ProRange Heating Underfloor heating solutions
Welcome to ProRange Heating UFH
ProRange is an exclusive brand to RGB Building Supplies and its sister companies. The products have been designed specifically for the Trade Installer and come with a 2 year guarantee on manifolds, pumps, controls and blend valves and 50 years on pipe.
• Quotations returned within 48 hours*
• Design & supply of materials within 5 working days
* Weekday only service
• Free design service
• High quality products suitable for a wide range of underfloor heating requirements, including alternative manufacturer options on pumps and controls
UFH DESIGN
ProRange Heating include a free bespoke design service on every order giving you the peace of mind that the system will operate in the most cost effective and efficient way. With our design team using the latest software, we are able to provide an accurate underfloor heating design for your project. All design layouts conform to BS EN1264.
At ProRange Heating, we believe planning is key. We supply designs with all our projects plus they are free!
Designs Include:
• Pipe Layouts • Pipe Loop Lengths • Manifold Schedule • Pipe Spacings • Flow rate settings
• Commissioning data • kW requirement (Designed within BS EN 1264)
What are the benefits of underfloor heating?
If you are thinking of installing underfloor heating in your home, here are some of the main benefits you’ll be able to enjoy.
• Works with different types of floor finishes
• Comfort
• Energy Efficiency
• Simple to control
• Free up valuable wall space
• Style with design
ENERGY EFFICIENCY
A traditional heating system using radiators typically have to reach quite a high temperature (65-75ºC) to maintain heat within a room.
Underfloor heating can meet the same room temperature but at a much lower rate of around 29ºC, or even less, depending on the floor type. Therefore, using less energy and substantially lowering energy bills.
Underfloor heating gives a more even room temperature ensuring all round comfortable warmth.
FREE UP WALL SPACE
LOW MAINTENANCE
ProRange Heating UFH is manufactured to high quality specification, although underfloor heating is largely maintenance free, a regular service of your underfloor heating system is generally recommended. It’s always better to regularly maintain a system to ensure it’s constantly running smoothly and efficiently.
Once installed you simply control the temperature as you need and the system does the rest by heating up your home.
With no more requirements for radiators, this in turn allows more creative freedom when it comes to decorating and designing individual rooms. Radiators restrict where objects can be positioned, but without them in place you can maximise the space available to you.
Floor construction & fixing system: 20mm
The ProRange Heating UFH ‘Staple System’ has been developed to be used in combination with floor insulation to provide a secure method of securing the pipes to the insulation layer below. ‘Staple System’ is suitable for use with screed floors.
The ProRange Heating UFH ‘Staple & Rail System’ has been developed to be used in combination with floor insulation to provide a secure method of securing the pipes to the insulation layer below. ‘Staple & Rail System’ is suitable for use with screed floors.
The ProRange Heating UFH ’Heat Emission Plate System’ has been developed to be used in combination with timber joists to provide a secure method of securing the pipes. Heat Emission ‘Plate System’ is used for joisted floors.
The ProRange Heating UFH ‘20mm Overlay System’ has been developed to be used where screeding is not an option. ‘20mm Overlay System’ is used for solid existing floors.
Heat Emission Plate System
Staple & Rail System
Pipe Staple System
20mm Overlay System
Floor construction & fixing system: 15mm
Installation
1. The sub floor needs to be flat and cleared of any debris.
2. The 15mm Slimboard are fixed down using a flexible tile adhesive or securely fixed using nine screws per board, the Slim return panels need to be secured using screws.
3. ProRange Heating pipework can then be laid into the panel in accordance with the design provided.
4. An optional layer of 3mm latex can then be laid before tiling or directly to the panel. If carpet or lino are being laid then the 3mm layer of latex is required.
5. Final floor finish can then be laid.
System information
The ProRange Heating ‘15mm Slimboard System’ has been developed where screed is not an option.
The ProRange Heating ‘15mm Slimboard System’ can be used for solid existing floors.
Pipe Diameter 10mm Length 1200mm
Width 600mm Thickness 15mm
Groove Distance 150mm
Material Cement Reinforced XPS
Water Absorption 6%
Pipework
Manifolds
• Stainless Steel 1” UFH manifold
Code Description
PROR00001
PROR00002
PROR00003
ProRange 100m Coil P-A-P 16mm UFH MLCP Pipe 20mm
ProRange 200m Coil P-A-P 16mm UFH MLCP Pipe 20mm
ProRange 500m Coil P-A-P 16mm UFH MLCP Pipe 20mm
PROR00004 ProRange 100m 16mm EVOH UFH Pipe 20mm
PROR00005 ProRange 240m 16mm EVOH UFH Pipe 20mm
PROR00046 ProRange 80m 10mm EVOH UFH Pipe 15mm
PROR00047 ProRange 240m 10mm EVOH UFH Pipe 15mm
Code Manifold Type Floor System
PROR00006 ProRange 2-Port 15mm or 20mm
PROR00007 ProRange 3-Port 15mm or 20mm
PROR00008 ProRange 4-Port 15mm or 20mm
PROR00009 ProRange 5-Port 15mm or 20mm
PROR00010 ProRange 6-Port 15mm or 20mm
PROR00011 ProRange 7-Port 15mm or 20mm
PROR00012 ProRange 8-Port 15mm or 20mm
PROR00013 ProRange 9-Port 15mm or 20mm
PROR00014 ProRange 10-Port 15mm or 20mm
PROR00015 ProRange 11-Port 15mm or 20mm
PROR00016 ProRange 12-Port 15mm or 20mm
• Manifolds supplied with End Sets (inclusive of Fill & drain points, Automatic Air Vent, Pressure Gauge)
• Isolating Ball Valves & Pipe Connectors (please order separately)
Manifold accessories
Manifold Isolation Valves Manifold Pipe Connectors
PROR00033 ProRange Pair 1"Ball Valves (Red/Blue Handle) 15mm or 20mm
Manifold Blanking Cap Manifold Replacement Flow Meter
Manifold Replacement End Units Repair Compression Coupling
Manifold Straight Connector
PROR00017 ProRange Pair 3/4"Ball Valves (Red/Blue Handle) 15mm or 20mm Code
Manifold Pin Assembly
Controls
Circulation Pump
Blend Valves for Circulation
Pump Single Room Mixing Valve
Code Description
PROR00019
UFH-BPUMP
Actuator Head
230V Controls
Wireless Controls
ProRange Pump 15-60/130 (for use with PROR00042 & PROR00020) 15mm or 20mm
Wilo Pump 15-60/130 (for use with PROR00042 & PROR00020) 15mm or 20mm
Code Description
PROR00020
ProRange Blending Valve (for use with UFH-BPUMP & PROR00019 ) 15mm or 20mm
Code Description
PROR00042
PROR00043
ProRange Single Room Mixing Valve (for use with UFH-BPUMP & PROR00019) 15mm or 20mm
ProRange 16x2mm x ½” M.I. Adapter (x 2 for use with PRO00042) 15mm or 20mm
Code Description Floor System
PROR00023 ProRange 230v Actuator Head 15mm or 20mm
Code Description
PROR00021 ProRange 8-Zone 230v Wiring Centre 15mm or 20mm
SAS920WHL-7(P) Saswell Touchscreen Thermostat 15mm or 20mm
BT-FLOORSENS Saswell Remote Floor Sensor Probe 15mm or 20mm
BTSENSHOUSE Saswell Sensor Housing
or 20mm
PROR00022 ProRange 8-Zone Wireless Wiring Centre 15mm or 20mm
BT-UFH-UH8-RF Heatmiser Wireless 8-Zone Wiring Centre 15mm or 20mm
BT-UFHSLIMLINE-RF Heatmiser Wireless Slimline Programmable Thermostat 15mm or 20mm
BT-RFSWITCH Heatmiser Wireless 2-Channel Receiver 15mm or 20mm
BT-UFHSENSOR W Remote Floor Sensor Probe (Heatmiser Only) 15mm or 20mm
BT-SENSHOUSE Saswell Sensor Housing 15mm or 20mm
Fixing systems
Pipe Staples
PROR00024
PROR00025
PROR00026
Foiled Overlay Panel
Heat Emission Plate
ProRange 60mm Pipe Staples (300 per box) 15mm or 20mm
ProRange 40mm Pipe Staples (300 per box) 15mm or 20mm
ProRange 1 Metre Lengths Interlocking Clip Rail 15mm or 20mm
Code Description
System PROR00027 ProRange Edge Insulation 50m Roll 20mm
Code Description
PROR00049
PROR00050
ProRange 15mm Slimboard 1200mm x 600mm x 15mm 15mm
ProRange 15mm Slimboard 1200mm x 600mm x 15mm - Distribution Panel 15mm
Code Description
PROR00028
PROR00029
PROR00030
PROR00031
ProRange 20mm XPS Foiled Grooved Overlay Panel - 200mm Centres 20mm
ProRange 20mm XPS Foiled Grooved Overlay Panel - 150mm Centres 20mm
ProRange 20mm XPS Backer Board200mm Centres 20mm
ProRange 20mm XPS Backer Board150mm Centres 20mm
PROR00032
PROR00044
ProRange Twin Groove Heat Emission Plate 390mmx1000mm - 200mm centres 20mm
ProRange Triple Groove Heat Emission Plate 390mmx1000mm - 150mm centres
Conduit Staple Gun
Pipe Guillotine Cutter
How to get a quote
• Please provide your drawings/plans to your local branch using the form on page 11 (or from our website)
• Please advise the floor construction
• Please advise manifold location
• Heat source - gas boiler, heat pump, LPG, oil, or other (please specify)
• Thermostat type: wired 230V or wireless
• Rooms to be heated: (Zones which require thermostat)
How to place an order
• Via your local branch, who will walk you through the process, agree costs and delivery date
Terms & Conditions
ProRange Heating use third party carriers/couriers and therefore delivery times and dates cannot be guaranteed. Furthermore, ProRange Heating cannot be held responsible or accept claims for any consequential loss as a result of a failed/late deliveries or miss-pick however caused.
UFH Warranty
RGB Building Supplies guarantees (to the original purchaser/customer] that pipe sold by it are free of defects in materials or manufacture under normal conditions of use for the period 50 years and in case of electrical and mechanical products for 2 years from the date of purchase, with pump packs & blend valves being 2 years.
This guarantee only applies to the products stored, installed, tested and operated in accordance with the fitting instructions issued by RGB Building Supplies and valid at the time of product installation.
Where a claim is made during the guarantee period and products are proven to be defective in materials and / or manufacture at the time of delivery, RGB Building Supplies will supply replacement products free of charge.
For the above to be valid the end user will need to complete a warranty application form which is available upon request from the office.
Warranty breakdown
Pipe - 50 Years
Controls - 2 Years
Mixing Valves - 2 Years
Manifolds - 2 Years
Pump - 2 Years
Insurances
Professional Indemnity - £2m
Product Liability - £2m
Pipe Manufacture
Product Insurance - €1.5m Euro
Scan the QR code for our branch finder and website.
RGB Building Supplies
We are one of the leading independent merchants in the South West operating across Devon, Cornwall and Somerset. We pride ourselves on the quality of supplies available and offer industry-leading brands at competitive prices.
