COMBi-CBE
The innovative Combi-CBE is designed to increase productivity, improve safety and help increase your storage capacity both indoors & outdoors.
combilift.com
COMBi- CBE
Multi-Directional
Features Include:
• +/- 100mm side shift
• Load sensing steering
• 4-Way lever positioning of wheels
• System Communication via CAN-BUS
• Multi-directional operation
• 2 Wheel Electric Drive
• Powered by AC Technology
Distributed by:
COMBILIFT HAS A POLICY OF CONTINUOUS PRODUCT DEVELOPMENT AND RESERVES THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE. SPECIFICATIONS AND/OR DIMENSIONS MAY VARY FROM THOSE ILLUSTRATED IN SOME COUNTRIES.
combilift.com CO. MONAGHAN IRELAND +353 47 80500 INFO@COMBILIFT.COM Protected by Design Registration Copyright: European Community No.: 000725668-0001|US No.: D579, 624| Canadian No.: 123292|Australian No.: 318370| Russian Federation No.: 70814 |Korean No.: 30-0516087| Japanese No.: 1330896|Taiwan No.: D126056| Chinese No.: ZL200730329732.6 REF. DESCRIPTION STD. OPTION 1 a Standard Lift Height 4000mm 4900mm 5500mm 6000mm 1 b Free Lift Height 0mm 1318mm 1518mm 1683mm 2 Height Mast Closed 2670mm 2243mm 2443mm 2610mm 3 Max. (Mast raised) 4850mm 5778mm 6378mm 6878mm 4 Overall Length 2565mm / 2695mm 5 Ground Clearance Under Mast 125mm 6 Ground Clearance to Wheelbase Centre 100mm 7 Height of Overhead Guard 2250mm 8 Width 1500mm 9 Outside Spread of Fork Arms 1325mm 10 Track Front 1320mm 11 Load Centre Distance 600mm 12 Overhang Front 300mm 13 Wheelbase 1070mm 14 Overhang Back 150 / 130 mm 15 Length From Face of Fork 1500mm / 1580mm 16 Approach Angle 30° 17 Ramp Angle 15° 18 Departure Angle 30° 19 Forward Tilt 3° 20 Backward Tilt 5° 21 Minimum Outside Radius 1400mm A Capacity 2500 kg / 3000 kg B Unladen Weight 6500 kg / 6800 kg C Maximum Ground Speed 11 km/h D Gradeability 10% E Battery Capacity 48 V / 930 Ah F AC Electric Traction Motor x 2 48 V / 5 kW G AC Electric Pump Motor 48 V / 14 kW H Fork Section 125mm x 50mm x 1065mm I 16 x 7 – 10.5 Front Tyre x 2 OD 406mm / Width 178mm J 22 x 10 x 16 Rear Tyre x 1 OD 559mm / Width 254mm K Standard Colour Green and Grey L Suspension Seat Grammer MSG 65 FRONTAL MODE 10 4 15 9 8 21 SiDEWARD MODE 2 1 3 11 7 13 14 12 18 17 16 19 20 5 6 rev. 1.1
