Reecher Marine AB www.reechermarine.com Kontakt: info@reechermarine.com Boat size 7.5 – 11 metres (25 – 36 ft) Length 920 mm Width 200 mm Handle Adjustable 0 - 45o Attachment Rudder stock 25 – 40 mm with
standard 60 mm wide rudder head Weight 3.1 kgs (5.3 lbs) Max load 400 N sideways and vertically Material Fixing for handle in marine adapted aluminium Arm and handle in marine grade stainless steel AISI 316L Tested to ISO 13929:2017 by RISE Institute Accessories • Reecher Pilot arm for autopilot
Handle leather cover (moose leather)
Bracket for tiller extension
reecher® fixed L Adjustable between 0 - 45o
a
•
•
Specifications
