Lotus Styling Chair
Receiving & Inspection
1. Before unpacking, please check the condition of the outer box. If the box is damaged, please report to Salons Direct immediately. 2. Be careful when unpacking and avoid using sharp tools.
After opening, check the condition of your product carefully.
4. Check that all parts are included before beginning to assemble your product.
5. Read all instructions carefully before assembling and installing. This product is designed for use in professional salons.
6. Keep these instructions safe for your future reference.
(Chair top for illustration purposes only)
Star Base - Chrome
Star Base - Black Square Base
Choose the correct assembly instructions for your chosen base
5 Star Base Chrome
Parts
A: Chair Top
(Shown for illustration purposes)
B: 5 Star Base
C: Hydraulic Stem
D: Lever
E: Round Disc Cover
F: Sprung Steel Pin
G: Cosmetic Silver Cap
H: Large Bolt
I: Small Bolt
J: Large Washer
K: Spring Washer
L: Allen Key
5 Star Base (Chrome) Assembly
Tools Required: Allen Key & Hammer (Hammer not included)
• Open the box carefully, making sure not to use any sharp blades which could damage the chair
• Remove all boxes from the outer box
• Carefully remove the chair, base, and all parts from the boxes, and ensure all parts are included
1. Place the round disc cover (E) on top of the chair base.
2. Take the hydraulic stem (C) and place into the base.
3. Secure the hydraulic stem to the base using the large bolt (H), large washer (J) and spring washer (K) and tighten.
4. Fit the lever (D) to the hydraulic stem using the allen key and fit the cosmetic silver cap (G) by tapping into position. Make sure the lever is positioned as shown in the image above.
5. Tap the sprung steel pin, tapered end (F) into the hole at the top of the hydraulic stem using a hammer.
6. Now place the chair top onto the base ensuring the cut out aligns with the sprung steel pin. Once secure sit on the chair to compress the joint.
Round Base / Square Base
Parts
A: Chair Top
(Shown for illustration purposes)
B: Round Base / Square Base
C: Hydraulic Stem
D: Lever
E: Sprung Steel Pin
F: Cosmetic Silver Cap
G: Small Bolt
H: Spring Washer
I: Screws x 4
J: Allen Key
Round Base / Square Base Assembly
• Open the box carefully, making sure not to use any sharp blades which could damage the chair
• Remove all boxes from the outer box
• Carefully remove the chair, base, and all parts from the boxes, and ensure all parts are included
1. Tap the sprung steel pin (E) into the hole of the hydraulic stem using a hammer. Make sure the tapered end goes into the hole first.
2. Attach the lever (D) to the hydraulic stem making sure that the lever is the correct way round, positioned as shown in the image above.
3. Once the lever is positioned correctly, fit the spring washer (H) and small bolt (G) using the allen key to tighten.
4. Once tight, put the silver cap (F) over the hole.
5. Using the lever you have just attached, support the hydraulic and lean the base against it to line up the holes. Attach the 4 screws (I) using the allen key, making sure they are secure.
6. Place the chair top onto the base and align with the sprung steel pin. Once secure sit on the chair to compress the joint.
Maintenance
The Hydraulic Pump
• After assembly, it is a good idea to pump the hydraulic to full height and back down several times to prime the hydraulic fluid. This will help to keep the pump smooth and responsive
• Note that short, quick pumping is more effective than pressing the lever all the way down each time
• It is advised to periodically check the chair to ensure all fittings are secure
Upholstery Care
• Wipe down the upholstery and metal parts with a soft cloth and mild soapy water. Dry with a clean, soft cloth
• Do not use brushes, scouring aids or any chemicals when cleaning the chair
• If the upholstery becomes stained by coming into contact with fabric, belts, or other items of clothing; wipe off the stain with soap and warm water as soon as possible and dry with a soft cloth
• Dry and polish metal parts using a suitable metal cleaner and a clean, dry cloth
• Keep the chair away from direct sunlight to avoid fading of the fabric
• We recommend using chair back covers as protection
PLEASE NOTE
On occasion some clothing colours, such as those used in denim, may transfer to lighter upholstery. This process increases in more humid conditions and stains can be extremely difficult to remove. Salons Direct cannot be held responsible for colour transfer caused by this process.
Lighter coloured upholstery on chairs is sensitive to staining from aggressive hair chemicals such as hair colour. There is a risk that marks cannot be removed if any chemicals are not cleaned immediately. Stained upholstery due to hair colour and other products cannot be covered by our warranty.
Our furniture is produced with strong resilient faux leather fabric, tested by our manufacturer to ensure strength, memory and heat resistance. We also fit our chairs with high-density foam to ensure continual use, client comfort and sustained durability.
The warranty covers any product defects arising from faulty materials or workmanship; or defects arising from direct delivery transport damage. Any damages must be reported within 48 hours. This warranty is valid for one year from the date of purchase. Salons Direct warrants to you, the original buyer, that goods shall be free of defects in material and / or workmanship attributing to manufacture for one year from the date of purchase. Salons Direct, will, at its discretion repair or replace defective products. We cannot be liable for any loss of business.
Warranty does not cover for the following...
• General wear and tear of the product over time
• Repair failures caused by physical damage
• Improper operation / handling
• Attempt to repair
• Natural or manmade disasters
• Staining or discoloration of fabric due to normal wear and tear, caused by client clothing (dye in jeans, skirts etc..), hair colour or bleach
• Any fading due to exposure of sunlight over a period of time
