Telescopic Boom Lifts
CE, UKCA
Genie S -60 DC & S-60 FE ®
®
Specifications Models Measurements
orking height max.(1) W Platform height max. Horizontal reach max. A Platform length (8 ft/6 ft) B Platform width (8 ft/6 ft) C Height - stowed C Height - storage/transport (jib tucked under) D Length - stowed D Length - storage/transport (jib tucked under) E Width F Wheelbase G Ground clearance - center
Productivity
L ift capacity max. - unrestricted Number of Platform Occupants Platform rotation Jib length Vertical jib rotation (up/down) Turntable rotation Turntable tailswing (riser up/riser down) Drive speed - stowed Drive speed - raised Gradeability - stowed(2) Turning radius - inside/outside Tires
Range of motion S-60 DC/S-60 FE S-60 DC & S-60 FE US Metric
67 ft 2 in 61 ft 2 in 40 ft 6 in 3 ft/2 ft 6 in 8 ft/6 ft 8 ft 12 in 9 ft 7 in 31 ft 8 in 23 ft 6 in 8 ft 2 in 8 ft 2 in 18.3 in
20.60 m 18.60 m 12.30 m 0.91 m / 0.76 m 2.44 m / 1.83 m 2.73 m 2.92 m 9.65 m 7.16 m 2.49 m 2.49 m 0.46 m
70 ft 21.3 m
60 ft 18.3 m
50 ft 15.2 m
40 ft 12.2 m
30 ft 9.1 m
20 ft 6.1 m
10 ft 3m
660 lb
300 kg 2 160°
6 ft
1.83 m
0 ft 0m
-10 ft -3 m
-10 ft
130° 353° 4 ft 1 in / 5 ft 2 in 4.0 mph 0.68 mph
-3 m
0 ft
10 ft
20 ft
30 ft
40 ft
50 ft
0m
3m
6.1 m
9.1 m
12.2 m
15.2 m
1.24 m / 1.57 m 6.44 km/h 1.1 km/h
45 % 10 ft/17 ft 3 in 3.06 m / 5.25 m 355 / 55D625
A
E
B
D
Power
Drive System Battery Pack, DC Battery Pack, FE AC generator, FE Auxiliary power unit, FE Hydraulic tank capacity Fuel tank capacity
Weight(3) and Floor Loading(4) Weight, DC Weight, FE Tire contact pressure Occupied floor pressure
Sound and Vibration Levels
S ound Pressure level (ground workstation) Sound Pressure level (platform workstation) Vibrations
48V 3-Phase AC 48V DC (8 × 6V), 390 Ah, FLA 48V DC (8 × 6V), 370 Ah, AGM Diesel 12V DC 18 gal 68 L 17 gal 64 L
17,600 lb 17,750 lb 73 psi 203 psf
C G F
7,983 kg 8,051 kg 500 kPa 9.74 kPa
70 dBA (DC)/83 dBA (FE) 70 dBA (DC)/76 dBA (FE) 0.34 m/s2 1.11 ft/s2
(1) The metric equivalent of working height adds 2 m to platform height. The imperial equivalent adds 6 ft to platform height. (2) Gradeability applies to driving on slopes and may vary depending on options and machine configurations. See operator’s manual for details regarding slope ratings. (3) Weight refers to standard configuration and may vary depending on options and/or country standards. (4) Floor loading information is approximate and may vary depending on options and machine configurations. It should be used only with adequate safety factors.
