Reecher Marine AB www.reechermarine.com Kontakt: info@reechermarine.com Boat size 7.5 – 11 metres (25 – 36 ft) Length 900 mm Width 200 mm Handle Adjustable 0 - 45o Attachment Rudder
60 mm wide
head Weight 2.6 kgs (5.7 lbs) Max load 300 N sideways and 200 N vertically Material Fixing for handle in marine adapted aluminium Arm and handle in marine grade stainless steel AISI 316L Accessories
Reecher Pilot arm for autopilot
Handle leather cover (moose leather)
Bracket for tiller extension Specifications reecher® reecher® fixed S Stainless steel
stock 25 – 40 mm with a standard
rudder
•
•
•
