President’s welcome I Pump Industry Australia Incorporated Kevin Wilson – Secretary PO Box 55, Stuarts Point NSW 2441 Australia Ph/Fax: (02) 6569 0160 pumpsaustralia@bigpond.com Ron Astall – President United Pumps Australia & Astech Consulting Services John Inkster – Vice President Brown Brothers Engineers Mike Bauer – Councillor Dynapumps Frankie Camilleri – Councillor John Crane Martin O’Connor – Councillor KSB Australia Alan Rowan – Councillor Life Member Keith Sanders – Councillor Australian Industrial Marketing & Life Member

n the last issue of this magazine we learnt that as a result of European Union Energy Efficiency Directives, all large EU enterprises will be required to undertake energy audits by December 2015. In the UK alone this is expected to lead to energy saving benefits of £1.6 billion.

The BPMA’s Steve Schofield outlined their related pump system auditor training and accreditation programs. In the US, in 2013 the power industry had over a $US6 billion spend on energy efficiency programs. This year it is expected to top $US9 billion. That’s a lot of money!

When attending the Hydraulic Institute annual meeting in Florida in February I learnt that the Hydraulic Institute is now also developing pump system auditor training and an accreditation regime.

While there I met Erin Hope from Bonneville Power and Geoff Wickes from the North West Energy Alliance; both of whom are actively involved with the Hydraulic Institute’s energy efficiency programs. I expressed surprise at how the utility companies were actively encouraging their customers to buy less of their product (electricity). Whilst there are some government incentive programs in Australia, I am not aware of incentives to this scale from the Australian power suppliers.

Erin and Geoff explained that one of their biggest problems in the US power industry is under capacity and limited opportunity to increase generating capacity. These incentive programs have been highly successful and have reduced the number of brown-outs and supply problems. Often where previously, additional poor stations had been mooted, they are now considered to be unnecessary. They had initially been focusing on lighting and now this focus is turning to pumps. An energy efficiency rating and labelling program for pumps is now being developed; similar to what we see in Australia on refrigerators and washing machines.

Energy efficiency has been PIA’s primary emphasis for a while and this will not go away. In the process industries it is believed that typically 70 per cent of installed electric motor capacity is for pumps.

This may be seen as a challenge for the pump industry but in reality it is a giant opportunity – and one we should all embrace.

Ron Astall President, Pump Industry Australia

Ashley White – Councillor Davey Water Products

www.pumpindustry.com.au

pump industry | May 2015 | Issue 11

1

ISSUE 11

MAY 2015

pumpindustry

Editor’s welcome

PUMP I NDU STRY

Repetitive pump failure: the unnecessary evil

Reassessing lifetime lubricated sealed bearings

The underground network

COOLING BRISBANE

Cover image highlights our story on the innovative new underground network that will cool Brisbane’s CBD buildings.

3,159

Published by

Monkey Media Enterprises ABN: 36 426 734 954 PO Box 3121 Ivanhoe North VIC 3079 P: (03) 9440 5721 F: (03) 8456 6720 monkeymedia.com.au info@monkeymedia.com.au pumpindustry.com.au magazine@pumpindustry.com.au Publisher and Editor: Chris Bland Managing Editor: Laura Harvey Marketing Consultant: Aaron White Associate Editor: Michelle Goldsmith Creative Director: Sandy Noke Graphic Designer: Alejandro Molano ISSN: 2201-0270

It’s been promising to hear in recent months that although the drop in commodities prices has had its impacts on the Australian mining industry (and in turn the pump industry), there are still bright spots for the industry to focus on.

In particular the oil and gas industry continues to power through major projects and greenlight new projects and expansions of existing projects – providing hope for the future.

The three CSG-LNG projects operating out of Queensland are all due to commence supply this year, feeding natural gas into Asia. With China announcing plans to move towards cleaner fuels, including natural gas, our industry seems poised to take advantage of the opportunities these ambitions present.

It’s fitting then that we’re showcasing this issue of Pump Industry at the APPEA Conference & Exhibition, taking place in Melbourne from May 17-20.

We’ll be exhibiting at stand 336 – if you’re in town for the event, make sure you stop by our stand and say hello.

The main focus of our stand will be the launch of our new magazine Unconventional Oil & Gas. If that’s an area of interest to you, then all Pump Industry subscribers can currently sign up for free. Visit www.unconventionaloilandgas.com.au today to reserve your free subscription.

After attending the PIA’s Melbourne General Meeting in February, it seems another big focus for the industry is the aftermarket, the repair and maintenance of existing pump systems.

The opportunities here are two fold.

First, there is the task of repairing and maintaining original pump systems to ensure they continue to do the job they were installed to do, providing revenue streams to companies and ongoing work for individuals.

Secondly, there is the opportunity to identify upgrades that can be made to existing systems to enhance their energy efficiency. As BPMA Executive Director Steve Schofield said in the last issue of Pump Industry – energy efficiency is the business opportunity we must embrace. Our own President Ron Astall has also reminded us in this issue of the importance of energy efficiency measures in our industry.

The key is to focus on the opportunities energy efficiency presents our industry, rather than getting bogged down in the challenges this opportunity presents.

Readers of our enewsletter will be familiar with a new campaign we’ve recently launched – ‘Pump up your selfie’ – designed to get members of the Australian pump community sharing photos of themselves reading Pump Industry. We’ve received a number of entries so far, but we’re keen to see more of you reading your favourite magazine in your workplace. Remember to send your entries to our Managing Editor Laura Harvey (laura.harvey@ monkeymedia.com.au) or tweet your photos, tagging @pumpmag and using the hashtag #pumpupyourselfie.

Chris Bland Publisher and Editor

This magazine is published by Monkey Media in cooperation with the Pump Industry Australia Inc. (PIA). The views contained herein are not necessarily the views of either the publisher or the PIA. Neither the publisher nor the PIA takes responsibility for any claims made by advertisers.

All communication should be directed to the publisher.

The publisher welcomes contributions to the magazine. All contributions must comply with the publisher’s editorial policy which follows. By providing content to the publisher, you authorise the publisher to reproduce that content either in its original form, or edited, or combined with other content in any of its publications and in any format at the publisher's discretion.

2

pump industry | May 2015 | Issue 11

www.pumpindustry.com.au

Repair, Re-Manufacture and Re-Design Service For ALL types of Centrifugal Pumps Efficiency Improvement Reconditioning Restore Clearances Re- Engineering P f Performance T Testing. ti Services available include:

• Inspection and trouble-shooting • Case build up and re-machining • Axial A i l split lit case facing f i and d reboring b i • Axial thrust balancing • Shaft and bearing API 610 upgrades • Mechanical Seal upgrades to API 682 • Bearing housing & back cover retrofit • Lube system upgrades • Composite Wear Parts • Tighter clearances • Hydraulic Re-Rating • Rapid R id prototyping t t i • Driver upgrades (MEPS compliance) • Baseplate adaptors and rebuilding • Custom Spare Parts • Rotating Element balancing • ASME & AS1210 qualified Welding • Hydrostatic Testing • Performance Testing • FFT Vibration analysis

A.B.N. 37 006 317 979

31 WESTERN AVENUE SUNSHINE, VICTORIA 3020 P.O. BOX 348, SUNSHINE, VICTORIA 3020 • PHONE +613 9312 6566 • FAX +613 9312 6371

EMAIL unitedpumps@unitedpumps.com.au http://www.unitedpumps.com.au/

pumpindustry C O N T E N T S MAIN FEATURES

22 RELIABILITY Repetitive pump failure: the unnecessary evil.......................... 22

22

Venturi Valve scores top marks.................................................. 25 The scope of pump reliability..................................................... 26

30

Oil and Gas

Unlocking Australia’s fraccing potential..................................... 30 Ichthys moves towards first production..................................... 32

33

Water and Wastewater

Partners keep the water flowing................................................. 33 Rotamixing an anaerobic digester............................................. 35 Monster sludge calls for monster pumps.................................. 36 Sustainable wastewater pumping.............................................. 38

40

HVAC

Connecting and cooling the urban environment....................... 40

44

Lubrication, Seals & Bearings

10

Re-assessing lifetime lubricated sealed bearings.................... 44 Better components make better drives..................................... 48

50

Aftermarket

Bringing new life to Mt Piper....................................................... 50

52

Fans

Energy reduction through fan efficiency.................................... 52

56

History

Kelly & Lewis: an Australian pumping legend........................... 56

4

pump industry | May 2015 | Issue 11

www.pumpindustry.com.au

IS SU E 1 1 | MAY 2 0 1 5

33 President’s welcome................................................................... 1 Editor’s welcome......................................................................... 2 News briefs.................................................................................. 6 Ask an expert............................................................................... 8 Index............................................................................................ 64

36

REGULARS 10

PIA News

Mingling with the rock stars of the pump industry................... 10 PIA develops new training course.............................................. 12 Calling Adelaide pump people.................................................... 13

14

PIA member news

Pentair’s offering grows.............................................................. 14 Steve Basclain Kelair’s new GM................................................. 14 New facility leads to rocketing production................................. 16 Balancing a reliable supply chain.............................................. 18

19

Industry news

Driving maximum pump performance....................................... 19 What’s on that truck: solutions for mobile applications........... 20

58

58

Pioneers

Bernard Hasell............................................................................. 58

60

Technical

Let’s get classy: pump classification.......................................... 60

63

Pump school

What is the function of a pump internal relief valve on positive displacement pumps?.................................... 63

www.pumpindustry.com.au

pump industry | May 2015 | Issue 11

5

Pump Industry News Briefs Get all the latest news at www.pumpindustry.com.au

The PIA remembers Arthur Feiner

Hydraulic Institute announces Member of the Year; new ED

Arthur joined Harland Engineering Australia to further the hydroelectric business, and subsequently became a director of the company. He was considered to be a very talented engineer and manager.

The Hydraulic Institute has named Weir Minerals Manager of Research and Design Aleks Roudnev as its 2014 Member of the Year. The award was made at the Hydraulic Institute’s 2015 annual meeting, held recently in St. Petersburg, Florida.

The PIA was saddened to hear of the passing of Life Member Arthur Feiner in January 2015, aged 92 years.

On receipt of his life membership, Arthur made a very gracious and interesting speech, however in later years the PIA sadly lost touch.

The Hydraulic Institute Board of Directors selected Mr Roudnev
