�Rugged. Interchangeable. Adjustable.� Overview
RAM offer custom and universal mounting solutions for a number of devices including:
Phones
Tablets
GPS
Cameras
laptops
Rugged, industrial strength mounting solutions
Patented, interchangeable ball & socket systems
Lifetime warranty**
Compatible with or without heavy-duty cases or skins
Suitable for low and high vibration environments **Lifetime warranty on mechanical parts 3 year warranty on electrical parts.
1
2
123: Building A Mount Building A Mount
>> Device Holder The device holder is the component that grips or attaches directly to your particular phone, tablet, GPS, action camera or any other device.
>> Double-Socket Arm The arm connects the holder to the base via the RAM ball & socket system and is what gives your mount its adjustability. Available in 3 lengths, 2 ball sizes (1� B size & 1.5� C size) and in 2 materials; the ideal choice of arm depends on the weight of your device and the environment / application in which the mount is being used. Base << The base is the component that hosts your mount and attaches it to the desired surface. The base and all other components are interchangeable, so depending on the application you can utilise suction, clamp, screw-on, adhesive bases and more.
3
Components
Part No: Material:
RAP-B-201-A
RAP-B-201
RAM-B-201-A
RAM-B-201
RAM-B-201-C
Composite
Composite
Aluminium
Aluminium
Aluminium
C-Size:
Part No: Material:
>> B-Size for 1� balls are available in both composite and aluminium. As aluminium arms are reinforced, this material offers an additional Long size as well as Medium and Short.
>> C-Size for 1.5� balls are also available in both composite and aluminium. As aluminium arms are reinforced, this material offers an additional Long size as well as Medium and Short.
RAP-201-B
RAP-201
RAM-201-B
RAM-201
RAM-201-D
Composite
Composite
Aluminium
Aluminium
Aluminium
Locking:
Part No: Material:
Components
B-Size:
(NOTE: for weight allowances, please refer to the technical information available on our website at www.ram-mount.co.uk)
B-Size:
C-Size:
RAM-B-201-SU
RAM-201-SU
Aluminium
Aluminium
4
Phones & Tablets
Phones & Tablets Used in a wide variety of commercial and fleet vehicles, our universal phone & tablet mounts can host a wide range of mobile electronics.
The Universal
X-Grip® For Phones & Tablets
The revolutionary X-Grip® is an extendable range of universal holders that can expand and contract to grip any phone or tablet with or without a case. Incorporating a smooth spring-loaded mechanism with rubber tipped arms, the X-Grip® offers a unique concept that provides a strong hold with quick & easy adjustment for mounting your devices.
The X-Grip® features: + Suitability for 99% of devices on the market + A universal fit for devices with or without cases + A high-strength rugged design + Easy access to all device ports + Powerful spring-loaded arms for a solid grip + Rubber tips to secure and protect your device + Rugged composites with stainless steel details + A lifetime warranty - Made In USA. + Security Tether included with UN7, UN8 & UN10
Part Number Specification
Width
RAM-HOL-UN7B
RAM-HOL-UN10B
Depth
MIN
MAX
X-Grip® Universal Phone Holder with 1” Ball
1.25”
3.25”
MAX 0.875”
Large X-Grip® Universal Phone Holder with 1” Ball
1.75”
4.5”
0.875”
RAM-HOL-UN8B
X-Grip® Universal 7” Tablet Holder with 1” Ball
2.25”
5.75”
0.875”
RAM-B-202-UN9
X-Grip® Universal 10” Tablet Holder with 1” Ball
6.25”
8.1”
0.875”
RAM-B-202-UN11
X-Grip® Universal 12” Tablet Holder with 1” Ball
7.25”
8.75”
0.875”
Action Cameras & Dash Cams With vibration absorbent materials and 360º adjustable components, RAM Mounts are the best available solutions for mounting your action camera in any location.
5
Part Number
Specification
Info
RAP-B-202-GOP1
GoPro Adapter with 1” Ball
Fits all GoPro Heros & any action camera using the GoPro footprint
RAP-B-366
1” Ball with 1/4”-20 Male Camera Thread
Connects to any standard female thread. Recommended for small cameras.
TAB ACTIVE MOUNTS Phones & Tablets
RAMÂŽ Mounts has partnered with Samsung to develop powered vehicle cradles for the Tab Active 2, 3 & Pro, including locking and non-locking versions. Designed to meet the demands of applications such as field services,logistics, manufacturing, transportation and more, these cradles both charge and protect the tablet.
Tab Active 2 & 3 Locking Holder RAM-HOL-SAM58PKL
Tab Active 2 & 3 Non-Locking Holder RAM-HOL-SAM60P
Tab Active 2 & 3 Power & Data Holder
Tab Active Pro Holder
RAM-HOL-SAM60PD
RAM-HOL-SAM52PD
Holders for the Tab Active 2, 3 & Pro are also availble with vehicle hard-wire kits and can connect to any RAM vehicle base (pages 11-12) while the rubber ball and socket system allows users to efficiently switch between portrait and landscape modes.
6
IntelliSkin
Not only do RAM offer a wide range of industry leading mounting brackets but we also provide a line of unique protective skins and charging docks for Samsung and Apple devices called the IntelliSkin速. From use at home or in the office to the warehouse or in-vehicle; with integrated charging pins the IntelliSkin速 works seamlessly with our GDS速 (Global Docking Systems) docking stations and can be mounted anywhere when paired with RAM Mounts.
For more information on our full range of IntelliSkin速 products, please visit www.ram-mount.co.uk
7 5
Part of our exclusive IntelliSkin® & GDS® range caters specifically for the Samsung Galaxy Tab Active tablets.
for the Samsung Galaxy Tab Active2
RAM-GDS-SKIN-SAM29
GDS® Dock for Samsung Tab Active2 RAM-GDS-DOCK-V2-SAM29
GDS® Desktop Dock Pro Charger
GDS® 6-Port Desktop Charger
RAM-GDS-DOCK-D1
RAM-GDS-DOCK-6G1P
IntelliSkin
IntelliSkin® for Samsung Tab Active2
This range includes custom form-fitting skins with integrated GDS® charging pins, locking / non-locking vehicle docks and desktop charging units.
GDS® Locking Dock for Samsung Tab Active2 RAM-GDS-DOCKL-V2-SAM29
For more information on our full range of IntelliSkin® products, please contact us via sales@ram-mount.co.uk, 020 8894 1234 or visit www.ram-mount.co.uk.
8
GPS Mounts
GPS Mounts RAM offer a wide variety of custom holders and mounts for the Garmin fleet, dezl, nuviCam, dezlCam series and more. For full details, prices and product specifications for all our our GPS holders and kits, please visit www.ram-mount.co.uk, or contact us via 0208 894 1234 or sales@ram-mount.co.uk
**For base options please refer to page 8 Product
Part Number
Locking Case for the Garmin dezl™ 760LMT, nuvi® 2797LMT & RV 760LMT
RAM-HOL-GA61L
Cradle for the Garmin dezl™ 760LMT, nuvi® 2797LMT & RV 760LMT
RAM-HOL-GA54
Locking Case for the Garmin Dezl 770LMTHD
RAM-HOL-GA70L
Locking Case for the Garmin Dezl 570LMT
RAM-HOL-GA71L
Locking EZ-Roll’r™ Cradle for the Garmin nuviCam and dezlCam
RAM-B-HOL-GA68L
Locking Case for the Garmin dezl™ 560LMT & 560LT
RAM-HOL-GA43L
Product
9
Part Number
Locking Case for the Garmin fleet 660/670
RAM-HOL-GA66L
Flat Surface Locking Mount for the Garmin Fleet 770, 780 & 790
RAM-B-138L-GA75L
EZ-Roll’r™ Locking Cradle for the Garmin Fleet 770, 780 & 790
RAM-HOL-GA75L
Pin-Lock™ Security/Key Knob & Locking Case for Garmin fleet 660/670
RAM-B-138B-GA66L
Pin-Lock™ Security Knob & Locking Case for Garmin fleet 660/670
RAM-B-138-S5-GA66L
Flat Surface Mount for the Garmin Fleet 770, 780 & 790
RAM-B-138-GA75L
GPS Mounts
For the TomTom Bridge we provide a selection of modular components to build custom mounts that attach to the adapter plate of the Bridge and can also be used to mount our other GPS holders
OR
2” X 1.7” Adapter Base
Double Socket Arm
Long Double Socket Arm
3.3” Suction Cup Base
2.5” Screw-Down Base
RAM-B-347U-TOM1
RAM-B-201
RAM-B-201-C
RAM-B-224-1
RAM-B-202
Tough-Track™ We also offer a comprehensive range of adjustable centre and end-loading track bases that can hold multiple devices on a single track via our patented Track Balls. For more information please see pages 13-14
**For our full range of custom GPS holders, please visit our website www.ram-mount.co.uk
10
POD HD™ Heavy Duty Mounts
Perfect for heavier devices, the Universal No-Drill™ RAM POD HD™ Vehicle Mount with Double Socket Arm & 2.5” Round Base AMPs Hole Pattern adapter is the perfect choice for safely and conveniently operating essential electronics inside your vehicle. The versatility of the RAM Pod HD™ makes it an ideal solution for mixed vehicle fleets, consumer vehicles of all types and other applications that require a robust mounting platform for your devices. Product Small POD HD™ Large POD HD™
Part Number RAM-316-HDR-202 RAM-316-HDR-18-202
Min-Max Pole Length 12” 24.75” - 31.75”
(NOTE: for more information on RAM POD HD™ compatibility for your vehicle, visit: www.ram-mount.co.uk)
11
RAM No-Drill™ Vehicle Base The RAM No-Drill Vehicle Bases build upon the same modular system that our regular mounting solutions utilise but on a larger and more robust scale.
The device holder can consist of either a Tab-Tite™ tablet holder or a Tough-Tray™. Both product lines come in multiple sizes to accommodate a variety of devices. Adjustable Swing-Arm
Heavy Duty Mounts
Tray / Holder
RAM Tele-Pole™ Tele-Pole (Upper) RAM Tele-Pole™ (Lower) Base Universal vehicle base expands from 9” to 19” seat bolt centre
Tab-Tite™ Tab-Tite™ features:
+ Interchangeable bumpers + Spring-loaded bumpers offer strong grip and quick & easy docking + Easy access to all device ports + Lifetime guarantee - Made In USA
(NOTE: for more information on the Tab-Tite™ range, please visit www.ram-mount.co.uk or email sales@ram-mount.co.uk
12
Heavy Duty Mounts
Tough-Tray™ The Tough-Tray™ range is pair of extendable universal tray systems for laptops, netbooks and tablets. The larger Tough-Tray™ can accommodate large heavy duty laptops whereas the smaller Tough-Tray™ II is designed for lightweight netbooks and tablets.
Laptop Tough-Tray™
MIN to MAX grip width: 8.56” to 11.12”
RAM-234-3FL
Swing-Arms
RAM-234-6
Tele-Pole™
The Swing-Arm range is pair of extendable universal tray systems for laptops, netbooks and tablets.
9” Long Lower Tele-Pole™ RAM-VP-TBF9
13
Tough-Tray™ II for Tablets & Netbooks
MIN to MAX grip width 10” to 16”
2” Long Top Tele-Pole™ RAM-VP-TTM12
12” Tele-Pole™ w/ Flange RAM-VP-TTMF12
RAM Vehicle Pole Mount Vehicle / Printer Mounts
Blending the best of versatility, strength and installation ease, RAM vehicle pole mounts with adjustable ratchet bases are true workhorses for commercial van fleet operators. Suitable for vans where the seating arrangement has either a tubular or a closed panel seat frame configuration. The RAM pole mount is an ideal solution for mounting tablets, small laptops, printers and other similar electronic devices. Requiring minimal space in the vehicle cab, it can be removed quickly without the use of tools. (Available with a variety of pipe lengths and ball mounts with 75mm VESA or the AMPS base plates).
(NOTE: for technical specifications regarding our vehicle mount range, please contact us via: www.ram-mount.co.uk sales@ram-mount.co.uk or on 020 8894 1234
Printer Mounts Ease of use, rugged and reliable are words used to describe RAMÂŽ Printer Mounts. Ideally suited to help create the ideal mobile office environment, RAM is the perfect solution for mounting a portable wireless printer in your vehicle. We offer both universal and form fitting designs for a number of leading printer brands. For more information and technical specifications please visit: www.ram-mount.co.uk
14
Installation Solutions
Tough-Track™
Rugged. Interchangeable. Adjustable.” ” Tough-Track™ The Tough-Track™ is an innovative product line that allows multiple devices to be mounted and adjusted on a single track system in any vehicle or on any suitable surface. Using a RAM Track Ball™, any compatible RAM kits can then be configured to suit a wide array of applications. Available in 2 materials - Aluminium & Composite - and in multiple lengths, the Tough-Track™ features:
Composite: >> High-strength glass filled nylon construction >> Centre device loading capabilities >> Compatible with RAM 1” B & 1.5” C Size balls, Post/Spline and Flex Rod components >> Lifetime Warranty
Aluminium: >> High-strength aluminium construction >> Adaptable, modular designs with centre or end loading capabilities >> Straight & 90º add-ons for connecting and extending multiple tracks >> Compatible with RAM B & C Size balls, Post/Spline and Flex Rod components
15
>> Lifetime Warranty
Composite:
RAP-TRACK-A2 3.75”
RAP-TRACK-A3 4.75”
RAP-TRACK-A5 7”
RAP-TRACK-A9 10.75”
RAP-TRACK-A12 14.5”
RAP-TRACK-A16 18.5”
Tough-Track™
Part No: Length:
Aluminium:
Part No: Length:
Part No: Info:
RAP-TRACK-EXA-3 3”
RAP-B-354-TRA1 RAM 1” Track Ball™ w/ T-Bolt
RAP-TRACK-EXA-5 5”
RAP-TRACK-EXA-9 9”
RAP-354-TRA1 RAM 1.5” Track Ball™ w/ T-Bolt
RAP-TRACK-EXA-13 13”
RAP-TRACK-EXA-CC90 90 Degree Connector
RAP-TRACK-EXA-17 17”
RAP-TRACK-EXA-CC Centre Load Connector
16
