MAKE: CHALLENGER MODEL: V10
ADDRESS: 176 Hall Street, Spotswood 3015 Victoria
WEB: www.challengerbusandcoach.com.au
EMAIL: sales@challengerbusandcoach.com.au
52 busnews.com.au
ABC 2023 BUS SEARCH BUYERS’ GUIDE
QLD, NSW: Mark Collins 0431 705 566 WA: Wayne Eather 0432 626 576
NSW: Dan Campbell 0425 752 948
CHASSIS & BODIES CHALLENGER
PHONE:
VIC,
APPLICATION: SCHOOL/CHARTER/DAY
AIR-CONDITIONING: AC Std Yes AC Make Thermo King/Coach Air AC Model TK: CS1000 AXLES: Front Make / Model / Desc. JB independent Rear Make / Model / Desc. Meritor SEATING OPTIONS: Seating Make Fainsa / Styleride Seating Model Various Seatbelts Yes SEATING: Seating Capacity Up to 62 Passenger Capacity Up to 45 Fixed Coach Optional Recliners Optional Metro Optional BODY OPTIONS: Wheelchair Lift Access Optional CD/PA/Radio Yes DVD/TV Yes Toilet Optional Individual Reading Lights Yes Individual AC Vents Yes Reverse Camera Yes Additional options On request BODY DIMENSIONS: Body Length (metres) 10.5 Body Width (metres) 2.5 Body Height (metres) 3.6 Body Floor Height (mm) 1300 Body Weight (GVM) 15,500 (Gross) BRAKES: Service Brakes Disc Retarding Brake System Yes EBS Yes SUSPENSION: Type – Front ECAS Independent suspension with 2 airbags Type – Rear ECAS 4 air bags TRANSMISSION: Auto Trans Make/ Model/ Description Allison T350R 6 Speed Manual Trans Make/ Model/ Description N/A ENGINE: Make / Model Cummins ISB6.7e5 300 or Cummins D6.7EVIE320 Configuration 6.7L Power (HP / kW) 300HP/ 224KW or 310HP/231 KW Torque (Nm) 1045Nm/2000 RPM or 1200Nm / 1200-1500 Bore and Stroke 107/124 Compression Ratio 17.3:1 or 18.5:1 Fuel Capacity (litres) 400 Oil Capacity (litres) 27 Emissions Euro 5 or Euro 6 CHASSIS DIMENSIONS: Chassis Length (metres) 10500 Chassis Wheelbase (mm) 5200 Chassis Front Overhang (mm) 2200 Chassis Rear Overhang (mm) 3100 Chassis Turning Circle Diameter (metres) 19 STORAGE: Through Bin Yes Internal Luggage Bins Yes
TOUR
MAKE: CHALLENGER MODEL: V12
ADDRESS: 176 Hall Street, Spotswood 3015 Victoria
WEB: www.challengerbusandcoach.com.au
EMAIL: sales@challengerbusandcoach.com.au
53 busnews.com.au
ABC 2023 BUS SEARCH BUYERS’ GUIDE
QLD, NSW: Mark Collins 0431 705 566
Wayne Eather 0432 626 576
NSW: Dan Campbell 0425 752 948
PHONE:
WA:
VIC,
SCHOOL/CHARTER/DAY
AIR-CONDITIONING: AC Std Yes AC Make Thermo King/Coach Air AC Model TK: CS1100 AXLES: Front Make / Model / Desc. ZF RL 75E Rear Make / Model / Desc. ZF A132 SEATING OPTIONS: Seating Make Fainsa / Styleride Seating Model Various Seatbelts Yes Seat layout as per customer request
OPTIONS: Wheelchair Lift Access Optional CD/PA/Radio Yes DVD/TV Yes Toilet Optional Individual Reading Lights Yes Individual AC Vents Yes Reverse Camera Yes Additional options On request BODY DIMENSIONS: Body Length (metres) 12.36 Body Width (metres) 2.5 Body Height (metres) 3.6 Body Floor Height (mm) 1300 Body Weight (GVM) 18,000 (Gross) BRAKES: Service Brakes Disc Retarding Brake System Yes EBS Yes SUSPENSION: Type – Front ECAS Independent suspension with 2 airbags Type – Rear ECAS 4 air bags TRANSMISSION: Auto Trans Make/ Model/ Description Allison T390R 6 Speed Manual Trans Make/ Model/ Description N/A ENGINE: Make / Model Euro 6 Cummins L9 or Euro 5 Cummins ISL360 Configuration 8.9L Power (HP / kW) 300-380HP/ 194-283KW or 360HP/268 KW Torque (Nm) 1166-1696 or 1550Nm/1100-1500 RPM Bore and Stroke 114/145 Compression Ratio 16.6:1 Fuel Capacity (litres) 400L Oil Capacity (litres) 24 litres or 27 litres Emissions Euro 5 or Euro 6 CHASSIS DIMENSIONS: Chassis Length (metres) 12360 Chassis Wheelbase (mm) 6550 Chassis Front Overhang (mm) 2425 Chassis Rear Overhang (mm) 3385 Chassis Turning Circle Diameter (metres) 22 STORAGE: Through Bin Yes Internal Luggage Bins Yes PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION PRODUCED BY AN AUTODESK STUDENT VERSION SEATING: Seating Capacity Up to 83 Passenger Capacity Up to 57 Fixed Coach Optional Recliners Optional Metro Optional
APPLICATION:
TOUR
BODY
