Voltz Remote Power Panels

TheAPPLICATIONVoltzRemote

Power Panels are made to provide branch circuit distribution in data centers. The enclosure is designed to fit on a half or whole 2 x 2 tile.

PRODUCT DESCRIPTION

The Voltz Remote power panel is a versatile and configurable solution that accommodates a variety of input and out voltage configurations. The Voltz RPP is available as 208V/120V, 208V DELTA, 415V/240V, and 480V/277V. Due to the unique din rail breaker assembly, the Voltz RPP is not limited to a specific number of poles per input. Choose as many or as little output breakers as needed in 1-pole, 2-pole, 3-pole, or even 4-pole configurations. Choose any current from 100 amps to 500 amps per input, available as main lug only or with a main input circuit

CIRCUITbreaker.

PROTECTION

Voltz Remote panels only use 100% rated, adjustable trip, electronic trip circuit breakers for main input protection. Branch circuit breakers are UL 489 hydraulic/magnetic. No thermal circuit breakers are utilized in the design of the remote power panel.

WHY CHOOSE A VOLTZ RPP?

The unique din rail construction of a Voltz Power Panel make it easy to customize without the need to undergo a new NRTL compliance certification. The Voltz Remote Panel uses the flexible UL 508A certification in conjunction with a modular din rail to make breaker ratings, number of poles, and positioning all customizable without sacrificing quality or lead time.

DEADFRONT VIEW Amp 84 Pole MLO Shown

INTERNAL VIEW

TheOPTIONSVoltzRemote

Power Panel has a variety of smart options. The unit can be customized with any of the following mains metering with over 40 power metrics

- Monitor current on mains

- Monitor current on branch circuits

- On/Off control branch circuits

- Thermal monitoring

- Local touch screen HMI

- Communication: Ethernet, Modbus, Wifi, or RS232

- TVSS & EMI Filters
