SITE PLAN
West Parkside ZONING: • Current Classification: I-2 Medium Industrial • Proposed Zoning: CMX-3 • Proposed Building Height: 60’ • Site Area: 45,000 SF
PAR K
SID
E AV
E
PROGRAM: • Retail & Eat & Drink Establishments (A2) • Apartments (R2)
ERS
ARCH 483 Studio 4C | A3 Assignment | Midterm
ON
ON
AVE
HS
TRE
ET
JEFF
MPS
48T
HO
NT AVE
WT
BELMO
49T
HS
TRE
ET
LEID YA VE
STR
EET
Jasmine Zhang | 2021 May 4th | 1
GROUND FLOOR Building Plans
GROUND FLOOR The ground floor contain spaces for hospitality (eat & drink establishments), retail, mechanical/service, and residential lobbies. The annex of the building extends into the green space adjacent to the property to interact with it. BUILDING • 20’ Floor-to-floor - Main • 23’ Floor-to-floor - Annex • 20’ X 25’ Structrual Bay • Building Coverage: 38,306 SF • Hospitality/Retail: 29,040 SF • Building Services; 4,040 SF
HOSPITALITY
MECHANICAL / SERVICE
MAIN RESIDENTIAL LOBBY
HOSPITALITY / RETAIL
HOSPITALITY / RETAIL
RESIDENTIAL SIDE
ANNEX BRIDGE
GROUND FLOOR PLAN ARCH 483 Studio 4C | A3 Assignment | Midterm
0’
10’
25’
40’
Jasmine Zhang | 2021 May 4th | 2
UPPER FLOOR Building Plans
TYPICAL FLOOR The typical upper floor plan contains residential apartments, with 21 units of 1-bedrooms and 2-bedrooms per floor, for a total of 84 units. The annex’s roof becomes an outdoor amenity space for the residents, overlooking the green space. BUILDING • 10’ Floor-to-floor • 20’ X 28’ Structrual Bay • Upper Floor Area: 21,789 SF/floor • Total Apartment Area: 87,128 SF • Number of Units: 21 units • Total Number of Units: 84 units
KEY: 1-BEDROOM UNIT 2-BEDROOM UNIT AMENITY SERVICE 0’
10’
25’
40’
TYPICAL UPPER FLOOR PLAN ARCH 483 Studio 4C | A3 Assignment | Midterm
Jasmine Zhang | 2021 May 4th | 3
SITE SECTION Building Plans
The proposed building section shows the varied heights of the main building and the annex. The bridge connects the two portions, allowing vehicular access into the courtyard for residents.
KEY PLAN:
PROPOSED BUILDING SECTION
0’
10’
25’
0’
10’
25’
40’
40’
ARCH 483 Studio 4C | A3 Assignment | Midterm
Jasmine Zhang | 2021 May 4th | 4
MODEL VIEWS Building Massing
A
Front of the Building
B
Building Courtyard
KEY PLAN:
A B
ARCH 483 Studio 4C | A3 Assignment | Midterm
Jasmine Zhang | 2021 May 4th | 5
MODEL VIEWS Building Massing
C
Building Corner
D
Building Annex
KEY PLAN:
C
D
ARCH 483 Studio 4C | A3 Assignment | Midterm
Jasmine Zhang | 2021 May 4th | 6
SUMMARY METRICS Building Massing
ZONING: • Current Classification: I-2 Medium Industrial • Proposed Zoning: CMX-3 • Proposed Building Height: 60’ • Site Area: 45,000 SF PROGRAM: • Retail & Eat & Drink Establishments (A2) • Apartments (R2) GROUND FLOOR: • 20’ Floor-to-floor - Main • 23’ Floor-to-floor - Annex • 20’ X 25’ Structrual Bay • Building Coverage: 38,306 SF • Hospitality/Retail: 29,040 SF • Building Services; 4,040 SF TYPICAL UPPER FLOOR: • 10’ Floor-to-floor • 20’ X 28’ Structrual Bay • Upper Floor Area: 21,789 SF/floor • Total Apartment Area: 87,128 SF • Number of Units: 21 units • Total Number of Units: 84 units
ARCH 483 Studio 4C | A3 Assignment | Midterm
Jasmine Zhang | 2021 May 4th | 7
JUROR FEEDBACK Notes
Feedback
Next Steps
• Distribution of the ground floor programs are clean and clear.
• Look into Sister Cities Park
• The annex bridge appears to be too big. • The annex bridge is perhaps not neccessary as it’s a tight space between the main building and annex. Try separating the main building and annex. • Engage the green space more. Show the activity. • Show site context on the ground floor to understand the site relationship.
• Explore options of where the lobby/ vehicule dropoff is in the building • Explore the annex bridge - change the scale or remove it • Explore more courtyards/pavilion spaces to engage the green space with the building • Begin considering facade materiality maybe this would help in locating the lobby/vehicle dropoff?
• Reference Sister Cities Park. • The current solution for the vehicule dropoff area is not the best, but there isn’t a clear alternative yet. • Explore redistributing the main building programs to the annex - try moving the lobby to the annex? • Make sure to consider accessibility to the lobby.
ARCH 483 Studio 4C | A3 Assignment | Midterm
Jasmine Zhang | 2021 May 4th | 8
ILLUSTRATIVE SITE PLAN Building Plans
0 10 25 ARCH 483 Studio 4C
50
GROUND FLOOR PLAN Jasmine Zhang | 1
LOBBY PLAN Building Plans
ENLARGED LOBBY PLAN 0
5
ARCH 483 Studio 4C
10
20
ENLARGED MEZZANINE PLAN 0
5
10
20
Jasmine Zhang | 2
UPPER FLOOR PLAN Building Plans
0 10 25 ARCH 483 Studio 4C
50
TYPICAL UPPER FLOOR PLAN Jasmine Zhang | 3
SITE SECTION Context
49TH STREET
SITE
0 20
ARCH 483 Studio 4C
50
GARDENS
80
Jasmine Zhang | 4
BUILDING SECTION Massing
APARTMENTS
LOBBY
0 20
ARCH 483 Studio 4C
COMMERCIAL
50
COMMERCIAL
80
Jasmine Zhang | 5
RENDER Context
ARCH 483 Studio 4C
Jasmine Zhang | 7
