HYDRAULIC MACHINE FOR SHEET CUTTING - MANUAL

2. Main uses, performance and characteristics of the machine This machine is suitable for cutting ordinary steel plates with a thickness of 0.6-6 mm and a width of 2500, 3200, and 4000 mm. The strength of the sheet to be sheared is based on 450N/mm2. If sheets of other strengths need to be sheared, the thickness of the sheet to be sheared should be adjusted accordingly.

This machine adopts steel plate welded body and slider. The fuselage and slider undergo vibration aging treatment to remove welding and machining stress to ensure the accuracy and accuracy of the machine tool are maintained. The shearing of the slider is driven by the hydraulic cylinder and the nitrogen cylinder returns, which can effectively realize the overload protection of the machine tool; the machine tool works stably, has a small size, light weight and good rigidity.

Adjusting the cutting edge gap is quick and convenient. The machine is equipped with front and rear stoppers, and the back stopper adopts mechanical transmission.

The rotating display shows the value and can be manually fine-tuned. The adjustment is convenient and reliable. The front stopper uses a ruler to count and the stopper is positioned. In addition, the stroke of the upper tool rest can be adjusted arbitrarily to improve the efficiency of cutting narrow sheets. The machine is also equipped with a guardrail to ensure safe operation.

3. Machine hydraulic transmission system The hydraulic system of the machine (see Figure 1) mainly consists of 10MCY141B axial piston pump 2, electromagnetic relief valve 3, pressure material 6, nitrogen return cylinder 7, main oil cylinder 8 and collar air reservoir 9. The entire system More reasonable.

The pressure oil required by the system is supplied by the 25MCY-1B axial piston pump 2. The maximum working pressure of the system is 20MPa. The return stroke of the upper tool rest is completed by a nitrogen cylinder, and the pressure of the nitrogen cylinder is about 5MPa. Working principle of hydraulic system (see Figure 1) The upper tool rest shears downward: When the electromagnet YV1 of the

electromagnetic relief valve 3 is electrically actuated, the oil output by the plunger pump 2 passes through the electromagnetic relief valve 3 and enters the pressure cylinder and the upper chamber of the main oil cylinder at the same time. When the piston of the pressing oil cylinder presses down to the sheet after overcoming the tension of the tension spring, the oil pressure begins to rise. When the oil pressure rises to overcome the nitrogen pressure of the return cylinder 7, the upper tool rest moves downward for shearing, and this process continues That is to say, the program action between the pressing cylinder 6 and the upper tool rest is realized.

Upper tool rest upward return stroke: When the upper tool rest moves down to the bottom dead center, the electromagnet YV1 of the electromagnetic relief valve 3 loses power under the action of the travel switch, and the upper tool rest begins its upward return journey under the action of the return nitrogen cylinder. At this time, the oil in the upper chamber of the main cylinder flows back to the fuel tank through the electromagnetic relief valve. At the same time, the piston of the pressure cylinder also returns upward under the action of the tension spring. The oil in the pressure cylinder also returns to the tank through the electromagnetic relief valve 3. When the upper tool rest returns to the starting point, the entire shearing process ends.

Hydraulic system faults and troubleshooting Fault phenomenon

cause Poor contact of the electrical plug of the electromagnetic reversing valve

The oil circuit is established and cannot be pressurized The tool holder does not move when the force is applied

The upper tool rest returns slowly or cannot return to the top dead center The action sequence of the upper tool rest and the pressing cylinder is not coordinated

The valve core of the electromagnetic reversing valve is stuck or roughened by debris and does not operate. The sealing port of each valve core of the combination valve has debris and does not function as a seal. Each throttle hole in the combination valve is blocked.

Insufficient nitrogen pressure in nitrogen cylinder

Method of exclusion Repair electrical plugs

Check for disassembly and washing

Nitrogen cylinder charging increases pressure

Common hydraulic faults of QC12Y shearing machine 1. The valve core is clogged due to lack of pressure in the system. Disassemble the solenoid valve and regulating valve. Use the M8 screw to pull out the pressure plate.

Take out the valve core spring. The valve sleeve does not need to be taken out. Clean it with gasoline, including the inside of the valve body. Clean and put it back as it is. If that doesn't work, clean the regulating valve and solenoid valve. Before cleaning, drain the oil inside the tank, clean the tank and filter it.

2. Check whether the main motor is fully started. Because the motor has high power, the starting mode is ▲ start.

3. According to "Electrician Inspection", the green light on the front operation panel is not on. "Motor power is above 18.5KW)

Hydraulic components detailed list serial name

number 1

2

Specification

Mesh oil filter

Q=160L/min

4

5

6

self made

valve pressure

gauge P=32MPa d=8mm

KZF-L8H-S

switch pressure gauge

P=25MPa φ=100mm

Y-100-NZh

Solenoid

P=31.5MPa d=8mm

SWH-G02-B2-E24-20

directional

7

ball valve

P=32MPa d=15mm

CJZQ－H15L

8

relief valve

P=31.5MPa d=6mm

F2ZB-H16F-4

P=16MPa

Y-60-NZh

10

Working 18MPa

valve

9

Remark

WU—160×100-J

Axial piston pump P=32MPa Q=25L/min 25MCY14-1B

Combination 3

model

inflation valve pressure gauge

Figure 1

pressure

4. Machine structure 1. Rack: The frame structure is welded by steel plates and has good rigidity. The two cylinders are fixed on the left and right columns. There is an auxiliary tool rest on the workbench to facilitate micro-adjustment of the lower tool rest to ensure that the gap between the upper and lower blades on the machine tool is consistent. There is also a feeding roller ball installed on the work surface, which is easy to operate.

2. Upper tool rest: It is a steel plate welded structure with good rigidity. It uses the eccentric sleeve (9) as the fulcrum to swing back and forth to complete shearing driven by the left and right oil cylinders and the accumulator return cylinder. (Figure II) The blade vertical supporting surface of the upper tool rest forms an arc-shaped backing plate to ensure the consistency of the gap between the upper and lower blades during the shearing process.

3. Pressing device: It consists of several pressing cylinders installed on the support plate in front of the frame. After the pressing cylinder is filled with oil, the pressing head presses against the tension of the tension spring (18) to compress the sheet.

After shearing is completed, it is reset by the tension of the tension spring.

The size of the pressing force increases with the thickness of the sheared plate.

4. Front and rear stoppers: Front stopper: Place it on the work surface and use a ruler to indicate the value to adjust the movable stopper to achieve the required stopper value. It is more convenient to use the front stopper when cutting thin steel plates.

The back gauge (see Figure 5) is installed on the upper tool rest and swings up and down with the upper tool rest. The adjustment of the back gauge is driven by a 0.55KW motor, which is driven by a screw rod after being reduced by gears. Press the adjustment button "+ ” (or “ - ” ), the baffle plate can be adjusted forward (or backward). When the motorized adjustment cannot reach the required adjustment value, the manual adjustment wheel (56) can be rotated for manual fine-tuning to ensure The required adjustment value, so the adjustment of the backgauge is convenient and reliable.

The adjustment range of the backgauge is 20~700mm. When the length of the sheet to be cut is greater than the maximum backgauge distance, the baffle plate (43) can be opened to the final position and passed through the slope on the bracket (47) Lift the baffle (43) to cut the sheet of any length.

5. Machine electrical system This machine uses 50HZ, 380V three-phase power supply. The machine's motor uses single-phase 380V, and the alignment light uses single-phase 220V. The control transformer adopts two-phase 380V. The output 220V of the control transformer is used for the control circuit and alignment lights, of which 27V is supplied to the electromagnetic reversing valve. 6V supply indicator light.

The machine's telegraph box is located on the left side of the machine tool. The operating components of the machine, except for the foot switch SF, are all concentrated on the button station in front of the machine tool. The function of each operating procedure component is marked by an image symbol above it.

The machine operating sequence is described as follows: open the electrical box door, close the power switches QF1 and QF2, turn on the machine power, and close the electrical box door. Turn on the key button SA1 ( circuit power. The indicator light HL1 ( Press button switch SB4 or SB5 (

) and turn on the control

) is on, indicating that the power is on. ) to increase or decrease the backgauge

opening to the required size. The specific size of the backgauge opening is displayed by the counter on the lower left side of the button. The maximum and minimum dimensions of the backgauge opening. It is equipped with a travel switch (SQ3 SQ4) to limit the maximum opening distance of the stopper to 500mm (600 mm) and the minimum opening distance to 20mm.

Press the button switch SB3 (

) to start the oil pump motor. The button switch

SB3 itself has an indicator light to prompt the oil pump motor to work.

Turn the knob switch SA3 (

) to select the cutting specification. When SA3

is turned to the ( ) position, it is a "one stroke", and when SA3 is turned to the

Electrical code

Name and purpose

SB 3 HL 2 SB 4 SB 5 SB 1

Button oil pump Stopper forward control Material blocking

SA 3 SA 2 SA 4

SA 1

SF

Technical data

quantity

model

1 1 1 2

LAY 3-11D /6V LAY 3 -11 LAY 3 -11 LAY-11ZS/1

1 1 1

LAY 3-02Y _ LAY 3-20X _ LAY 3-11Y _

1

LAY 3-20Y _

1

YDT 1-11 _

1《a》Green 1《a》black 1《a》black φ35mm red Single board 2 switch places Cut Vc=220V continuous/single 1th=6A Alignment switch 2《a》+1《b》 Cut count on/off 1《a》+1《b》 2《a》 Single board 2 positions Vc=360 key switch 1th=6a2 "a" Foot switch

1《a》

Remark

( ) position, it is a "continuous stroke". When SA3 is in the first stroke position, press the foot switch once and the upper tool rest of the SF machine will cut downwards.

Release the SF upper tool holder to stop shearing downward. and immediately rise to top dead center. Cut again and then depress SF. It must be noted that when the sheet is not completely cut, do not release the foot switch SF to prevent the sheet from being sheared. When SA3 is in the continuous stroke position, press the foot switch SF (the depressed The time should not be too long, otherwise it will become one cut) The machine will cut continuously. Turn SA3 to one stroke and continuous shearing will stop.

Turn the knob switch SA2 to one stroke, (

) turns on the light, and the sheet to

be sheared can be sheared by moving it. Turn the knob switch SA4 to the (1) position to start shearing counting, and turn it to the (0) position to stop shearing and counting.

Note: 1. The machine must be reliably grounded 2. When the knob switch SA3 is in the continuous position, the oil pump motor must be started first, and then the foot switch is pressed.

KA 1 KA 2 KA 3

Touch electrical appliances

Coil-50HZ 220V U1=660 20A 4《a》+4《b》

1

JZC 1-31 _ JZC 1-44 _ JZC 1-22 _

Touch button

Coil 50HZ 220V U1=660 20A 1th=30A 2《a》+1《b》

1

CJX 1-22 _ CJX 1 -9 CJX 1 -9

KT 1

Time Relay

Coil-50HZ 220V 1-10 seconds

1

JSZ 3 (ST 3 P) AB

YV

commutating

Single coil AC

1

24EI-H6B-T

HL 1

indicator light

6V

1

ND 1 -25/40

1

JBK 3-250 _

K

KM 1 KM 2 KM 3

380±5% TC

control transformer

220V/165VA 26V 80VA 6V/5VA

Electrical

Name and

code

purpose

ED 1

Fluorescent lamp

ED 2

alignment

QF 2

breaker

Rated current 20A

FU 3 FU 4 FU 5 FU 1 FU 2 FU 6

Fuse Holder

With fuse core 3A With fuse core 2A With fuse core 4A With fuse core 2A With fuse core 2A With fuse core 2A

SQ1 _ SQ2 _ SQ3 _ SQ4 _

Limit switch Forward limit protection Reverse limit protection

VC=380V 1th=6A 1《a》1《b》+1 "b" 1《a》1《b》

Technical data 220V 40W Rectangular iron shell cover

quantity 2/4m 1/2.5m 1

6

1 1 1 1

model

YG1-1

DZ47-60

RT14-20

LXK 3-20H /L LXW 5-11G2 /F

Remark

M 1 M 2

Three-phase AC asynchronous electric motor Oil pump motor Back gauge motor

3-50HZ 220/380V 900r/mmE-class insulation 7.5KW B 5 1500r/mm 0.55KW B 3 double output shaft

1

Y123M-4 YU80M6B

2m

JC5025

4 holes

1

P20K6S

15A

47

TD-15

30A

6

TD15

1

MS304-1

Universal row trunking P type ordinary round plug socket Terminals Press wire terminal door lock

System usage instructions: 1. Reference point logarithm : Press this key and the logarithmic indicator light will flash. Use a ruler to measure the current position of the rear gear. After inputting the value, press the OK key to exit the logarithmic state. Press the logarithmic key again to return to the main state. picture.

2. Loop/single step : In the single-step state, it can only run the current program. It only has the counting function to determine a certain number. The main tool rest or slider moves down once, and the number is subtracted once until the value is zero. The running light extinguished.

3. Press this button repeatedly, and the cycle light will turn on. When the current program running times is zero, it will immediately jump to the next program to run. This cycle repeats. To stop running, you need to press the run/stop key , and the running light will go out.

4. Programming : After pressing the programming key, the words in the program box start to flash. At this time, you can enter the program number (0-9) to be changed, then press ENT to confirm, then the count column flashes, enter the program number to be run. times, press ENT again to confirm, then the rear gear value column flashes, enter the required value, press ENT again to complete programming, and press the programming key to exit.

5. Program selection : Press this button to immediately select the program to be run or modified.

6. Run/Stop : Press this button to immediately stop the motor, and press it again to start running the program.

Manual mode description: Press the + key (when the running light is off), the rear gear box will flash and enter the manual state. Press the + or - key again to start the rear gear operation.

Press Run/Stop to stop the manual state: Press this key to select the program to be run or modified.

6. Machine lifting and installation 1. Lift the machine according to the method shown in the lifting and lifting diagram (see Figure 10) 2. Basics of the machine: ① For foundation dimensions, please refer to the installation foundation diagram (see Figure 11) ② The soil around the foundation must be compacted, and the depth depends on the specific conditions of the soil.

3. Machine installation When the machine is installed and fixed, the rolling ball cover on the work surface should be removed, use a one-meter ruler to measure on the two pads, and then use a level to make vertical and horizontal corrections so that the tolerance within every 1000mm should not be greater than 0.2mm.

7. Machine lubrication 1. Each main lubrication point of this machine adopts oil gun injection dispersion lubrication. The lubrication points are as follows: Lubrication point serial

Lubrication point name

number

Oil

Refueling

Lubricating oil types

volume

interval

and brands

Small

16

One point each on the upper 1

and lower ends of the left and right return cylinders The swing fulcrum of the

2

upper tool rest is one

Calcium based grease Small

point each on the left and

twenty

ZG—3 GB491—65

four

Machinery oil

right.

N46GB443—84B

One point on the left and 3

right of the gap adjustment shaft bushing

Small

48

One point each on the left 4

and right cylinder piston

middle

8

rods 4 #Graphite lithium grease

A little spacer for the 5

left and right cylinders

middle

8

Q/SY1000-65

Note: 1. Mix 50% calcium-based grease and 50% mechanical oil before use.

2. Graphite lithium grease must be mixed with 30% mechanical oil.

3. In principle, the oil in the fuel tank should be changed once every six months.

Figure 10 Machine lifting diagram

User's Guide……………………

第 18 页 共 31 页

Figure 11 Installation foundation diagram

8. Machine adjustment and operation 1. Adjustment of cutting edge clearance: Whether the blade gap adjustment is appropriate is an important factor that affects the shearing quality and extends the blade life. It is recommended to select the gap value according to the table below.

When adjusting the gap (see Figure 2), loosen the locking screw (4), then turn the handle to the required scale value, and then tighten the screw (4).

The ball valve (on the right side of the machine tool, outside the oil cylinder) is used to measure the uniformity of the gap between the upper and lower blade ports.

Specific method: In a single stroke, when the upper tool rest reaches the bottom dead center, quickly turn the ball valve to close the oil circuit to make the upper tool rest

stop at the bottom dead center, and then continue to open and close the ball valve slightly to make the upper tool rest move in the full stroke. As it rises step by step, the uniformity of the cutting edge gap can be measured step by step.

Knife edge gap adjustment method: 1. Rotate the transfer switch to the single position, step on the foot switch, completely overlap the knife edge and quickly close the ball valve (the ball valve is on the other side of the electrical box).

2. Turn off the power 3. Open the ball valve slightly and let the upper knife rise slowly. Close the ball valve every 100mm and check that the knife edge gap measurement part is at the 20mm position of the knife edge coincidence point. But first, adjust the scale to the 0.05 position and lock it.

4. See the figure for the adjustment method: After aligning the position of the blade, loosen the nut and measure the clearance.

The positive rotation clearance of the ejector becomes smaller and the clearance of the rod becomes larger. In the optimal state of the gap, a feeler gauge of 0.03mm can be easily inserted, but a feeler gauge of 0.05mm cannot be inserted. After the completion of the arrangement of the rod and The ejector pin presses against each other and the ejector pin and the movable tool holder press against each other and the locking nut is tightened.

5. Disassemble the pressure plate and check whether the internal hexagonal rod is tightened.

6. After cutting for a period of time, recheck the uniformity of the knife edge gap.

2. Preparation before operation: (1) Clean the dirt on the surface of each component, and note that the engraved line on the ball valve should point to the open position.

(2) Inject grease into each lubricating part.

(3) Add HL46 hydraulic oil to the tank.

Ground the machine, turn on the power supply, and check the coordination of the actions of each electrical appliance.

3. Operation: (1) Start the machine and run it dry for several cycles. After ensuring that there are no abnormalities, try cutting sheets of different thicknesses (from thin to thick).

(2) During the shearing process, open the pressure gauge switch and observe the oil line pressure value. If it is abnormal, adjust the relief valve to make it meet the requirements.

(3) During operation, if any abnormal noise or fuel tank overheating is found, stop the vehicle immediately for inspection. The maximum temperature of the fuel tank is <60℃.

9. Machine safety technology and maintenance 1. The operator must be familiar with the structure and performance of this machine. This machine is operated by multiple people at the same time, so a dedicated person must be responsible for directing production.

2. Do not put your hands between the upper and lower blades to avoid accidents.

3. Do not place all miscellaneous tools on the workbench to avoid accidents caused by rolling into the knife edge.

4. The sharpness of the blade should be checked regularly. If the blade is found to be blunt, it should be polished or replaced in time. To polish the blade, you only need to polish the thickness of the blade.

5. All parts of the machine should be checked regularly, the machine and surrounding areas should be kept clean, and the wires should be well insulated.

6. The mesh oil filter installed on the oil suction port of the oil pump should be checked and cleaned regularly to ensure that the oil filter maintains the proper oil flow.

If the oil filter is blocked, the oil flow will be reduced and the oil pump will be sucked out, affecting the performance of the oil pump. life.

7. The nitrogen cylinder must not be filled with oxygen, compressed air or other flammable gases. When filling with nitrogen, it should be done slowly.

8. Fill the nitrogen cylinder with nitrogen using a filling tool. The filling pressure is 8MPa.

9. The nitrogen must be drained before removing the nitrogen cylinder.

10. Rolling bearing detailed list seri

Bearin

Accu

Numb

Installati

al

Bearing name

numb

g name

racy

er

on

grad

of 2

location Upper

7

3518

Double row radial

d=90 D=160 H=40

twen

80202

Single row radial ball

a=15 D=35 H=11

2

Backgauge

27

80205

Single row radial ball

a=25 D=52 H=15

4

Backgauge

28

8305

One-way thrust ball

a=25 D=52 H=18

2

Backgauge

36

180502

Single row radial ball

a=15 D=35 H=14

2

Backgauge

40

180502

Single row radial ball

a=15 D=35 H=14

2

Backgauge

31

941/12

Needle roller bearings

a=12 D=17 B=12

2

Backgauge

Specification

11. Gear details list seri al numb

name

B

a

m

Z

da

β

fa

H

er 5

Num

spira l

Accuracy

Mate

direc

level

rial

tion gear

20

20

0

2

25

18

20

0

2

250

50

ber of pie

heat treatment

ces

1

4.5

9FHGB10095

45

2

1

4.5

9FHGB10095

45

2

sector 6 gear 25

gear

18

20

0

2

17

34

1

4.5

8GJGB10095

45

1

26

gear

16

20

0

2

68

136

1

4.5

8GJGB10095

45

1

37

sprocket

20

0

14

57.1

1

45

2

20

0

20

20

1

45

1

45

1

Cone 38

Level 10

1

wheel

9-8-8DC

Bevel 39

Level 10

gear

20

0

1

50

50

1 9-8-8DC

HRC38-43

12. List of wearing parts purchased by users Specifications and models 4×3200 6×3200 8×3200 10×3200

Seal ring UN

O-ring

60×70×6

Parts Oil cylinder

65×75×6 85×100×9

Oil cylinder

95×110×9 110×125×12

Oil cylinder

120×140×12 120×140×12

Oil cylinder

130×150×12 160×140×12

12×3200

180×200×12

200×5.7

Oil cylinder

220×5.7

Oil cylinder

295×8.6 330×8.6

Oil cylinder

120×132×9 180×160×12 16×3200

200×220×12 125×120×12 250×230×12.5

20×3200

200×220×12 120×135×9 265×295×18

25×3200

300×330×18

Oil cylinder

150×165×9 12×3200 (parallel connection) 12×3200 (parallel connection)

140×160×12 150×170×12 175×190×9 160×180×12

Oil cylinder Oil cylinder

1. Geometric accuracy inspection seri

test

al

Simplified

numb

drawing

Test items

Allowance

tool

Actual

Testing method

value

er Move the tool holder to the position where the upper and lower blade edges overlap. When the gaps between the two ends are equal,

Blade edge

measure the blade

clearance

0.06

G1 uniformity

feeler

Inspect

gauge

ors

edge gap δ every 150 degrees starting from a distance of 50 degrees from the blade end face. The error is calculated as the difference between the maximum and minimum gaps.

Adjust the jaws of the front feeding

Level

I clamp to the maximum

accuracy and minimum

is

0.10

over

1000

positions respectively, and

Inside

lengths;

measure the

Parallelis m of lower G2 blade stopper

and

II diamet

Level

distance between

accuracy

er

is 0.20 on microm a length of

eter

1000;

feeler

Level

III gauge

Inspect

the stopper and the

ors

lower blade at multiple places, at least three

accuracy is

0.50

over

1000

lengths;

measurements per meter. The error is calculated by the maximum reading difference within any 1000 length.

2. Working precision seri al numb

Simplified

Test

test

Actual

tool

value

Allowance drawing

items

Testing method

er Place the test piece on the platform, place an

Inspec inspection ruler

tion with a length of

flat

1000 against the

strai ruler ghtne P1

ss of speci

0.35 over 1000 lengths

shear surface of

Inspec Inspect tion

ors

platfo

the test piece, and use a feeler gauge to measure

men rm

the gap between

feeler

the two. The error

gauge

is calculated based on the maximum gap value.

Use a vernier caliper to measure

Paral

the width of the

Vernie lelis P2

m

of

speci men

specimen at

0.25 over

r

Inspect

1000 lengths

calipe

ors

multiple locations (no less

r than three locations per meter), and the

error is calculated as the maximum difference in readings within any 1,000 lengths.

Note: 1. The accuracy inspection sequence specified in this standard does not represent the actual inspection sequence. For the convenience of assembly and disassembly of inspection tools and inspection, inspection may not be performed in the specified order.

2. During the accuracy inspection process, adjustments to mechanisms and parts that affect accuracy are not allowed.

3. Inspection conditions for workpiece accuracy: i. Requirements for test pieces for working accuracy inspection: width;

A. The length of the specimen is the shearable plate b. The width of the test piece is 20 times the thickness

of the test piece, but not less than 80mm; c. The thickness of the specimen is half of the shearable plate thickness; d. The tensile strength of the specimen σb≤450Mpa ii. The number of test pieces should be no less than 3. iii. No inspection will be conducted within a length of 10 times the plate thickness from the end of the specimen.

4. When the actual measured length is less than the length specified in the tolerance, it should be converted according to the actual measured length, and the conversion result is rounded to the nearest micron in accordance with GB8170.

Preface

This manual describes operation of E21S numerical control device and is meant for operators who are instructed for operation of the device.

Operator shall read this manual andknow operation requirements before using this device.

Copy right is preserved by ESTUN. It is not allowed to add or delete part or all of the manual content without ESTUN’s consent. Do not use part or all of manual content for the thirdparty’s design.

E21S device provides complete software control and has no mechanical protection devicefor operator or the tool machine. Therefore, in case of malfunction, machine tool must provide protection device for operator and external part of the machine tool. ESTUN is not responsible for any direct or indirect losses caused by normal or abnormal operation of the device.

ESTUN preserves the right to modifying this manual in the event of function adding or print error.

Chapter 1 Product Overview 1.1 Product introduction This product is equipped with the shear machine dedicated numerical control device which is applicable to various users. Based on ensuring work precision, the cost of numerical control shearing machine is reduced significantly.

Features and functions of this product are as following: 

Back gauge can be controlled.



Cut-angle can be controlled.



Cut-gap can be controlled.



Stroke time can be controlled.



Intelligent positioning control.



Unilateral and bidirectional positioning which eliminates spindle clearance effectively.



Retract functions.



Automatic reference searching.



One-key parameter backup and restore.



Fast position indexing.



40 programs storage space, each program has 25 steps.



Power-off protection.

1.2 Operation panel Operation panel is shown in Figure 1-1.

Figure 1-1 Operation panel

Functions of panel keys are described in Table 1-1.

Table 1-1 Description of key functions Key

Function description Delete key: delete all data in input area on left bottom of displayer.

Enter key: confirm the input content. If no content is input, the key has the similar function to direction key

.

Start key: automatic start-up, top left corner of the key is operation indicator LED. When operation is started, this indicator LED is on.

Stop key: stop operation, top left corner of the key is Stop indicator LED. When initialize normal start-up and no operation, this indicator LED is on.

Left direction key: page forward, cursor remove Right direction key: page backward, cursor remove Down direction key: select parameter downward Function switch: switch over different function pages Symbolic key: user input symbol, or start diagnosis. ~

Numeric key: when setting parameter, input value.

Decimal point key: when set up parameter, input decimal point.

Manual movement key: in case of manual adjustment, make adjustment object move in forward direction at low speed.

Manual movement key: in case of manual adjustment, make adjustment object move in backward direction at low speed.

High speed selection key: in case of manual adjustment, press this key and press

simultaneously, make adjustment object

move in increasing direction at high speed, then press , make adjustment object move in decreasing direction at high speed.

1.3 Displayer

Chapter 2 Operation Instruction

2.1 Programming The device has two programming methods, which are single-step programming andmulti-step programming. User can set up programming according to actual demand.

2.1.1 Single-step programming Single-step programming is generally used for processing single step to finish work piece processing. When controller is power on, it will automatically enter single-step program page. Operation steps Step 1 After starting up, the device will enter setting up page of single-step programautomatically, as shown in Figure 2-2.

Single X: A:

50.00

G:

200.00 9.98

XP: DX: CUT: DLY:

2 3.00 1.00

F: PP: CP:

20.00 0 0 14

Range: 0~9999.999mm Figure 2-2 Single-step program setting page

Step 2 Click

, select parameter that needs to be set up, press numerical key to input program value, press

to complete input.

[Note] Parameter can only be set when Stop indicator is on.Setting range of singe step parameter is shown in Table 2-1.

Table 2-1 Set up range of singe step parameter Parameter name X

Unit mm/inch

Range -

Remarks Current position of X axis, unable to be modified.

A

°

-

Current position of A axis, unable to be modified.

G

mm/inch

-

Current position of G axis, unable to be modified.

XP

mm/inch

0~9999.999

Program position of X axle.

DX

mm/inch

0~9999.999

Retract distance of X axle;

Parameter name DLY

Unit

Range

s

0~9.99

Remarks In case of single step, delay time for X axle concession.

CUT

s

0~9.99

There is a delay time for the cutter goes to the next work-step, after it leaves the top dead center.

[Note] Only the parameter CutDelay En. is set to 1, displaying this parameter.

F

None

0~3

Functions configure output.

PP

None

0~9999

Number of preset work piece.

CP

None

0~9999

Number of current work piece.

Step 3

Press

, system will execute according to this program, as shown in Figure 2-3.

Single

X: A: G: C: PP:

200.0 3.0 9.99 0 0

metric

Figure 2-3 Single step operation page

----End Operation example On single-step program page, program back gauge position to 80.00mm, retract distance to 50mm, concession waiting time to 2s, and work piece to 10.

Operation steps are shown in Table 2-2.

Table 2-2 Operation steps of single step example Operation steps

Operation

Step 1

Click

Step 2

Input 80.00 by numerical key.

Step 3

Click

, select “XP” parameter.

, confirm setting of this parameter.

Operation steps Step 4

Operation , select “DX” parameter, “DLY” parameter, “PP”

Click

parameter respectively.

Step 5

Set up parameter to 50mm, 2s, 10 by numerical key.

Step 6

Click

, system execute according to this program.

2.1.2 Multi-step programming Multi-step program is used for processing single work piece of different processing steps, realize consecutive implementation of multi-steps, and improve processing efficiency.

Operation step Step 1 Power on, the device enters to single-step parameter set up page automatically.

Step 2 Click

, switch to program manage page, as shown in Figure 2-4.

PROGRAMS

0P

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

1program

5ST Figure 2-4 Program management page

Step 3 Click Step 4

Click

, select program serial number, or input program number directly,such as input “1”. , enter multi-step program setting page, as shown in Figure 2-5.

PROGRAM1 ST: PP: CP: DLY: CtDly:

5 20 9 0.00 0.00

Range: 0~25

Figure 2-5 Multi-step program setting page

Step 5 Click effect.

, select multi-step programming parameter which requires set up, input setting up value, click

Step 6 In completion of set up, click

, and the configuration takes

, enter step parameter set page, as shown in Figure2-6.

PROGRAM1

1/ 5ST

X:

50.00

XP: DX: RP: F:

9.000 25.00 54 1

Range：0~9999.999mm Figure 2-6 Step parameter set page

Step 7 Click Step 8

, select step parameter that needs to be set up, input program value, click

Click

to switch over between steps. If the current step is the first step, click

the current step is the last one, click

to enter the first page of step parameter setting.

Multi-step parameter setting range is shown in Table 2-3.

Table 2-3 Multi-step parameter setting range Parameter name ST

Unit None

Range 0-25

Remarks Set up total processing step number of this program

PP

, and the setup takes effect.

None

0~99999

Number of work piece to be processed, decreasing piece when more than zero; negative increasing count.

CP

None

0~99999

Number of finished work piece

DLY

s

0~9.99

Time between retract signal and concession execution.

to enter the last page of step parameter setting; if

Parameter name

Unit

CtDly

Range

s

0~9.99

Remarks There is a delay time for the cutter goes to the next work-step, after it leaves the top dead center.

[Note] Only the parameter CutDelay En. is set to 1, displaying this parameter.

X

mm/inch

None

Current position of X axle, can’t be modified.

XP

mm/inch

0~9999.999

Program position of X axle.

DX

mm/inch

0~9999.999

Distance of X axle concession.

RP

-

1~99

Repeat times required by this step.

F

-

0~3

F function configure output

Step 9

Click

, system will operate according to this program, as shown in Figure 2-7.

PROGRAM1

X: A: G: C: PP: 12345

Rp：1/54

200.0 30 9.99 0 St: 1/ 5

Figure 2-7 Multi-step programming operation page ----End Operation example [Background] One work piece requires processing 50 as shown below; 

First shear: 50mm;



Second shear: 100mm;



Third shear: 300mm;

[Analysis] according to work piece and technological conditions of machine tool: 

First shear: X axle position is 50.0mm, concession 50mm;



The second shear: X axle position is 100.0mm, concession 50mm;



The third shear: X axle position is 300.0mm, concession 50mm; Edit processing program of this work piece on No. 2

program.

Operation procedure is shown in Table 2-4.

Table 2-4 Operation steps of multi-step programming example Operation step Step 1

Operation On single step parameter setting page, press

to enter

program selection page.

Step 2

Input “2”, click

, enter multi-step general parameter setting

page of program 2.

Step 3

Select “Program step”, input “3”, click

, the setting takes

effect.

Step 4

Select “PP”, input “50”, click

Step 5

Similar to step 3 and step 4, set “DLY” to 3 respectively.

Step 6

Click

Step 7

Select “XP”, input 50, click

Step 8

Similar to step 7, set up “concession distance” and “repeat

, the setup takes effect.

to enter first step setup page of step parameter. , the setup takes effect.

times” to 50, 1 respectively.

Step 9

Click

to enter second step setup page of step parameter,

the setup method is similar to that of step one.

Step 10

Click

again, to enter third step setup page of step

parameter, the setup method is similar to that of step one and step two.

Step11

Click

, return to setup page of the first step.

Step12

Click

, system will operate according to this program.

[Note] 

In completion of multi-step programming, you should back to starting step before launching the system; otherwise, the program will start



Press left and right direction key to circulate page turning and browsing among all step parameters.



Program can be called and revised again.



In completion of processing all work pieces (50 in the example), the system stops automatically. Restart directly will start another round of

position processing at current step.

processing 50 work pieces.

2.2 Parameter setting User can setup all parameters required for normal operation of the system, includingsystem parameter, X axle parameter.

Step 1 On program management page, click

to enter programming constant page, as shown in Figure 2-8. On this page, programming

constant can be set.

CONST mm/inch: 中文/English: Pulse Time: Version:

0 0 0.020 V1.10

0:mm 1:inch

Figure 2-8 Programming constant page

Range of programming constant setup is shown in Table 2-5.

Table 2-5 Range of programming constant setup Parameter name

Unit

Range

X-tea. in

mm

0-9999.99

Default 0

Remarks Input current X axle position when teach enable.

mm/inch

中文/English

X-tea. In

-

-

mm

0 or 1

0 or 1

0~9999.999

0

0

10



0: mm



1: inch



0: 中文



1: English

Input current X axle position when teach enable.

G-tea. In

mm

0~9.99

0

Input current G axle position when teach enable.

Pulse Time

s

0.000~1.000

0.020

The duration of the pulse signal.

Version

-

None

-

Software version information, V refers to version, 1 indicates version number, and 0 indicates version level.

Step 2 Input password “1212”, click

to enter system parameter setting page, as shown in Figure 2-9.

SYS PARA

1/ 2PG

X-digits: X-safe: Step delay: CutDelay En.: MaxCut Delay: X-tea.in: G-tea.in:

3 1.000 3.33 1 9.99 200 5

Range：0~3

Figure 2-9 System parameter setting page Step 3 Step up parameter, parameter setup range is shown in Table 2-6.

Table 2-6 System parameter description Parameter

Unit

X-digits

-

Range 0-3

Default 1

Description Decimal point displayed by X axle position parameter

X-safe

mm

0-9999.999

10

X axle keeps low speed in this range

Step delay

s

0-9.99

0.5

Interval between valid change step signal and change step operation executed

CutDelay

-

0 or 1

0

En. MaxCut



0: disable



1: enable

s

0~9.99

0

Set the maximum cut delay time.

-

0 or 1

1



0: disable



1: enable

Delay A-Enable

A-Max

°

2.50 or 3.00

3.00

The max value of the Cut-Angle.

G-Enable

-

0 or 1

1



0: disable



1: enable



0: Decrease



1: Increase

G-Encoder

-

0 or 1

0

Dir. GMF

-

1~99999999

40

Multiplication factor of G-axis, used for the convert between pulses and mm.

GDF

-

1~99999999

1

Division factor of G-axis, used for the convert between pulses and mm.

Step 4 Click ----End

, return to programming constant page.

2.3 Manual movement In single-step mode, axle movement can be controlled by pressing key manually. Thismethod helps user to adjust machine tool and work piece. ，

Step 1 On single step parameter setup page, click

or

to enter manual

page, as shown in Figure 2-10.

MANUAL

X: A: G:

50.00 0.00 9.98

X current pos.

Figure 2-10 Manual page

Step 2 Click Click

, operate at low speed in increasing direction. Click , click

, operate at low speed in decreasing direction.

at the same time, and operate at high speed in increasing direction (this operation is valid only when using

frequency converter as the drive). Click

, click

at the same time, and operate at high speed in decreasing

direction (this operation is valid only when using frequency converter as the drive).

Step 3 Click ----End

return to single step parameter setting page.

Chapter 3 Alarm The device can detect internal or external abnormity automatically and send out alarm prompt. Alarm message is available on alarm list.

Step 1 On programming management page, click Step 2 On programming constant page, click

to enter programming constant page. to enter “Alarm history” page to view all alarm history.

As shown in Figure 3-1, the latest 6 alarms, alarm number and causes can be viewed on this page.

ALARM RECORD A.24

Mach. Not ready

Figure 3-1 Alarm history pageAlarm history and message is shown in Table 3-1.

Table 3-1 Alarm number and alarm message Alarm number

Alarm name

A.01

Pieces reached

A.02

X.Pos < min.

Alarm description Count reaches preset value X-axis current position beyond the minimum limit X-axis current position beyond the

A.03

X.Pos > max. maximum limit The current position of the X-axis beyond

A.04

the soft limit A-axis current position beyond the

A.05

A Axis MAX maximum limit A-axis current position beyond the

A.06

A Axis MIN minimum limit G-axis current position beyond the

A.07

G Axis MAX maximum limit G-axis current position beyond the

A.08

G Axis MIN minimum limit

Alarm number

Alarm name

Alarm description When count reaches preset value,

A.11

Finished work system shut down automatically.

In single step and multistep mode, slider

A.12

Out of UDP is not on upper dead center.

A.22

Encoder abnor.

Encoder voltage is too low

A.24

Mach. not ready

The pump signal is invalid

A.25

Angle Abnormal

Angle input error

A.26

X Stop Err

The backgauge motor is abnormal stop.

A.28

X V2 Err

The speed of backgauge motor is abnormal on the Low-Speed Mode.

The speed of backgauge motor is A.29

X V3 Err abnormal on the High-Speed Mode.

X-axis position has exceeded the zero

A.32

XPos < 0

point in manual mode, you should turn back.

A.41

Para. error

-

A.42

Power off

-

A.43

System fault

-

Appendix

Common fault and troubleshooting

Fault phenomena When power on, the device will not

Trouble shooting 

display.

The electrode of power supply terminal is connected error; please see the information of power nameplate.

When X axle programming is



Voltage is too low.



Electrical outlet is not connected.

Two motors are reversed. Reconnect.

operating, back gauge motor does not move, but Y AXIS motor moves.

When program is operating, motor



does not move.

Check whether mechanical part has been locked or slider returns to upper dead center.



Check whether the motor wiring is connected well.

Motor can’t switch from high speed to



low speed.

Check whether high-low speed signal has been sent or motor power is too small.



Check whether the parameter of distance conversion is correct.

When system is in multi-step

Check when slider is on upper dead center, STEP

programming, the program can’t

terminal is connected to +24V or not.

change step.

When system is in multi-step

Check when slider is on upper dead center, STEP

programming, the program can’t count.

terminal is connected to +24V or not.

When programming is operating, the



device loses control.

Check whether encoder cable is connected or not.



Check whether the motor-direction wiring is correct (X+, X-, A+, A-, G+, G-).

When programming is operating,

Check whether encoder wiring is correct or

system actual position will not display

encoder cable is connected well.

or change.
