Forward This portfolio speaks to my interpretation of how I envision the construct of a building. I focus on these three aspects: The physical materials that are the building blocks of the structure. How the building blocks respond to the user. How the building blocks start to relate to the site. My process: before I put a pen to paper, I think in words. I imagine myself as a character on the site, within the environment and its community, and I write about the experience. I let poetry speak design into existence.

Unit layout diagram of precedent study Hunters View Housing Blocks 5 + 6 for Orleans 164


TABLE of CONTENTS 2018

Summer FAB

4

Design-Build Program Pavilion The building blocks of structure

2019

Pine Academy

8

Maine Boat Building School The language of structure

2020

Orleans 164

12

Affordable Housing in East Boston The language of structure as it responds to the user

2021

Framery

18

Maker-Space for the Instructables The language of structure as it responds to place

2022

C a r v e r C o n s e r v a t o r y & L a c k s L a b o r a t o r y3 Research laboratory in Tuskegee, Alabama The language of structure as it responds to injustice

32


SUMMER FAB Design-Build Program Pavilion

The building blocks of structure

A four-week design-build program offered at Wentworth Institute of Technology to high school students. We spent the first two weeks exploring the city of Boston and focusing on the experiences of pavilion spaces. For the last weeks, we designed what we felt would be the best pavilion to place on the site based on its environmental and social factors. We were instructed on the skills and materials needed to bring our design to life. boston, ma summer fab 2018 professor robert trumbour collaboration with 12 team members* *contributed to the design of the repeated structural frame

The design of the pavilion focused on the processional sense of scale. One end of the structure was formed to a certain angle that increased with each additional frame as the user walked to the opposite end.

5


PHASE ONE

Sketching and modeling ideas.

Coming up with the final design and full scale mock-up.

summer fab

6


PHASE TWO

Construction of the foundation and jig begins.

Assembling the individual frames together.

summer fab

7


PINE ACADEMY Maine Boat Building School

The language of structure

only on summer nights when tones of fresh oak beckon me out of hiding, exploration calls out to me, not just the shiver of cool air on my skin but what lies in the shadows, do the birds end their chirping? does the sun truly sink into the ground? as it appears to be? among these grown up branches I feel less alone, comforted by the whispers of the leaves calling out my name... drawn by wavering planks drifting among the land, into a space where warm dust swims in the breath of bodies brushing around me, sanding, pierced by metal against metal, softened by metal against wood, carving, smooth to touch, pungent paint glossy against streams of light, waves between my fingers, until I’m standing where the slap of the ocean against land engulfs my wooden vessel in crimson rays.

brooklin, maine studio 03 2019 professor luis flores This project was a response to a proposal for a wooden boat making school that would serve the community during the summer months. My design is meant to serve as the missing link to the preexisting buildings on the site. In doing this, I aimed to make the structure symbolize the connection between land, water, and the boat building process. This idea was implemented in the roof design. Angles and long spans of distance to create a sense of direction to tie in all the aspects of the site.

9 9


SITE PLAN

1

lear

n

me

ing 3

n eti

g

2

ng

ma ki

1. Wooden Boat School 2. Wooden Boat Publications Inc 3. Connection School

Connecting the process of boat building through the existing structures on the site towards the direction of the water. The roof spans create this movement.

connection school

10


AXON, SECTION, FLOOR PLAN, SOUTH ELEVATION AND CONCEPT DIAGRAM

openings between the roof planks

learning diagonal timber bracing

10

2”x4” timber beams

8

making meeting

9

7

2x4 timber framing

6”x6” timber columns

4

A

A 6

1. gift shop 2. planning/meeting room 3. library 4. bathroom 5. big shed 6. classroom 7. dining/kitchen 8. wood workshop 9. sewing room 10. wood storage

5

3

1

2

concrete foundation wall An open floor plan consisting of three levels. Each symbolizing one of the existing buildings on the site to emphasize their connection to one another.

connection school

11


ORLEANS 164 Affordable Housing in East Boston

The language of structure as it responds to the user

el alma de eastie, maverick square, donde los triple deckers alinea la calle, un madre caminando con sus hijos, faces stuffed with miguelitos, “ay! un avión ruidoso, cubra sus narices, no quiero que estés enfermo.” “mira! otra tienda out of business.” madre mira a la apartamento lujo, lagrimas en sus ojos. a city divided among racial lines, one side a generic representation of what once were bodegas and barrios, only existing to fuel corporate paychecks, unphased by the disconnect, grounded in disrespect, en la casa, la familia, la comunidad. an ocean of bodies coping with unwavering realities, overlooked unless fighting for a world already inherited, dedicated to an atmosphere established by a terrain built on an ocean returning to consume it, to destroy, analogous of those drawn to its border, living on ignorance is bliss, when pollution and gentrification doesn’t tear apart su casa, su familia, su comunidad.

east boston, ma studio 05 2020 professor liem than This was an affordable housing project based in East Boston. Presented with the issues of environmental racism and the effects of climate change, I wanted my design to make a positive impact on its user. I focused on a structure that would maintain existing site typologies, foster community through transparency and create an atmosphere of home. I began with a simple path, similar to the adjacent Greenway and built upon the community aspects.

13


SITE CONTEXT

Logan Airport

Mary Ellen Welch Greenway

Site

East Boston is impacted by its proximity to the ocean and Logan Airport—from future flood issues to constant noise and air pollution.

orleans 164

14


NON-PARIEL and DIAGRAMS

Embodying the Greenway adjacent to the site and creating a path with a sheltered experience for the residents—almost as and oasis from the harsh realities of city life. The path drives the landscape and spacial relationships. Above the path residents are exposed to the outside community through the use of translucent materials.

Parti

orleans 164

Landscape

Flood Prevention

Common Spaces

15


SITE PLAN

each building interlocks A

beauty salon

pool

lobby gym

barber shop spa

game room lounge

bodega

movie theatre

Mary Ellen Welch Greenway

Orleans Street library

mail unit k laundry

common room

residential parking unit j

The ground floor consists of commercial real estate that mimics the surrounding site typologies and includes new options while creating a community atmosphere.

orleans 164

16


SECTION, FIRST FLOOR PLAN, RENDERS and NORTH ELEVATION bridge connections

led glass floors window panels steps into the Greenway

unit 1d

unit 1c

translucent polycarbonate panels unit 1e

unit 1g unit 1h unit 1j unit 1k

common area

unit 1f unit 1a

park

unit 1b

unit 1i

residential parking

Upper floors are residential. Individual buildings overlap to create common spaces with each proceeding floor. Residential levels raised above grade due to flood risk. higher ceiling height for bedrooms

balcony bedroom

bath

bedroom kitchen

living room

Common Room

Entrance translucent polycarbonate panels

inverted window openings

staggered facade to mimic traditional triple-deckers

orleans 164

17


FRAMERY

Maker-Space for the Instructables

The language of structure as it responds to place

place defines structure, history molds future, present reveals. place. land consumed by water at a junction of the merroh awke, spoken by the pawtuckets as the strong place, where neighbor meets friend along the water’s edge. history. when the water has dried up for a network of frames, where overworked girls powered a revolution of innovation, a place once known for its water now nicknamed mill city. industrialization, shaping well oiled machines built on the back of stone facades and rigid steel bodies. present. framing the antecedent, capturing the prospective, to continue a thriving revolution, its impact not forgotten as it frames the future of innovation.

lowell, ma studio 06 2020 professor ryan thomas collaboration with pricilla rosa* *developed conceptual and visual representation

The city of Lowell is historically known for its industrial character. This design was meant to be a maker-space that would serve the Instructables Community—an online community that shares instructional videos. The design focused heavily on maintaining the industrial quality of Lowell while remaining modern. It draws in the history and the future by focusing on views and materiality that inspire and serve as a reminder.

19


CONNECTIVITY DIAGRAM

Connecting the site to the canal system, adjacent educational facilities, the Greenway system and maximizing views in the area.

framery

20


CONCEPTUAL STUDIES and RENDERS

Framing a view of Lowell that captures the essence of its material quality and industrial history.

Views and Circulation

Workshop

framery

1

Site Axis

Program and Facade Approach

Gallery

2

21


SECTION A, SOUTH ELEVATION and Precedent Study

spider glass curtain wall

cantilever

framery

22


ductwork

roof skylight

glass freight elevator

Building systems study of the New Museum of Contemporary Art by SANAA.

framery

23


STRUCTURE SYSTEM

1. 4’ foundation wall 2. 6’ concrete pillar 3. w 12x14 beam, column and girder 4. 7 3/4” concrete slab 5. end cap 6. 6” metal stud wall 7. 5” metal decking 8. portal column 9. copper cross-braced cables 10. steel howe truss system 11. 6” copper cross-braced columns 12. column end cap 13. 2” steel plate

10

8 9

7

6 4

5

11 3

12 13

2

1

framery

Keeping the structure in tune with the historical and industrial aspects of the site by using steel members, trusses and cross-bracing.

24


SITE PLAN and FIRST FLOOR PLAN

gallery

a re

m

ion naturally egetat fou nd nd v a in s l a th i r e ea t a

2

lobby

mechanical closet entrance

1 workshop loading dock

boardwalk connection to existing Greenway path

koi pond

entrance E Merrimack St

Concord River

loading truck path Davidson St

framery

The structure is oriented toward two views on the site while leaving space in the middle for human interactions.

25


ENCLOSURE SYSTEM

1. 2’x6’ translucent fiber cement panel 2. 2’x10’ translucent fiber cement panel 3. spider glass curtain wall 4. LED strip light 5. 1/4” gypsum board 6. 5/8” plywood 7. vapor barrier 8. 6” rigid foam 9. 2” dens glass 10. metal backing system 11. metal paneled roof 12. hanging acoustical panel 13. wood laminate flooring

11

1 2

4

10

3

5

7

9

12

13 6

framery

Adding modern elements to the exterior while sticking to a gray, muted industrial quality.

8

1

26


SPACIAL RELATIONSHIPS

office

locker ro

om

fabricatio

n lab

mechanical by

lob

bathroom reception cafe

lery gal Connecting programing through the workflow of each area.

locker room mechanical

office classroom

design

galley

gallery

workshop

Bubble Diagram and Matrix

framery

Programing Massing

fabrication

27


MECHANICAL SYSTEM 1. roof skylight 2. tubular duct 3. chilled beam 4. 1” pex tubing 5. 6” polyethylene pipe 6. gray water tank 7. filtration cistern 8. water heater 9. hydronic heat pump

1

2

3

10

4 9

8

5 7

framery

6

A focus on self-sufficiency and sustainability led to the usage of ground source heating, radiant heat as well as a rainwater collection system.

28


WALL SECTION DETAILS gutter A

A

metal sheet roof howe truss wood laminate flooring

exterior wall assembly rigid foam

B

B

spider glass panel spider clamp vertical support

horizontal mullion C C

concrete slab c-shaped mullion steel beam

Wall Section D

fiber cement panels metal backing dens glass rigid foam end cap concrete slab steel beam

Wall Section C

framery

29


INTEGRATED BUILDING SYSTEMS

B

G

D

A E A

cross-bracing columns

framery

B

C

D

howe trusses

metal stud wall assembly

spider glass curtain wall

30


F

H

C

E

led exterior strip lighting

framery

F

hydronic heating equipment

G

H

linear recessed lighting

wall washer lighting

31


CARVER CONSERVATORY & LACKS LABORATORY Research laboratory in Tuskegee, Alabama

The language of structure as it responds to injustice

King was so anguished by “wait”, mentioning it only five times in his 6,912-word letter. It is the one word that lingers, that bares any weight, 21,632 days later, we still wait. We’re such a deep disappointment. How is a dog greeted with more compassion? How did we twist Jesus love into religious hurry? Why is there such awkward fear at the store? What makes me ask for a paper receipt? Why do I step aside on the sidewalk? What does it mean when my hand pulsates around police? How do I take shelter from clouds of inferiority? Why do we perform under injustice? Why does my anger require evidence of tension? Who do we call on for direct action? Why does my dialogue feel rehearsed? How am I the antecedent for self-purification? When does my hair become scintillating beauty? Why do my mannerisms fog around violence? What happened to the urgency of our ancestors? Where is the sublime courage they exhibited? When do we step into the garment of destiny? How am I still fighting for my God-given rights? “We hold these truths to be self-evident, that all men are created equal, that they are endowed by their creator with certain unalienable rights, that among these are Life, Liberty and the pursuit of Happiness.”

tuskegee, al studio 08 2022 professor samuel maddox collaboration with pricilla rosa and quanglin zheng* *developed a site within the larger group region

This project was part of a semester long study of the Alabama Black Belt. The chosen site was Tuskegee, which is known for education, being the home of Tuskegee University. My group’s concept focused on capitalizing on learning to propose new sources of educational activity for the community. We centered each proposal around hidden figures in Tuskegee with mine being the legacies of George Washington Carver and Henrietta Lacks.

33


THE CIVIL RIGHTS MOVEMENT

The Alabama Black Belt The Black Belt region of Alabama is named after it’s distinct dark soil but also it’s dark history. This region has shaped the evolution of Black history in America. The most significant being the Civil Rights Movement. This diagram highlights the 54 mile journey on highway 80, from Selma to Montgomery, that Dr. King and many others walked in their fight for freedom. Overlayed are the events and political circumstances that led up the the climax of the march. The events that played out as well as the locations in which they occurred have lasting impacts that are felt by these communities today.

carver conservatory & lacks laboratory

34


carver conservatory & lacks laboratory

35


MASTER PLAN

Within the Black Belt, my team chose Tuskegee as our focus. The three site proposals take into consideration highway access as well as community reach.

carver conservatory & lacks laboratory

36


HISTORICAL and COMMUNITY ANALYSIS

In order to understand this community, we did an analysis of its history as well as looking at reviews and demographics to compile realistic character profiles.

carver conservatory & lacks laboratory

37


SITE ‘C’ CONTEXT

A closer look at site ‘C, which serves as the location of the research center. Nearby is a residential and mixed commercial area.

carver conservatory & lacks laboratory

38


CHARACTER PROFILE Character

Site photos

Due to Tuskegee being a university town, students made up the majority of the population. These were either students from Tuskegee University or younger ones from nearby high school and middle schools.

Data Thirty percent of the Tuskegee population is between the ages of 18-24. For a student who is within the 1% population of multiracial residents working in retail, an annual salary of $7,593 was expected. According to this review, a students felt that the town was lacking in recreational activities.

Tuskegee University

Abbot Park

Tuskegee Airmen Historic Site

Locations In looking at possible locations for students to use, most students could be found around the university.

These character profiles helped us tie in community needs and perspectives into our proposals. My focus was on ways for students to benefit from a new facility.

carver conservatory & lacks laboratory

39


EXISTING TYPOLOGIES

Robert Taylor was the first registered black architect who designed much of the university campus. My design incorporated elements from his designs.

carver conservatory & lacks laboratory

40


HISTORICAL and PROGRAMMATIC ANALYSIS History George Washington Carver + Jesup Wagon Henrietta Lacks + He-La Cell

Funding + Support Lifetime Organic Natural Farm Tuskegee University (Agricultural Department)

Program Carver Conservatory Houses native plant species researched by Carver Production of Carver’s 300 inventions Lacks Laboratory A science lab on ethical plant cell manipulation Jesup Wagon Delivers food and products made on site Vendor wagon for the George Washington Carver Festival

The history and legacy of Carver and Lacks who were significant figures in Tuskegee, helped shape the program of a student research center.

carver conservatory & lacks laboratory

41


SITE AXON

The structure sits on the site as a bridge, allowing visitors to pass underneath into the conservatory.

carver conservatory & lacks laboratory

42


EXPLODED AXON

Sedum roof

Woven carbon fiberglass

Polycarbonate panels

Steel columns Wood framing Underground irrigation systems

Solar chimney

cell structure

mitosis

cell walls

Conceptual references The form is inspired by the molecular, tissue and cell make up of plants.

carver conservatory & lacks laboratory

43


FLOOR PLAN

conservatory

The conservatory in the middle serves as the main entry with access to vegetation from Carver’s research. The classrooms and laboratory remain on the upper level.

carver conservatory & lacks laboratory

44


classroom and laboratory

carver conservatory & lacks laboratory

45


INTEGRATED BUILDING SYSTEMS

This cut shows the relationship and activity of the entire structure. The mechanical systems in place allow for the ease of growing and studying in the same facility.

carver conservatory & lacks laboratory

46


carver conservatory & lacks laboratory

47
