MAKE: MERCEDES-BENZ MODEL: O 500 RS
APPLICATION: CHARTER - LONG DISTANCE, SCHOOL
DIMENSIONS:
Length (metres) 12.5
Wheelbase (mm) 3000 (buggy format)
Front Overhang (mm) 2570
Rear Overhang (mm) 3280
Turning Circle Diameter (m) 20.6 (wall to wall at overall length of 12.5)
ENGINE:
Make/Model Mercedes Benz/OM457LA
6 cylinders in line
354/260 (Opt: 428hp)
Torque (Nm) 1600 (Opt: 2100hp)
Oil Capacity (litres) 28
FUEL SOURCE / CAPACITY:
TRANSMISSION:
AXLES:
speed with torque converter and retarder
Type – Front Mercedes-Benz/V0 4/40 DCL-7.1/Forged steel ‘I’ beam 7100kg
Type – Rear Mercedes-Benz/RO 440/Rigid, single ratio hypoid axle. 12,500kg capacity
SUSPENSION:
Type – Front Rigid I-Beam. Electronic Air Suspension (ECAS) with Electronic Level Control (ENR), 2 air bellows , 4 telescopic double acting shock absorbers and stabilizer bar
Type – Rear Live axle. Electronic Air Suspension (ECAS) with Electronic Level Control (ENR), 4 air bellows, 4 telescopic double acting shock absorbers and stabilizer bar
BRAKES:
Service Brakes Ventilated disc brakes, ABS, EBS, ASR, ESP, AEBS
Retarding Brake System Engine/Trans
EBS Yes
ELECTRONIC SYSTEM:
Alternator 2x 28V/140A
Starter 24V/6.2kW
Batteries 2x 12V/200Ah
WHEELS & TYRES:
Type 10 stud alloy
Rim Size 8.25 x 22.5
MAKE: MERCEDES-BENZ MODEL: 0 500 RSD
APPLICATION: CHARTER - LONG DISTANCE
DIMENSIONS:
Length (metres) 12.5 to 14.5
Wheelbase (mm) 3000 (transport)
Front Overhang (mm) 2200 (2570 opt)
Rear Overhang (mm) 2825
Turning Circle Diameter (m) 26.3 (wall to wall at overall length of 14.5)
ENGINE:
Make/Model Mercedes Benz/OM457LA
Configuration 6 cylinders in line
Power (hp/kW) 354/260 (Opt: 408hp & 428hp)
Torque (Nm) 1600 (Opt: 1900, 2100)
Oil Capacity (litres) 28
FUEL SOURCE / CAPACITY:
Type Diesel Capacity (litres) Various Fuel & 35L Adblue tank
TRANSMISSION:
Auto Model / Type OM457: Mercedes-Benz GO240-8, 8 speed automated manual
AXLES:
Type – Front Mercedes-Benz/VO 4/40 DCL-7.1/Forged steel ‘I’ beam, 7100kg
Type – Rear Mercedes-Benz/RO 440/Rigid, single ratio hypoid axle. 12500 kg capacity. Tag axle: Actively steered, maximum design capacity 6000kg
SUSPENSION:
Type – Front Rigid I-Beam electronic air suspension (ECAS) with Electronic Level Control (ENR), 2 air bellows, 4 telescopic double acting shock absorbers and stabilizer bar
Type – Rear Live axle. Electronic air suspension (ECAS) with Electronic Level Control (ENR), 4 air bellows, 4 telescopic double acting shock absorbers and stabilizer bar. Tag axle Suspension: Air suspension with 2 air bellows, 2 double acting shock absorbers
BRAKES:
Service Brakes Ventilated disc brakes, ABS, EBS, ASR, ESP, AEBS
Retarding Brake System Engine/Trans EBS Yes
ELECTRONIC SYSTEM:
Alternator 2 x 28V/140A
Starter 24V/6.2kW
Batteries 170Ah
WHEELS & TYRES:
Type 10 stud Alloy
Rim Size 8.25 x 22.5
1800 033 557
SALES INQUIRIES
National: Grant Simmonds – 0408 172 157
NSW & ACT: Paul Weber – 0418 494 881, Iain Dorward – 0466 415 026
QLD & NT: Dion Keating – 0400 640 072
WA, VIC, SA & TAS: Paul Kennedy – 0412 352 761
MAKE: MERCEDES-BENZ MODEL: OC 500 RF
APPLICATION: CHARTER - LONG DISTANCE, SCHOOL
DIMENSIONS:
Length (metres) 12.5
Wheelbase (mm) 3000 (buggy format)
Front Overhang (mm) 2570
Rear Overhang (mm) 3200
Turning Circle Diameter (m) 23.4 (wall to wall at overall length of 12)
ENGINE:
Make/Model Mercedes Benz/OM936LA
Configuration 6 cylinders in line
Power (hp/kW) 300/220
Torque (Nm) 1200
Oil Capacity (litres) 23
FUEL SOURCE / CAPACITY:
Type Diesel Capacity (litres) 280L Fuel & 45L Adblue tank
TRANSMISSION:
Auto Model / Type ZF or Voith/Ecolife or DIWA 6
ZF: 6 speed with lock up torque converter & retarder. Voith: 4 speed with integrated retarder and electronic control
AXLES:
Type – Front Mercedes-Benz/V0 4/39 CL-7.5/Forged steel ‘I’ beam 7100kg
Type – Rear Mercedes-Benz/RO 440/Rigid, single ratio hypoid axle 12500kg
SUSPENSION:
Type – Front Rigid I-Beam. Electronic air suspension (ECAS) with Electronic Level Control (ENR), 2 air bellows , 2 telescopic double acting shock absorbers and stabilizer bar
Type – Rear Live axle. Electronic air suspension (ECAS) with 4 air bellows, 4 telescopic double acting shock absorbers and stabilizer bar
BRAKES:
Service Brakes Ventilated disc brakes, ABS, EBS, ASR, ESP
Retarding Brake System Engine/Trans
EBS Yes
ELECTRONIC SYSTEM:
Alternator 3x 28V/150A
Starter 24V/6.2kW
Batteries 2x 12V/225Ah
WHEELS & TYRES:
Type 10 stud Steel or Alloy option
Rim Size 8.25 x 22.5
Length (metres) 12.5
Wheelbase (mm) 3000 (buggy format)
Front Overhang (mm) 2570 (2100 Opt)
Rear Overhang (mm) 3300
Turning Circle Diameter (m) 21.6 (wall to wall at overall length of 12.5)
ENGINE:
Make/Model Mercedes Benz/OM457LA
Configuration 6 cylinders in line
Power (hp/kW) 354/260 (Opt: 430hp)
Torque (Nm) 1600 (Opt: 2100)
Oil Capacity (litres) 28
FUEL SOURCE / CAPACITY:
Type Diesel Capacity (litres) 415L Fuel & 45L Adblue tank
TRANSMISSION:
Auto Model / Type ZF/Ecolife/6 speed with torque converter & retarder
AXLES:
Type – Front ZF/RL75E/Upper & lower suspension arms, 7500kg capacity
Type – Rear Mercedes-Benz/RO 440/Rigid, single ratio hypoid axle. 12500 kg capacity
SUSPENSION:
Type – Front Independent electronic air suspension (ECAS) with Electronic Level Control (ENR), 2 air bellows, 2 telescopic double acting shock absorbers and stabilizer bar
Type – Rear Live axle. Electronic air suspension (ECAS) with Electronic Level Control (ENR), 4 air bellows, 4 telescopic double acting shock absorbers and stabilizer bar
BRAKES:
Service Brakes Ventilated disc brakes, ABS, EBS, ASR, ESP, AEBS, LDWS
Retarding Brake System Engine/Trans EBS Yes
ELECTRONIC SYSTEM:
Alternator 3x 28V/150A
Starter 24V/6.2kW
Batteries 2x 12V/225Ah
WHEELS & TYRES:
Type 10 stud Alloy
Rim Size 8.25 x 22.5
1800 033 557
Level 4, 631 Springvale Road, Mulgrave | Victoria, Australia, 3170
www.mercedes-benz-bus.com/en_AU/
SALES INQUIRIES
National: Grant Simmonds – 0408 172 157
NSW & ACT: Paul Weber – 0418 494 881, Iain Dorward – 0466 415 026
QLD & NT: Dion Keating – 0400 640 072
WA, VIC, SA & TAS: Paul Kennedy – 0412 352 761
MAKE: MERCEDES-BENZ MODEL: OC 500 RF EURO 6
APPLICATION: CHARTER – LONG DISTANCE, SCHOOL
DIMENSIONS:
Length (metres) 12.5
Wheelbase (mm) 3000 (buggy format)
Front Overhang (mm) 2570 (2100 Opt)
Rear Overhang (mm) 3300
Turning Circle Diameter (m) 21.6 (wall to wall at overall length of 12.5)
ENGINE:
Make/Model Mercedes Benz/OM936LA (OM470LA Opt)
Configuration 6 cylinders in line
Power (hp/kW) 354/260 (Opt: 300hp & 390hp)
Torque (Nm) 1400 (Opt: 1200, 1900)
Oil Capacity (litres) 28
FUEL SOURCE / CAPACITY:
Type Diesel Capacity (litres) 415L Fuel & 45L Adblue tank
TRANSMISSION:
Auto Model / Type ZF/Ecolife 2/6 speed with torque converter & retarder
AXLES:
Type – Front ZF/RL75E/Upper & lower suspension arms, 7500kg capacity
Type – Rear Mercedes-Benz/RO 440/Rigid, single ratio hypoid axle. 12500 kg capacity
SUSPENSION:
Type – Front Independent electronic air suspension (ECAS) with Electronic Level Control (ENR), 2 air bellows, 2 telescopic double acting shock absorbers and stabilizer bar
Type – Rear Live axle. Electronic air suspension (ECAS) with Electronic Level Control (ENR), 4 air bellows, 4 telescopic double acting shock absorbers and stabilizer bar
BRAKES:
Service Brakes Ventilated disc brakes, ABS, EBS, ASR, ESP, AEBS, LDWS
Retarding Brake System Engine/Trans
EBS Yes
ELECTRONIC SYSTEM:
Alternator 3x 28V/150A
Starter 24V/6.2kW
Batteries 2x 12V/225Ah
WHEELS & TYRES:
Type 10 stud Alloy
Rim Size 8.25 x 22.5
MAKE: MERCEDES-BENZ MODEL: OC 500 RF 3 AXLE EURO 6
APPLICATION: CHARTER - LONG DISTANCE
DIMENSIONS:
Length (metres) 12.5 to 14.5
Wheelbase (mm) 3000 (buggy format)
Front Overhang (mm) 2100 (2570 opt)
Rear Overhang (mm) 2775
Turning Circle Diameter (m) 23.9 (wall to wall at overall length of 14.5)
ENGINE:
Make/Model Mercedes Benz (OM470LA Euro6 Opt)
Configuration 6 cylinders in line
Power (hp/kW) 428/315 (Opt: 456hp)
Torque (Nm) 2100 (Opt: 2200)
Oil Capacity (litres) 28
FUEL SOURCE / CAPACITY:
Type Diesel
Capacity (litres) 415L Fuel & 45L Adblue tank
TRANSMISSION:
Auto Model / Type Mercedes-Benz GO250-8 speed automated manual
AXLES:
Type – Front ZF/RL75E/Upper & lower suspension arms, 7500kg capacity
Type – Rear Mercedes-Benz/RO 440/Rigid, single ratio hypoid axle. 12500 kg capacity. Tag axle: Actively steered, maximum design capacity 6000kg
SUSPENSION:
Type – Front Independent electronic air suspension (ECAS) with Electronic Level Control (ENR), 2 air bellows, 2 telescopic double acting shock absorbers and stabilizer bar
Type – Rear Live axle. Electronic air suspension (ECAS) with Electronic Level Control (ENR), 4 air bellows, 4 telescopic double acting shock absorbers and stabilizer bar. Tag axle Suspension: Air suspension with 2 air bellows, 2 double acting shock absorbers
BRAKES:
Service Brakes Ventilated disc brakes, ABS, EBS, ASR, ESP, AEBS, LDWS
Retarding Brake System Engine/Trans
EBS Yes
ELECTRONIC SYSTEM:
Alternator 3x 28V/150A
Starter 24V/7kW
Batteries 2x 12V/225Ah
WHEELS & TYRES:
Type 10 stud Alloy
Rim Size 8.25 x 22.5
