PRODUCT DATASHEET
Tel: 02 9829 1555 E: sales@rojone.com.au www.rojone.com.au
AC7-M8
AC Mounting hardware for Anchor Bar A7 profile
Clamping plate with M8 thread made of aluminium for fixation onto Anchor Bar A7 profile FEATURES / BENEFITS Lateral lugs for easy handling during installation
External Document Links
Notes
Technical features GENERAL SPECIFICATIONS Product Line
Coaxial Cable Accessories Radiating Cable Accessories
Product Type
Hanger
Hanger Type
Clamping plate for anchor bar
Installation Hardware Type
Anchor bar with slotwidth 18 to 22 mm (0.7 to 0.9 inch) Coaxial Foam Dielectric Radiating Cable
Cable Type MECHANICAL SPECIFICATIONS Number of Cable / Waveguide Runs
1
Material
Aluminium
TEMPERATURE SPECIFICATIONS Installation Temperature
°C (°F)
-50 to 85 (-58 to 185 )
Operation Temperature
°C (°F)
-50 to 85 (-58 to 185 )
Storage Temperature
°C (°F)
-50 to 85 (-58 to 185 )
kg (lb)
0.012 (0.026)
PACKAGING INFORMATION Package Quantity Weight per piece
AC7-M8
1
REV : A
REV DATE : 04 Apr 2013
All values nominal unless tolerances provided; information contained in the present datasheet is subject to confirmation at time of ordering
