Optimum mounting height above cooking surface: 30”
For optimal ventilation performance, Vent-A-Hood recommends a 27” deep hood with BBQ Extension Kit
Optimum mounting height above cooking surface: 30” For optimal ventilation performance,
recommends a
hood with BBQ Extension Kit
- Price includes mirrored stainless bands to match most grills - Price does not include Transition
By Vent-A-Hood

- Must purchase M1200 Blower, sold separately
Optimum mounting height above cooking surface: 30”
For optimal ventilation performance, Vent-A-Hood recommends a 27” deep hood with BBQ Extension Kit


- Includes VP566 transition.
If ordering a BBQ extension kit, please specify a deeper duct cover for proper installation.
Stock Items are Listed in Red
Vent-A-Hood recommends that outdoor hoods overlap grill width by a minimum of 3” on each side.
• The Extension Kit extends the blower over the cooking surface for optimal performance and is recommended for 27” deep hoods
• Saves the cost of building out the wall for installation

Extension Kit attaches directly to the wall
The BBQ extension kit can be added to any PRXH18, or XRXH18, up to 60” wide.

Hood attaches to 6” Extension Kit Extends 27” depth to 33”

The WR Accessory Rail is designed to attach to the bottom of the BBE Extension. Accessories not included with WR Rail or BBE extension.
If ordering a BBQ extension kit, please specify a deeper duct cover for proper installation. Duct Covers for use with BBQ Extension Kits Only
- Price does not include Transition (See Page 2)
Additional outdoor hoods and options are available for custom order. Please see the Pinnacle Vent-A-Hood list price book for complete details.
Stock Items are Listed in Red
