Ensure DAS Power Quality through Surge Protection As an alternative to small cell architectures, distributed antenna system (DAS) designs are taking hold worldwide as an avenue for providing coverage in targeted locations. Utilizing a structure similar to spokes off a hub in a wheel (with a cell site, or macrocell, as the hub and antenna as the spokes outward in areas of concentrated demand), DAS solutions typically can be shared by multiple operators and utilize localized power.

Application

Network Component

Value

Urban/Enterprise Sport Arenas Campuses

• Baseband Pooling Base Station Hotel • Remote Radio Heads

• Concentrates Network Nodes in Co-Location Space/Data Center

• High-Power DAS Remote Antenna (oDAS) • High and Low Power Nodes (iDAS)

• IP Connection • Broadens Wireless Access

• WiFi/Security Cameras

• Fills Dead-Zone Areas and RF Shadowing

• Baseband Pooling • Base Station Hotel • Remote Radio Heads • High and Low Power Nodes (iDAS)

• Concentrates Network Nodes in Co-Location Space • Broadens Wireless Access

• WiFi/Security Cameras

• IP Connection

• Base Station Interface Units • Head-End Repeaters • UHF/VHF Remote Units

• Extends Carrier Wireless Access Coverage • Broadens Wireless Access

• Network Management System

• Monitoring

Airports Hospitals Malls

Public Safety

AC

DC

APEX Series

RMP 615

Mini-Cab

3DC48-20

DC Edge

DC Defender

Lightning Protection Experts for Distributed Antenna Systems DAS system architectures enable 100% wireless uplink in all locations regardless of building size or geographical setting. Through the partnership of reliable surge protection and broadband DAS technology, carriers provide seamless access to data, voice and emergency communication services.

•

AC, DC, Data (Gigabit Ethernet) and RF protection engineered specifically for DAS radios, antennas and operability.

•

PolyPhaser patented RF technology offers outstanding let through voltage of ≤± 200mV for 3kA @ 8/20µs, while providing ultra PIM protection.

•

AISG compliant and IEC 60529 IP67 certified RF protection.

•

Preferred vendor status – ranked as a top supplier for on-time delivery and customer responsiveness.

•

Dedicated regional staff to assist in site audits, 4G protection designs and logistics management.

For Information Contact ROJONE, PTY LTD. Tel: 02 9829 1555 E: sales@rojone.com.au www.rojone.com.au

Superior Protection. Patented Technology.

Guaranteed Performance.

Surge Protection Required

Recommended Surge Protection

• AC Power Source, DC Power Source Option, GPS Link

• APEX Series, RMP 615, DC Edge, 3DC48-20, DC Defender, GX-Series GPS, BFN Ground Kits

• AC Power Tap on Pole or Roftop, RF Coax Link to Remotes/Nodes

• Mini-Cab, TSX-DFM-P, TSX Series, DAS-JP, DAS -TP, 4.3-10 Series, BFN Ground Kits

• High-Speed Data

• TSJ, ALPU, TB Series

• AC Power Source, DC Power Source, Option, GPS Link

• APEX Series, RMP 615, DC Edge, 3DC48-20, DC Defender, GX-Series GPS, DAS-JP, DAS-TP, TSX-DFM-P, TSX Series, 4.3-10 Series

• High-Speed Data

• TSJ, ALPU, TB Series

• AC Power Source, Ethernet, GPS, Microwave Link

• APEX Imax, TSX-NFF, IS-B50 Series, VHF50 Series GX-Series GPS , BFN Ground Kits

• High-Speed Data

• TSJ, ALPU

RF

Data

DAS-JP

DAS-TP

IS-B50 series

TSX

VHF50 series

ALPU

TB series

TSJ

Committed to Service Meeting our customers’ requirements is paramount to our effort in creating highly satisfied customers. We are the only surge protection supplier that offers a full line of professional services, including: •

Consulting and Site Audits: More than 30 years of expertise and professional experience in power and grounding consulting, site audits and educational courses for mobile network operators responsible for Distributed Antenna Systems (DAS).

•

Custom-Engineered Solutions: Experts in transient technology and standards required for UL, CE, AISG, IEC and RoHS.

•

Tailored Product Expedite (TPE) Program: Designed to provide application-specific surge protection solutions through modification or enhancement of a current product.

•

Customer Service: Dedicated inside sales and customer service teams trained in the unique surge protection requirements found within iDAS or oDAS networks.
