02 | SELECTED PROJECT IN gmp

Guangzhou Xilang Transportation Hub (Competition)

Location:

Category:

Client:

Project Year:

GFA:

Work Involved: Guangzhou, China

Transportation Hub, Commercial Guangzhou Metro Group Co., Ltd 2019

1,600,000 sqm

Conceptual development, Modelling, CAD drawings, Diagrams, Competition packages, Attending key meetings

Guangzhou Xilang Transportation Hub development is a large scale urban design competition for the client Guangzhou Metro Group. The site is located at the border of one of the largest Chinese city Guangzhou and tier 2 city Foshan. It is within the Pearl River Delta, one of the most developed area in China.

The masterplan provided an overall development and improvement strategy for the 3.3 square -kilometre area of Xilang District, promoting the renovation of surrounding areas from multiple aspects, such as landscape, dynamic community, integration of industry and urban space, and integration of transportation station and city. The urban design proposal aimed to create a regional business centre in Liwan District by developing a complete open space system, introducing a pedestrian-friendly urban space, and integrating a comprehensive public transportation system into the urban fabric.

The scheme uses an elevated platform system to organically connect different functional blocks within the site, at the same time, integrate it with the surrounding urban public space. The concept of ‘Integration of transportation station and urban space’ facilitates the metro transfer hall and commercial space within a large atrium space under the big roof.

Work involved: Concept development AutoCAD drawings SketchUp model making Diagrams drawings Competition package

DESIGN CONCEPT

The concept for the master plan is based on the ‘Banyan Tree’ which is one of the most typical trees in Guangzhou. It symbolizes the spirit of people in Guangzhou, like the roots of the Banyan tree can grow in the toughest conditions such as the gap of the wall. The platform inspired by the Banyan tree roots connect different functions from south of the site (station area) to north (commercial & residential area).

Site plan Conceptual sketch

TRANSFER HALL

The station-urban space integrated concept was achieved by integrating the transfer hall, transportation facilities and commercial area into a big space covered by a massive roof. Floating metro platform for metro line 1 exposed in the transfer and shopping space, as a unique feature for the transportation hub.

Upper floor plan Transfer hall section Ground floor plan Transfer hall floor plan

02 | SELECTED PROJECT IN gmp Location: Category: Client: Project Year: Shenzhen, China Urban design Shenzhen City Council 2020 Shenzhen Technology Park Work involved: Concept development AutoCAD drawings SketchUp modelling Diagrams drawings Competition package

INNOVATION CLUSTER

The innovation park located in the east of the site includes 8 innovation clusters with each innovation cluster consisted by 4 tower blocks in different height to provide unobstructed view to Shenzhen Wetland Conservation area. The 8 clusters are connected with each other through the linking platform on the first floor level extended form the shared indoor communal atrium space in each cluster.

研发者沙龙 Developer’s Salon 研发者沙龙 Developer’s Salon 空中花园 Sky Garden 二层云平台 Cloud Platform (2F) 研发者沙龙 Developer’s Salon 空中花园 Sky Garden 二层云平台 Cloud Platform (2F) 研发者沙龙 Developer’s Salon

01 | SELECTED PROJECT IN gmp Location: Category: Client: Project Year: Hubei, China Urban design Xiongan City Council 2020 Xiongan Train Statation and Surrounding Area Urban Design Work involved: Concept development AutoCAD drawings SketchUp modelling Diagrams drawings Competition package

TRAIN STATION + COMMERCIAL SPACE

F1 B1

A three-dimesnional space system was formed by the folding roof design on the train station with elevated outdoor walkways and the sunken plaza to the south

F1 B1 B2 雄安城际站及小里站周边建筑设计 Xiong’an

F1 B1 B2 B3 雄安城际站及小里站周边建筑设计 B1 B2 B3 B4 Train station floor plans - Level B3 Train station floor plans - Level B2 Train station floor plans - Level B1 Train station floor plans - Level 00

Xiong’an Intercity Railway

Intercity Railway Station, Xiaoli Railway Stations, and Their Surrounding

02 | SELECTED PROJECT IN WW+P

Transport Hub Interior Design

Location: Category:

Client:

Guangzhou, China

Background Guangzhou Baiyun Station is a transportation hub interior design project appointed by the client Guangzhou Metro Group. It is part of the major extension to the existing Guangzhou Baiyun International Airport.

Our scope include the design of concourse and platform level soffit, wall & column cladding, flooring, lighting system and wayfinding system.

Design proposal

This interior design project covers the floor area of 68,000 m2 . The overall strategy of the interior design is to provide contemporary interior solution with intuitive wayfinding system for the interchange station which includes multiple metro lines and national rails. The design embraces the natural features of the mountains into the interior finishes. The sweeping forms of the mountains are reflected in the soffit geometry, together

with the Lantern-like feature light system doubles as an intuitive wayfinding device. Colours used within the space are natural and reflect the green of vegetation and the buff of the natural rock. An overall theme of threads through all the elements to unify the language and link to local craft culture.

Budget:

Interior

2024 20 million

Project Year: Project

Design Guangzhou Metro Group

Work involved: Concept development Revit drawings Rhino modelling Visualization (Enscape) Diagrams Design report

WAYFINDING SOFFIT

DIAGRAMMATIC RCP Overlay 广州地铁白云站

Guangzhou Metro Baiyun Station

4. Lighting Strategy - Feature Lights - Nodal

4. Lighting Strategy - Feature Lights - Nodal Type

照明策略 - 主题灯具

LED 灯具和支架

LED Light Fixtures & Frame

LED 灯具和支架 LED Light Fixtures & Frame

涂色金属反光罩 Patinated Metal Reflector

金属编织灯光扩散器 Woven Metal Diffuser Dish

吊顶 Soffit

主题灯具效果图 I Visualisation

主题灯具效果图 I Visualisation

LED 灯具和支架

LED Light Fixtures & Frame

LED 灯具和支架 LED Light Fixtures & Frame

涂色金属反光罩 Patinated Metal Reflector

金属编织灯光扩散器 Woven Metal Diffuser Dish

照明灯具轴测图 I Light Fixture Diagrammatic Axonometric

WAYFINDING FEATURE LIGHT SYSTEM

主题灯具剖面图 I Section

照明灯具轴测图 I Light Fixture Diagrammatic Axonometric 主题灯具剖面图 I Section

广州地铁白云站 Guangzhou Metro Baiyun Station 77

Baiyun

白云站

Station -

照明策略 - 主题灯具

Type

Guangzhou Metro Baiyun Station 77

广州地铁白云站 |

Baiyun Station - 白云站

03 | SELECTED PROJECT IN Campbell Architects

Large-scale Residential Development

Location:

Client:

Background

Osborne development is a large-scale residential project appointed by the client Kitewood Estates Private Development in relation to the Reserved Masters Application for land south of Osborne Gardens, Hillborough, Herne Bay. It is part of the major extension to the coastal area of Herne Bay.

Design proposal

The proposal includes the development of 180 dwellings on greenfield site part of wider master plan of circa 3000 houses. The site layout follows the approved Land Use Parameter Plan which gives structure to the density of homes within the site. Two character areas are proposed within the site, which are defined to reduce

the scale of the residential development, relative to the wider Masterplan.

The areas are split strategically by a generous green space and linked by a single road to encourage access routes from opposite sides of the scheme. Pedestrian and access is promoted throughout the scheme.

Category:

Project Year: Project Budget:

Residential Kitewood 2022 40 million

Herne Bay, England

Work involved: Concept development AutoCAD drawings Visualization (Vray, Enscape) SketchUp modelling Diagrams drawings Design code Design access statement Planning package

Use & Amount

WR WR Lobby Entrance Canopy Above Plot: 099 2B4P (M4(2)) Plot: 102 1B2P (M4(2)) Lobby Storage Bathroom Buggy Store Stairs Post Bathroom Balcony Above Balcony Above Riser Bathroom Storage Storage Storage Bathroom Plot: 101 1B2P (M4(2)) Living Dining Kitchen 26.1 sqm Bedroom 1 12.2 sqm Living Dining Kitchen 22.7 sqm Bedroom 1 12.1 sqm Living Dining Kitchen 28.0 sqm Bedroom 13.2 sqm Bedroom 2 13.8 sqm Living Dining Kitchen 30.5 sqm Bedroom 1 13.6 sqm Bedroom 2 13.3 sqm WM WM WR WR WR WM WM WR Plot: 100 2B4P (M4(2)) Bin/Cycle Store Dry riser Plot 110-113 Refer to 1386-DR-A-100-204 Ground Floor Plan Fan Coil Unit Finishes Schedule Please refer to drawings 1386-DR-A-30-105, 106, 107 1 4 Apartment typical floor plan Site plan Design Statement Site layout highlighting the various types and quantities proposed throughout the site The proposed use and amount of development respects the prevailing character of existing residential areas nearby, and maintains residential use throughout. The distribution and use are also aligned with the consented Land Use Parameter Plan. The proposed mix promotes varied scale, mass and density throughout the site and is considered in conjunction with the uses proposed within the large areas of open space within the Each dwelling is designed to meet or exceed the national 'Technical Below are the types and quantities that make up the 180 Total:

Chalvington - 3 bed Square Field - 3 bed Cuckmere - 2 bed Wilmington - 4 bed Arlington - 4 bed Cuckmere and Chalvington - 2 and 3 bed KEY N 13 dwellings of which 9 are affordable 20 dwellings of which 12 are affordable 8 dwellings of which 0 are affordable 33 dwellings of which 11 are affordable 68 dwellings of which 17 are affordable 40 dwellings of which 5 are affordable 180 dwellings of which 54 are affordable Design Statement 15 The proposed use and amount of development respects the prevailing character of existing residential areas nearby, and maintains residential use throughout. The distribution and use are also aligned with the consented Land Use Parameter Plan. The proposed mix promotes varied scale, mass and density throughout the site and is considered in conjunction with the uses proposed within the large areas of open space within the scheme. Each dwelling is designed to meet or exceed the national 'Technical Housing Standards 2015.' Below are the types and quantities that make up the 180 properties: 1 bedroom flats: 2 bedroom flats: 3 bedroom flats: 2 bedroom houses: 3 bedroom houses: 4 bedroom houses: Total:

Chalvington - 3 bed Square Field - 3 bed Cuckmere - 2 bed Wilmington - 4 bed Arlington - 4 bed Cuckmere and Chalvington - 2 and 3 bed Apartment Blocks - 2 and 3 bed KEY N Site layout highlighting the various types and quantities proposed throughout the site 13 dwellings of which 9 are affordable 20 dwellings of which 12 are affordable 8 dwellings of which 0 are affordable 33 dwellings of which 11 are affordable 68 dwellings of which 17 are affordable 40 dwellings of which 5 are affordable 180 dwellings of which 54 are affordable

7.0 Use & Amount

urban housetypes of curate the dwellings, individual and within will be lead to areas application sequence materiality typology.

8.2 Materials: Character Area 1

Brickwork

Manufacturer: IBSTOCK

Product: Morpeth

Use: Facing brickwork to external walls

Style: Stretcher bond with bucket handle pointing, natural non-coloured mortar

Manufacturer: IBSTOCK

Product: Cooksbridge Buff

Use: Facing brickwork to external walls

Style: Stretcher bond with bucket handle pointing, natural non-coloured mortar

Cladding

Manufacturer: James Hardie

Product: Hardieplank Family - Arctic White

Use: Vertical cladding to external walls

Style: 178mm with 30mm overlap

Manufacturer: James Hardie

Product: Hardieplank Family - Anthracite Grey

Use: Horizontal cladding to external walls

Style: 178mm with 30mm overlap

Roofing

Manufacturer: SVK - Fibre Cement Greys

Product: Montana Textured Blue and Black Use: Roof tiling to pitched roofs

Style: Lapped - 600 x 300mm with Riven edge

Manufacturer: Redland

Product: Rosemary Clay Classic Russet mix

Use: Roof tiling to pitched roofs

Style: 265 x 165mm with min. 65mm overlap

Design Statement 17

RL 9.2 EL 5.2 RL 9.2 EL 5.2 RL 9.2 EL 5.2 RL 9.2 EL 5.2 ELEC Proposed Front Elevation Proposed Side Elevation Proposed Rear Elevation Proposed Side Elevation Windows removed on plot 56, 79, 143, 145) Windows removed on plot 78, 142, 144 to mitigate overlooking) Finishes Schedule Please refer to drawings 1386-DR-A-30-105, 106, 107 Project No Scale A3 Issue Drawing No 1386 1:100 PLANNING 00 1386-DR-A-100-102 KITEWOOD Land South Of Osborne Gardens, Hillborough, Herne Bay Proposed Chalvington Elevation detailed site surveys must carried existing drawing informtion indicative subject detailed survey. Drawing for information only. General Note drawing and noted the Designer Risk Assessments and health and safety plan, note following: - a - Where applicable, significant residual risks are highlighted body drawing. campbellarchitects

Arlington Square Field Wilmington RL 9.3 EL 5.2 RL 9.3 EL 5.2 RL 9.3 EL 5.2 RL 9.3 EL 5.2 Proposed Front Elevation Proposed Rear Elevation Proposed Side Elevation Proposed Side Elevation ( Windows removed on plot 55) Finishes Schedule Please refer to drawings 1386-DR-A-30-105, 106, 107 Project No Scale A3 Issue Drawing Status Drawing No 1386 1:100 PLANNING 00 1386-DR-A-100-106 Client Job Title Drawing Title KITEWOOD Land South Of Osborne Gardens, Hillborough, Herne Bay Proposed Cuckmere Elevation Safety, Health and Environmental Information levels dimensions are approximate, detailed site surveys must carried Contractor before commencement building works. levels dimensions Drawing information only. scale from drawing. - assured that works on this carried a competent Contractor workingcampbellarchitects RL 8.8 EL 5.3 RL 8.8 EL 5.3 ELEC RL 8.8 RL 8.8 EL 5.3 Proposed Front Elevation Proposed Side Elevation Proposed Rear Elevation Proposed Side Elevation Finishes Schedule Please refer to drawings 1386-DR-A-30-105, 106, 107 Project No Drawing No 1386 PLANNING 1386-DR-A-100-116 KITEWOOD Land South Of Osborne Gardens, Hillborough, Herne Bay Proposed Arlington Elevation Safety, Health and Environmental Information existing drawing informtion indicative subject detailed survey. General Note drawing and noted the Designer Risk Assessments and health and safety plan, note following: - a - Where applicable, significant residual risks are highlighted body drawing. campbellarchitects EL 5.2 RL 8.6 EL 5.2 ELEC RL 8.6 RL 7.5 RL 8.6 RL 7.5 EL 5.2 Proposed Front Elevation Proposed Side Elevation (Windows removed on plot 28, 29) Proposed Rear Elevation Proposed Side Elevation Finishes Schedule Please refer to drawings 1386-DR-A-30-105, 106, 107 Project Scale A3 Issue Drawing Status Drawing No 1386 1:100 PLANNING 00 1386-DR-A-100-112 Job Title Drawing Title KITEWOOD Land South Of Osborne Gardens, Hillborough, Herne Bay Proposed Wilmington Elevation Safety, Health and Environmental Information levels and dimensions are approximate, detailed site surveys must carried Contractor before commencement building works. levels and dimensions existing drawing informtion indicative and subject detailed site survey. Drawing information only. following: - acampbellarchitects RL 8.7 EL 5.2 RL 8.7 EL 5.2 ELEC RL 8.7 EL 5.2 RL 8.7 EL 5.2 Proposed Front Elevation Proposed Side Elevation Proposed Rear Elevation Proposed Side Elevation Finishes Schedule Please refer to drawings 1386-DR-A-30-105, 106, 107 Project No Scale at A3 Issue Drawing Status Drawing No 1386 1:100 PLANNING 00 1386-DR-A-100-109 Drawing Title KITEWOOD Land South Of Osborne Gardens, Hillborough, Herne Bay Proposed Chalvington and Cuckmere Elevation Safety, Health and Environmental Information Contractor before commencement building works. levels and dimensions existing drawing informtion indicative and subject detailed site survey. This drawing copyrighted. General Note addition the hazards/risks normally associated with the types work detailed this following: - a where appropriate, be approved method statement. - Where applicable, significant residual risks are highlighted the body the drawing. campbellarchitects RL 8.7 EL 5.2 RL 8.7 EL 5.2 RL 8.7 EL 5.2 RL 8.7 EL 5.2 Proposed Front Elevation Proposed Side Elevation Proposed Rear Elevation Proposed Side Elevation Finishes Schedule Please refer to drawings 1386-DR-A-30-105, 106, 107 Project No Scale A3 Issue Drawing No 1386 1:100 00 1386-DR-A-100-121 KITEWOOD Land South Of Osborne Gardens, Hillborough, Herne Bay Proposed Squarefield Elevation are approximate, detailed surveys must carried out All existing drawing informtion indicative and subject the detailed site survey. Drawing information only. General Note drawing noted Designer Risk Assessments and health and safety plan, note the following: - a - Where applicable, significant residual risks highlighted the body the drawing. campbellarchitects Apartment Block (Private) Apartment Block (Affordable) RL 12.7 EL 9.1 EL 5.4 campbellarchitects Land South Osborne Gardens, Hillborough, Herne Bay Proposed Affordable Apartment Unit Block - aPLANNING Please refer drawings 1386-DR-A-30-105, 106, 107 RL 12.7 EL 9.1 1386 campbellarchitects 1386-DR-A-100-222 Land South Osborne Gardens, Hillborough, Herne Bay Proposed Private Apartment 10 Unit Block Plot 161-170: South Elevation Safety, Health and Environmental Information - aFinishes Schedule Please refer to drawings 1386-DR-A-30-105, 106, 107

Chalvington and Chalvington Cuckmere and Cuckmere

Chalvington

and Cuckmere

R1 B1 L1 D1

Material

ST CT Refer to drawing 1386-DR-A-30-106 House Types

Combinations

03 | SELECTED PROJECT IN Campbell Architects

Ickenham Office and Industrial Warehouse Development

Location: Category:

Client:

Project Year:

Ickenham, England

Commercial, Industrial Keltbray 2022

Ickenham development is an industrial and commercial project appointed by client Keltbray. The site is located to the north of Ickenham, a residential suburb situated between Uxbridge and Ruislip.

The subject lands have been vacant for 2 years. The existing buildings sit within a convoluted layout that are not only small in size but unsuitable for re-use for a modern employment operator.

The proposal aims to upgrade the spatial quality within the site by providing significant percentage of the landscape area and updating existing buildings. The scheme includes an office block based on existing structure and 4 newly built industrial warehouses.

Work involved: Concept development AutoCAD drawings Visualization (Enscape) SketchUp modelling Diagrams drawings Design code Design access statement Planning package

1 2 Y5 Y2 Y4 Y3 5 4 4.80m 3.8m (existing width to address RPZ locations) 2.00m 7.20m 6.0m locally to tie into existing roadway Guard Proposed Access to HS2 lands PARKING 2 FFL: 52.15 FFL: 51.00 FFL: 45.50 FFL: 53.00 FFL: 48.50 FFL: 53.50 45.5 53.20 52.50 51.90 51.50 50.80 49.5 45.5 45.8 46.0 45.50 50.80 48.0 48.3 48.0 41.000 41.000 41.500 42.000 42.500 43.000 43.000 43.500 43.500 44.000 44.500 45.000 45.000 45.500 46.000 46.500 47.000 47.500 48.000 48.000 48.500 49.000 49.000 49.500 50.000 50.000 50.000 50.500 50.500 50.500 51.000 51.000 51.000 51.500 51.500 51.500 52.000 52.000 52.000 52.000 52.000 52.500 52.500 53.000 53.000 53.000 53.000 53.000 53.500 53.500 53.500 53.500 53.500 53.500 53.500 53.500 53.500 53.500 54.000 54.000 54.000 54.500 54.500 54.500 54.500 54.500 55.000 55.000 55.000 55.000 55.500 55.500 56.000 56.000 56.500 56.500 57.000 57.500 58.000 58.500 59.000 59.500 EX.FFL: 55.4 MOTORCYCLEPARKING (TWOSTORE TIER) COVERED STORE WASH WASHSTORECOVERED 10 11 13 15 16 19 48 PRESENTATION OS OS 53.000 43.000 PARKING 0 50 1 Key Roads Do not scale Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A0 Issue Drawing Status Drawing No 55 Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - It is assured that all works on this will be carried out by a competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted in the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing informtion is indicative and subject to the detailed site survey. - Drawing is for information only. - Do not scale from this drawing. - This drawing is copyrighted. 1:500 1381-DR-A-00-015 USE KEY: BUILDING 01 Office BUILDING 02 Plant Workshop BUILDING 03 GF:Small Tools Workshop Storage FF:Split in half - Spray Shop Small Tools BUILDING 04 GF:Storage FF:Workshop BUILDING 05 Structures, Fabrication (Overhead Gantry Crane required) YARD 01 Car Parking YARD 02 Plant storage Yard, RTC Machines, Attachments YARD 03 Storage for small tools (Lorries, HIABS, Delivery Vans) YARD 04 Structures Storage, Falsework, Panels, Scaffold YARD 05 Structures Storage. Formwork, Spec Protection, Concrete Plant, Pumps, Booms New Buildings Woodland Proposed Trees Ponds Parking Proposed Topography Retained Buildings Keltbray Former MSD Facility, Breakspear Road South, Ickenham SN 00 28/09/22 MMRS Proposed Site Layout PLANNING 1381 00

0 24 10M FFL +0.00 Bottom edge Insulated Cladding Panels +2.50 Top Masonry Wall Precast Concrete Cladding +2.69 FFL +3.95 B C F G GL -0.15 RL +8.85 Bottom edge of Insulated Cladding Panels +2.50 Top Masonry Wall Precast Concrete Cladding +2.69 A B F G H Top Masonry Wall Precast Concrete Cladding +4.45 (Where associated with window openings) Window head level +7.50 +3.45 DateByChkdAppdIssueDateByChkdAppd Client Job Title Drawing Title Project No Scale at A0 Issue Drawing Status Keltbray Drawing No 1381 Former MSD Facility, Breakspear Road South, Ickenham campbell architects Safety, Health and Environmental Information General Note detailed Assessments and safety working where appropriate, be an approved method statement. significant highlighted in the body the drawing. - levels and dimensions are approximate, detailed site must be carried out by Contractor before commencement building works. All levels and - All existing drawing subject the detailed site survey. - Drawing for information only. - Do not scale from this drawing. - This drawing copyrighted. Stage 3+ 1:50 00 SN 00 RSCC 1381-DR-A-30-105 Building 1: General Arrangement North & South Elevations 01 Proposed GA Elevation: North Scale 1:50 01 0 24 10M GL -0.15 Bottom edge Insulated Cladding Panels +2.50 Top Masonry Wall Precast Concrete Cladding +2.69 CL +3.45 PL +9.53 A B G H Top of Masonry Wall Precast Concrete Cladding +4.45 (Where associated with window openings) FFL +3.95 Issue DateByChkdAppdIssueDateByChkdAppd Client Drawing Title Project No Drawing Status Keltbray Drawing No 1381 Former MSD Facility, Breakspear Road South, Ickenham campbell architects Safety, Health and Environmental Information General Note addition the hazards/risks normally associated with the types of work detailed this drawing and noted Designer and safety plan, note the following: - assured that works on this will be carried out by competent Contractor working where appropriate, be an approved method statement. - Where applicable, significant residual risks are highlighted in the body the drawing. - levels and dimensions approximate, detailed surveys by building dimensions confirmed on site. - All existing drawing information is indicative and subject the detailed site survey. - Drawing for information only. - Do not scale from this drawing. - This drawing copyrighted. Stage 3+ 1:50 00 SN 06/04/23 RSCC 1381-DR-A-30-105 Building 1: General Arrangement North & South Elevations 01 Proposed GA Elevation: North Scale 1:50 01 Proposed GA Elevation: South Scale 1:50 +9.53 Top Masonry Wall Precast Concrete Cladding +4.45 (Where associated with window openings) Window head level +7.50 +9.53 Top Masonry Wall Precast Concrete Cladding +2.69 Top Masonry Wall Precast Concrete Cladding +4.45 (Where associated with window openings) FFL +3.95 DateByChkdAppdIssueDateByChkdAppd campbell architects Safety, Health and Environmental Information normally types drawing the Designer Risk Assessments and health and safety plan, note the following: - by competent Contractor working where appropriate, to an approved method statement. - Where applicable, significant residual risks are highlighted the body the drawing. - approximate, site surveys must be carried out Contractor before commencement building works. All levels and - All existing drawing subject to the detailed site survey. - Drawing information only. - Do not scale from this drawing. - This drawing copyrighted. SN 00 06/04/23 RSCC 01 Proposed GA Elevation: East Scale 1:50 02 Proposed GA Elevation: West Scale 1:50 Building Fabric Specification (Refer to detailed manufacturer specification for further information) Element U-Value -Kingspan Quadcore KS1000 RW - 115mm Wall 0.26 -Kingspan Quadcore AWP -KS600-1000MR Wall Panel, Micro-Rib - 74mm -Forticrete Fairfaced Dense Concrete Block 'Flint' (390mm 190mm 90mm) -Insulated Cavity - 50mm Kooltherm K108 insulation -Creagh Pre-cast Concrete Panel - 150mm (Rekli Formliner (Rib Type N)) Wall 3:(Buildings & only) -Reinforced concrete retaining wall - 300mm -Cellecta Hexatherm XPeri (External) - 70mm Ground Floor: 0.18 -RC Concrete Slab - 250mm (with Sikafloor -1 MetalTop, one part, pre-blended metallic dry shake hardener) -Cellecta Hexatherm Xfloor 300 (20mm) insulation -160mm dufaylite clayboard OSA (to S/E specification) Openings: -Norton Industrial Doors Insulated Roller Shutter Door Personnel Doors 1.4 -Strongdor Climador Roof lights -Kingspan Day-Lite Trapezoidal Rooflight (KS1000 DLTR Opal) Curtain Walling 1.6 -Reynaers ConceptWall 50 Curtain Walling system -Reynaers ConceptSystem 77 window system RL +8.85 PL +9.53 1 2 3 4 3805.0 6285.0 2170.0 5 5750.0 GL -0.15 FFL +0.00 RL +8.85 PL +9.53 Bottom edge of Insulated Cladding Panels +2.50 Top of Masonry Wall Precast Concrete Cladding +2.69 Top of Masonry Wall Precast Concrete Cladding +4.45 (Where associated with window openings) Window head level +7.50 FFL +3.95 CL +3.45 1 5 01 Proposed GA Elevation: East Scale 1:50 Building Fabric Specification (Refer to detailed manufacturer specification for further information) Element U-Value (W/m2K) Roof: 0.18 -Kingspan Quadcore KS1000 RW - 115mm Wall 1: 0.26 -Kingspan Quadcore AWP -KS600-1000MR Wall Panel, Micro-Rib - 74mm Wall 2: 0.24 -Forticrete Fairfaced Dense Concrete Block 'Flint' (390mm 190mm x 90mm) -Insulated Cavity - 50mm Kooltherm K108 insulation -Creagh Pre-cast Concrete Panel - 150mm (Rekli Formliner (Rib Type N)) Wall 3:(Buildings 3 & 4 only) 0.26 -Reinforced concrete retaining wall - 300mm -Cellecta Hexatherm XPeri (External) - 70mm Ground Floor: 0.18 -RC Concrete Slab - 250mm (with Sikafloor -1 MetalTop, one part, pre-blended metallic dry shake hardener) -Cellecta Hexatherm Xfloor 300 (20mm) insulation -160mm dufaylite clayboard OSA (to S/E specification) Openings: Access Doors 0.69 -Norton Industrial Doors Insulated Roller Shutter Door Personnel Doors 1.4 -Strongdor Climador Roof lights 1.6 -Kingspan Day-Lite Trapezoidal Rooflight (KS1000 DLTR Opal) Curtain Walling 1.6 -Reynaers ConceptWall 50 Curtain Walling system Windows 1.3 -Reynaers ConceptSystem 77 window system GL -0.15 RL +8.85 Bottom edge Insulated Cladding Panels +2.50 Top of Masonry Wall Precast Concrete Cladding +2.69 (Where associated with window openings) Window head level +7.50 +3.45 Bottom edge Insulated Cladding Panels +2.50 Top of Masonry Wall Precast Concrete Cladding +2.69 Top of Masonry Wall Precast Concrete Cladding +4.45 (Where associated with window openings) Issue DateByChkdAppdIssueDateByChkdAppd campbell architects Safety, Health and Environmental Information addition the hazards/risks normally associated with types of work drawing Designer and safety plan, note the following: - is assured that all works on this will be carried out by competent working appropriate, be an approved method statement. - Where applicable, significant residual risks are highlighted the body the drawing. - approximate, surveys by commencement on building works. All levels and dimensions be confirmed on site. - All existing drawing information subject the detailed site survey. - Drawing is for information only. - Do not scale from this drawing. - This drawing copyrighted. SN 06/04/23 RSCC 01 Proposed GA Elevation: East Scale 1:50 02 Proposed GA Elevation: West Scale 1:50-Creagh Pre-cast Concrete Panel - 150mm (Rekli Formliner (Rib Type N)) Wall 3:(Buildings only) 0.26 -Reinforced concrete retaining wall - 300mm -Cellecta Hexatherm XPeri (External) - 70mm Ground Floor: -RC Concrete Slab - 250mm (with Sikafloor MetalTop, one part, pre-blended metallic dry shake hardener) -Cellecta Hexatherm Xfloor 300 (20mm) insulation -160mm dufaylite clayboard OSA (to S/E specification) Openings: Access Doors 0.69 -Norton Industrial Doors Insulated Roller Shutter Door Personnel Doors 1.4 -Strongdor Climador Roof lights 1.6 -Kingspan Day-Lite Trapezoidal Rooflight (KS1000 DLTR Opal) Curtain Walling 1.6 -Reynaers ConceptWall 50 Curtain Walling system Windows 1.3 -Reynaers ConceptSystem window system Elevations / Floor plans / Specifications Food Service Counter up Canteen Meeting room Entrance Kitchen Storage Storage Post Acc WC WC A A Meeting room Meeting room WC WCWC SH Acc WC/SH up Meeting Office Storage Void Male WC Female WC CC Acc WC Storage Booth Booth Booth Booth A A Issue Issue Drawing No 55 Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbell architects Safety, Health and Environmental Information General Note addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - is assured that all works on this will be carried out by competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted in the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions be confirmed on site. - All existing drawing information indicative and subject to the detailed site survey. - Drawing for information only. - Do not scale from this drawing. - This drawing is copyrighted. 00 1381-DR-A-01-010 LEVEL 0 LEVEL 1 00 012 Food Service Counter up Canteen Meeting room Entrance Kitchen Storage Storage Post Acc WC WC A A Meeting room Meeting room WC WCWC SH Acc WC/SH up Meeting Office Storage Male WC Female WC CC Acc WC Storage Booth Booth Booth Booth A A LEVEL LEVEL 1

HL (+2.287) 00 (+0.00) 01 (+4.575) 300.0 Lowest Point 300.0 1100.0 1200.0 300.0 300.0 2000.0 1300.0 2500.0 1300.0 2500.0 10 11 12 13 14 21 20 19 18 17 16 15 22 23 24 25 26 27 28 A A 3550.0 7740.0 54 32 A A 3550.0 7740.0 not scale Issue DateBy Chkd Appd Issue DateBy Chkd Appd Client Job Title Drawing Title Project No Scale at A0 Issue Drawing Status Keltbray Drawing No 1381 Former MSD Facility, Breakspear Road South, Ickenham campbell architects Safety, Health and Environmental Information General Note addition normally the types of work detailed this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - assured that all works on this will be carried out by competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted in the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before building dimensions be confirmed on site. - All existing drawing information indicative and subject to the detailed site survey. - Drawing is for information only. - Do not scale from this drawing. - This drawing is copyrighted. Stage 3+ 1:20 00 SN 00 06/04/23 RSCC Notes to Contractor: - Stair balustrade to comply with Approved Document Part K - Final design subject to fire consultant input regarding width of stairs and riser/going - Signage strategy subject to client input 01 B4 Typical Core Section A-A 1:20 03 B4 Typical Stair Core Ground Floor Plan 1:20 02 B4 Typical Stair Core First Floor Plan 1:20 1381-DR-A-24-604 Proposed B4 Stair Core Typical Details Accessible door Accessible door Concrete staircase, to S/E design Stair nosings as per approved docs Half landing support to S/E design & specification Riser: 163.4 mm Going: 280 mm Steel beam behind 2000mm clear head height Stair nosings 2900 FFL +0.05 FFL +2.49 DL +2.25 2377 2900 FFL +0.05 FFL +2.49 DL +2.25 3400 2900 FFL +0.05 FFL +2.49 DL +2.25 2377 1023 882 473 2900 FFL +0.05 FFL +2.49 DL +2.25 3400 C A B D D4 D3 473 1023 882 2377 3400 977 1023 1400 1048 1852 500 1600 777 Do not scale Issue DateBy Chkd Appd Issue DateBy Chkd Appd Client Job Title Drawing Title Project No Scale at A0 Issue Drawing Status Keltbray Drawing No 1381 Former MSD Facility, Breakspear Road South, Ickenham campbell architects Safety, Health and Environmental Information General Note the hazards/risks normally associated with the types work detailed this drawing and noted the Designer Risk Assessments and health and safety plan, note the following: - out by competent Contractor working where appropriate, be an approved method statement. - Where applicable, significant residual risks are highlighted the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement building works. All levels and dimensions to be confirmed on site. - All existing drawing information is indicative and subject the detailed site survey. - Drawing for information only. - Do not scale from this drawing. - This drawing copyrighted. Stage 3+ 1:20 1:10 00 SN 00 06/04/23 RSCC 1381-DR-A-70-609 Proposed B2 Welfare Facilities DetailsChanging Room 04 Changing Room Elevation C 1:20 02 Changing Room Elevation A 1:20 03 Changing Room Elevation B 1:20 05 Changing Room Elevation D 1:20 05 01 05 07 01 02 03 06 06 07 04 Changing Room Plan 1:10 Key 01 02 03 04 Stud wall Mirror Seating Hand dryer 05 06 07 08 Lockers Basin Sofa D4 01 06 05 07 03 3350 3950 FFL +0.05 CL +2.75 DL +2.25 3950 3810 2550 1880 3350 3810 FFL +0.05 CL +2.75 DL +2.25 3350 3950 FFL +0.05 CL +2.75 DL +2.25 3350 3810 FFL +0.05 CL +2.75 DL +2.25 Do not scale Issue DateBy Chkd Appd Issue DateBy Chkd Appd Client Job Title Drawing Title Project No Scale at A0 Issue Drawing Status Keltbray Drawing No 1381 Former MSD Facility, Breakspear Road South, Ickenham campbell architects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types work detailed this drawing and noted the Designer Risk Assessments and health and safety plan, note the following: - assured that all works on this will be carried out by competent Contractor working where appropriate, be an approved method statement. - Where applicable, significant residual risks highlighted the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement building dimensions to be confirmed on site. - All existing drawing information is indicative and subject the detailed site survey. - Drawing for information only. - Do not scale from this drawing. - This drawing copyrighted. Stage 3+ 1:20 1:10 00 SN 00 06/04/23 RSCC 1381-DR-A-70-606 Key 01 02 03 04 Stud wall Mirror Hand dryer Sink 05 06 07 Accessible Toilet Toilet Doors Toilet Proposed B1 Welfare Facilities Details First Floor Toilet 04 02 03 05 B1 First Floor Typical WC Plan 1:10 B1 First Floor Typical WC Elevation A 1:20 B1 First Floor Typical WC Elevation B 1:20 B1 First Floor Typical WC Elevation C 1:20 B1 First Floor Typical WC Elevation D 1:20 01 01 02 03 04 06 03 04 05 03 07 04 C A B D D1 3395 3623 290 1450 300 1023 560 1135 1200 1065 2900 FFL +0.05 FFL +2.49 DL +2.25 3400 2900 FFL +0.05 FFL +2.49 DL +2.25 3623 2900 1450 750 1065 FFL +0.05 FFL +2.49 DL +2.25 1200 1135 3400 2900 FFL +0.05 FFL +2.49 DL +2.25 3623 1450 750 not scale Issue DateBy Chkd Appd Issue DateBy Chkd Appd Client Job Title Drawing Title Project No Scale at A0 Issue Drawing Status Keltbray Drawing No 1381 Former MSD Facility, Breakspear Road South, Ickenham campbell architects Safety, Health and Environmental Information General Note addition to the hazards/risks normally the types of work detailed this drawing and noted the Designer Risk Assessments and health and safety plan, note the following: - assured that all works on this will be carried out by competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted in the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before building dimensions be confirmed on site. - All existing drawing information indicative and subject to the detailed site survey. - Drawing is for information only. - Do not scale from this drawing. - This drawing is copyrighted. Stage 3+ 1:20 1:10 00 SN 00 06/04/23 RSCC 1381-DR-A-70-623 Proposed B5 Welfare Facilities DetailsOffice Officee Plan 1:10 Key 12 13 14 Book shelves Storage Office chair & desk 04 02 Office Elevation A 1:20 03 Office Elevation B 1:20 05 Office Elevation C 1:20 Office Elevation D 1:20 13 12 14 15 01 12 13 14 Detail arrangement

03 | SELECTED PROJECT IN Campbell Architects

Listed Building Restoration and Mixed-use Development

Background and Site

Location:

Category:

Client:

Project Year: London, England Restoration, Mixed-use Kitewood 2022

London 446 Fulham Road Development is a design competition based on the site which comprises the existing listed building Sir Oswald Stoll Mansions used as services veterans, the charities administration facilities, NHS medical centre and various ancillary communal facilities for use by the charity. The site is 0.71 Hectares and includes a total of 137 residential units.

The flats and facilities are considered obsolete and not ‘fit for purpose’ with a key objective of the new scheme to deliver efficient new space as demonstrated within our proposal.

A further 20 Veterans apartments are located in Bush House, located on the sites access road, adjacent and to the west, outside of the site boundary.

Design Proposal

Our proposals seek to intensify the existing use of ‘previously developed land’ and under-used buildings to deliver high quality homes and supporting accommodation. An increased footprint is supported as a starting point by the council, who wish to resist the net loss of permanent residential accommodation as a result of new redevelopment.

Work involved: Concept development AutoCAD drawings SketchUp modelling Visualization (Photoshop) Diagrams drawings Competition package preparation

DESIGN METHODOLOGY

High quality design utilising suitable materials such as brick and stone to offer a natural transition with the Grade II listed Mansion building on Fulham Road.

‘Stepped’ building heights away from Fulham Road of suitable building height, with full consideration of the surrounding environment and townscape.

Suitable building relationships considered in the context of outlook, relationship with the surrounding urban grain and to offer appropriate ‘Sunlight and daylight’ reflecting initial due diligence.

Introduction of permeability with a large central garden to form a key feature of the site. The move away from linear building forms offers multiple views into the central amenity spaces, for the enjoyment of tenants and the local community.

Promote a high quality scheme that reflects its central and sustainable urban location which provides a depth of amenities and good transport infrastructure reflected by PTAL rating, 5/6a alongside its well recognised address.

Communal space view

Communal space view Medical centre and formal garden view Formal garden view

03 | SELECTED PROJECT IN Campbell Architects

This project is a modern private house situated in Holywood, Northern Ireland, designed to sit on sloping topography. The house is a two-storey building with a total Gross Internal Area (GIA) of 300 square meters. The design of the house includes an open plan living room and kitchen on the upper floor, with large glazing that provides magnificent views of Belfast loch.

The upper floor also features a balcony that runs across the living room and TV room, creating an outdoor dining and leisure space. The main entrance to the house is on the upper floor, while the lower floor comprises three bedrooms and a potential fourth bedroom. The circulation core of the house is located in the centre, allowing easy movement between the different areas.

The house’s design is focused on creating a comfortable and modern living space that maximizes the benefits of its location. The large glazing of the living room and TV room introduces plenty of natural light and allows for an unobstructed view of the surroundings. The balcony provides a perfect place for outdoor entertainment and relaxation.

Category: Client: Project Year: Holywood, Northern Ireland Residential Private 2023 45 Old Quay Road House Work involved: Concept development Revit / AutoCAD drawings 3D modelling Visualization (Vray) Diagrams drawings Planning application package

Location:

UP UP TV Fireplace 0123 45m Issue DateByChkdAppdIssueDateByChkdAppd Client Job Title Drawing Title Project No Scale at A3 Issue Drawing Status Drawing No www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer safety plan, note the following:It is assured that all works on this will be carried out by a competent Contractor working where appropriate, to approved method statement.Where applicable, significant residual risks are highlighted in the body of the drawing.approximate, surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site.All existing drawing information is indicative and subject to the detailed site survey.Drawing is for information only.Do not scale from this drawing.This drawing is copyrighted. XX 00 00/00/00 XXXX Campbell Architects 1335 Old Quay Road PLANNING 1:100 1335-DR-A-00-000 Proposed First Floor Plan 00 UP WR WR UP WR 0123 45m Do not scale Issue DateByChkdAppdIssueDateByChkdAppd Client Job Title Drawing Title www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note normally associated the types of work detailed on this drawing and noted in the Designer safety plan, note the following:It is assured that all works on this will be carried out by a competent Contractor working where appropriate, to be an approved method statement.Where applicable, significant residual risks are highlighted in the body of the drawing.All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site.All existing drawing information is indicative and subject to the detailed site survey.Drawing is for information only.Do not scale from this drawing.This drawing is copyrighted. XX 00 00/00/00 XXXX Campbell Architects Old Quay Road Proposed Ground Upper floor plan Lower floor plan

Visualisation (Vray)

Proposed South Elevation

Proposed North Elevation

| SELECTED PROJECT IN Campbell Architects

Trory Lodge is a private residential restoration project in Cultra area, Northern Ireland. The clients aim to restore their vacant old house which was designed and built in 1948. The proposal is to maximise the existing structure for minimising the budget while upgrade the spatial quality of dwelling. Therefore, the design team focused on the rearrangement of the window opening and internal space arrangement. Demolition plan and detailed construction drawings have been provided.

Location: Category: Client: Project Year: Cultra , Northern Ireland Residential Private 2023 Restoration of a residential house 873 2135 W-01 W-02 EXD-01 W-05 EXD-02 1897 1245 2135 2478 2135 2478 2135 1866 2135 3523 2040 906 1533 1245 1245 * * * * * * * **** **** Δ Emergency Egress Window (see note) W-15 1245 890 2135 2478 * W-13 1559 576 2135 1263 * 2135 1500 W-12 1559 576 2135 1263 * W-10 1559 505 2064 3348 * W-08 1050 1050 2100 1800 FFL * ** * * * * *See note re. Safety Glazing EXD-05 **** **** **** **** Work involved: Technical drawings FFL * EXD-01 W-05 EXD-02 EXD-03 W-06 2478 890 2135 1866 2135 3523 2040 906 890 2135 1866 1245 1533 602 1245 *** **** * * * * * * * * * * * * * external steps 2 no. risers, 280mm going, 125mm rise external steps 2 no. risers, 280mm going, 125mm rise external steps 2 no. risers, 280mm going, 125mm rise 2878 *** * *** * *** * Δ Emergency Egress Window (see note) Δ Emergency Egress Window (see note) 890 890 576 576 505 FFL **** Do not scale Issue DateByChkdAppdIssueDateByChkdAppdClient 55 Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following:

It is assured that all works on this will be carried out by a competent Contractor working where appropriate, to be an approved method statement.

Where applicable, significant residual risks are highlighted in the body of the drawing.

All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and

to be confirmed on site.

NJ 00 27/01/23 RSCC

dimensions

- All existing drawing information is indicative and subject to the detailed site survey. - Drawing is for information only. - Do not scale from this drawing. - This drawing is copyrighted.

Emergency Egress Window (see note) W-01 See note re. Safety Glazing EXD-03 1897 2478 2478 890 1866 3523 906 1866 * external steps no. risers, 280mm going, 125mm rise external steps no. risers, 280mm going, 125mm rise external steps no. risers, 280mm going, 125mm rise **** Emergency Egress Window (see note) Emergency Egress Window (see note) W-16 2478 2478 W-13 1559 576 1263 1500 1263 3348 FFL FFL *See note re. Safety Glazing Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 Issue Drawing Status Mr & Mrs Prosser Drawing No 1390 13 Clanbrassil Road, Cultra 55 Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note addition the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - assured that all works on this will be carried out by competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted in the body the drawing. - All levels and dimensions are approximate, detailed site surveys be carried out by before commencement building works. All levels and dimensions to be confirmed on site. - All existing drawing information indicative and subject the detailed site survey. - Drawing for information only. - Do not scale from this drawing. - This drawing copyrighted. 1:50 00 NJ 00 27/01/23 RSCC Proposed South & North Elevations Construction 1390-DR-A-50-100 01 Proposed South Elevation 02 Proposed North Elevation W-09 1263 W-07 1866 *See note re. Safety Glazing Emergency Egress Window (see note) *See note re. Safety Glazing W-04 Existing window opening blocked up and finishes made good Existing door opening be partially blocked up and all finishes made good Do not scale Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 Issue Drawing Status Mr & Mrs Prosser Drawing No 1390 13 Clanbrassil Road, Cultra 55 Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note addition normally the types of work detailed this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - assured that all works this will be carried out by competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks highlighted in the body the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement building works. All levels and dimensions to be confirmed on site. - All existing drawing information indicative and subject the detailed site survey. - Drawing for information only. - Do not scale from this drawing. - This drawing copyrighted. 1:50 00 NJ 00 27/01/23 RSCC Proposed West East Elevations Construction 1390-DR-A-50-101 03 Proposed West Elevation 04 Proposed East Elevation Ensuite 2 Bedroom Bedroom Ensuite 3 Bedroom Hall Porch Garage Boiler House Existing 600mm Existing Wavin Existing 600mm Existing Wavin Existing 600mm Existing 600mm Existing 600mm Existing Wavin Existing Existing BIGT Gully Existing BIGT Gully Existing BIGT Gully Existing BIGT Gully Existing Gully TD WM Monoxide CM Heat HD 3616 W-01 W-05 W-08 W-10 EXD-05 W-13 W-15 W-16 W-03 D-01 positioned 1000mm 3000mm away from the boiler ensure that point the away from detector. Heat detector located to ensure that no point the room is more than 5300mm away from Kitchen Utility Living Room Lounge Study Smoke Detector Smoke Detector A A D-03 D-04 Existing Gully Existing Gully Existing BIGT Gully Existing BIGT Gully Existing BIGT Gully Existing SVP Existing Gully WC Ensuite 1 8200 Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 Issue Drawing Status Mr & Mrs Prosser Drawing No 1390 13 Clanbrassil Road, Cultra www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note In addition the hazards/risks normally associated with the types work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - be carried out competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing information indicative and subject the detailed site survey. - Drawing for information only. - Do not scale from this drawing. - This drawing is copyrighted. 1:50 00 Proposed Floor Plan Construction 1390-DR-A-30-101 KEY Existing fabric Proposed areas to be altered DXXX DXXX DXXX DXXX 01 Proposed Floor Plan 1981 830 Existing Wavin WM Smoke Detector 1203 600 1580 W-08 D-03 1800 600 Existing Gully Existing BIGT Gully A A 2100 1800 KEY A Existing Fabric not scale Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale A1 Issue Drawing Status Mr & Mrs Prosser Drawing No 1390 13 Clanbrassil Road, Cultra 55 Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted the Designer Risk Assessments and health and safety plan, note the following: - assured that all works on this will be carried out by competent Contractor working where appropriate, be an approved method statement. - Where applicable, significant residual risks are highlighted in the body the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement building works. All levels and dimensions be confirmed on site. - All existing drawing information indicative and subject to the detailed site survey. - Drawing is for information only. - Do not scale from this drawing. - This drawing copyrighted. 1:20/1:50 00 NJ 00 27/01/23 RSCC Utility Room Construction Detail A Construction 1390-DR-A-110-100 01 Section A-A 1:20 Construction detail through utility room 02 Elevation A 1:50 South elevation of proposed utility room and window 03 Plan A 1:50 Construction detail through utility room A Elevations Floor plans / Technical details

03 | SELECTED PROJECT IN Campbell Architects

Category: Client: Project Year: Kenton Road, Harrow, England Residential Strawberry Star 2022

01 Typical Envelope Bay Study 01 Section A-A 02 DET A-A DET A-A Existing brickwork onto existing concrete frame Existing brickwork be repointed where required subject to scope agreement Existing brickwork to have colour tint treatment colour to be agreed Contractor to allow full brick reveal requirement for metal window reveal surround to be reviewed on site See window package for details Windows to existing brickwork areas will be fitted within existing openings. Openings to be primed and made good. Contractor to allow for EPDM to all sides and sealant as per the manufacturer's details New insulated brick slip system fixed to 12mm sheathing board onto new metsec (assume 100mm insulated stud) Allow for full brick reveal in new brick slip extent See window package for details Contractor to allow for EPDM works, cavity stops and cavity trays to all windows where required Contractor to allow for metal trim with cavity tray behind at junction between new brick slip system and existing brick facade New insulated brick slip system fixed to 12mm sheathing board onto new metsec (assume 100mm insulated stud) See metalwork package for steel balustrade details. Metal capping profile to top of parapet on metsec with cavity stop Insulated aluminium cladding system fixed back to sheathing board to new steel frame structure Aluminium reveal as part of cladding system Contractor to allow for metal trim with cavity tray behind at junction between new brick slip system and existing brick facade Existing brickwork be repointed where required subject to scope agreement Existing brickwork to have colour tint treatment colour to be agreed Refer to Drawing 36-700 Detail 1 Refer to Drawing 36-700 Detail 5 Refer to Drawing 36-700 Detail 4 Refer to Drawing 36-700 Detail 3 Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Scale at A1 Issue Drawing Status Strawberry Star campbellarchitects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing informtion is indicative and subject to the Stage 3+ NOT FOR CONSTRUCTION Notes to Contractor: - Drawing to be read in conjunction with window package and envelope scope drawings - Contractor to allow for none combustible brick slip system - Contractor to allow for all required accessories ie cavity trays, sheething board where required, weep holes etc. - Contractor to allow for movement joints as per manufacturer's recommendations - All envelope details yet to be coordinated with structural design - All fire stopping as per the fire strategy package Location Diagram SN 00 29/07/22 MMRS 02 Existing brickwork onto existing concrete frame Existing brickwork be repointed where required subject to scope agreement Existing brickwork to have colour tint treatment colour to be agreed Contractor to allow full brick reveal requirement for metal window reveal surround to be reviewed on site See window package for details Windows to existing brickwork areas will be fitted within existing openings. Openings to be primed and made good. Contractor to allow for EPDM to all sides and sealant as per the manufacturer's details existing brick facade Do not scale 55 Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental In addition to the hazards/risks normally work detailed on this drawing and Assessments and health and safety - is assured that all works on this Contractor working where appropriate, statement. - Where applicable, significant residual body of the drawing. Location Diagram Work involved: Technical drawings Existing Building Proposed Scheme

Location:

Apartment block refurbishment project in Harrow

LIFT (min 1700x1750 shaft) 1 2 3 4 J K L M N O P Q R S T U V W X J K L M N O P Q R S T U V W X WM WM WM 1500x2000 WM WM 1500x2000 WM WM WM MAOV MECH DATA LSS MAOV DRY RISER DRY RISER INLET DRY RISER INLET Dry riser at high level A B B Core 1 DRY RISER LIFT (min 1700x1750 shaft) Core 2 Do not scale Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 Issue Drawing Status Strawberry Star Drawing No 1375 Kenton Road, Harrow 55 Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the ypes of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - It is assured that all works on this will be carried out by a competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted in the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing informtion is indicative and subject to the detailed site survey. - Drawing is for information only. - Do not scale from this drawing. - This drawing is copyrighted. Stage 3+ XX-DR-A-30-101 1:50 00 Proposed Ground Floor Plan - 02 NOT FOR CONSTRUCTION MM 00 29/07/22 RSCC Sample Floor Plan - Ground Floor (Not to scale)

WM Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Scale at A1 Issue Drawing Status Strawberry Star NOT FOR CONSTRUCTION

Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the ypes of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing informtion is indicative and subject to the STAGE 3+ 01 02 03 1500mm turning circle 1500mm turning circle Utility Cupboard Built in wardrobe SEC A SEC A SEC B SEC B Plan - Typical Apartment 1.4 1 Bedroom 1 Person 1:25 Section A - Typical Apartment 1.4 1 Bedroom 1 Person 1:20 Section B - Typical Apartment 1.4 1 Bedroom 1 Person 1:20 04 Typical Bathroom Elevation 01 1:20 05 Typical Bathroom Elevation 02 1:20 Full height tiling to shower enclosure Tile specification to be confirmed Frameless glass fixed shower screen Specification to be confirmed Refer to sanitaryware specification Tiled cistern enclosure on softwood frame to match wall tile Painted finish to wall specification to be confirmed Painted finish to wall specification to be confirmed Full height tiling to shower enclosure Tile specification to be confirmed Wall mounted mirror Tiling to splashback Tile selection confirmed Tiled cistern enclosure on softwood frame to match wall tile Sanitaryware specification to be confirmed Kitchen finish subject to client agreement and kitchen specialist input Contractor to allow for lacquer finish to doors Contractor to allow for back painted glass splashback Contractor to allow for Corian counter top Painted finish to wall specification to be confirmed Painted finish to wall specification to be confirmed Sprayed MDF cupboard doors 15mm shadow gap/scribing fillet Sprayed MDF doors - see door package for details ELE 01 ELE 02 MDF pained skirting board 06 Typical Utility Cupboard Elevation 1:20 Sprayed MDF cupboard doors 15mm shadow gap/scribing fillet Painted finish to wall specification to be confirmed Detail Arrangement - Typical Apartment (Not to scale)

campbellarchitects

03 Typical Envelope Detail Floors 2-3 Existing Brick Tinted 06 Typical Envelope Detail Level 1-2 Existing Brick Tinted 02 Typical Envelope Detail Floors 2-3 Brick Slips on Existing Brick 01 Typical Level Parapet Detail 04 Typical Level Terrace Parapet Detail 05 Typical Level Threshold Detail 07 Typical Envelope Detail Level 1-2 Existing Brick Tinted ET05 RT03 CT03 ET01 ET04 FT07 CT01 CT01 WT01E WT01C ET03 ET04 WT01B WT01A ET05 MT02 WT01E RT01 CT03 CT03 WT03A FT10 WT01C WT01A FT04 FT04 WT01C WT01A CT01 CT01 ET01 ET03 FT07 IWT06 IWT06 IWT05 IWT05 DETAIL DETAIL DETAIL & 5 Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 Issue Drawing Status Strawberry Star Drawing No Kenton Road, Harrow 55 Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the ypes of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - It is assured that all works on this will be carried out by a competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted in the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing informtion is indicative and subject to the detailed site survey. - Drawing is for information only. - Do not scale from this drawing. - This drawing is copyrighted. Stage 3+ 1:10 00 SN 00 29/07/22 MMRS NOT FOR CONSTRUCTION DETAIL Notes to Contractor: - All roofing products based on Alumasc or similar system as noted - Insulation depth and specification subject to U value requirements and SAP calculation - Contractor to allow for roof drainage outlets as per M&E design - Contractor to allow for parapet upstand and service penetrations as per M&E design - Contractor to ensure any exposed single ply membrane is robust and suitable for maintenance access - All falls and to insulation to be agreed - All edge protection to be agreed. Contractor to allow for a Latchway system to level 5 main roof including the necessary fixing point upstands - All structural substrates to be confirmed subject to structural engineer's details - All plant requirements to roof to be confirmed by M&E consultant Key: ET - External Wall Type (Refer to Envelope Scope) RT Roof Type (Refer to Roof Scope) CT - Ceiling Type (Refer to Internal Ceiling Scope) WT - Window Type (Refer to Window Scope) IWT- Internal Wall Type (Refer to Internal Wall Scope) 06 03 07 01 04 02 Location Diagram Envelop Section Details - Typical Wall (Not to scale)

4) Existing envelope over clad brick slips INTERNAL 12.5mm plasterboard (soundbloc) on 50mm steel frame w/ Isover batts insulation Existing 100mm block (inner leaf) 50/60mm cavity fill between existing masonry Existing 100mm Brick (Outer leaf) Insulation board Brick slip build up EXTERNAL 3) Existing envelope brick tinted INTERNAL 12.5mm plasterboard (soundbloc) on 50mm steel frame w/ Isover batts insulation Existing 100mm block (inner leaf) 50/60mm cavity fill between existing masonry Existing 100mm Brick (Outer leaf) EXTERNAL 1) New building structure Rheinzinc cladding INTERNAL 2x 15mm sound bloc on 50mm steel frame w/ Isover batts insulation 100mm metsec structure with 100m insulating batts 12mm sheathing board Insulation board Cavity Brick Slips (P-clad) EXTERNAL 2) New building structure - Rheinzinc cladding INTERNAL 2x 15mm sound bloc on 50mm steel frame w/ Isover batts insulation 100mm metsec structure with 100m insulating batts Insulation board Cavity Rheinzink cladding EXTERNAL 5) Existing envelope over clad - Rheinzink INTERNAL 12.5mm plasterboard (soundbloc) on 50mm steel frame w/ Isover batts insulation Existing 100mm block (inner leaf) 50/60mm cavity fill between existing masonry Existing 100mm Brick (Outer leaf) 12mm Sheathing board Insulation board Cavity Rheinzink cladding EXTERNAL IWT05 ET04 IWT05 ET05 IWT06 ET03 IWT06 ET01 IWT06 ET02 Note: Insulation thickness to satisfy SAP's. Note: Insulation thickness to satisfy SAP's. Note: Insulation thickness to satisfy SAP's. Note: Insulation thickness to satisfy SAP's. Note: Insulation thickness to satisfy SAP's. Notes to Contractor: - All roofing products based on Alumasc or similar system as noted - Insulation depth and specification subject to U value requirements and SAP calculation - Contractor to allow for roof drainage outlets as per M&E design - Contractor to allow for parapet upstand and service penetrations as per M&E design - Contractor to ensure any exposed single ply membrane is robus and suitable for maintenance access - All falls and to insulation to be agreed - All edge protection to be agreed. Contractor to allow for a Latchway system to level 5 main roof including the necessary fixing point upstands - All structural substrates to be confirmed subject to structural engineer's details - All plant requirements to roof to be confirmed by M&E consultant Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 Issue Drawing Status Strawberry Star Drawing No Kenton Road, Harrow 55 Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the ypes of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - It is assured that all works on this will be carried out by a competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted in the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing informtion is indicative and subject to the detailed site survey. - Drawing is for information only. - Do not scale from this drawing. - This drawing is copyrighted. Stage 3+ 1:5 00 SN 00 29/07/22 MMRS NOT FOR CONSTRUCTION Key: IWT - Internall Wall Type (Refer to Internal Wall Scope) ET - External Wall Type (Refer to Envelope Scope) Performance Key Requirements as per JRA report dated 26/05/22 Envelop Plan Details - Typical Wall (Not to scale) brick slips

01 CT 01 TYPICAL APARTMENT INSULATED MF CEILING ON EXISTING SLAB Specification ref: K10 11 TBC 02 CT 02 TYPICAL APARTMENT INSULATED MF BATHROOM CEILING ON EXISTING SLAB Specification ref: K10 11 TBC 03 04 CT 03 TYPICAL APARTMENT MF CEILING ON NEW FLOOR STRUCTURE CT 04 TYPICAL APARTMENT MF BATHROOM CEILING ON NEW FLOOR STRUCTURE FCL USL USL FCL USL FCL USL FCL 05 FCL USL CT 05 TYPICAL CORRIDOR ACCESSIBLE CEILING TYPE TBC Specification ref: K10 11 TBC Existing concrete slab Gypframe soffit cleat fixed to hanger Gypframe strap hanger Gypframe MF6 ceiling perimeter channel fixed to wall 600mm centres Gypframe MF7 primary support channel 12.5mm Gyproc, taped and jointed with painted finish Gypframe MF5 ceiling section 450mm centres 50mm Isover Spacesaver Ready-Cut insulation in the cavity Gypframe MF5 ceiling section at 450mm centres Existing concrete slab Gypframe soffit cleat fixed hanger Gypframe strap hanger Gypframe MF7 primary support channel 100mm Isover Spacesaver Ready-Cut insulation the cavity 12.5mm Gyproc MR, taped and jointed with painted finish Gypframe MF5 ceiling section at 450mm centres Gypframe soffit cleat fixed hanger Gypframe strap hanger Gypframe MF7 primary support channel 12.5mm Gyproc suspended, taped and jointed with selected finish Gypframe soffit cleat fixed to hanger Gypframe strap hanger Gypframe MF7 primary support channel 12.5mm Gyproc suspended MR, taped and jointed with painted finish Gypframe MF6 ceiling perimeter channel fixed Gypframe MF5 ceiling section at 450mm centres Gypframe MF6 ceiling perimeter channel fixed to wall 600mm centres Gypframe MF6 ceiling perimeter channel fixed wall 600mm centres Gypframe MF5 ceiling section 450mm centres Existing concrete slab Gypframe soffit cleat fixed to hanger Gypframe strap hanger Gypframe MF7 primary support channel Gypframe MF6 ceiling perimeter channel fixed to wall at 600mm centres Suspended ceiling tile 2x15mm Soundbloc on resilient bars fixed timber floor joists Acoustic batts between joists 2x15mm Soundbloc on resistant bars fixed to timber floor joists Acoustic batts between joists Steel and timber floor build uprefer to structural engineer Steel and timber floor build uprefer to structural engineer Potential drop down boxing for image VR inlet and outlet duct be brought to floor level not scale Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 Revision Drawing Status Strawberry Star 1375 Stage 3+ Kenton Road, Harrow Whitfield Street, London W1T www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note addition the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - assured that all works on this will be carried out by a competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. levels and dimensions be confirmed on site. - All existing drawing information indicative and subject to the detailed site survey. - Drawing information only. - Do not scale from this drawing. - This drawing copyrighted. Proposed Internal ceiling detail types XX-DR-A-35-701 Project number 1375 CH 00 27/05/22 CC RS GM 00 29/07/22 CC RS Drawing No 1:2 00 01 CT 01 TYPICAL APARTMENT INSULATED MF CEILING ON EXISTING SLAB Specification ref: K10 11 TBC 02 CT 02 TYPICAL APARTMENT MF BATHROOM CEILING ON EXISTING SLAB Specification ref: K10 11 TBC 03 04 CT 03 TYPICAL APARTMENT MF CEILING ON NEW FLOOR STRUCTURE CT 04 TYPICAL APARTMENT MF BATHROOM CEILING ON NEW FLOOR STRUCTURE FCL USL USL FCL USL FCL USL FCL 05 FCL USL CT 05 TYPICAL CORRIDOR ACCESSIBLE CEILING TYPE TBC Specification ref: K10 11 TBC Existing concrete slab Gypframe soffit cleat fixed hanger Gypframe strap hanger Gypframe MF6 ceiling perimeter channel fixed to wall 600mm centres Gypframe MF7 primary support channel 12.5mm Gyproc, taped and jointed with painted finish Gypframe MF5 ceiling section at 450mm centres 50mm Isover Spacesaver Ready-Cut insulation the cavity Gypframe MF5 ceiling section at 450mm centres Existing concrete slab Gypframe soffit cleat fixed hanger Gypframe strap hanger Gypframe MF7 primary support channel 100mm Isover Spacesaver Ready-Cut insulation the cavity 12.5mm Gyproc MR, taped and jointed with painted finish Gypframe MF5 ceiling section 450mm centres Gypframe soffit cleat fixed hanger Gypframe strap hanger Gypframe MF7 primary support channel 12.5mm Gyproc suspended, taped and jointed with selected finish Gypframe soffit cleat fixed to hanger Gypframe strap hanger Gypframe MF7 primary support channel 12.5mm Gyproc suspended MR, taped and jointed with painted finish Gypframe MF6 ceiling perimeter channel fixed Gypframe MF5 ceiling section 450mm centres Gypframe MF6 ceiling perimeter channel fixed wall 600mm centres Gypframe MF6 ceiling perimeter channel fixed wall 600mm centres Gypframe MF5 ceiling section at 450mm centres Existing concrete slab Gypframe soffit cleat fixed hanger Gypframe strap hanger Gypframe MF7 primary support channel Gypframe MF6 ceiling perimeter channel fixed to wall 600mm centres Suspended ceiling tile 2x15mm Soundbloc on resilient bars fixed timber floor joists Acoustic batts between joists 2x15mm Soundbloc on resistant bars fixed to timber floor joists Acoustic batts between joists Steel and timber floor build uprefer structural engineer Steel and timber floor build uprefer to structural engineer Potential drop down boxing for image VR inlet and outlet duct to be brought floor level Do scale Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 Revision Drawing Status Strawberry Star 1375 Stage 3+ Kenton Road, Harrow Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note addition the hazards/risks normally associated the types work detailed on this drawing and noted the Designer Risk Assessments and health and safety plan, note the following: - assured that works on this will be carried out a competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted the body the drawing. - All levels and dimensions are approximate, detailed site surveys must carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing information indicative and subject the detailed site survey. - Drawing for information only. - Do not scale from this drawing. - This drawing copyrighted. Proposed Internal ceiling detail types XX-DR-A-35-701 Project number 1375 CH 00 27/05/22 CC RS GM 00 29/07/22 CC RS Drawing No 1:2 00 01 (+3.497) 02 (+6.850) 03 (+10.520) 04 (+13.755) ROOF (+17.265) 00 (+0.00) HL (+1.752) HL (+5.258) HL (+8.608) HL (+11.930) HL (+15.495) New core walls be lined with painted plasterboard and super graphic signage New steel & timber stair core be lined with plasterboard Existing concrete stair to be made good and finish with clear seal Existing concrete walls to be made good and finished with clear seal and super graphic signage New lift car New steel & timber stair core be lined with plasterboard New concrete core - concrete finish exposed stair lobby New ensitue concrete shaft Allow for over run and lifting beam Existing slab with new structural build up over - refer Structural engineer. Location of corridor door shown (behind) Location of dry riser Allow for new painted steel balustrade with PVC handrail capping to all stair flights New steel stair structure from level 03 upwards to structural engineer's details New lift shaft. Subject to SE and M&E engineer input Existing concrete walls to be finished with clear seal and super graphic signage New steel stair be lined with plasterboard New floor structure over existing slab (L3) refer engineer's details Existing balustrade retained, height to be confirmed SEC A-A Existing and new stair treads to have anti slip edge nosing strips DRY RISER NEW LIFT (min 1700x1750 shaft) Core 1 Additional steps to level only shown dotted handrail to suit New ensitu concrete lift shaft formed to host evacuation lift Refer SE for detail Existing concrete stair core and stair retained made good. Stair core extended with Steel & timber construction to Level 3, L4 Roof. Refer SE for detail. New lift shaft. Subject SE and M&E engineer input Location Diagram Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 Issue Drawing Status Strawberry Star Drawing No 1375 Kenton Road, Harrow Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note addition the hazards/risks normally associated with the types of work detailed on this drawing and noted the Designer Risk Assessments and health and safety plan, note the following: - assured that works on this will be carried out a competent Contractor working where appropriate, approved method statement. - Where applicable, significant residual risks are highlighted the body the drawing. - All levels and dimensions are approximate, detailed site surveys must carried out by Contractor before commencement on building works. All levels and dimensions confirmed on site. - All existing drawing informtion indicative and subject to the detailed site survey. - Drawing for information only. - Do not scale from this drawing. - This drawing copyrighted. 00 STAGE 3+ XX-DR-A-24-601 MM 00 29/07/22 RSCC Proposed Stair Core 01 Typical Details 1:20 50 Notes to Contractor: - Stair balustrade comply with Approved Document Part K - Final design subject to fire consultant input regarding width stairs and riser/going - Stair core venting to be agreed with fire consultant and M&E consultant - New structure to levels 03-05 require structural input - Lift shaft and car indicative only and require M&E and lift specialist input - Signage strategy subject client input 01 02 03 Typical Core Plan (Level 03) 1:20 Typical Core Section A-A 1:50 Typical Core Section Detail 1:20 NOT FOR CONSTRUCTION DET B-B DET A-A DET B-B DET A-A 01 Typical Envelope Bay Study 01 02 Section B-B Section A-A 03 Existing brickwork to be repointed where required subject scope agreement Existing brickwork to have colour tint treatment colour be agreed Existing brickwork to be repointed where required subject scope agreement Existing brickwork to colour be agreed Existing brickwork to be repointed where required subject scope agreement Existing brickwork to have colour tint treatment colour be agreed Existing DPC be reviewed injected DPC required See window package for details Windows to existing brickwork areas will be fitted within existing openings. Openings to be primed and made good. Contractor allow for EPDM to all sides and sealant as per the manufacturer's Contractor to allow for supplier See metalwork package for steel balustrade allow for side fixing through brick slip system and weathering as required See window package Contractor to allow for EPDM works, cavity stops and cavity trays all windows where required Brick slip reveals to head and jamb reveals New insulated brick slip system fixed 12mm sheathing board onto existing concrete frame/new metsec where required Existing brickwork be repointed where required subject to scope agreement Existing brickwork have colour tint treatment colour to be agreed Existing DPC be reviewed injected DPC required Entrance surround to be formed aluminium profile and cladding by specialist onto steel back existing concrete frame as per structural engineer's details Existing brickwork existing concrete frame Entrance surround be formed of aluminium profile and cladding by specialist onto steel sub-frame and fixed back to existing concrete frame as per structural engineer's details Refer Drawing 36-700 Detail Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 Issue Drawing Status Strawberry Star Drawing No 1375 Kenton Road, Harrow Whitfield Street, London W1T 4AH www.campbellarchitects.co.uk campbellarchitects Safety, Health and Environmental Information General Note addition to the hazards/risks normally associated with the types work detailed on this drawing and noted the Designer Risk Assessments and health and safety plan, note the following: - assured that all works on this will carried out by a competent Contractor working where appropriate, be an approved method statement. - Where applicable, significant residual risks are highlighted the body the drawing. - All levels and dimensions are approximate, detailed site surveys must carried out by Contractor before commencement building works. All levels and dimensions confirmed site. - All existing drawing informtion indicative and subject the detailed site survey. - Drawing for information only. - Do not scale from this drawing. - This drawing copyrighted. Stage 3+ XX-DR-A-36-603 1:20 00 Proposed Envelope Detailed Elevations Sheet 03 NOT FOR CONSTRUCTION Notes to Contractor: - Drawing to be read in conjunction with window package and envelope scope drawings - Contractor to allow for none combustible brick slip system - Contractor to allow for all required accessories ie cavity trays, sheething board where required, weep holes etc. - Contractor to allow for movement joints as per manufacturer's recommendations - All envelope details yet to be coordinated with structural design - All fire stopping as per the fire strategy package Location Diagram 00 DRAWINGS NOT TO SCALE Envelop detailed elevation Metal work typical details Stair core typical details

03 | SELECTED PROJECT IN Campbell Architects

Residential Development in Rochester

Location: Category: Client: Project Year: Rochester, England Residential Kitewood 2022-2023

Work involved: Technical drawings 50° NOTE: Extent of required underbuild to be confirmed 2400 2700 1050 1050 600 600 1500 300 2100 2100 1050 1050 RWP RWP RWP RWP RWP RWP RWP 12-W01 11-W01 EXD1 10-W01 9-W01 8-W01 EXD1 EXD1 SG SG SG 12-W05 12-W06 11-W04 10-W04 9-W04 8-W04 E E E E E Extract to Bathroom Below terminated with tile vent. Extract to Bathroom Below terminated with tile vent. SVP terminated with tile vent. SVP terminated with tile vent. Extract to Bathroom Below terminated with tile vent. Extract to Bathroom Below terminated with tile vent. SVP terminated with tile vent. SVP terminated with tile vent. SG SG SG SG SG SG SG SG 10 01 02 10 10 08 08 03 03 05 04 04 04 04 04 04 04 04 04 07 07 07 07 07 02 02 02 50° 2400 2700 1050 1050 600 600 1500 300 2100 2100 1050 1050 DPC in external wall to be Minimum 150mm Above Finished Ground Level Fire-stopping over separating wall extended into eaves and to continue to underside of roof covering as detailed and as AD.B1 Diagram 11 E E E E E SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG SG 5-W02 5-W03 EXD2 4-W03 4-W04 EXD2 3-W03 3-W04 EXD2 2-W03 2-W04 EXD2 1-W03 1-W04 EXD2 5-W05 4-W05 3-W05 2-W05 1-W08 1-W09 SG SG SG SG 01 04 02 06 04 02 09 09 09 08 05 06 06 06 06 04 04 04 02 02 Safety, Health and Environmental Information 01 Elevation 1 1:50 02 Elevation 2 1:50 Note: Section heights based on 253mm dp metal web joist - specialist manufacturer's design and drawings 2410 Flr to Ceiling 2385 Flr to Ceiling 2650 SSL to U/S Floor Joist 253 2422 TOJ to U/S Truss 1050 1050 1275 600 1050 1050 1050 1050 1050 DPC in external wall to be Minimum 150mm Above Finished Ground Level Foundations to Speedeck Foundations Ltd's design and drawings CB RWP 8-W01 EXD1 EXD1 SG SG SG SG 8-W04 E terminated with tile vent. SG SG 2410 Flr to Ceiling 2385 Flr to Ceiling 2650 SSL to U/S Floor Joist 253 2422 TOJ to U/S Truss 2100 30° DPC in external wall to be Minimum 150mm Above Finished Ground Level Foundations to Speedeck Foundations Ltd's design and drawings CB RWP RWP RWP 9-W01 EXD1 SG SG 9-W04 E terminated with tile vent. Issue DateByChkdAppdIssueDateByChkdAppd Client Drawing Status campbell architects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and PRELIMINARY Kitewood 02 Stick Section D-D 1:20 C C SN 00 02/03/23 RS CC 01 Stick Section C-C 1:20 D D RJ 01 10/05/23 RS CC NOTE: ACOUSTIC CEILING DETAIL TO BE CONFIRMED, WHICH MAY ALTER THE FINAL TRUSS POSITION NOTE: ACOUSTIC CEILING DETAIL TO BE CONFIRMED, WHICH MAY ALTER THE FINAL TRUSS POSITION 225 2700 2400 Note: Section heights based on 253mm dp metal web joist - to specialist manufacturer's design and drawings 2410 Flr to Ceiling 290 2385 Flr to Ceiling 2650 SSL to U/S Floor Joist 253 2422 TOJ to U/S Truss 1275 600 1050 1050 1050 DPC in external wall to be Minimum 150mm Above Finished Ground Level Foundations to Speedeck Foundations Ltd's design and drawings CB RWP 8-W01 EXD1 EXD1 SG SG SG SG 8-W04 E terminated with tile vent. SG SG 2410 Flr to Ceiling 290 2385 Flr to Ceiling 2650 SSL to U/S Floor Joist 253 2422 TOJ to U/S Truss 2100 30° DPC in external wall to be Minimum 150mm Above Finished Ground Level Foundations to Speedeck Foundations Ltd's design and drawings CB RWP RWP RWP 9-W01 EXD1 SG SG 9-W04 E terminated with tile vent. Issue DateByChkdAppdIssueDateByChkdAppd Client Job Title Scale at A1 Issue Drawing Status campbell architects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - is assured that all works on this will be carried out by - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing information is indicative and subject to the detailed site survey. PRELIMINARY Kitewood Bridgeside, Warwick Crescent, Rochester 1:20 01 02 Stick Section D-D 1:20 C C SN 00 02/03/23 RS CC 01 Stick Section C-C 1:20 D D RJ 01 10/05/23 RS CC NOTE: ACOUSTIC CEILING DETAIL TO BE CONFIRMED, WHICH MAY ALTER THE FINAL TRUSS POSITION NOTE: ACOUSTIC CEILING DETAIL TO BE CONFIRMED, WHICH MAY ALTER THE FINAL TRUSS POSITION DRAWINGS NOT TO SCALE

AA D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm td dw 12-W01 EXD1 12-W03 12-W04 EXD2 CB D02 7313 1428 8257 2663 2165 7313 1443 7280 1075 2578 2577 3648 7280 7670 3250 3640 7280 7670 3652 6975 44090 19228 44090 12253 RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP 1002 1023 553 1010 578 1010 440 1023 1677 1023 553 1010 418 1010 392 1023 1660 1023 440 1010 465 1010 638 1023 1002 1023 420 1010 465 1010 440 1023 1677 1023 552 1010 433 1010 377 1023 1677 1023 440 1010 495 1010 553 1023 1002 722 225 225 5052 685 6515 5052 685 6515 777.5 2485.0 385.0 777.5 2485.0 1115.0 2485.0 418 777.5 2485.0 1145.0 2485.0 777.5 337.5 777.5 2485.0 377.5 777.5 2485.0 1115.0 2485.0 417.5 777.5 2485.0 1110.0 2485.0 812.5 390 2485.0 777.5 2485.0 427.5 65 11-W01 11-W02 11-W03 EXD2 EXD2 EXD2 EXD2 EXD2 EXD2 EXD2 EXD2 EXD2 EXD2 EXD2 EXD1 EXD1 EXD1 EXD1 EXD1 EXD1 EXD1 EXD1 EXD1 EXD1 EXD1 1-W01 1-W03 1-W04 1-W02 2-W02 2-W03 3-W02 3-W03 4-W02 4-W03 5-W02 5-W03 6-W02 6-W03 7-W02 7-W03 8-W02 8-W03 9-W02 9-W03 10-W02 10-W03 10-W01 9-W01 8-W01 7-W01 6-W01 5-W01 4-W01 3-W01 2-W01 113 CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm td D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm td dw dw dw 3349 3180 2572 1287 797 910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 700 93 93 93 551 551 475 464 1850 1499 3349 3180 2572 1287 797 910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 1100 93 551 551 475 464 1850 1499 3349 1287 797 910 186 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 93 551 551 475 464 1850 1499 3349 3180 2572 1287 797 910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 700 93 1100 93 93 551 551 475 464 1850 1499 3349 3180 2572 1287 797 910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 93 551 551 475 464 1850 1499 3349 3180 1672 1287 797 910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 700 93 1100 93 93 551 551 475 464 1850 1499 3349 1287 797 910 186 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 475 464 1850 1499 3349 3180 1672 1287 797 910 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 93 551 551 475 464 1850 1499 3349 3180 1672 1287 797 910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 700 93 1100 93 93 475 464 1850 1499 3349 1287 797 910 186 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 93 551 551 475 464 1850 1499 900 900 900 Internal Stairs: 207.7mm Rise (13 Equal Risers) 225mm Going Subject to specialist design 3377 1287 797 910 850 1977 1400 1032 2345 1182 85 910 187 2195 1090 1100 700 93 1100 93 551 551 475 464 1850 1527 3372 3180 1672 1287 797 910 1050 4800 850 1972 1400 1032 2340 1182 85 910 187 2190 1090 1100 700 93 1100 93 551 551 475 464 1850 1522 900 PLOT 01 Occupancy Bedroom Person GIA Ground Floor: 37.87 m² First Floor:39.17 m² Total: 77.04 m² NOTE: GIA Measured in accordance with RICS code of measurement practice and excludes internal finishes to external + party walls. PLOT 02 Occupancy Bedroom 3 Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 04 Occupancy Bedroom Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 06 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 07 Occupancy Bedroom Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42m² PLOT 10 Occupancy Bedroom Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 12 Occupancy Bedroom Person GIA Ground Floor: 37.82 m² First Floor:39.12 m² Total: 76.94 m² PLOT 03 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 05 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 08 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 09 Occupancy 2 Bedroom Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 11 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² RAD EX RAD RAD EX ASHP RAD EX RAD EX ASHP EX RAD EX ASHP Issue DateByChkdAppdIssueDateByChkdAppd Client Job Title Scale at A0 Drawing Status KITEWOOD campbell architects Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. PRELIMINARY 01 Ground Floor Plan 1:50 (CONTRACTOR /CLIENT SHOULD DETAILS DURING CONSTRUCTION) PROPOSED BUILDING FABRIC Element Specification External Cavity Wall 102.5mm Brickwork 125mm Cavity insulation (10mm (50mm polyurethane and jambs to achieve W/m²K) 100mm Concrete Plasterboard (350mm) Ground Floor 75mm Sand (Polythene separation 150mm Kingspan Concrete Floor Membrane & (Solid) Windows TBC by Client External Doors TBC by Client Pitched Roof 110mm Reticel 100mm Eurothane Polythene VCL, Plasterboard Party WallRobust Detail Gypsum based area 12.5kg/m2) cement:sand (exterior both 215mm Dense laid on its side, (291mm) General Notes: The Contractor shall complete or other authorities. All dimensions discrepancies reported immediately followed in preference to scaled the local Building Control Office. The Project shall be carried Regulations, Codes of Practice, workmanship, protection and secure job. This drawing is to be read in other statutory & regulatory requirements. The enclosed is to be read strictly and foundation specialist details. by the Structural Engineer as information indicated or errors Architects. Extent and location Structural Engineer Disclaimers This drawing is consultant information. All information subject to detailed design by Architects accepts no responsibility inaccuracies contained therein. Stair design is indicative only, supplier, including confirmation Kitchen, bathroom and utility services layouts) and remains Dimensions are measured to the Operating and Maintenance shall give, not more than 5 days to the building owner giving maintenance requirements, to to be operated and maintained should be directly related to should be readily understandable format that can be kept and referred Space for Fridge or WM LEGEND Cavity Barrier location Cooker hood recycling OBS BF CHR CB Bolier flue Space for Washing under EF Obscure glazed window External tap Broom Cupboard BM Space for Ancillary fr/fz Extractor fan SPace for Tumble TD M Space for microwave Waste bin Anc Bin FD30 Fire Door FD60 Fire Door FD30S Fire Door with Partition with Acoustic BLOCK WORK HATCH LEGEND All block strengths to be confirmed by Structural Engineer. 7.3N/mm² Celcon 'High Density 730kg/m²) 1850-2300 kg/m3 Tarmac Robust Detail E-WM-9 Facing Brickwork KITCHEN NOTES: Layout is indicative Refer to to specialist out VENTILATION NOTES: Ventilation layout is indicative Refer specification of equipment etc. 01 230503SNRSCC 02 230510SNRSCC 00 230428SNRSCC 03 230711RJRSCCAA D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td dw 12-W01 EXD1 12-W02 12-W03 12-W04 EXD2 CB D02 7313 1428 8257 2663 2165 7313 1443 2577 44090 19228 12253 RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP RWP 1002 1023553101057810104401023 1677 1023553101041810103921023 1660 1023440101046510106381023 1002 1023420101046510104401023 1677 1023552101043310103771023 722 225 225 5052 685 6515 11-W01 11-W02 11-W03 EXD2 EXD2 EXD2 EXD2 EXD2 EXD1 EXD1 EXD1 EXD1 EXD1 EXD1 EXD1 EXD1 EXD1 7-W02 7-W03 8-W02 8-W03 9-W02 9-W03 10-W02 10-W03 10-W01 9-W01 8-W01 7-W01 6-W01 5-W01 4-W01 1 2 113 CB CB CB CB CB CB CB CB CB CB CB CB CB CB D01 Hall WC Store dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td dw D01 Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td dw dw 3180 2572 1287 797910 186 1050 850 1400 1032 1182 85 910 187 1090 1100 700 93 1100 93 93 551 551 475 464 1850 3180 2572 1287 797910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 93 551 551 475 464 1850 1499 3349 3180 2572 1287 797910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 93 551 551 475464 1850 1499 3349 3180 2572 1287 797910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 93 551 551 475 464 1850 1499 3349 3180 2572 1287 797910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 93 551 551 475 464 1850 1499 3349 3180 1672 1287 797910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 93 551 551 475464 1850 1499 3349 3180 1672 1287 797910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 93 551 551 475 464 1850 1499 3349 3180 1672 1287 797910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 93 551 551 475464 1850 1499 3180 1672 1287 797910 186 1050 4800 850 1949 1400 1032 2318 1182 85 910 187 2168 1090 1100 700 93 1100 93 93 551 551 475464 1850 1499 900 900 900 900 3372 3180 1672 1287 797910 186 1050 4800 850 1972 1400 1032 2340 1182 85 910 187 2190 1090 1100 700 93 1100 93 93 551 551 475464 1850 1522 900 PLOT 04 Occupancy - 2 Bedroom 3 Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 06 Occupancy - 2 Bedroom 3 Person GIA - Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 07 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42m² PLOT 10 Occupancy 2 Bedroom 3 Person GIA - Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 12 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 37.82 m² First Floor:39.12 m² Total: 76.94 m² PLOT 03 Occupancy 2 Bedroom GIA Ground Floor: First Floor:38.85 Total: PLOT 05 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 08 Occupancy - 2 Bedroom 3 Person GIA - Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 09 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 11 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² RAD EX RAD RAD RAD EX ASHP Issue DateByChkdAppdIssueDateByChkdAppd Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before 01 Ground Floor Plan 1:50 01 230503SNRSCC 00 230428SNRSCC DRAWINGS NOT TO SCALE

4038 7280 6890 4030 3640 7280 6890 4042 44090 12253 7280 7670 3250 3640 7280 7670 3652 3647 12253 6975 6638 18890 44090 900 1800 900 1800 900 2475 2475 900 1800 1800 338 338 900 1002.5 910.0 215.0 910.0 1000.0 1567.7 1022.5 2015.0 1585.0 1090.0 1150.0 1585.0 1530.0 1022.5 1602.5 982.5 910.0 215.0 910.0 1012.5 740.0 910.0 215.0 910.0 865.0 1002.5 910.0 215.0 910.0 1005 1595.2 1022.5 1980.0 1585.0 1527.6 1585.0 1565.0 1022.5 1579.9 707.4 1002.5 910.0 215.0 910.0 610.0 1202.5 1585.0 2015.0 1585.0 892.7 1202.5 1585.0 2060.0 1585.0 1237.5 592.5 910.0 622.5 510.0 1002.5 910.0 615 1202.5 1585.0 2095.0 1585.0 892.5 1585.0 2015.0 1585.0 1202.5 1202.5 12-W05 12-W07 12-W0812-W09 12-W06 D03 D05 D04 D06 D07 Bathroom Bedroom (12.9m² Inc Wdr) Bedroom (13.0m² Inc Wdr) Store (0.86m²) 11-W04 11-W05 10-W04 10-W05 9-W04 9-W05 8-W04 8-W05 7-W04 7-W06 6-W04 6-W06 5-W04 5-W05 4-W04 4-W05 3-W04 3-W05 2-W04 2-W05 1-W05 1-W08 7-W05 6-W05 1-W06 1-W07 7-W07 6-W07 1-W09 215.0 910.0 910.0 910.0 1095.0 215.0 215.0 910.0 8 CB CBAA PLOT 01 Occupancy Bedroom 3 Person GIA Ground Floor: 37.87 m² First Floor:39.17 m² Total: 77.04 m² NOTE: GIA Measured in accordance with RICS code of measurement practice and excludes internal finishes to external party walls. PLOT 02 Occupancy Bedroom Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 04 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 06 Occupancy Bedroom Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 07 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42m² PLOT 10 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 12 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 37.82 m² First Floor:39.12 m² Total: 76.94 m² PLOT 03 Occupancy Bedroom Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 05 Occupancy Bedroom Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 08 Occupancy Bedroom Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 09 Occupancy Bedroom Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 11 Occupancy Bedroom Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² Store (0.6m²) 5052 685 6515 CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 758 834 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 1900 1051 4516 93 850 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 4516 93 850 412 834 2103 175 297 130 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 758 297 834 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 1900 93 1051 4516 93 850 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 297 130 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1283 1850 1526 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 440 834 2103 175 297 130 2093 1283 185 834 265 93 2000 3377 3377 2155 957 1283 1850 1526 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 440 834 2103 175 758 297 834 130 1104 3411 2093 1283 185 834 265 93 2000 3377 3377 Ø110 SVP Changes vertical position in boxing void Bedroom (12.9m² Inc Wdr) Bedroom (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom (12.9m² Inc Wdr) Bedroom (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom (12.9m² Inc Wdr) Bedroom (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom (12.9m² Inc Wdr) Bedroom (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom (12.9m² Inc Wdr) Bedroom (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom (12.9m² Inc Wdr) Bedroom (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom (12.9m² Inc Wdr) Bedroom (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom (12.9m² Inc Wdr) Bedroom (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom (12.9m² Inc Wdr) Bedroom (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bathroom Bathroom Bathroom Bathroom Bathroom Bathroom Bathroom Bathroom Bathroom Bathroom Bathroom Issue DateByChkdAppdIssueDateByChkdAppd Client Job Title Scale at A0 Drawing Status KITEWOOD

Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. PRELIMINARY 01 First Floor Plan 1:50 01 230503SNRSCC Space for Fridge or WM LEGEND Cavity Barrier location Cooker hood recycling OBS BF CHR CB Bolier flue Space for Washing under EF Obscure glazed window External tap Broom Cupboard BM Space for Ancillary fr/fz Extractor fan SPace for Tumble TD M Space for microwave Waste bin Anc Bin FD30 Fire Door FD60 Fire Door FD30S Fire Door with Partition with Acoustic KITCHEN NOTES: Layout is indicative Refer to to specialist out VENTILATION NOTES: Ventilation layout is indicative Refer specification of equipment etc. General Notes: The Contractor shall complete or other authorities. All dimensions discrepancies reported immediately followed in preference to scaled the local Building Control Office. The Project shall be carried Regulations, Codes of Practice, workmanship, protection and secure job. This drawing is to be read in other statutory & regulatory requirements. The enclosed is to be read strictly and foundation specialist details. by the Structural Engineer as information indicated or errors Architects. Extent and location Structural Engineer Disclaimers This drawing is consultant information. All information subject to detailed design by Architects accepts no responsibility inaccuracies contained therein. Stair design is indicative only, supplier, including confirmation Kitchen, bathroom and utility services layouts) and remains Dimensions are measured to the Operating and Maintenance shall give, not more than 5 days to the building owner giving maintenance requirements, to to be operated and maintained should be directly related to should be readily understandable format that can be kept and referred 02 230510SNRSCC 00 230428SNRSCC 03 230711RJRSCC BLOCK WORK HATCH LEGEND All block strengths to be confirmed by Structural Engineer. 7.3N/mm² Celcon 'High Density 730kg/m²) 1850-2300 kg/m3 Tarmac Robust Detail E-WM-9 Facing Brickwork 4038 7280 6890 4030 3640 7280 44090 12253 19228 900 1800 900 1800 2475 900 1800 1800 900 900 1500x2000 1500x2000 1002.5910.0 215.0 910.01000.0 1567.7 1022.5 2015.0 1585.0 1090.01150.0 1585.0 1530.0 1022.5 1602.5 982.5910.0 215.0 910.01012.5740.0910.0 215.0 910.0865.0 1585.0 1527.6 1585.0 1565.0 1022.5 1579.9 707.4 12-W05 12-W07 12-W0812-W09 12-W06 D03 D05 D04 D06 D07 Bathroom Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) 11-W04 11-W05 10-W04 10-W05 9-W04 9-W05 8-W04 8-W05 7-W04 7-W06 6-W04 5-W04 4-W04 7-W05 6-W05 7-W07 456 7 8 9 11 12 13 CB CBAA PLOT 04 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 06 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 07 Occupancy 2 Bedroom 3 Person GIA - Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42m² PLOT 10 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 37.57 m² First Floor:38.85 m² Total: 76.42 m² PLOT 12 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 37.82 m² First Floor:39.12 m² Total: 76.94 m² PLOT 03 Occupancy - 2 Bedroom GIA Ground Floor: First Floor:38.85 Total: PLOT 05 Occupancy - 2 Bedroom 3 Person GIA - Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 08 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 09 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² PLOT 11 Occupancy 2 Bedroom 3 Person GIA Ground Floor: 38.85 m² First Floor:38.85 m² Total: 77.70 m² Store (0.6m²) 5052 685 6515 CB CB CB CB CB CB CB CB CB CB CB CB CB 1500x2000 1500x2000 1500x2000 1500x2000 1500x2000 1500x2000 2155 957 1850 93 1006 93 850 93 2093 2000 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 3349 2155 957 1256 1850 1499 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 412 834 2103 175 758 297 834 130 1104 3411 2093 1256 185 834 237 93 2000 3349 2155 957 1283 1850 1526 93 901 93 1006 3857 93 1900 93 1051 93 4516 93 850 93 440834 2103 175 758 297 834 130 1104 3411 2093 1283 185 834 265 93 2000 3377 3377 Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bedroom (12.9m² Inc Store Bathroom Bathroom Bathroom Bathroom Bathroom Bathroom Bathroom Bathroom Bathroom Issue DateByChkdAppdIssueDateByChkdAppd Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before 01 First Floor Plan 1:50 01 230503SNRSCC 00 230428SNRSCC DRAWINGS NOT TO SCALE

campbell architects

2155 2000 834 1220 C A B D 2155 2400 FFL 0.00 CL +2.40 820 415 2000 2400 FFL 0.00 CL +2.40 FFL 0.00 CL +2.40 1330 1615 2000 2400 FFL 0.00 CL +2.40 2155 2400 FFL 0.00 CL +2.40 535 2100 834 1615

Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - It is assured that all works on this will be carried out by a competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted in the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing informtion is indicative and subject to the detailed site survey. - Drawing is for information only. - Do not scale from this drawing. - This drawing is copyrighted. 1:20 Do not scale Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 (A3) Issue Drawing Status KITEWOOD Drawing No 1392 Bridgeside, Warwick Crescent, Rochester 1392-DR-A-110-102 Bathroom Layout 00 PRELIMINARY 04 02 03 05 Typical First Floor Bathroom Plan 1:20 Typical First Floor Bathroom Elevation A 1:20 01 Typical First Floor Bathroom Elevation B 1:20 Typical First Floor Bathroom Elevation D 1:20 Typical First Floor Bathroom Elevation C 1:20 01 02 03 04 05 06 08 04 07 06 02 05 02 02 01 04 05 04 07 05 Key 01 02 03 04 05 06 07 08 07 Shower head 300 x 600 mm tile Mirror Basin Bath tub Toilet paper holder Toilet Heated towel rail DRAWINGS NOT TO SCALE

campbellarchitects

AA Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td dw BT H CO RAD EX M P SC RAD RAD RAD P P EX CHW F FSP ASHP RWP RWP RWP RWP RWP 1 2 BT Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining H CO fr/fz wm / td dw RAD EX M P SC RAD RAD RAD P P EX CHW F FSP ASHP P P SH EX P RAD RAD R-Heat S P RAD TR 750x500 loft hatch over Bathroom Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) 456 7 8 9 10 11 12 13AA Store (0.6m²) P P s SH EX S P RAD RAD R-Heat S P RAD TR 750x500 loft hatch over Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bathroom 01 Electrical Layout - Ground Floor 1:50 02 Electrical Layout - First Floor 1:50 PROPOSED MECHANICAL & ELECTRICAL KEY External light fitting.security light IH BT CHW 13 Amp. Twin switched socket outlet above worktop Switched spurs appliance panel above worktop controlling un-switched sockets below worktop level and etched with appliance name accordingly. Strip Light GAS EXT GM FSP EM SC F ☼ 13 Amp. Un-switched spur at high level for extractor 13 Amp. Fused switched spur SL for future Stair Future Alarm, B=Boiler, F= Extractor fan, TA = TV 5A RAD TR 13 Amp. Twin switched socket outlet 13 Amp. Single un-switched socket outlet 13 Amp. Twin switched external weatherproof socket 5 Amp. Switched lighting socket Immersion heater switch with engraved Neon Shaver socket with light fitting (Low Energy) External photocell dusk to dawn sensor switch Two way switch One way switch Pull cord ceiling switch Push button with time delay switch Cooker flex outlet plate Cooker switch (Engraved) Consumer service unit with lockable door BT Intake adaptable box. Central Heating wiring junction box with programmer Door bell mains operated Dedicated low energy bathroom bulkhead vapour light fitting Recessed down lighter (LED) Illuminated bell push Room digital thermostat with load compensator Stopcock Radiator Towel Rail (Indicative only, sized by others) Mains interlinked smoke detector H Mains interlinked heat detector CO Mains interlinked carbon monoxide detector Gas point Gas Ground meter box Electric Wall mounted or wall mounted meter box Gas Semi recessed meter box SYMBOLDESCRIPTION P Boiler flue BF Extractor fan isolation switch (B with Boost switch) Telephone point (M BT Master Socket) Television Point Satellite Point (Dual) M Under unit lighting R-Heat Radiant heater Plinth Heater Notes: 1.Heating, gas and electrical layouts on drawings are indicative subject to detailed design by specialist installers 2.All gas installation and commissioning to be undertaken registered persons 3.Gas boiler to be as SAP Calculations and fitted with "Gas 4.All electrical installation and commissioning to be undertaken registered persons 5.All electrical installations to be in accordance with BS7671:2008 PH SH EX Ceiling wall mounted extract duct and grill Light fitting (Low Energy) P=Pendent B=Bayonet B W General Notes: The Contractor shall complete all notices required Building Regulations or other authorities. All dimensions be verified on site and any discrepancies immediately to the Architect. Noted dimensions in preference to scaled dimensions. All work satisfaction of the local Building Control Office. The Project shall be carried out in accordance Building Regulations, Codes of Practice, British proper methods of workmanship, protection and so as to give a complete, sound and secure job. This drawing is to be read in conjunction with Documents and other statutory & regulatory requirements. The enclosed is to be read strictly in accordance Structural Engineers and foundation specialist structural information indicated is provided by Engineer as received. No responsibility for information indicated or errors contained therein taken by Campbell Architects. Extent and location load bearing walls to be confirmed by Structural Disclaimers : This drawing is to be read accordance with all relevant consultant information. information indicated relating to structure remains detailed design by the appointed Structural Engineer, Campbell Architects accepts no responsibility Information indicated or inaccuracies contained therein. Stair design is indicative only, and is subject design by a specialist supplier, including confirmation structural openings. Kitchen, bathroom and utility room layouts are indicative (including services layouts) and remains subject design by specialist supplier. Dimensions are measured to the structural face partitions only. RAD ASHP RWP RWP BT Kitchen (7.7m²) Hall WC Store (1.0m²) Dining H CO fr/fz wm / td dw EX M P SC RAD RAD EX CHW F FSP ASHP P SH EX RAD R-Heat S P RAD TR 750x500 loft hatch over Bathroom Bedroom 1 (12.9m² Inc Wdr) Store (0.86m²)A Store (0.6m²) SH EX RAD S P RAD TR 750x500 loft hatch over Bedroom 1 (12.9m² Inc Wdr) Bathroom Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Drawing Title Project No Scale at A1 (A3) Issue Drawing Status KITEWOOD Drawing No 1392 Bridgeside, Warwick Crescent, Rochester Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - It is assured that all works on this will be carried out by a competent Contractor working where appropriate, to be an approved method statement. - Where applicable, significant residual risks are highlighted in the body of the drawing. - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing informtion is indicative and subject to the detailed site survey. - Drawing is for information only. - Do not scale from this drawing. - This drawing is copyrighted. 1:50 1392-DR-A-120-100 Mechanical & Electrical Layouts 02 PRELIMINARY Floor 02 Electrical Layout - First Floor 1:50 PROPOSED MECHANICAL & ELECTRICAL KEY External light fitting.security light IH BT CHW 13 Amp. Twin switched socket outlet above worktop Switched spurs appliance panel above worktop controlling un-switched sockets below worktop high level and etched with appliance name accordingly. Strip Light GAS EXT GM FSP EM SC F ☼ 13 Amp. Un-switched spur at high level for extractor fan 13 Amp. Fused switched spur SL = for future Stair Lift, A= for Future Alarm, B=Boiler, F= Extractor fan, TA = TV amplifier) 5A RAD TR 13 Amp. Twin switched socket outlet 13 Amp. Single un-switched socket outlet 13 Amp. Twin switched external weatherproof socket outlet 5 Amp. Switched lighting socket Immersion heater switch with engraved Neon Shaver socket with light fitting (Low Energy) External photocell dusk to dawn sensor switch Two way switch One way switch Pull cord ceiling switch Push button with time delay switch Cooker flex outlet plate Cooker switch (Engraved) Consumer service unit with lockable door BT Intake adaptable box. Central Heating wiring junction box with programmer Door bell mains operated Dedicated low energy bathroom bulkhead vapour proof light fitting Recessed down lighter (LED) Illuminated bell push Room digital thermostat with load compensator Stopcock Radiator Towel Rail (Indicative only, sized by others) s Mains interlinked smoke detector H Mains interlinked heat detector CO Mains interlinked carbon monoxide detector Gas point Gas Ground meter box Electric Wall mounted or wall mounted meter box Gas Semi recessed meter box SYMBOL DESCRIPTION P Boiler flue BF Extractor fan isolation switch (B with Boost switch) Telephone point (M - BT Master Socket) Television Point Satellite Point (Dual) S M Under unit lighting R-Heat Radiant heater Plinth Heater Notes: 1.Heating, gas and electrical layouts on drawings are indicative only and subject to detailed design by specialist installers 2.All gas installation and commissioning to be undertaken by Gas Safe registered persons 3.Gas boiler to be as SAP Calculations and fitted with "Gas Saver" as noted 4.All electrical installation and commissioning to be undertaken by EIC/NIC registered persons 5.All electrical installations to be in accordance with BS7671:2008 (as amended) and Building Regulations Approved Document P 6.Consumer unit enclosure to be manufactured from non-combustible material in compliance with BS 7671:2008 Chapter 42 (Amendment 3:2015) PH SH EX Ceiling wall mounted extract duct and grill Light fitting (Low Energy) P=Pendent B=Bayonet W=Wall Light B W 01 230503RJRSCC 02 230711RJRSCCAA Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining fr/fz wm / td dw BT H CO RAD EX M P SC RAD RAD RAD P P EX CHW F FSP ASHP RWP RWP RWP RWP RWP 1 2 BT Kitchen (7.7m²) Hall WC Lounge Dining (21.7m²) Store (1.0m²) Dining H CO fr/fz wm / td dw RAD EX M P SC RAD RAD RAD P P EX CHW F FSP ASHP P P SH EX S P RAD RAD R-Heat S P RAD TR 750x500 loft hatch over Bathroom Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) 456 7 8 9 10 11 12 13AA Store (0.6m²) P P s SH EX S P RAD RAD R-Heat S P RAD TR 750x500 loft hatch over Bedroom 1 (12.9m² Inc Wdr) Bedroom 2 (13.0m² Inc Wdr) Store (0.86m²) Store (0.6m²) Bathroom Issue DateByChkdAppdIssueDateByChkdAppdClient Job Title Scale at A1 (A3) Issue Drawing Status KITEWOOD Safety, Health and Environmental Information General Note In addition to the hazards/risks normally associated with the types of work detailed on this drawing and noted in the Designer Risk Assessments and health and safety plan, note the following: - All levels and dimensions are approximate, detailed site surveys must be carried out by Contractor before commencement on building works. All levels and dimensions to be confirmed on site. - All existing drawing informtion is indicative and subject to the PRELIMINARY 01 Electrical Layout - Ground Floor 1:50 02 Electrical Layout - First Floor 1:50 PROPOSED MECHANICAL & ELECTRICAL KEY External light fitting.security light IH BT CHW 13 Amp. Twin switched socket outlet above worktop Switched spurs appliance panel above worktop controlling un-switched sockets below worktop level and etched with appliance name accordingly. Strip Light GAS EXT GM FSP EM SC F ☼ 13 Amp. Un-switched spur at high level for extractor 13 Amp. Fused switched spur SL for future Stair Future Alarm, B=Boiler, F= Extractor fan, TA = TV 5A RAD TR 13 Amp. Twin switched socket outlet 13 Amp. Single un-switched socket outlet 13 Amp. Twin switched external weatherproof socket 5 Amp. Switched lighting socket Immersion heater switch with engraved Neon Shaver socket with light fitting (Low Energy) External photocell dusk to dawn sensor switch Two way switch One way switch Pull cord ceiling switch Push button with time delay switch Cooker flex outlet plate Cooker switch (Engraved) Consumer service unit with lockable door BT Intake adaptable box. Central Heating wiring junction box with programmer Door bell mains operated Dedicated low energy bathroom bulkhead vapour light fitting Recessed down lighter (LED) Illuminated bell push Room digital thermostat with load compensator Stopcock Radiator Towel Rail (Indicative only, sized by others) Mains interlinked smoke detector H Mains interlinked heat detector CO Mains interlinked carbon monoxide detector Gas point Gas Ground meter box Electric Wall mounted or wall mounted meter box Gas Semi recessed meter box SYMBOLDESCRIPTION P Boiler flue BF Extractor fan isolation switch (B with Boost switch) Telephone point (M BT Master Socket) Television Point Satellite Point (Dual) M Under unit lighting R-Heat Radiant heater Plinth Heater Notes: 1.Heating, gas and electrical layouts on drawings are indicative subject to detailed design by specialist installers 2.All gas installation and commissioning to be undertaken registered persons 3.Gas boiler to be as SAP Calculations and fitted with "Gas 4.All electrical installation and commissioning to be undertaken registered persons 5.All electrical installations to be in accordance with BS7671:2008 amended) and Building Regulations Approved Document 6.Consumer unit enclosure to be manufactured from non-combustible material in compliance with BS 7671:2008 Chapter 42 (Amendment 3:2015) PH SH EX Ceiling wall mounted extract duct and grill Light fitting (Low Energy) P=Pendent B=Bayonet B W 01 230503RJRSCC General Notes: The Contractor shall complete all notices required Building Regulations or other authorities. All dimensions be verified on site and any discrepancies immediately to the Architect. Noted dimensions in preference to scaled dimensions. All work satisfaction of the local Building Control Office. The Project shall be carried out in accordance Building Regulations, Codes of Practice, British proper methods of workmanship, protection and so as to give a complete, sound and secure job. This drawing is to be read in conjunction with Documents and other statutory & regulatory requirements. The enclosed is to be read strictly in accordance Structural Engineers and foundation specialist structural information indicated is provided by Engineer as received. No responsibility for information indicated or errors contained therein taken by Campbell Architects. Extent and location load bearing walls to be confirmed by Structural Disclaimers : This drawing is to be read accordance with all relevant consultant information. information indicated relating to structure remains detailed design by the appointed Structural Engineer, Campbell Architects accepts no responsibility Information indicated or inaccuracies contained therein. Stair design is indicative only, and is subject design by a specialist supplier, including confirmation structural openings. Kitchen, bathroom and utility room layouts are indicative (including services layouts) and remains subject design by specialist supplier. Dimensions are measured to the structural face partitions only. 02 230711RJRSCC DRAWINGS NOT TO SCALE

04 | ACADEMIC WORKS

Regeneration of the Market Area in Belfast

Location:

Category:

Project Year: Belfast , Northern Ireland

Mixed-use, Urban Farm, Residential 2021-2022 (Master research and design project)

In the first year of my master, my studio project was about the sustainability aspect of the built environment. My design project focused on the issue of high food carbon footprint in the current food industry. Trying to reduce the food carbon footprint by shortening the food supply chain. This was achieved by localizing the food production. Therefore, my MArch 1 project was an urban farm located next to the main railway station in Belfast – The Lanyon Station. The urban farm aims to provide residents with easy and efficient access to local produced farm food.

At the same time, my MArch 1 humanity dissertation research focused on the social aspect of the built environment. It discussed the under considered humanistic care in the planning of a rapid developing city, use the Chinese city, Shenzhen as example. It argues that the humanistic care to migrants and marginalized residents was not considered sufficiently in city’s rapid development. And stressed the responsibility of the planning authorities to improve the consideration for marginalized groups in the planning of a city.

In this year, my research and design project are based on the MArch 1 urban farm project. It focused on the sustainability of the built environment both environmentally and socially.

THE FARM

‘The Farm’ is a possible solution to deal with the issues of urban food security, affordability and sustainability by localising the food production. The site was chosen at an empty plot next to the Lanyon Place (Belfast Central Station) for easy access by local and surrounding residents. The farm will also utilise the railway system to deliver the food it produced to the surrounding towns and cities.

The project include food market, food collection, local food

restaurant, local food research centre & lab, farm stay, farms, warehouse and urban farming experience centre.

The project will work as a local food production and supply system to provide safe, cheap and low carbon embodied food for Belfast and surrounding area, meanwhile to add cultural and educational value to the community.

04 | ACADEMIC WORKS

Regeneration of the Market Area in Belfast

Location:

Category:

Project Year: Belfast , Northern Ireland Mixed-use, Urban Farm, Residential 2021-2022 (Master research and design project)

‘The Market’ is an urban design project in central Belfast. It particularly focused on the social sustainability of the built environment.

The Market project aimed to offer the surrounding communities a very vibrant social environment with strong sense of belongs, sense of communities and economical resilience which the place lost due to the gentrification of the area since commercialisation started in 1980s.

The scheme provided spaces for local small business with venue for market activities such as flexible market space in the central of the scheme, the housing units on the top of commercial retail units with communal linkage on the second floor level which response to the previous building typologies before the gentrification of the area.

Housing Units

2 storey 2-bedroom housing unit on the first floor level with direct access to private front ‘garden’ and communal space.

Central Market Space

The semi-open central market space can be used flexibly. It is the space for daily market trading, community event and exhibition.

First Floor Platform

Open-air first floor platform connecting 4 blocks and providing outdoor communal space for residents.

Level 03

Level 02 Level 00 Level 01

Loading area for receiving the food from urban farm and loading the processed food delivering to other area. Cookery school kitchen with a view into the food production underneath Communal BBQ corner in the centre of the second floor roof platform Linking bridge connecting four residential blocks on the second floor. Level Living room, kitchen and reading room on the lower floor of the duplex housing, with access to the front garden. Two bedrooms on the upper floor of the duplex housing. Software Used: SketchUp Enscape Photoshop Double height space for the entrance and reception space of the cookery school. Food collection point for collecting the food processed and packaged in the food production space. Food production for processing and packaging the food produced from the urban farm. The vertical circulation core for residents to access their housing through roof platform on the second floor. Retail space on ground floor for local small business, each unit comes with workshop space on the first floor. Section Site elevation

1 2 3 4 5 6 Vapour control barrier 160 mm PU thermal insulation Vapour control barrier 200 mm reinforced concrete roof 10 mm mineral plaster 3 mm sheet anodized-aluminium Parapet-wall covering Vapour control barrier 40 mm thermal insulation 215/102/50 mm facing brick skin Galvanized-steel wall ties 100 mm cavity Bituminous-felt seal 140 mm mineral-wool thermal insulation 180 mm reinforced concrete wall 10 mm mineral plaster 30 mm oak parquet 50 mm screed separating layer 200 mm reinforced concrete floor 20 mm ipe boarding 50/60 mm squared timbers PVC layer on stilts two-layer bituminous felt seal 100 mm polyurethane thermal insulation Vapour barrier 200 mm reinforced concrete floor 10 mm mineral plaster Suspended timber ceiling 30 mm oak parquet 30 mm thermal insulation Trowelled smoothed polythene separating layer 200 mm reinforced concrete floor Two-layer polythene separation 120 mm XPS thermal insulation Bituminous sealing layer 50 mm blinding layer 1 2 4 3 5 6 Technical details Street view

Visualisation | Model making | Photography

Visualisation is a key component of effective communication in architecture. By using 3D modelling software, architects can create visual representations of their designs, helping clients to better understand and visualize the final product. This promotes better communication between architects and clients, resulting in more successful projects. During over two years work, I have developed solid skill in visualisation with SketchUp, Vray, Enscape and Lumion.

Model making is an important method of architectural thinking. Thinking through making is a process in which making and thinking alternate back and forth all the time, in rapid iterations. The making or designing could be taking place intuitively. Reflecting on what has been made helps create knowledge and insights. Creation and reflection go hand in hand – the relationship between the making and the thinking opens up an opportunity to also express knowledge through what is made.

05 | OTHER WORKS

VISUALISATION 25 43 & 45 Old Quay Road, Cultra - No. 43 Master Bedroom

MODEL MAKING

PHOTOGRAPHY

Photography has become an exciting hobby of mine since I started to study architecture. Combining travel and photography has particularly allowed me to appreciate culture from further afield. Looking at architecture through a lens enables you analyse critical principles of form, space, light and shadow to greater details. Photography is also a great way to document my life through visual diary.
