Perimeter Protection

 INTRODUCTION

Perimeter Protection The leading provider of temporary security solutions We close off areas, redirect traffic and create safe temporary passageways.

Ramudden Perimeter Protection Ramudden Perimeter Protection

We close off areas, redirect traffic and create safe temporary passageways Ramudden delivers temporary safety solutions for high-risk environments. We protect roads, construction sites, public spaces, high-security zones, and military areas, always with strict standards, compliance, and reliable delivery.

Our services include:

Secure handling of classified information

• •

Our certified personnel, working with high-security solutions, undergo thorough background checks and training in accordance with current legal requirements.

Through strong internal procedures, they follow strict guidelines to minimize risks and ensure the secure handling of classified information.

• •

Customized solutions for perimeter protection.

Project-specific installations tailored to each requirement.

Ability to manage traffic flow and create secure passages.

Qualified staff trained and authorized to handle classified information.

Vehicle attack and intrusion protection We protect public events, high-security sites, and critical assets in several countries, always with the aim of keeping people and places safe. Our solutions adapt quickly to changing threats, with expertise and resources on site.

With systems offering unique features, we provide protection by preventing visibility, stopping intrusions, and reducing the impact of hostile vehicle attacks.

Protection planning Ramudden has carried out a comprehensive security protection analysis, forming the basis for our security protection plan and clear instructions for handling classified data. This ensures that sensitive information is safeguarded at every stage during storage, transfer, access, and processing.

Setting the standard in perimeter security Our perimeter protection systems combine flexibility and strength to address a wide range of safety and security needs. Designed for rapid installation where time is critical, they are built to meet the world’s highest security standards. In today’s evolving security environment, we deliver tailored solutions — from temporary installations requiring fast deployment, to long-term protective measures for construction sites, high-value properties, classified facilities, and other sensitive areas.

Traffic Bridges Temporary bridges for heavy traffic, worksites and military use Traffic Bridges combine unmatched strength, versatility, and safety. Quickly deployed under demanding conditions, they provide reliable temporary crossings for heavy traffic, urban sites, and military operations where robust bridge solutions are essential.

Svea Barrier System Barrier system for road work, security zones and military applications Svea is a high-performance temporary barrier system, equipped with a wide range of accessories to provide protection for road works, worksites, and perimeter security. Crash-tested to AASHTO MASH TL-3 and ISO 22343 for hostile vehicle mitigation.

XBS Area Shield System Perimeter protection with secure access points safeguards protected sites XBX is a flexible system for temporary protection of sensitive and security-classified areas. With sturdy base blocks, height options, access solutions, and accessories, the system can be tailored to your specific needs regarding size and security level.

Ramudden Perimeter Protection

Traffic Bridges

Temporary bridges for heavy traffic, worksites and military use Traffic Bridges combine unmatched strength, versatility, and safety. Quickly deployed under demanding conditions, they provide reliable temporary crossings for heavy traffic, urban sites, and military operations where robust bridge solutions are essential.

Traffic Bridge 4 m

Traffic Bridge 6 m

Traffic Bridge10 m

Traffic Bridge 12 m

Heavy duty railing provides multiple features Use the Heavy duty railing system to create controlled passages and manage flows. The system can, for example, prevent vehicles from entering restricted areas while still allowing safe pedestrian access.

Single passage

Various passage

Traffic bridge with single passage can be used to control pedestrian flows at large events.

For crowd control, when a wider passage is needed, you can combine single and full width as desired

Temporary Bridges for Demanding Environments Traffic Bridges are modular steel bridges that quickly create safe crossings over roads, waterways, and secured areas. They combine strength, flexibility, and easy installation, making them indispensable for everything from infrastructure projects to military operations.

Built to Handle All Vehicles and Loads The bridges are designed for heavy traffic and can handle free spans of up to 10 meters. Tested according to Eurocode EN 1991-2 and the Swedish SS 7750-2 standard, they ensure capacity for everything from civilian transport to combat vehicles and military convoys.

The driving surface features anti-slip coating to provide safe crossings in all weather conditions.

Flexibility and Adaptation The system is modular and can be connected to achieve the desired width. The bridges are available in several lengths – 4, 6, 10, and 12 meters, and can be complemented with railings, ramps, and protective fencing for different applications. Whether the need is a quick solution in an urban environment or a robust field system in rough terrain, the design can be adapted.

Civil and Military Perimeter Protection Thanks to their robust steel construction, easy handling, and quick installation, Traffic Bridges are ideal for both civilian needs and military applications. They create clear, secure crossings and strengthen perimeter protection in everything from construction sites and cities to base areas and operational fields. With Traffic Bridges, you get a reliable solution that withstands all vehicles and the most demanding conditions.

Traffic bridge 12 m with 200 ton load capacity Our largest traffic bridge is designed for the toughest conditions, yet is still quick to set up. It has full load-bearing capacity, up to 10 m between the support points, and can handle the heaviest vehicles.

BEARING CAPACITY

200 TON

Traffic Bridge 12 m Our largest traffic bridge is 12 m. It is designed to handle the largest military vehicles, such as tanks and transport trucks.

•

1.5 meters wide section.

•

Can be assembled to desired width.

•

Free span 10 m.

•

3rd party verified according to eurocode.

•

Compatible with HD-Railing for heavy traffic.

•

Compatible with Light Railing.

Ramudden Perimeter Protection

Traffic Bridge

Traffic bridge applications

Vehicle access for inspections Traffic bridge 6 m with a barrier is used when vehicles need to be inspected at established border.

Crowd control Traffic Bridge sections are used for large-scale pedestrian crossings at established borders.

Our traffic bridges can withstand the toughest conditions and are quickly deployed wherever vehicle access needs to be created.

Traffic Bridge Can be quickly deployed and used in the toughest conditions.

Traffic Bridge Modular design enables seamless assembly, allowing sections to be connected side-by-side for desired width.

Traffic Bridge Engineered for quick and straight forward installation.

Ramudden Perimeter Protection

SVEA Barrier system

Barrier system for road work, security zones and military applications Svea is a High Performance Temporary Barrier System crash-tested according to AASHTO MASH TL-3 and ISO 22343 for hostile vehicle mitigation.

Tested for military use

Quick, easy Installation

Safety is our top priority. SVEA barriers are rigorously crash-tested to EN 1317-2 (T2, T3, N1, N2) and MASH TL-3, with excellent results. The system also meets ISO 22343 for Hostile Vehicle Mitigation (HVM), ensuring resilience against vehicle-borne threats. CE-certified, it provides reliable protection for road workers, the public, and high-security areas, with effective traffic control and redirection. Svea is also suited for military use, where safety and reliability are critical.

SVEA’s patented connection system allows one person and a crane truck to install an EN 1317-compliant setup in ten minutes. The design permits barrier angles up to 3° in all directions, accommodating vertical shifts of up to 140 mm while ensuring a strong connection. Ideal for road zones and secure areas needing rapid deployment.

Durability you can trust SVEA barrier is lined with an ISO 1461 hot-dip galvanized steel frame, providing long-term durability and protection from damage. Built to last in tough conditions, Svea is reliable for roads, security zones, and military applications.

Adaptability for critical environments SVEA’s flexible system allows for quick responses in road work, security zones, and military operations. The connection system enables easy removal for emergency access, and with three barrier lengths and various accessories, SVEA can adapt to diverse needs. A hinge element lets barriers turn up to 100°, increasing versatility.

Ramudden Perimeter Protection

SVEA Barrier system

SVEA barrier applications

Area Protection Permanent or temporary privacy and sound-protecting perimeters for airports.

Security passage Full height gates and pedestrian access systems for continuous enclosures.

Event and terror protection Ideal for privacy and sound-protected areas at events.

Traffic control Allocate a part of the road for military vehicles with a SVEA Barrier installed to the desired length.

Checkpoint Quickly establish a checkpoint for inspection at the passage of vehicles.

Block off a passage Install blockades quickly and easily with SVEA

Ramudden Perimeter Protection

XBX Area Shield System

Perimeter protection with secure access points safeguards protected sites XBX is a flexible system for temporary protection of sensitive and security-classified areas. With sturdy base blocks, height options, access solutions, and accessories, the system can be tailored to your specific needs regarding size and security level.

XBX System surrounds a high-security site with controlled access for personnel and vehicles at selected locations.

Perimeter protection quickly in place

Stable and neutral construction

XBX is a high-security barrier that delivers perimeter protection fast. The modular design allows quick setup without major groundwork, making it ideal for short, time-limited needs. At the same time, the robust construction ensures durability for extended use when long-term security is required.

With sturdy base blocks, braces, and panels in various lengths, XBX remains stable even in demanding conditions.

The aesthetically neutral appearance makes the system discreet in public spaces while strong and reliable for security classified sites.

Flexible design and access points The XBX system adapts to different environments and layouts. Gates, doors, and checkpoints can be integrated to create controlled passages for vehicles and pedestrians.

This makes it easy to manage traffic flows, regulate access, and keep unauthorized individuals at a safe distance.

Security in critical environments XBX is used where safety cannot be compromised. As a flexible solution for perimeter protection, it secures everything from temporary events and projects to long-term installations at sensitive facilities and military sites.

Reliable, adaptable, and always ready when protection is needed.

Variation of set-ups •

XBX systems offer flexible height configurations.

•

Choose the Tripple-Height setup for a maximum height of 5.1 m (16' 10"),

•

Quadruple-Height setup for a height of 6.4 m (21') including the barbed wire.

•

Add secure access points

Ramudden Global is a network of infrastructure safety companies, providing expertise in urban and high-speed traffic management, and world-leading solutions in perimeter protection and infrastructure safety, continuously evolving in line with new requirements and the needs of our users.

With over 5,000 employees across 13 different countries and sales of €1 billion a year, our success is down to our focus on our mission, ‘to get people home safely every day’. No matter where you are, our employees, our customers’ employees and the general public deserve to work, travel and move through the world safely. We believe this is what matters most.

It inspires our entrepreneurial spirit and creativity, sharing ideas and solutions to lead the way in innovation and governance to become a force for good. A caring force for a safer world. www.ramuddenglobal.com

Canada

USA

Europe

Global presence, local impact Ramudden Global develops products together with its customers and partners across multiple regions. With an extensive distribution network and efficient logistics flows, we deliver complete systems worldwide, from standardized solutions to complex applications.

Unrivalled support from 85 depots across the Nordics and Baltics Ramudden ensures readiness through stocked products and an extensive depot network across the Nordics and the Baltics. This enables rapid deployment and installation of complete applications, even under changing security conditions, complex site requirements, and urgent workplace needs.

Nordics Baltics

Middle East

Australia

New Zeeland

Your Safety.

Delivered.

Ramudden Sweden Strömsbrovägen 26 | 803 09 Gävle Tel: + 46 10 303 50 00

Ramudden Norway Myråsdalen 10 | 1407 Vinterbro Tel. +47 92110000

Ramudden Estonia Artelli 16/18 | 10 621 Tallinn, Eesti Tel +372 622 9530

Ramudden Denmark Navervej 24, 4000 Roskilde CVR: 29511098 | Tel: +45 70202094

Ramudden Finland Veturitie 27 | 00240 Helsinki Tel: + 358 10 205 1200

www.ramuddenglobal.com With over 5,000 employees across 13 countries, Ramudden Global is the leading full-service provider of infrastructure safety solutions. Driven by our mission - “To get people home safely every day” - we harness innovative products, digital solutions, and professional services to ensure the highest quality in every project we undertake.

Revision 2507
