Onyx library is comprised of the four slabs shown above at their full size of 48" (1219mm) x 102" (2591mm).

To see the slab libraries for all ViviStone families, go to www.forms-surfaces.com/vivistone.

57 | FORMS+ SURFACES

ViviSTONE applications

Backlit wall in ViviStone Abalone Onyx glass with custom interlayer, Standard finish. Royal Sonesta, Houston, Texas. | LEVELe-106 Elevator Interior: insets in ViviChrome Chromis glass, Slate Blue interlayer, Pearlex finish; and Stainless Steel, Seastone finish; LightPlane Panels in ViviStone Pearl Onyx glass, Pearlex finish. 1100 Louisiana Street, Houston, Texas.

FORMS+SURFACES | 58

LightPlane Panels in ViviStone Abalone Onyx, Pearlex finish. Woolworth Building, Eugene, Oregon. | LEVELe Wall Cladding System: LightPlane Panels with ViviStone Abalone Onyx glass, Pearlex finish. Private location, Houston, Texas.

59 | FORMS+ SURFACES

ViviDGlass Finishes Opalex

Pearlex

Standard

Opalex has a very finely etched surface that creates a moderate amount of diffusion, is non-reflective, and fingerprint-resistant.

Pearlex is a lightly textured, non-reflective, non-distortive surface that creates a minimal amount of diffusion and is fingerprint-resistant.

Standard finish is reflective and non-distortive.

Finishes define the surface appearance of each VividGlass selection. The different options vary in levels of light diffusion, reflectivity, glare and optical distortion, and provide unique solutions for the needs of each individual project. Specific finish availability for each VividGlass family is referenced on the preceding pages.

FORMS+SURFACES | 60

Lumilevel Options LumiLevel #1

LumiLevel #2

LumiLevel #3

LumiLevel #4

LumiLevel #5

LumiLevel #6

LumiLevel is a measurement of the translucency of View glass. It can also be used to diffuse light from the reflective glass backer in Reflect glass. There are six LumiLevel options, and only one LumiLevel option can be used per configuration.

61 | FORMS+ SURFACES

FORMS+SURFACES | 62

ViviForm Impression, Alta

Impression, Champagne

Impression, Epsilon

VivForm Impression glass, Kalahari pattern.

Impression, Kalahari

ViviForm Impression glass permits diffused light transmission while providing appropriate privacy. In addition to the standard patterns shown here, custom designs are also available.

Impression glass is ideal for two-sided applications where the transference of the dimensional pattern across both sides of the glass can be appreciated from all perspectives.

63 | FORMS+ SURFACES

Viviform Applications

Windows in ViviForm Impression glass, Kalahari pattern. Duluth International Airport, Duluth, Minnesota. | Door insets, sidelites and transom in ViviForm Impression glass, Champagne pattern. Las Olas City Centre, Fort Lauderdale, Florida.

FORMS+SURFACES | 64

Silhouette Railing System with infill in ViviForm Impression glass, Epsilon pattern. Washington University, School of Medicine, St. Louis, Missouri. | Windows in ViviForm Impression glass, Kalahari pattern. Duluth International Airport, Duluth, Minnesota.

65 | FORMS+ SURFACES

FORMS+SURFACES | 66

LEVELe Wall Cladding System: insets in Stainless Steel, Linen finish. The Center for Care and Discovery, University of Chicago Medicine, Chicago, Illinois.

stainless steel & fused metal Unmatched in quality and beauty, Forms+Surfaces is the world's premier resource for architectural stainless steel. Our high-durability finishes and a wide range of distinctive patterns offer limitless design and performance options for public spaces of all kinds.

Fused Metal, our exclusive line of colored stainless steel, is created using vapor deposition technology to fuse titanium alloys at the molecular level to stainless steel substrates. Fused Metal provides the durability and maintenance ease of stainless steel in a rich range of colors.

67 | FORMS+ SURFACES

FORMS+SURFACES | 68

Stainless Steel, Sandstone finish, Denver Impression pattern.

stAinless steel Finishes Stainless Steel, Sandstone

Stainless Steel, Seastone

Stainless Steel, Linen

Stainless Steel, Marquisette

Stainless Steel, Diamond

Stainless Steel, Mist

Stainless Steel is available in a variety of distinctive finishes including standard and High-Durability options. High-Durability finishes – designated by the “HD” logo above – are manufactured in a process that creates a work-hardened surface with enhanced resistance to abrasion and wear.

69 | FORMS+ SURFACES

stAinless steel Finishes continued CeramiLoc treatment CeramiLoc is an invisible, protective treatment that significantly increases the fingerprint resistance and maintenance ease of stainless steel. Utilizing patented technology that molecularly bonds nano-silica particles to the surface of stainless steel, CeramiLoc combines ceramic durability with an unparalleled ability to lock out fingerprints and dirt.

The CeramiLoc treatment works with our finishes and patterns without altering the surface appearance.

Benefits include: easy to Clean: The CeramiLoc treatment creates a surface that simultaneously resists fingerprints and is easy to clean. Water spots, grease marks and more can be quickly wiped away. It also creates an “antigraffiti” surface – even permanent marker is easily removed with a clean microfiber towel and water.

Stainless Steel, Satin

Durable: CeramicLoc-treated stainless steel is abrasion- and scratch-resistant. The treatment offers the permanence of a molecular bond, is UV stable, and won’t degrade or discolor over time.

FORMS+SURFACES | 70

workable: Unlike applied finishes or coatings, which can be damaged when cut or formed, CeramiLoctreated stainless steel can be sheared, cut, formed, laser cut and processed in numerous ways.

Versatile: CeramiLoc-treated stainless steel can be used in many of our Systems products; it can also be specified with sheet goods. environmentally Sound: The CeramiLoc treatment is a no-VOC, water-based process. Because CeramiLoc surfaces are so easily maintained, cleaning solutions and maintenance are kept to a minimum.

Stainless Steel, Satin finish, Stacks Eco-Etch pattern.

Stainless Steel, Mirror

71 | FORMS+ SURFACES

FORMS+SURFACES | 72

Fused White Gold, Seastone finish, Kalahari Impression pattern.

Fused metAl colors & Finishes Fused White Gold, Sandstone

Fused White Gold, Seastone

Fused White Gold, Linen

Fused White Gold, Diamond

Fused White Gold, Mirror

Fused White Gold, Satin

Fused Metal is available in a variety of distinctive finishes, including standard and High-Durability options. High-Durability finishes – designated by the "HD" logo above and on the following pages – are manufactured in a process that creates a work-hardened surface with enhanced resistance to abrasion and wear.

73 | FORMS+ SURFACES

Fused metAl colors & Finishes continued Fused Nickel Silver, Sandstone

Fused Nickel Silver, Seastone

Fused Nickel Silver, Linen

Fused Nickel Silver, Diamond

Fused Nickel Silver, Mirror

Fused Nickel Silver, Satin

FORMS+SURFACES | 74

Fused Graphite, Sandstone

Fused Graphite, Seastone

Fused Graphite, Linen

Fused Graphite, Diamond

Fused Graphite, Mirror

Fused Graphite, Satin

75 | FORMS+ SURFACES

Fused metAl colors & Finishes continued Fused Bronze, Sandstone

Fused Bronze, Seastone

Fused Bronze, Linen

Fused Bronze, Diamond

Fused Bronze, Mirror

Fused Bronze, Satin

FORMS+SURFACES | 76

Fused Nickel Bronze, Sandstone

Fused Nickel Bronze, Seastone

Fused Nickel Bronze, Linen

Fused Nickel Bronze, Diamond

Fused Nickel Bronze, Mirror

Fused Nickel Bronze, Satin

77 | FORMS+ SURFACES

FORMS+SURFACES | 78

IMPRESSION Patterns Champagne (shown in Stainless Steel, Seastone)

profile scale approximately 1:1

Sheet Thickness: .032" (0.8mm) Sheet Sizes: 48" x 96" (1219mm x 2438mm), 48" x 120" (1219mm x 3048mm) Pattern Height: .147" (3.7mm)

< 24" x 24" square represented

Chardonnay (shown in Fused Bronze, Seastone)

Stainless Steel, Satin finish, Dune Impression pattern.

profile scale approximately 1:1

Sheet Thickness: .032" (0.8mm) Sheet Sizes: 48" x 96" (1219mm x 2438mm), 48" x 120" (1219mm x 3048mm) Pattern Height: .147" (3.7mm)

< 24" x 24" square represented

High-relief Impression patterns add visual interest, enhance durability and expand the customization potential of stainless steel and Fused Metal surfaces.

79 | FORMS+ SURFACES

Impression patterns continued Dallas (shown in Fused White Gold, Seastone)

profile scale approximately 1:1

Sheet Thickness: .032" (0.8mm) Sheet Sizes: 48" x 96" (1219mm x 2438mm), 48" x 120" (1219mm x 3048mm) Pattern Height: .0625" (1.6mm)

< 24" x 24" square represented

NOTE: Pattern is available in vertical or horizontal orientation

Denver (shown in Fused Nickel Silver, Seastone)

profile scale approximately 1:1

Sheet Thickness: .032" (0.8mm) Sheet Sizes: 48" x 96" (1219mm x 2438mm), 48" x 120" (1219mm x 3048mm) Pattern Height: .053" (1.3mm)

< 24" x 24" square represented

FORMS+SURFACES | 80

NOTE: Pattern is available in vertical or horizontal orientation

Dune (shown in Stainless Steel, Satin)

profile scale approximately 1:1

Sheet Thickness: .032" (0.8mm) Sheet Sizes: 48" x 96" (1219mm x 2438mm), 48" x 120" (1219mm x 3048mm) Pattern Height: .087" (2.2mm)

< 24" x 24" square represented

Kalahari (shown in Fused Nickel Bronze, Seastone)

profile scale approximately 1:1

Sheet Thickness: .032" (0.8mm) Sheet Sizes: 48" x 96" (1219mm x 2438mm), 48" x 120" (1219mm x 3048mm) Pattern Height: .106" (2.7mm)

< 24" x 24" square represented

81 | FORMS+ SURFACES

FORMS+SURFACES | 82

Eco-etch Patterns City Lights (shown in Fused White Gold, Mirror)

27" x 8" section represented

Stainless Steel, Satin finish, Sequence Eco-Etch pattern.

Current (shown in Fused Nickel Silver, Mirror)

27" x 8" section represented

Eco-Etch patterns are beautiful etched designs that are applied using an advanced photolithographic bead-blasting system instead of acids or other harmful chemicals. The largest physical etching system in North America, our equipment can handle materials up to two meters wide by six meters long. Please note that the standard patterns shown here are only a starting point. The flexibility and speed of our Eco-Etch system allow for a wealth of design options with artwork supplied by the specifier or developed by Forms+Surfaces.

83 | FORMS+ SURFACES

Eco-Etch patterns continued Dash (shown in Fused White Gold, Mirror)

27" x 8" section represented

Flicker (shown in Fused Graphite, Satin)

27" x 8" section represented

FORMS+SURFACES | 84

Glacier (shown in Stainless Steel, Satin)

27" x 8" section represented

Mica (shown in Fused Nickel Silver, Satin)

27" x 8" section represented

85 | FORMS+ SURFACES

Eco-Etch patterns continued Reeds (shown in Fused Nickel Silver, Seastone)

27" x 8" section represented

Seagrass (shown in Stainless Steel, Satin)

27" x 8" section represented

FORMS+SURFACES | 86

Sequence (shown in Fused Bronze, Satin)

27" x 8" section represented

Silkworm (shown in Fused Graphite, Seastone)

27" x 8" section represented

87 | FORMS+ SURFACES

Eco-Etch patterns continued Stacks (shown in Stainless Steel, Satin)

27" x 8" section represented

Stripe (shown in Fused Graphite, Satin)

27" x 8" section represented

FORMS+SURFACES | 88

Thatch (shown in Fused White Gold, Mirror)

27" x 8" section represented

Trace (shown in Fused Nickel Bronze, Satin)

27" x 8" section represented

89 | FORMS+ SURFACES

FORMS+SURFACES | 90

Fusion patterns Carbon (shown in Stainless Steel, Satin)

profile scale approximately 1:1

Sheet Thickness: .032" (0.8mm) Sheet Sizes: 48" x 96" (1219mm x 2438mm), 48" x 120" (1219mm x 3048mm) Pattern Height: .1" (2.3mm)

< 12" x 12" square represented

NOTE: Pattern is available in vertical or horizontal orientation

Cinch (shown in Stainless Steel, Seastone)

Stainless Steel, Seastone finish, Mesa Fusion pattern.

profile scale approximately 1:1

Sheet Thickness: .032" (0.8mm) Sheet Sizes: 48" x 96" (1219mm x 2438mm), 48" x 120" (1219mm x 3048mm) Pattern Height: .088" (2.0mm)

< 24" x 24" square represented

Fusion is a collection of surfaces by the Forms+Surfaces Design Studio. As the name implies, each design combines two or more pattern types, including Impression, Eco-Etch and Screen, to create a unique and visually intriguing surface.

91 | FORMS+ SURFACES

Fusion patterns continued Mesa (shown in Stainless Steel, Seastone)

profile scale approximately 1:1

Sheet Thickness: .032" (0.8mm) Sheet Sizes: 48" x 96" (1219mm x 2438mm), 48" x 120" (1219mm x 3048mm) Pattern Height: .188" (4.8mm)

< 24" x 24" square represented

Moraine (shown in Stainless Steel, Seastone)

Sheet Thickness: .032" (0.8mm) Sheet Sizes: 48" x 96" (1219mm x 2438mm), 48" x 120" (1219mm x 3048mm) Pattern Height: .053" (1.3mm)

< 12" x 12" square represented

FORMS+SURFACES | 92

NOTE: Pattern is available in vertical or horizontal orientation

Stainless Steel, Satin finish, Cinch Fusion pattern.

profile scale approximately 1:1

93 | FORMS+ SURFACES

FORMS+SURFACES | 94

SCREEN patterns Circa (shown in Stainless Steel, Linen) 1.6"

Thickness: Sheet Size: Impression: Open Area:

2"

.060" (1.5mm) 44.8" x 94.4" (1138mm x 2398mm) .03" (.76mm) 27%

< 24" x 24" square represented

Kente (shown in Stainless Steel, Seastone) 3"

Stainless Steel, Sandstone finish, Valencia Screen pattern.

.3"

Thickness: .032" (0.8mm), .060" (1.5mm) Sheet Size: 48" x 96" (1219mm x 2438mm) Open Area: 54% .378"

< 24" x 24" square represented

Taking inspiration from textiles, nature, and traditional cultural motifs, our Screen patterns provide countless ways to divide space, alter light, provide privacy, and shape the built environment. Suitable for interior or exterior use, Screen patterns may be specified in stainless steel or Fused Metal and can be incorporated into wall panels, partitions, and other architectural features.

95 | FORMS+ SURFACES

Screen patterns continued Lotus (shown in Stainless Steel, Sandstone) 2.21"

Thickness: .032" (0.8mm), .060" (1.5mm) Sheet Size: 48" x 96" (1219mm x 2438mm) Open Area: 52%

2.7"

< 24" x 24" square represented

Scape (shown in Stainless Steel, Seastone) .25"

.188"

Thickness: .032" (0.8mm), .060" (1.5mm) Sheet Size: 48" x 96" (1219mm x 2438mm) Open Area: 32% .125" < 24" x 24" square represented

FORMS+SURFACES | 96

Valencia (shown in Stainless Steel, Sandstone) 1.85"

1.8"

Thickness: Sheet Size: Impression: Open Area:

.060" (1.5mm) 44.4" x 92.8" (1128mm x 2357mm) .03" (.76mm) 32%

< 24" x 24" square represented

97 | FORMS+ SURFACES

Stainless steel & fused metal applications

LEVELe Wall Cladding System: insets in Stainless Steel, Mist finish. Silvercar - DFW, Dallas, Texas. | LEVELe Wall Cladding System: insets in Fused White Gold, Seastone finish, Kalahari Impression pattern. Fountain Place, Dallas, Texas.

FORMS+SURFACES | 98

Pedestrian bridge in Stainless Steel, Sandstone finish, custom perforation and Eco-Etch patterns. Houston Ballet Center for Dance, Houston, Texas. | LEVELe Wall Cladding System insets and Elevator Doors in Fused Nickel Silver, Sandstone finish.

The Regent, Washington, DC.

99 | FORMS+ SURFACES

Stainless steel & fused metal applications continued

LEVELe Wall Cladding System: insets in Stainless Steel, Linen finish. The Center for Care and Discovery, University of Chicago Medicine, Chicago, Illinois. | LEVELe Wall Cladding System: insets in Stainless Steel, Sandstone finish, Dallas Impression pattern; and custom painted aluminum. Phoenix Sky Train, Phoenix Sky Harbor International Airport, Phoenix, Arizona.

FORMS+SURFACES | 100

Elevator doors in Fused Bronze, Mirror finish, ECO205H Eco-Etch pattern. The Stanford Court Renaissance Hotel, San Francisco, California. | LEVELe Wall Cladding System: insets in ViviChrome Chromis glass, White color interlayer, Standard finish. Column in Stainless Steel, Seastone finish. Nationwide Children's Hospital - Research Building III, Columbus, Ohio. | LEVELe-101 Elevator Interior: insets in Bonded Bronze, Natural Patina, Grass pattern; Stainless Steel, Linen finish; and ViviChrome Chromis glass, custom color interlayer, Pearlex finish. Renaissance Towers, San Diego, California.

101 | FORMS+ SURFACES

FORMS+SURFACES | 102

Wall panels in Bonded Aluminum, Dark Patina, Grass pattern. JPMorgan Chase Tower, Houston, Texas.

bonded metal Bonded Metal has achieved a place of distinction among high-performance surfacing materials. Providing a striking breadth of design possibilities, Bonded Metal is the product of a unique technology that casts metal granules in a tough, FRP matrix. Advanced mold-making techniques assure perfect reproduction of every fine detail in the original patterned surface. The result is lightweight but extremely durable castings with the character and appearance of solid metal. Bonded Metal can be specified for walls, doors, elevators, accents or any application where visual richness and exceptional resistance to wear are requirements. Field-proven for more than 40 years, Bonded Metal is exclusive to Forms+Surfaces.

103 | FORMS+ SURFACES

FORMS+SURFACES | 104

Bonded Aluminum, Dark Patina, Talus pattern.

Bonded metal Colors & PatINAS Bonded Aluminum, Natural Patina

Bonded Bronze, Natural Patina

Bonded Nickel Silver, Natural Patina

Bonded Aluminum, Dark Patina

Bonded Bronze, Dark Patina

Bonded Nickel Silver, Dark Patina

Bonded Metal selections are defined by three basic parameters: 1) Colors are established by the metal incorporated into the Bonded Metal matrix. 2) Patinas are a contrast-enhancing treatment applied to the Bonded Metal surface. 3) Patterns are the distinctive texture or design cast into the Bonded Metal surface. Most Bonded Metal patterns are available in the color/patina combinations shown here; refer to the following pages for specific pattern details.

105 | FORMS+ SURFACES

BONDED METAL PATTERNS Austin (shown in Bonded Aluminum, Dark Patina)

profile scale approximately 1:1

Sheet Size: Thickness: Colors: Patinas:

48" x 120" (1219mm x 3048mm) .124" (3.1mm) All colors shown on page 105 Dark & Natural

< 6" x 6" square represented

Chardonnay (shown in Bonded Nickel Silver, Natural Patina)

profile scale approximately 1:1

Sheet Size: 48" x 120" (1219mm x 3048mm) Thickness: .140" (3.6mm) Colors: All colors shown on page 105 Patina: Natural only < 24" x 24" square represented

FORMS+SURFACES | 106

NOTE: Pattern is available in horizontal orientation (Chardonnay, shown) or vertical orientation (Champagne, not shown).

Charleston (shown in Bonded Bronze, Dark Patina)

profile scale approximately 1:1

Sheet Size: Thickness: Colors: Patinas:

36" x 120" (914mm x 3048mm) .132" (3.4mm) All colors shown on page 105 Dark & Natural

< 6" x 6" square represented

Delta (shown in Bonded Aluminum, Dark Patina)

profile scale approximately 1:1

Sheet Size: Thickness: Colors: Patinas:

48" x 120" (1219mm x 3048mm) .143" (3.6mm) All colors shown on page 105 Dark & Natural

< 12" x 12" square represented

NOTE: Pattern is available in vertical or horizontal orientation

107 | FORMS+ SURFACES

BONDED METAL PATTERNS continued Grass (shown in Bonded Aluminum, Dark Patina)

profile scale approximately 1:1

Sheet Size: Thickness: Colors: Patinas:

48" x 120" (1219mm x 3048mm) .128" (3.3mm) All colors shown on page 105 Dark & Natural

< 6" x 6" square represented

Herringbone (shown in Bonded Nickel Silver, Natural Patina)

profile scale approximately 1:1

Sheet Size: Thickness: Colors: Patinas:

48" x 120" (1219mm x 3048mm) .132" (3.4mm) All colors shown on page 105 Dark & Natural

< 12" x 12" square represented

FORMS+SURFACES | 108

Kalahari (shown in Bonded Bronze, Natural Patina)

profile scale approximately 1:1

Sheet Size: 48" x 120" (1219mm x 3048mm) Thickness: .190" (4.8mm) Colors: All colors shown on page 105 Patina: Natural only < 24" x 24" square represented

NOTE: Pattern is available in vertical or horizontal orientation

Loft (shown in Bonded Aluminum, Dark Patina)

profile scale approximately 1:1

Sheet Size: Thickness: Colors: Patinas:

48" x 120" (1219mm x 3048mm) .100" (2.5mm) All colors shown on page 105 Dark & Natural

< 12" x 12" square represented

109 | FORMS+ SURFACES

BONDED METAL PATTERNS continued Mara (shown in Bonded Nickel Silver, Natural Patina)

profile scale approximately 1:1

Sheet Size: 48" x 120" (1219mm x 3048mm) Thickness: .190" (4.8mm) Colors: All colors shown on page 105 Patina: Natural only < 24" x 24" square represented

NOTE: Pattern is available in vertical or horizontal orientation

Rain (shown in Bonded Bronze, Dark Patina)

profile scale approximately 1:1

Sheet Size: Thickness: Colors: Patinas:

48" x 120" (1219mm x 3048mm) .107" (2.7mm) All colors shown on page 105 Dark & Natural

< 6" x 6" square represented

FORMS+SURFACES | 110

Sahara (shown in Bonded Aluminum, Natural Patina)

profile scale approximately 1:1

Sheet Size: 48" x 120" (1219mm x 3048mm) Thickness: .150" (3.8mm) Colors: All colors shown on page 105 Patina: Natural only < 24" x 24" square represented

Talus (shown in Bonded Aluminum, Dark Patina)

profile scale approximately 1:1

Sheet Size: Thickness: Colors: Patinas:

48" x 120" (1219mm x 3048mm) .128" (3.3mm) All colors shown on page 105 Dark & Natural

< 24" x 24" square represented

111 | FORMS+ SURFACES

BONDED METAL PATTERNS continued Terrane (shown in Bonded Nickel Silver, Natural Patina)

profile scale approximately 1:1

Sheet Size: 48" x 120" (1219mm x 3048mm) Thickness: .113" (2.9mm) Colors: All colors shown on page 105 Patinas: Natural only < 24" x 24" square represented

Trevia (shown in Bonded Bronze, Dark Patina)

profile scale approximately 1:1

Sheet Size: Thickness: Colors: Patinas:

48" x 120" (1219mm x 3048mm) .115" (2.9mm) All colors shown on page 105 Dark & Natural

< 12" x 12" square represented

FORMS+SURFACES | 112

Vancouver (shown in Bonded Nickel Silver, Dark Patina)

profile scale approximately 1:1

Sheet Size: Thickness: Colors: Patinas:

48" x 120" (1219mm x 3048mm) .132" (3.4mm) All colors shown on page 105 Dark & Natural

< 6" x 6" square represented

Waterfall (shown in Bonded Aluminum, Natural Patina)

profile scale approximately 1:1

Sheet Size: 48" x 120" (1219mm x 3048mm) Thickness: .123" (3.1mm) Colors: All colors shown on page 105 Patina: Natural only < 24" x 24" square represented

113 | FORMS+ SURFACES

FULL-SHEET BONDED METAL PATTERNS Corona (Bonded Bronze, Natural Patina)

Crete (Bonded Aluminum, Dark Patina)

Eclipse (Bonded Nickel Silver, Natural Patina)

Sheet Size: Thickness: Colors: Patinas:

Sheet Size: Thickness: Colors: Patinas:

Sheet Size: Thickness: Colors: Patinas:

36" x 120" (914mm x 3048mm) .275" (7mm) All colors shown on page 105 Dark & Natural

48" x 120" (1219 mm x 3048 mm) .34" (8.6 mm) All colors shown on page 105 Dark & Natural

48" x 120" (1219mm x 3048mm) .275" (7mm) All colors shown on page 105 Dark & Natural

The five patterns shown here are special, full-scale symmetrical patterns available with mating left and right sides. While any Bonded Metal pattern may be specified for our doors, these five patterns are designed specifically for full-sheet use on doors, wall panels or other large-scale applications where a dramatic visual effect is desired. Choosing just one side of the pattern for a single leaf door or narrower wall panel is also an option.

FORMS+SURFACES | 114

Equinox (Bonded Bronze, Dark Patina)

Solstice (Bonded Aluminum, Dark Patina)

Sheet Size: Thickness: Colors: Patinas:

Sheet Size: Thickness: Colors: Patinas:

36" x 120" (914mm x 3048mm) .110" (2.8mm) All colors shown on page 105 Dark & Natural

48" x 120" (1219mm x 3048mm) .275" (7mm) All colors shown on page 105 Dark & Natural

115 | FORMS+ SURFACES

BONDED Metal applications

Wall panels in Bonded Aluminum, Natural Patina, Herringbone pattern. 515 North State Street, Chicago, Illinois. | Wall panels, elevator surrounds and LEVELe-101 Elevator Interior: insets in Bonded Bronze, Dark Patina, custom pattern.

Residences at the InterContinental, Boston, Massachusetts.

FORMS+SURFACES | 116

Doors in Bonded Bronze, Dark Patina, Corona pattern. Private location. | LEVELe-104 Elevator Interior: insets in Bonded Nickel Silver, Natural Patina, Chardonnay pattern; Fused Nickel Silver, Sandstone finish. Gerding Theater at the Armory, Portland, Oregon.

117 | FORMS+ SURFACES

FORMS+SURFACES | 118

Wall panels in Bonded Quartz, White, Mara pattern. KI Showroom, Merchandise Mart, Chicago, Illinois.

bonded quartz Bonded Quartz is a high-performance surfacing solution ideal for todayâ&#x20AC;&#x2122;s interior spaces. Unlike anything else on the market, Bonded Quartz incorporates ceramic microspheres in a fiberreinforced polymer matrix. This combination yields incredibly durable, lightweight castings that have a stunning surface appearance and are easy to clean.

The standard colors for Bonded Quartz are White and Charcoal; custom colors are also an option. Bonded Quartz is ideal for use on walls, columns, elevator interiors, counter facings and other applications where visual richness is desired.

119 | FORMS+ SURFACES

FORMS+SURFACES | 120

Bonded QUARTZ Colors

Bonded Quartz, White, Grass pattern.

Bonded White

Bonded Charcoal

Bonded Quartz selections are defined by two basic parameters: 1) Colors include the two options here. Both are integral to the castings so scratches and blemishes are far less apparent than with surface-applied color finishes. 2) Patterns are the distinctive texture or design cast into the Bonded Quartz surface. Some Bonded Quartz patterns are available in both colors, some in only one color; refer to the following pages for details.

121 | FORMS+ SURFACES

Bonded Quartz patterns Carbon (shown in Bonded Charcoal)

profile scale approximately 1:1

Sheet Size: Thickness: Colors:

48" x 120" (1219mm x 3048mm) .146" (3.7mm) Bonded Charcoal & Bonded White

< 24" x 24" square represented

NOTE: Pattern is available in vertical or horizontal orientation

Crinkle (shown in Bonded White)

profile scale approximately 1:1

Sheet Size: Thickness: Colors:

48" x 120" (1219mm x 3048mm) .150" (3.8mm) Bonded Charcoal & Bonded White

< 24" x 24" square represented

FORMS+SURFACES | 122

Dune (shown in Bonded White)

profile scale approximately 1:1

Sheet Size: Thickness: Colors:

48" x 120" (1219mm x 3048mm) .140" (3.6mm) Bonded Charcoal & Bonded White

< 24" x 24" square represented

Grass (shown in Bonded Charcoal)

profile scale approximately 1:1

Sheet Size: Thickness: Colors:

48" x 120" (1219mm x 3048mm) .128" (3.3mm) Bonded Charcoal & Bonded White

< 6" x 6" square represented

123 | FORMS+ SURFACES

BONDED QUARTZ PATTERNS continued Kalahari (shown in Bonded White)

profile scale approximately 1:1

Sheet Size: Thickness: Color:

48" x 120" (1219mm x 3048mm) .190" (4.8mm) Bonded White

< 24" x 24" square represented

NOTE: Pattern is available in vertical or horizontal orientation

Loft (shown in Bonded Charcoal)

profile scale approximately 1:1

Sheet Size: Thickness: Colors:

48" x 120" (1219mm x 3048mm) .100" (2.5mm) Bonded Charcoal & Bonded White

< 12" x 12" square represented

FORMS+SURFACES | 124

Mara (shown in Bonded White)

profile scale approximately 1:1

Sheet Size: Thickness: Color:

48" x 120" (1219mm x 3048mm) .190" (4.8mm) Bonded White

< 24" x 24" square represented

NOTE: Pattern is available in vertical or horizontal orientation

Sahara (shown in Bonded White)

profile scale approximately 1:1

Sheet Size: Thickness: Color:

48" x 120" (1219mm x 3048mm) .150" (3.8mm) Bonded White

< 24" x 24" square represented

125 | FORMS+ SURFACES

BONDED QUARTZ PATTERNS continued Trevia (shown in Bonded White)

profile scale approximately 1:1

Sheet Size: Thickness: Color:

48" x 120" (1219mm x 3048mm) .115" (2.9mm) Bonded White

< 12" x 12" square represented

Waterfall (shown in Bonded White)

profile scale approximately 1:1

Sheet Size: Thickness: Color:

48" x 120" (1219mm x 3048mm) .123" (3.1mm) Bonded White

FORMS+SURFACES | 126

Bonded Quartz, Charcoal, Crinkle pattern.

< 24" x 24" square represented

127 | FORMS+ SURFACES

BONDED QUARTZ applications

LEVELe Wall Cladding System: insets in Bonded Quartz, White, Waterfall pattern. Gracie Mews Pool & Health Club, New York, New York. | LEVELe Wall Cladding System: insets in Bonded Quartz, White, Crinkle pattern. MoZaic, Minneapolis, Minnesota.

FORMS+SURFACES | 128

LEVELe-103 Elevator Interior: insets in Bonded Quartz, White, Kalahari pattern; and Stainless Steel, Seastone finish. The Mother Baby Center at Abbott Northwestern and Children's Hospitals & Clinics, Minneapolis, Minnesota. | Wall panels in Bonded Quartz, White, Mara pattern. KI Showroom, Merchandise Mart, Chicago, Illinois. | LEVELe-106 Elevator Interior: insets in Bonded Quartz, White, Carbon pattern; and Stainless Steel, Seastone finish. Private location.

129 | FORMS+ SURFACES

FORMS+SURFACES | 130

LEVELe Wall Cladding System: insets in Stainless Steel, Linen finish. Center for Care and Discovery, University of Chicago Medicine, Chicago, Illinois.

systems Architects and designers around the world rely on our Surfaces to create dramatic signature statements. However, while our Surfaces palette is vast, it is only part of our story. It's the Systems we've designed to accommodate our Surfaces that infinitely expand the possibilities. From walls and columns to elevator interiors and more, our Systems unite beauty, durability and environmental responsibility. They're engineered to invite creativity, yet satisfy real-world budgets and time lines. And, highly configurable like our Surfaces, they can be used to customize a look, carry design themes across a property, and cost-efficiently perform in any environment. Our Systems. Our Surfaces. Your vision. It adds up to a winning equation for transforming public spaces of all kinds.

131 | FORMS+ SURFACES

LEVELe WALL CLADDING SYSTEM Uniting green materials, remarkable design flexibility, and the convenience of a panelized system.

LEVELe is a highly configurable wall cladding system that accommodates a wide range of field conditions without sacrificing ease of specification, installation, maintenance, or breadth of material choices.

Aluminum-framed panels with a lightweight structural backing form the basis of the system. Panel frames incorporate LEVELe’s wall panel attachment system; panel insets draw from our full Surfaces line-up. Four panel styles provide different visual end results and support different material selections.

Standard system components—corners, bases, and self-revealing mounting channels—eliminate the need for custom solutions and make it easy to resolve typical trim and installation challenges.

The LEVELe Wall Cladding System coordinates with LEVELe Elevator Interiors, LEVELe Columns, and LightPlane Panels.

FORMS+SURFACES | 132

133 | FORMS+ SURFACES

Lightplane Panels Engineered, edge-lit LED panels allow seamless illumination of walls, columns, elevator interiors and standalone panels.

LightPlane Panels combine our cutting-edge lighting technology, our VividGlass line of specialty architectural glass, and a highly engineered framing system to create an illuminated panel unlike any other.

With a remarkably thin profile and a minimal bezel, LightPlane Panels provide uniform light output, energy efficiency, and the unparalleled performance of CreeÂŽ LEDs, delivering up to 100,000 hours of worry-free illumination. Each panel is manufactured with a size-specific algorithm to ensure the look of even, natural light, and eliminate hot spots, haloes or dark areas.

LightPlane Panels represent a complete system that can be easily configured to meet project-specific needs.

LightPlane Panels readily integrate with our LEVELe Wall Cladding System, LEVELe Elevator Interiors, and LEVELe Columns.

FORMS+SURFACES | 134

135 | FORMS+ SURFACES

Elevator Interiors Our comprehensive program meets the needs of today's public spaces and new or modernization projects everywhere.

Since introducing the CabForms® system more than ten years ago, we’ve become expert in the specific requirements of elevator interiors and the evolving challenges these spaces face. Panel and ceiling weights, energy efficiency, lighting, and air quality all have increasing importance in today’s buildings.

Our comprehensive elevator program was designed to address these issues. CabForms and LEVELe Elevator Interiors draw on our full Surfaces line-up and meet diverse aesthetic, performance, budgetary, and environmental requirements. Ideal for new or modernization projects, complete packages suit all typical cab sizes and door configurations.

LEVELe Elevator Interiors are designed to coordinate with our LEVELe Wall Cladding System, LEVELe Columns, and LightPlane Panels. CabForms Elevator Interiors incorporate many of the same materials and finishes and expand the visual possibilities.

FORMS+SURFACES | 136

137 | FORMS+ SURFACES

Elevator DOORS Materials and finishes can coordinate with the elevator interior or lobby or make a statement on their own.

Elevator doors are the perfect way to carry a design theme across a property, from elevator interior to elevator lobby and beyond. Included within this group are door skins for elevator car doors and hoistway doors in a variety of materials, finishes and patterns.

Elevator Door Skins in stainless steel and Fused Metal create a striking design statement. High-Durability finishes and patterns that draw from our Impression and Eco-Etch palettes add visual interest and help conceal the occasional surface blemish.

Bonded Metal Elevator Door Skins offer exceptional resistance to abrasion and wear. Design options include a wide range of colors, patterns and patinas.

FORMS+SURFACES | 138

139 | FORMS+ SURFACES

columns & Column Covers Engineered to accommodate real-world field conditions while offering impressive design options.

Column Covers in stainless steel and Fused Metal are a durable, versatile solution for cladding existing structural columns. Designed to suit a wide range of field conditions, they can be adapted for site-specific needs and used for round, square or irregularly shaped columns.

The LEVELe Column System aligns with the rest of the LEVELe family and pairs the benefits of a panelized system with diverse material options. It is appropriate for square and rectangular column shapes.

The system is based on a series of individual panels comprised of two configurable elements: frames and insets. Extruded aluminum frames serve as framing elements for the insets and incorporate LEVELeâ&#x20AC;&#x2122;s innovative column panel attachment system. Inset options draw from our Surfaces line-up and include LightPlane Panels.

FORMS+SURFACES | 140

141 | FORMS+ SURFACES

Doors Stainless Steel & Fused Metal Doors combine our legendary design and materials palette with a full range of ULÂŽ fire labeling options. Doors are expertly crafted of stainless steel or Fused Metal and provide the performance ratings modern projects require without sacrificing aesthetics.

Stile & Rail Doors pair visual sophistication with extraordinary design flexibility. Three configurations and virtually limitless combinations of materials, finishes and patterns make custom-looking doors readily attainable.

Glass Doors offer unrivaled creative freedom and the versatility of glass. The line gives you endless ways to incorporate colors, patterns and graphics, vary privacy and light diffusion levels, and truly personalize an entrance.

System 7 Doors are contemporary interpretations of the traditional glazed door. Characterized by the precise detailing and rugged construction of all F+S doors, options include stainless steel or Fused Metal door faces and various glazing configurations and glass styles.

Bonded Metal & Bonded Quartz Doors feature our patterned cast composites. Bonded Metal has the appearance of solid metal, while Bonded Quartz offers a clean contemporary look in Charcoal or White.

FORMS+SURFACES | 142

143 | FORMS+ SURFACES

silhouette railing system Versatility & performance in a smartly engineered system make it easy to create custom-looking railing designs.

The Silhouette Railing System is based on a series of standard components that can be configured for diverse applications and project-specific needs.

The system starts with a collection of cast stainless steel fittings that have a beautiful polished finish. Rails and balusters in tubular stainless steel have a satin finish that provides subtle contrast and a crisp, clean look. Infill elements complete the package with materials from our Surfaces palette, including stainless steel, Fused Metal and VividGlass. Cable infill is also available.

Silhouette is an exceptional choice, indoors or out, in straight, curved or stairway applications. Options include ADA compliant handrails, guardrails, handrail and guardrail combinations, and LED illuminated railing. In addition, Silhouette's flexibility allows the system to be tailored for partitions, information displays, and other specialized applications.

FORMS+SURFACES | 144

145 | FORMS+ SURFACES

FORMS+SURFACES | 146

interactive design tools Use our interactive Design Tools to bring your creative vision to life. Each application in this growing collection blends sophisticated design functionality with an intuitive, easy-to-use interface. Three configuration tools – our Zoom Digital Darkroom, ViviStone Virtual Quarry, and Elevator Design Studio – let you explore ideas, build your designs, share your projects, and request budget pricing.

The fourth tool – our augmented reality app – puts visualization within reach of your mobile device with dynamic 3D models that give you a real-world view of some of our most popular Surfaces. You can see materials and patterns up close, ‘apply’ them to any wall or setting, and get a feel for the end results.

You’ll find all of these tools, plus more to come, on our website: www.forms-surfaces.com.

147 | FORMS+ SURFACES

Zoom diGitAl dArkroom The Zoom Digital Darkroom makes it easier than ever to bring nature’s beauty to large-scale glass applications and transform public spaces of all kinds with stunning highresolution photography of the natural world. This dynamic design tool builds on the photographic capabilities of our Spectra glass, offers incomparable customization potential, and gives you infinite ways to zoom into a photo to discover art within the bigger picture.

Welcome Back | My Account | My Project | Log out


LAYOUT

HIDE SAVED SELECTIONS

IMAGE LIBRARY

W:

60”

H:

108”

SACRAMENTO MOUNTAINS max image size: 292" X 94" @ 150 dpi

Register | Log in

APPLY

CATEGORY (clear all)

HOTEL LOBBY LightPlane Wall

GLACIER POINT max image size: 126" X 47" @ 300 dpi 252" X 94" @ 150 dpi

1

2

3

4

5

6

7

8

9

ALKALAI LAKE SUNSET max image size: 147" X 45" @ 300 dpi 294" X 90" @ 150 dpi

1

IMAGE LIBRARY

CANCEL

MCCLURE PASS max image size: 213" X 120" @ 300 dpi 426" X 240" @ 150 dpi

FULL SCREEN

+1 SAVE IMAGE

SIERRAS BEFORE SUNRISE max image size: 71" X 35" @ 300 dpi 142" X 70" @ 150 dpi

VIEWING DISTANCE

Build your design by selecting areas within your full-size image.

□ □ □ □ □ □ □ □ □ □ □ □ □

2

3

4

360 Botanical

BURNEY FALLS max image size: 224" X 124" @ 150 dpi

Canyon Desert Field Forest Macro Mineral Mountain Ocean Panoramic Sunset Waterfall

Red Rock Canyon 3 max image size: 240" X 120" @ 150 dpi

SHAPE

? Zoom Design Tool Tips

□ Horizontal CENTER SELECTION □

52%

RESOLUTION: 300 DPI | 150 DPI

Square

Report A Bug | Submit A Question | Resource Center

©2014 Forms+Surfaces

forms-surfaces.com

SIZE Largest to Smallest Smallest to Largest

INFRARED ZION max image size: 302" X 120" @ 300 dpi 604" X 240" @ 150 dpi

Report A Bug | Submit A Question | Resource Center

HIMALAYA max image size: 176" X 120" @ 300 dpi 352" X 240" @ 150 dpi

GRAND CANYON max image size: 240" X 120" @ 300 dpi 480" X 240" @ 150 dpi

©2014 Forms+Surfaces

FORMS+SURFACES | 148

MONO LAKE max image size: 168" X 17" @ 300 dpi 336" X 34" @ 150 dpi

RESOLUTION 300 dpi 150 dpi

forms-surfaces.com

Use the Zoom Digital Darkroom to add a unique photographic dimension to the Systems shown on the preceding pages, and to all of your architectural glass projects.

Part interactive design studio, part curated photo library, the Zoom Digital Darkroom gives you access to Zoom images – our growing collection of large-scale, superhigh-resolution photos created using sophisticated gigapixel image capturing equipment. Offering breathtaking visual possibilities, Zoom images range from sweeping panoramic vistas to intriguing close-ups of nature as you’ve never seen it before.

Zoom images bring the beauty of nature to any space. Browse the Zoom photo library and you’ll find literal and abstract views of a wide range of natural scenes: dramatic seascapes, vast mountain ranges, dappled forests, and extraordinary slices of the world around us.

149 | FORMS+ SURFACES

Zoom diGitAl dArkroom The Zoom Digital Darkroom gives you the tools you need to build your Zoom designs. From within the app you can select images, size, scale and crop specific areas within your photos, zoom in or out, and use the design board to assemble your work and create your own photographic point of view.

Welcome Back | My Account | My Project | Log out


LAYOUT

HIDE SAVED SELECTIONS

FULL SCREEN

VIEWING DISTANCE

IMAGE LIBRARY

Build your design by selecting areas within your full-size image.

+1 W:

48”

H:

24”

ADIANTUM FERN max image size: 73" X 73" @ 300 dpi

Register | Log in

APPLY

IMAGE LIBRARY

SAVE IMAGE

CATEGORY (clear all)

CANCEL

RECEPTION AREA Counter Front

SAGE max image size: 120" X 97" @ 300 dpi 240" X 194" @ 150 dpi

EVERGREEN HEATHER NEEDLES max image size: 153" X 83" @ 300 dpi 306" X 166" @ 150 dpi

SILVER DRAGON GRASS max image size: 257" X 108" @ 300 dpi 514" X 216" @ 150 dpidpi

1

2

3

4

5

6

7

8

9

WOVEN GRASS max image size: 138" X 124" @ 300 dpi 276" X 248" @ 150 dpi

? Zoom Design Tool Tips

□ □ □ □ □ □ □ □ □ □ □ □ □

360 Botanical Canyon

1

Field Forest Macro Mineral Mountain Ocean Panoramic Sunset Waterfall

SUNSET FLAX max image size: 150" X 150" @ 300 dpi

SHAPE

52%

CENTER SELECTION

□ □

DAVALLIA FERN max image size: 138" X 130" @ 300 dpi

Desert

Horizontal

RESOLUTION: 300 DPI | 150 DPI

Square

Report A Bug | Submit A Question | Resource Center

©2014 Forms+Surfaces

forms-surfaces.com

SIZE Largest to Smallest Smallest to Largest

ADIANTUM FERN max image size: 73" X 73" @ 300 dpi 146" X 146" @ 150 dpi

Report A Bug | Submit A Question | Resource Center

DAVALLIA FERN max image size: 138" X 130" @ 300 dpi 276" X 260" @ 150 dpi

SUNSET FLAX max image size: 150" X 150" @ 300 dpi 300" X 300" @ 150 dpi

©2014 Forms+Surfaces

FORMS+SURFACES | 150

WILDFLOWERS max image size: 53" X 45" @ 300 dpi 106" X 90" @ 150 dpi

RESOLUTION 300 dpi 150 dpi

forms-surfaces.com

As comprehensive as it is intuitive, the Zoom Digital Darkroom lets you explore ideas, configure designs, and request budget pricing – all from within a single, easy-to-use application.

What you see here is just a starting point. The creative possibilities are astounding, especially when Zoom images are illuminated in our LightPlane Panels, and used in the Wall, Column and Elevator Interior Systems shown on the preceding pages.

We encourage you to visit our website – now and in the future – to discover what’s new, and be among the first to realize the full potential of the Zoom Digital Darkroom.

Zoom in today: www.zoomdigitaldarkroom.com.

As the Zoom program continues to grow and evolve, your creative options will too.

151 | FORMS+ SURFACES

ViVistone VirtuAl QuArrY The Virtual Quarry is a remarkable online application that allows you to configure your ViviStone designs. The Virtual Quarry makes it easy to unleash your creativity, free from the physical constraints of real stone, and transform projects of any size with our state-of-the-art ViviStone glass.

This project used the "Bookmatch" feature to create two mirrored Opal Onyx LightPlane Panels installed in a LEVELe-106 Elevator Interior.

FORMS+SURFACES | 152

From the Virtual Quarry you can select from our families of ViviStone slabs, assemble and configure your designs, work on multiple projects simultaneously, share your ideas with colleagues or clients, and request budget pricing â&#x20AC;&#x201C; all from within a single application. Try it for yourself at www.virtualquarry.com

153 | FORMS+ SURFACES

eleVAtor desiGn studio The Elevator Design Studio is an interactive tool that puts design control at your fingertips. The intuitive step-by-step format lets you choose an elevator interior configuration, apply materials and finishes from our extensive Surfaces palette, view your progress in realistic renderings, and request budget pricing – all with a few simple clicks.

Just set up an account – a quick and safe process – then start building and managing your projects.

Within a project you can add multiple elevator interiors, note job-related details, work through design ideas, and save Surfaces to your ‘Favorites’ library for future reference and use.

Unparalleled in its reach, the Elevator Design Studio is a comprehensive visualization tool that helps you tailor our Surfaces and Elevator Interiors to your project-specific needs. Try it, and discover how easy it is to bridge the gap between creative vision and installed reality.

Get started at www.elevatordesignstudio.com

FORMS+SURFACES | 154

STEP 1: Configuration selection

STEP 2: Wall Panel selection

STEP 3: Handrail selection

STEP 4: Ceiling selecton

Stainless Steel, Seastone finish

American Walnut wood veneer

Round handrail in stainless steel

155 | FORMS+ SURFACES

Ceiling with LED perimeter lighting

AuGmented reAlitY Our augmented reality app puts visualization within reach of your mobile device with dynamic 3D models that give you a real-world view of some of our most popular Surfaces. You can see materials and patterns up close, ‘apply’ them to any wall or setting, and get a feel for the end result.

The app relies on sophisticated technology that pairs the use of a printed ‘tracking marker’ with the camera on your smart phone or tablet. To see it in action: • Position the tracking marker (page 159) in your desired location – the area to which you’d like to ‘apply’ your Surface.

• Download and launch the Forms+Surfaces app from the Apple App Store or Google Play.

• Select ‘Surfaces’ from the on-screen menu.

• Browse the options. When you reach your Surface of choice, tap 'visualize' and aim your mobile device camera at your marker.

This will generate a realistic 3D model you can use to simulate your vision and explore the design possibilities.

To print out additional tracking markers and learn more about Augmented Reality, visit www.forms-surfaces.com/augmented-reality.

FORMS+SURFACES FORMS+SURFACES | 156

(left) Surfaces menu; (top) tracking marker; (bottom) tracking marker taped to wall

(above) augmented visualization of selected Bonded Metal option atop tracking marker on wall

(top) moving closer to marker; (bottom) different swatch selected

157 | FORMS+ SURFACES

Comprehensive Support Systems that Invite Creativity

Interrelated Product Lines

Time-Tested Expertise

All of our Systems products balance the convenience of a standardized system with impressive design flexibility. Our Systems let you move seamlessly from bold new concept to installed reality by:

Our interrelated product lines make it easy to carry design and material themes across a property.

We recognize that every project is unique, and that multi-faceted projects require an array of talents and capabilities.

• Providing a framework for our Surfaces. With literally hundreds of material and finish combinations to choose from, you benefit from countless design options as well as the cost-efficiencies of using our Surfaces in our Systems, and vice versa.

• Addressing mechanical details: those you see, like trim pieces and other finishing elements, and those you don’t, like attachment systems and mounting assemblies. This gives you the freedom to focus on designs and finishes, while saving on the time and costs associated with custom solutions.

• Offering project-specific technical support that can help you with: • Shop drawings and project detailing • Material yields • Weight calculations • Mounting and installation details • Budget pricing early in the process

Within our line you’ll find: Surfaces – as introduced on the preceding pages, an extensive palette of materials, finishes and patterns that can be specified as sheet goods or incorporated into many F+S products.

Systems – the products represented throughout this book: walls, LightPlane Panels, elevator interiors, elevator doors, columns, doors & door pulls, railings, and information displays.

Site Furniture – a versatile group that includes benches, bike racks, litter & recycling receptacles, planters, tables and chairs.

Outdoor Lighting – contemporary designs, precision craftsmanship, and LED technology shape our collection of bollards and pedestrian fixtures.

FORMS+SURFACES | 158

For nearly five decades, we’ve worked with our clients to develop real-world product solutions.

We’ve also invested steadily in high-end manufacturing facilities and equipment, innovative materials and finishes, and the skilled professionals that make up our team.

So, whether you’re navigating building code requirements, ADA guidelines or environmental issues, we’re here to support you at every step in the process by giving you access to: • Unparalleled manufacturing expertise • State-of-the-art technologies and materials • Decades of industry experience • Products with proven performance in demanding environments • Knowledgeable employees around the world who can assist you with design and engineering challenges; project management; technical and customer support; and sustainability compliance

F+s AuGmented reAlitY App & trAckinG mArker

Cut here, then place the marker on the other side of this card in your desired location

The Forms+Surfaces augmented reality app puts visualization within reach of your mobile device with dynamic 3D models that give you a real-world view of some of our most popular Surfaces. You can see patterns and

1

Select a product from the menu

materials up close, ‘apply’ them to any wall or setting, and get a feel for the end result. The app relies on sophisticated technology that pairs the use of a printed ‘tracking marker’ with the camera on your smart phone or tablet.

Try it for yourself: Download the Forms+Surfaces App from the Apple App Store or Google Play. Place the marker on the other side of this card in your desired location, then proceed through a few simple steps:

2

3

4

Tap the "visualize" button

Aim your camera at the tracking marker

View the product from any angle

To print out additional tracking markers and for more information, visit www.forms-surfaces.com/augmented-reality

159 | FORMS+ SURFACES

Cut here, then place the marker in your desired location

FORMS+SURFACES | 160

ADditional Resources Visit Our Website: www.forms-surfaces.com

U.S. Locations

Pennsylvania 30 Pine Street Pittsburgh, PA 15223 800.451.0410 412.781.9003 F 412.781.7840

California 6395 Cindy Lane Carpinteria, CA 93013 800.451.0410 F 805.684.8620

Arizona 1025 North 71st Avenue Phoenix, AZ 85043 800.451.0410 F 623.594.6312

International Locations

UK / EUROPE 88 Kingsway London WC2B 6AA, UK +44 203 755 3731 F +44 207 841 1001

Middle East Suite B 307, Dubai Silicon Oasis PO Box 341052, Dubai, UAE +971 4 501 5605 F +971 4 501 5606

India Office No. 104, Pentagon 4, Magarpatta City, Hadapsar, Pune 411028, MH, India +91 20 30492400

Hong Kong 11/F, AXA Centre, 151 Gloucester Road, Wanchai, Hong Kong +852 25823742 F +852 30113864

Singapore 1, Jalan Saudara Ku, Singapore, 457438 +65 6241 0206 F +65 6441 1185

Thailand 37th Floor, Sathorn Square Office Tower 98 North Sathorn Road Silom, Bangrak, Bangkok 10500, Thailand +66 2 105 6447 F +66 2 105 6301

Updated regularly, our website is a comprehensive resource designed to help you discover what’s new and stay up-to-date on product and company developments.

In support of all of our Systems and Surfaces, you’ll find: + Product Data Sheets & Design Guides + Full-sheet Pattern Drawings + Technical Specs + Installation Instructions + Environmental Data + Image Galleries + Project References Contact Us Contact Forms+Surfaces for additional information about any of our products or to reach a sales representative in a territory near you. + Telephone: 800.451.0410 + General Inquiries: marketing@forms-surfaces.com + Sustainability: green@forms-surfaces.com

Sign up for Forms+Surfaces New Product Announcements at www.forms-surfaces.com/news IMPORTANT: The surfaces shown in this catalog are intended as a visual guide.

Because photographic reproduction may not present true product colors, actual finishes may vary slightly from the colors shown here.

Taiwan No. 18, Ln. 238, Gongye Road Longjing District, Taichung City 434, Taiwan (R.O.C.)

161 | FORMS+ SURFACES

We maintain an Environmental Management System and are continually working to improve our impact through efficiency, material selection, vendor education, employee involvement, and an unwavering commitment to being exemplary corporate citizens. If you would like additional information on our Environmental Management System or our company environmental initiatives and policies, please feel free to contact our Sustainability Team at green@forms-surfaces.com.

offices worldwide | 800.451.0410 | 412.781.9003 | www.forms-surfaces.com Member of the USGBC | LEED® Accredited Professionals on Staff | FSC® Certified Supplier | FSC-C004453 | SCS-COC-001461 © 1996 Forest Stewardship Council A.C.

FORMS+SURFACES | 162

Printed on 50% recycled, 25% post consumer paper FSSURFBRO-0914-7500-REV004
