CHASSIS & BODIES
NEXPORT
WEB:
PHONE:
0478 725 104 1800 NEXPORT (1800 639 767)
www.nexport.com.au EMAIL:
steve.fisher@nexport.com.au
MAKE: NEXPORT
MODEL: ZEB 12.5M
MAKE: NEXPORT
MODEL: ZEB 8.6M - ZEB 10.6M
SERIES: ELECTRIC - ZERO EMISSIONS
SERIES: ELECTRIC - ZERO EMISSIONS
APPLICATION: CITY - ROUTE BUS
APPLICATION: CITY - ROUTE BUS
VARIATIONS: 12.5M
VARIATIONS: 8.6M - 10.6M
BODY SPECIFICATIONS:
BODY SPECIFICATIONS:
Frame Material
Bolted extruded aluminium system
Frame Material
Bolted extruded aluminium system
Body Material
Fibreglass front and rear panels
Body Material
Fibreglass front and rear panels
Seating Capacity
46 - 47
Seating Capacity
32 - 35
Passenger Capacity
80
Passenger Capacity
60 - 67
No. of Doors
2
No. of Doors
1 to 2
SEATING OPTIONS:
SEATING OPTIONS:
Seating Type
Individual or bench type
Seating Type
Individual or bench type
Seating Make/s
Customers Choice
Seating Make/s
Customers Choice
Seating Model/s
Customers Choice
Seating Model/s
Customers Choice
Seatbelts (Yes / No)
Optional
Seatbelts (Yes / No)
Optional
BODY DIMENSIONS:
BODY DIMENSIONS:
Body Length - metres
12.5m
Body Length - metres
8.6m - 10.6m
Body Width - metres
2.5m
Body Width - metres
2.5m
Body Height -metres
3.3m
Body Height -metres
3.3m
Body Floor Height - mm
N/A
Body Floor Height - mm
N/A
PERFORMANCE:
PERFORMANCE:
Range
400 / 500 / 600km
Range
300 - 350km
Speed
100km/hr
Speed
100km/hr
Battery Type
LFP
Battery Type
LFP
Battery Capacity
280 / 324 / 462 kWh
Battery Capacity
264 / 324 kWh
Charging Time
3 - 5 hrs
Charging Time
2 - 4 hrs
AIR-CONDITIONING:
AIR-CONDITIONING:
Air-Conditioning Standard
Yes
Air-Conditioning Standard
Yes
Air-Conditioning Make/s
Thermoking
Air-Conditioning Make/s
Thermoking
Air-Conditioning Model/s
E Series
Air-Conditioning Model/s
E Series
BODY OPTIONS:
BODY OPTIONS:
Wheelchair lift/access
Yes (Manual)
Wheelchair lift/access
Yes (Manual)
CD/PA/Radio
Optional
CD/PA/Radio
Optional
DVD/TV
No
DVD/TV
No
Toilet
No
Toilet
No
Individual reading lights
No
Individual reading lights
No
Individual AC vents
No
Individual AC vents
No
Reverse camera
Yes
Reverse camera
Other (please specify)
68
Driver interface screen, Wireless bell pushes, Bonded Doube Dark tinted side windows, 4 - 8 camera CCT system, Electric heated external mirrors, Driver security screen, TS155 compliance Safety System (suitable), Additional Electric bus options: passenger information system, WIFI system, USB Charge Ports
ABC 2023 BUS SEARCH BUYERS’ GUIDE
Other (please specify)
Yes Driver interface screen, Wireless bell pushes, Bonded Doube Dark tinted side windows, 4 - 8 camera CCT system, Electric heated external mirrors, Driver security screen, TS155 compliance Safety System (suitable), Additional Electric bus options: passenger information system, WIFI system, USB Charge Ports
