MICROPLASTICS

MICROPLASTIC EMISSIONS: A MATERIALS PERSPECTIVE This article considers just how much microplastic pollution really originates from road markings. icroplastic emissions from road markings are negligible, in both absolute and relative quantities.

This is because road markings are protected by glass beads during functional service life and mostly renewed before they can be abraded. The European Union Road Federation combined the position papers of road markers and academic research into this topic – abrasion was consistently estimated at about 5% and not 100%, as has been claimed in some theoretical assessments.

M

MATERIALS PERSPECTIVE Road markings (in North America called pavement markings) are present on almost all paved roads worldwide. While there is a considerable amount of research related to the visibility of road markings and their impact on drivers[1], they are weakly described from a materials perspective.

Road markings are a specific type of industrial maintenance coatings that are a dual-layer system. The bottom coating layer is protected from abrasion by the top layer of glass beads[2]. The glass beads layer also provides retroreflectivity, which is determining the functional service life of

06

ROAD SURFACE TECHNOLOGY 2023

road markings. Road markings are required to be homologated before their use is permitted; in most cases, the performance parameters that include retroreflectivity (measured through the coefficient of retroreflected luminance, RL) must be maintained throughout the entire service life[3,4].

The coating layer of road markings usually contains polymeric binder; thus, when abraded, it could contribute to microplastic pollution. Typically, microplastics are divided into primary (plastic particles designed in small dimensions) and secondary (resulting from the disintegration of larger polymers) – those originating from road markings clearly belong to the latter.

According to a regulation proposed in the European Union[5], secondary microplastics are defined as pieces of synthetic polymers, other than liquid or fully biodegradable polymers, with dimensions 0.0001–5mm.

Also, if any particle of such dimensions contains more than 0.01% of such polymer, it is to be considered a microplastic in its entirety. While it would be forbidden to sell such microplastics, there would be numerous derogations permitting the vast majority of

the contemporary uses. Nonetheless, excessive reporting would be demanded. Road markings would be within the scope of the proposed legislation.

There are several reports claiming that road markings contribute about 7% of all microplastics released to the oceans (note that these estimates were not subjected to scientific peer-review and were not based on field research). However, the assumptions that permitted for estimating such enormous quantities were fundamentally wrong – the role of glass beads and the renewal procedures were omitted. Because the clear distinction between functional and physical service life of road markings was lost, almost 100% abrasion was assumed, which was plainly incorrect.

From the perspective of scientific integrity, it is quite disturbing that in many cases, despite warnings of uncertainty (like data “almost or completely non-existing and believed essential to know”), the data was considered robust. Overall, the various theoretical emission estimates available in the literature were inconsistent, lacked any scientific foundation and the absence of knowledge about actual road marking practice was evident[6]. www.worldhighways.com
