Traction Catalog 2020 - 2021

Welcome to the pewag group We are an internationally operating group of companies.

Our track record goes back to the year 1479.

Mission statement Because of our joy and determination to innovate, we at pewag manufacture the world’s best chains today and in the future. The high quality of our products and services as well as the passionate performance of our employees, guarantees safety for moving people and goods. Our success is measured by our customers.

Environmental responsibility

Important information

Ecological awareness

Warranty

We continuously strive to keep the influence of our business on the environment as low as possible. Our production and warehousing is organized so that all legal requirements on environmental protection are fulfilled. Furthermore, we consider ecological aspects for our product development, processes and distribution channels and include these in our business planning.

The goods sold in this catalog are warranted free from defects in workmanship and materials for 90 days from the date of purchase. No other warranty, expressed or implied, is given.

And no affirmation of seller, by words or action, shall constitute a manufacture warranty. Buyer must notify seller in writing and within 10 days of discovery of the alleged defect to be considered within the warranty period stated above.

Consequently, we are permanently striving for a continuous improvement and development of our established products to reach higher load capacities and safety for our customers with lighter weights and longer life spans.

Wherever we cannot avoid an environmental impact, we strive to reduce the use of energy, environmentally harmful emissions, and keep the production of waste to a minimum. When investing in new machines we consider the technically most adequate and economically feasible state-of-the-art designs for their designated area of use.

Our environmental management is certified according to ISO 14001:2015. Regular internal audits assist to supervise compliance, test the effectiveness of our set standards and serve as a basis to determine improvement potentials.

Out of this long-lasting tradition we take responsibility for our products, employees, our sites and the environment very seriously.

We commit to comply with all environment-related regulations and continually improve our performance for the environment by defined goals. For that purpose we use modern production technologies.

We enhance the ecological awareness of our employees by regular trainings.

We engage with our customers, neighbors and government agencies in an open communication and inform them about our environmental management wherever appropriate.

By providing advice, we want to inform our customers about the environmental aspects related to the use of our products – especially their long life spans. We are striving to motivate our customers and suppliers to consider environmental protection in their sphere of influence and use the same environmental standards as we do.

Snow chain advice Please check if there are specifications or recommendations for the use of snow chains for your vehicle (instruction manual, etc.).

Please make yourself familiar with the chains before you need them. Read the mounting instructions carefully and learn how to use the new chain with an installation on dry ground.

Always mount the chain on the drive axle (instruction manual).

And for 4x4 vehicles, please consider the recommendation of the manufacturer.

After about 100 yards, inspect the chains for the correct tension and fit. Re-tension if necessary.

Re-tension the chain if it starts to hit the wheel well. Please be careful: Too much tension can lead to tire damage, wheels spinning, and increased chain wear.

The road performance of your vehicle changes with snow chains (especially on bare pavement)! Please do not go faster than 25-30 mph. Speeds faster than 30 mph will increase the risk of a chain failure.

Remove the chains as soon as the road conditions improve to avoid unnecessary wear.

Check the wear condition of the chains regularly. The lifetime of a pewag tire chain can be increased by reversing the chains.

Attention: In any application, please consider the enclosed operating and mounting instructions of the chains as well as the warnings!

Our goal is customer satisfaction To reach this goal, the quality management of the pewag group is determined by the principle: “We supply our customers with high-quality products which fully meet technological standards and its usage requirements.�

3

TitanGrip® & ThickThin® technology pewag snow chains – now lighter and with longer life span Snow chains marked with the TitanGrip® trademark are made from a special high-grade alloy steel. The combination of titanium and Boron steel in conjunction with a sophisticated heat treatment process provides maximum wear resistance.

A chain is only as strong as its weakest link.

But why must every chain link have the same shape?

Can we build better chains by combining different types of chain links? pewag found the answer by consistently working on a new technology to radically improve chains. The result of this research is the ThickThin® technology. For the first time in the history of chain manufacturing different chain links (different in shape, length and thickness) can be assembled in one chain.

For this reason pewag can manufacture the best combination for the various areas of use.

What is your advantage?

Reduced weight, considerably longer life span and optimum traction performance.

snox® technology pewag snox: world’s most convenient snow chain Chains often have to be mounted when the weather is extremely unfriendly. Conventional hooks, and other fasteners on the chain, increases the overall mounting time. pewag snox is the first chain system without these connecting elements. The tensioning system acts automatically and regulates the perfect amount of tension throughout the chain.

servo technology pewag snow chains are clever Tensioning systems for snow chains have to get more convenient: This was pewag’s main goal when developing the latest generation of automatic ratchets. The key objective was to make mounting the chains easier by enhancing the tensioning system, and to improve performance and user friendliness. We created the new servo-technology to achieve these objectives.

4

Starwave ® profile links pewag snow chain with starwave® profile links To increase both grip and life span,pewag introduced the wave profile. pewag differentiates chain links between a rectangular (for example 7 mm wide but 8.2 mm high) and a square version (for example 7 mm wide and 7 mm high). Which one of these basic shapes used depends on the chain’s application. For example, pewag unimove has a rectangular link shape, while the pewag asv partly consists of square wave profile links.

Square grip links pewag snow chains with square grip links Square grip links intertwine and prohibit the chain from twisting when exposed to pressure and provide optimum drive and brake performance because they “bite” into the terrain.

This gives each pewag chain with these distinct edges an advantage over our competition.

Asymmetrical Pattern-Style Chains pewag Asymmetrical Pattern-Style Chains run smoother and provide better traction The chain track shows that the distances between the chains A1 are considerably closer with the Asymmetrical Pattern-Style Chain compared to the similar built H-Pattern-Style Chain with the distance A 2. The center section of the H-Pattern-Style Chain serves exclusively to keep the vehicle on track. The asymmetrical pattern in contrast contributes not only to keeping the vehicle on track, but also improving brake and drive performance.

Consequently, the Asymmetrical Pattern-Style Chain runs smoother with higher performance.

History of the pewag group Advantage through tradition

Areas of application pewag offers a substantial and diverse spectrum of products and services

The history of pewag group goes back to the 15th century and therefore makes us the oldest chain manufacturer worldwide.

With our experience we are ready for the future.

Timetable of important events 1479 First documented references of a forging plant in Brückl 1787 Foundation of a chain forgery in Kapfenberg 1803 Foundation of a chain forgery in Graz 1836 Establishment of an iron casting plant in Brückl 1912 Production of the first snow chain worldwide 1923 Merger of plants in Graz and Kapfenberg – Creation of the name “pewag” 1972 Foundation of a sales company in Germany 1975 Foundation of a sales company in the USA 1993 Foundation of pewag austria GmbH 1994 Foundation of the first subsidiary in Czech Repbulic 2005 Reorganization into 2 groups: Schneeketten Beteiligungs AG Group – Snow Chains pewag austria GmbH Group – Technical Chains 2009 Acquisition of Chaineries Limousines S.A.S. 2014 Manufacturing starts in Pueblo, CO - USA 2016 Foundation of pewag Canada, Inc. in Mississauga, ON 2017 Merger of snow chain division from pewag, Inc. with the production team at pewag Traction Chain, Inc.

Traction chains

Tire protection chains

Industrial chains

Engineering

ISO 14001:2015 ISO 9001:2015 pewag austria GmbH A-8041 Graz Gaslaternenweg 4 +43 (0) 316 / 60 70-0

ISO 14001:2015 ISO 9001:2015

Lithography forging plant Brückl 1855

pewag Traction Chain, Inc. 190 Greenhorn Drive Pueblo, CO 81004 (800) 445-2895

pewag Traction Chain, Inc. 3825 Cincinnati Avenue Rocklin, CA 95765 (800) 445-2895

Anchor chain forgery 1878

Chain forgers 1956

pewag, Inc. 600 West Crossroads Pkwy Bolingbrook, IL 60440 (800) 526-3924

pewag Canada, Inc. 3600 B Laird Road Mississauga, ON L5L 6A7 (888) 598-0626 5

Content passenger class “S” snox pro servo

8 8

light truck, SUV & 4WD studded ladder zig-zag pattern starwave ladder brenta-c SUV snox SUV servo SUV

10 10 11 11 12 12

heavy truck & trailer studded ladder starwave ladder mud chain CL (cervino) ASV (austro super verstärkt) zig-zag pattern starwave pattern (USAP)

14 15 15 16 16 17 17

loader, grader & tractor H pattern zig-zag pattern starwave ladder universal ED erzberg ED

20 20 20 21 22

forklift & skid steer forklift & small equipment skid steer pattern skid steer ladder

24 24 24

parts & accessories universal &erzberg parts bulk cross chain bulk side chain cam chain cross chain hooks swivel hooks adjusters/tensioners chain pliers repair links cams, levers & clevis ends cam tools

26 27 27 27 27 28 28 28 29 29 29

fit guide passenger class “S” light truck, SUV & 4WD heavy truck & trailer loader, grader & tractor

32 35 43 48

technical data chain specifications wire diameter & link specifications

6

53 56

pewag chains are the strongest chains for each area of application With our determination to innovate, we design snow chains that guarantee maximum safety and confidence in every situation. pewag snow chains can not only be used during inclimate weather conditions; but are also well suited for all different seasons and ground surfaces. When found on impassable terrain; equipment operators and drivers alike, rely on pewag’s renowned quality and strength.

For many years, pewag has been the leading supplier of traction chains around the world.

As a technology leader, we offer innovative, reliable, and proven solutions for the most challenging applications.

Scan this QR code to view our traction catalog on your mobile device.

passenger class “S� content snox pro servo

8 8

snox

PRO

s(nox)olution! pewag snox pro is the only snow chain that is not mounted, but snoxed!

No rings, no hooks, no re-tensioning - snow chain mounting has never been so easy. At a given speed, the pewag snox system locks the ring - and ideal tensioning of the chain is regulated automatically. When the vehicle stops, the ring is released again and you can simply pull the chain off the tire. For an even quicker removal of the chain, pewag snox is additionally equipped with the patented quick-release latch system.

•High quality chain with innovative technology •pewag snox system tensions the chain automatically •Always pre-fit chains before use

Mounting Video

servo Sporty, thrilling, and durable. pewag servo was developed for vehicles with high powered engines and offers the ease of stationary mounting and reliability under all conditions. Due to its low profile pattern for class “S” applications; pewag servo allows for vehicle clearance, perfect traction, and a long life span.

•High quality chain with innovative technology •pewag servo ratchet tensions the chain automatically •Always pre-fit chains before use

Mounting Video

8

light truck, SUV & 4WD content studded ladder zig-zag pattern starwave ladder brenta-c SUV snox SUV servo SUV

10 10 11 11 12 12

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

studded ladder Aggressive off-road traction on demand. pewag’s revolutionary 8-sided design is proven to outlast and outperform the competition. Breaking the mold of conventional round studs; pewag’s 8-sided allows for a deeper hardening on each individual piece. This chain is engineered for the most aggressive off-road applications.

Built to last, and Made in USA! •Can be custom built to any tire size, with or without cams •Always pre-fit chains before use TM

TM

Optional tightener

Front View

zig-zag pattern Proven design with optimum traction.

The alternating pewag zig-zag pattern chain for trucks that demand high traction but also want a smooth and stable ride.

This zig-zag design can be built to suit any application. This chain performs on or off road, and is suitable for any application while maintaining a low profile.

•Cross chain replacements available •Can be custom built to any tire size, with or without cams •Always pre-fit chains before use

starwave® 10

Front View

starwave ladder The standard of quality; pewag square link. pewag nickel manganese alloy square link tire chains wear up to 8 times longer than conventional twist link tire chains while giving you up to 32% more traction. Our ladder style chain features both a cam (SC) or non-cam (S) side chain for every driver preference.

•Made using pewag premium alloy •Can be reversed for better wear and longer life •Always pre-fit chains before use

05

#1

Available in duals

Optional tightener

brenta-c SUV Simply strong and reliable. pewag brenta-c 4x4 has been proven worldwide a thousand times over for class “S” clearance rated vehicles. This top-seller has everything that a first class chain needs. The square link is suited for the hardest requirements, and resists even the most adverse conditions. Its configuration allows for easy and fast mounting of the chain. From the city, to the mountains, brenta-c chains are truly a link above the rest.

•Always pre-fit chains before use

Front View 11

snox SUV s(nox)olution! pewag snox suv is the only snow chain that is not mounted, but snoxed!

No rings, no hooks, no re-tensioning - snow chain mounting has never been so easy. At a given speed, the pewag snox system locks the ring - and ideal tensioning of the chain is regulated automatically. When the vehicle stops, the ring is released again and you can simply pull the chain off the tire. For an even quicker removal of the chain, pewag snox is additionally equipped with the patented quick-release latch system.

•High quality chain with innovative technology •pewag snox system tensions the chain automatically •Always pre-fit chains before use

Mounting Video Front View

servo SUV Sporty, thrilling, and durable. pewag servo was developed for vehicles with high powered engines and offers the ease of stationary mounting and reliability under all conditions. Due to its low profile pattern for class “S” applications; pewag servo allows for vehicle clearance, perfect traction, and a long life span.

•High quality chain with innovative technology •pewag servo ratchet tensions the chain automatically •Always pre-fit chains before use

Mounting Video Front View 12

heavy truck & trailer content studded ladder starwave ladder mud chain CL (cervino) ASV (austro super verstärkt) zig-zag pattern starwave pattern (USAP)

14 15 15 16 16 17 17

studded ladder Aggressive off-road traction on demand.

TM

pewag’s revolutionary 8-sided design is proven to outlast and outperform the competition. Breaking the mold of conventional round studs; pewag’s 8-sided allows for a deeper hardening on each individual piece. This chain is engineered for the most aggressive off-road applications, ideally forestry, oil fields, and ice road trucking. Now Made in USA! •Always pre-fit chains before use TM

TM

Regular Spacing

Levers Stock No.

Replacement Lever Assembly

USA8260 7ST

7mm Lever Kit

USA8260 8ST

8mm Lever Kit

2 Link Spacing

Available in: • 7mm and 8mm premium high-grade alloy • Cam(SC) & Non-Cam(S) • Singles, Wide Base & Dual-Triples • 2 Link and 4 Link Spacing for certain sizes

03

#1

Close-up 14

TM

Design

Available in duals

Optional tightener

starwave ladder NEW

The standard of quality; pewag square link. pewag nickel manganese alloy square link tire chains wear up to 8 times longer than conventional twist link tire chains while giving you up to 32% more traction. Our ladder style chain features both a cam (SC) or non-cam (S) side chain for every driver preference.

•Made using pewag premium alloy •Can be reversed for better wear and longer life •Proudly made in Pueblo, Colorado •Always pre-fit chains before use

03

#1

Super Single/Wide Base

Optional tightener

mud service Extra heavy duty traction for deep mud.

Oversized cross chain, combined with heavier side chain, deliver the off-road traction in deep mud. Made only from pewag premium alloy square link for extended wear and strength. It’s quality that you can trust and rely on every time.

•Made with cam (SC) or non-cam (S) locking side chain •Always pre-fit chains before use

Need a special Mud Service Chain?

We can build any special Mud Chain upon request.

#1 03

Available in duals

Optional tightener 15

CL The standard chain for medium-weight.

The proven and popular pewag Cervino (CL) is the standard chain for medium-weight utility vehicle use. Due to its light weight and tension chain, this chain can be easily mounted on the vehicle.

Made using our brilliant 7mm square link titanium alloy steel for lasting wear. CL chains perform at their peak on or off-road, maintain a low profile and are suitable for any application. •Always pre-fit chains before use

Cross chain replacements and spare parts are available

ASV Strength for heavy-duty vehicle use.

The Austro SV (ASV) pattern chain has been engineered to stand up to the most severe conditions where traction is a must. This design provides exceptional lateral and braking traction. pewag ASV chains are depended upon for professional use on heavy duty utility vehicles on or off-road. Welded rings connect the chain mesh to the side chain, which guarantee a long life span. The latest starwaveÂŽ innovation provides additional grip and a longer life.

Easy mounting, with hassle free traction when you need it. •Always pre-fit chains before use

Available in: 7mm & 8.2mm

Cross chain replacements and spare parts are available 16

zig-zag pattern Proven design, optimum traction.

The alternating pewag zig-zag pattern chain for trucks that demand high traction but also want a smooth and stable ride.

This zig-zag design can be built to suit any application. This chain performs on or off road, and is suitable for any application while maintaining a low profile.

•Can be custom built to any tire size, with or without cams •Cross chain replacements available •Always pre-fit chains before use

Studded Zig-Zag

Tread view

starwave pattern The chain for heavy-duty vehicle use.

The NEW pewag starwave® pattern USA chain is the standard chain for truck and utility vehicle use. Due to its light weight and cam locks; this chain can be easily mounted. This design provides exceptional lateral and braking traction. The latest 7mm starwave® innovation provides additional grip and a longer life. This pattern chain performs at its peak on or off road, suitable for any application and maintaining a low profile.

•Can be custom built to any tire size, with or without cams •Always pre-fit chains before use

17

loader, grader & tractor content H pattern zig-zag pattern starwave ladder universal ED erzberg ED

20 20 20 21 22

loader, grader & tractor For Plows, Scrapers, Loaders, Graders, Backhoes & Tractors.

We manufacture and assemble chains for any application with trusted traction for snow removal and agriculture machinery. All made from pewag nickel manganese alloy square link; guaranteed to last longer and outperform conventional twist link. •Can be reversed for better wear and longer life •Always pre-fit chains before use

20

Special order build available with swivel hook or 5858SP hook shown here

USA H-Pattern

USA Zig-Zag Pattern

USA Ladder 4-Link Spacing

USA Ladder 2-Link Double Spacing

universal ED Net chain for high traction demand.

Available in wire diameter: 7mm, 8.2mm, 10mm & 12mm

The reinforced version of the popular universal chain now comes with welded wear bars added to the 3-Link design, providing wear resistance and durability that is unmatched. The addition of these wear bars, made of pewag strengthened steel, significantly increase grip, stability, and life span of these chains.

The universal chain mesh design provides great wear resistance and smoother riding. •Always pre-fit chains before use

21

erzberg ED Triple net chain for extreme traction. pewag erzberg features a densely meshed net-style chain in a robust welded ring version. This design offers improved grip matched with tire protecting properties. The forged closing hooks reduce noise and ensure quiet running in operation. All around very reliable chain which is easy to handle and can withstand the harshest conditions. •Always pre-fit chains before use

22

Available in wire diameter: 7mm, 8.2mm, 10mm & 12mm

forklift & skid steer content forklift & small equipment skid steer pattern skid steer ladder

24 24 24

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

53

forklift & small equipment Simple and functional on forklifts, tractors, snow blowers & specialty vehicles. pewag nickel manganese alloy square link tire chains wear up to 8 times longer than conventional twist link tire chains while giving you up to 32% more traction.

•Can be reversed for better wear and longer life •Available in 2 and 4 link spacing •Additional sizes available •Always pre-fit chains before use

Tire Size 6.5x10 7.00x12 7.00x15 250x15 28x9x15 300x15

Light Duty Stock No. USA65010S 4.5mm -----------

Medium Duty Stock No. USA65010S 5.6mm USA70012S 5.6mm USA70015S 5.6mm USA25015S 5.6mm USA28915S 5.6mm USA30015S 5.6mm

Heavy Duty Stock No. USA65010S 7mm USA70012S 7mm USA70015S 7mm USA25015S 7mm USA28915S 7mm USA30015S 7mm

A ll O pt io ns A v a ila ble in 2 Link S pa c ing. A dd D S t o t he e nd o f S t o c k N o .

starwave skid steer Strength for your plow equipment.

A reliable, lasting traction solution for skid steer equipment. Whether it’s plowing snow 24 hours a day, or getting materials around that muddy job site; pewag chains take you where you need to go.

•Can be custom made for any skid steer size •Always pre-fit chains before use

24

USA Pattern

Tire Size 10x16.5 12x16.5 14x17.5 31x12-16.5

USA Pattern Stock No. USASSE10165P USASSE12165P USASSE14175P USASSE3112165P

USA Ladder 2-Link Spacing

USA Ladder 2-Link Stock No. USASSE10165-2 USASSE12165-2 USASSE14175-2 USASSE3112165-2

USA Ladder 4-Link Stock No. USASSE10165-4 USASSE12165-4 USASSE14175-4 USASSE3112165-4

USA Ladder 4-Link Spacing

parts & accessories content universal &erzberg parts bulk cross chain bulk side chain cam chain cross chain hooks swivel hooks adjusters/tensioners chain pliers repair links cams, levers & clevis ends cam tools

26 27 27 27 27 28 28 28 29 29 29

genuine parts pewag slit ring Stock No.

Trade Size

Description

Application

Package

Weight

5073

8mm x 36mm

Slit Ring

Pattern Chains

10

2 lbs

71793

12mm x 45mm

Slit Ring

Pattern Chains

10

5 lbs

7093TC

14mm x 52mm

Slit Ring

Pattern Chains

10

7 lbs

17mm x 64mm

Slit Ring

Pattern Chains

10

9 lbs

7094TC

pewag coupling ring Stock No.

Trade Size

Description

Application

Package

Weight

05625

8.2mm

Coupling Ring

8.2mm UNE & ERZ

10

6 lbs

7078TC

10mm

Coupling Ring

10mm UNE & ERZ

10

7 lbs

7079TC

12mm

Coupling Ring

12mm UNE & ERZ

10

12 lbs

pewag connecting hook Stock No.

Trade Size

Description

Application

Package

Weight

9008

8.2mm

Connecting Hook

8.2mm UNE & ERZ

10

3 lbs

9010

10mm

Connecting Hook

10mm UNE & ERZ

10

6 lbs

9012

12mm

Connecting Hook

12mm UNE & ERZ

10

10 lbs

21363

8.2mm

5 lbs

10mm

Connecting Hook w/Ring 8.2mm UNE & ERZ Connecting Hook w/Ring 10mm UNE & ERZ

10

84942

10

8 lbs

88502

12mm

Connecting Hook w/Ring

12mm UNE & ERZ

10

12 lbs

Weight

pewag 3-link replacement Stock No.

Trade Size

Description

Application

Package

9900

8.2mm

3-Link Replacement

8.2mm UNE & ERZ

10

5 lbs

9902

10mm

3-Link Replacement

10mm UNE & ERZ

10

10 lbs

9904

12mm

3-Link Replacement

12mm UNE & ERZ

10

20 lbs

pewag pin lock - 8.2mm Stock No.

Trade Size

Description

Application

Package

Weight

7084TC

8.2mm

UNE & ERZ Pin Lock

8.2mm UNE & ERZ

10

5 lbs

pewag pin lock - 10 mm & 12mm Stock No.

Trade Size

Description

Application

Package

Weight

35326

12mm

UNE & ERZ Pin Lock

10mm & 12mm UNE/ERZ

10

9 lbs

pewag USA end hook Stock No. 12013

26

Trade Size

Description

Application

Package

Weight

8.2mm

USA End Hook

USA Studded

2

1 lbs

genuine parts

pewag hardened twisted square link Stock No.

Trade Size

Diameter

Application

Package

Weight

3008TSLUSA

8.2mm

3010TSLUSA

10mm

.322 (5/16")

Truck/Equip

100'

108 lbs

.409 (3/8")

Heavy Equip

100'

162 lbs

pewag hardened square link Stock No.

Trade Size

Diameter

Application

Package

Weight

3003USA 3004USA

3.7mm

.145(9/64")

Passenger

100'

21.2 lbs

4.5mm

.177 (5/32")

Passenger

100'

31.2 lbs

3005USA

5.6mm

.220 (3/16")

Light Truck

100'

49 lbs

3007USA

7mm

.275 (1/4")

Truck

100'

78 lbs

3008USA

8.2mm

.322 (5/16")

Truck/Equip

100'

108 lbs

3010USA

10mm

.409 (3/8")

Heavy Equip

100'

162 lbs

3012USA

12mm

.472 (7/16")

Heavy Equip

50'

119 lbs

pewag side chain Stock No.

Trade Size

Diameter

Application

Package

Weight

1004USA

4/0

1006USA

6/0

.219 (7/32")

Light Truck

100'

35 lbs

.281 (9/32")

Heavy Truck

100'

1007USA

7/0

56 lbs

.312 (5/16")

Truck/Equip

100'

71 lbs

1009USA

9/0

.375 (3/8")

Heavy Equip

100'

108 lbs

1011USA

11/0

.437 (7/16")

Heavy Equip

100'

138 lbs

1008USA (Hard)

7/0

.312 (5/16")

Truck/Equip

100'

68 lbs

1010USA (Hard)

9/0

.375 (3/8")

Heavy Equip

100'

104 lbs

1012USA (Hard)

11/0

.437 (7/16")

Heavy Equip

100'

141 lbs

pewag side chain with cam lock Stock No.

Trade Size

Diameter

Application

Package

Weight

1017USA

4/0

3 cams .219 (7/32")

Light Truck

10 pcs

37 lbs

1016USA

6/0

3 cams .281 (9/32")

Heavy Truck

10 pcs

64 lbs

1019USA

7/0

3 cams .312 (5/16")

Truck/Equip

10 pcs

71 lbs

pewag repair link Stock No.

Trade Size

Diameter

Application

Package

Weight

705

5.6mm

3/16"

Light Truck

10

0.33 lbs

707

7mm

1/4"

Heavy Truck

10

0.63 lbs

708

8.2mm

5/16"

Heavy Truck / Equip

10

1.12 lbs

710

10mm

3/8"

Heavy Equipment

10

2.11 lbs

712

12mm

7/16"

Heavy Equipment

10

3.25 lbs

pewag cross chain hook Stock No.

Trade Size

Diameter

403USA

Application

Package

Weight

3/0

405USA

5/0

.207 (13/64")

Passenger

50

1.26 lbs

.250 (1/4")

Small Equipment

50

406USA

3.5 lbs

6/0

.281 (9/32")

Light Truck

50

5.5 lbs

407USA

7/0

.312 (5/16")

Heavy Truck

50

8.2 lbs

409USA

9/0

.375 (3/8")

Equipment

50

13.3 lbs

411USA

11/0

.433 (7/16")

Heavy Equipment

50

21.8 lbs

27

hooks & adjusters Swivel Style Hooks Stock No.

Trade Size

Diameter

Fits

509 5858SP

9/0

.563 (9/16")

8.2mm & 10mm

Package Weight 25

7 lbs

9/0

.563 (9/16")

8.2mm & 10mm

25

7 lbs

Adjusters & Tensioners Stock No.

Description

Application

Fits Rim

Package Weight

101

Rubber-Ring

Heavy Equipment

20 - 33"

20

3 lbs

103

Multi-Arm

Heavy Truck

19.5 - 24.5''

25

1.5 lbs

105

Multi-Arm

Light Truck

16.5 - 19''

40

1 lbs

107

Multi-Arm

Passenger

12 - 16''

25

1.5 lbs

chain tools Glacier Chains

®

203 H.K. Porter

201

202R

202A & 203A

Stock No.

Description

Application

201

Import Short Handle Plier

Light & Heavy Truck

22"

1

7.96 lbs

202R

Import Long Handle Plier

Light & Heavy Truck

30"

1

10.5 lbs

202A

Import Replacement Jaw

For 201 & 202R

----

1

2.2 lbs

USA HK Porter Long Handled Plier

Light & Heavy Truck

30"

1

10.8 lbs.

USA HK Porter Replacement Jaw

For 203A

----

1

2.2 lbs

203 203A

28

Pliers & Cutters

Length Package Weight

links, levers & cams Side Chain Repair Link Stock No.

Trade Size

603SC

3.5mm

605SC

5.6mm

607SC

7mm

608SC

Diameter

Application

Package

Weight

1/8"

Passenger

25

0.31 lbs

3/16"

Light Truck

25

1 lbs

1/4"

Heavy Truck

25

2 lbs

8mm

5/16"

Heavy Truck

25

3 lbs

609SC

10mm

3/8 x 2 1/8"

Heavy Truck & Equipment

25

6.5 lbs

610SC

10mm

3/8 x 1 5/8"

Heavy Truck & Equipment

25

5 lbs

Emergency Quick Link/Side Chain Repair Link Stock No.

Trade Size

Diameter

Application

Package

Weight

8004

PLC

.15 (3/20")

Passenger

20

1.0 lbs

8005

4/0

.19 (13/64")

Light Truck

20

1.3 lbs

8006

6/0

.22 (7/32")

Light/Heavy Truck

20

1.5 lbs

8008

7/0 & 9/0

.312 (5/16")

Med/Heavy Equip

20

3.3 lbs

8010

11/0

.375 (3/8")

Heavy Equipment

20

6.0 lbs

8013

13/0

.5 (1/2")

Heavy Equipment

20

9.3 lbs

Lever Fastener Stock No.

Type

USA8230 USA8250

Application

Package

Weight

Lever

Light Truck

20

3.5 lbs

Lever

Heavy Truck

20

11.6 lbs

USA8260 7ST

Lever

7mm Studded

20

10 lbs

USA8260 8ST

Lever

8mm Studded

20

21 lbs

5297

Lever

UNE & ERZ

20

36 lbs

8230

8250 5297

Clevis Fastener Stock No.

Type

Application

Package

Weight

312

Clevis

Small Equipment

10

4.5 lbs

317

Clevis

Heavy Equipment

10

11 lbs

Cam Tightener Stock No.

Application

Package

Weight

5998

Light Truck

10

3 lbs

5999

Heavy Truck

10

7 lbs

Cam Tool Stock No.

Application

Package

Weight

205

LT/HT - pewag

1

1.65 lbs

204

Heavy Truck

20

8 lbs

Do you have a question about parts?

Call our friendly, knowledgeable staff!

We’re here to help.

205 Truckers Tool

Customer Service (800) 445-2895

29

passenger class “S� light truck, SUV & 4WD heavy truck & trailer pattern heavy truck & trailer ladder loader, grader & tractor chain specifications wire diameter & link specifications

32 35 43 45 48 53 56

comprehensive fit guides

content

passenger class “S” 32

Self-tension Tire 175/70 155/80 155165/70 165/80 165175/65 175/70 175/80 175185/55 185/60 185/65 185/70 185/75 185/80 195/50 195/55 195/60 195/65 195/70 195/75 205/60 205/65 205/70 225/60 7.00145/80 155/70 155/80 165/60 165/65 165/70 165/75 165/80 165175/60 175/65 175/70 175/75 175/80 175185/50 185/55 185/60 185/65 185/70 185/75 185/80 185195/55 195/60 195/65 195/70 195/80 205/50205/55 205/60

Rim Snox 12 13 13 13 13 13 13 13 13 SXP 520 13 13 13 13 13 13 SXP 520 13 SXP 530 13 13 13 13 SXP 520 13 SXP 530 13 SXP 530 13 13 SXP 530 13 SXP 530 13 14 14 14 14 14 14 14 14 14 SXP 520 14 14 14 14 14 SXP 520 14 SXP 530 14 14 14 14 14 14 SXP 530 14 SXP 530 14 SXP 540 14 14 14 SXP 520 14 SXP 530 14 SXP 530 14 SXP 550 14 14 SXP 520 14 SXP 530

Snox SUV

Manual Servo RS 60 RS 60 RS 60 RS 60 RS 62 RS 62 RS 60 RS 62 RS 64 RS 64 RS 60 RS 60 RS 62 RS 64 RS 64 RS 67 RS 60 RS 60 RS 62 RS 64 RS 67 RS 68 RS 64 RS 67 RS 69 RS 67 RS 69 RS 60 RS 60 RS 62 RS 60 RS 60 RS 62 RS 64 RS 64 RS 64 RS 60 RS 62 RS 64 RS 64 RS 68 RS 67 RS 60 RS 62 RS 62 RS 64 RS 67 RS 68 RS 69 RS 69 RS 62 RS 64 RS 67 RS 68 RS 74 RS 62 RS 64 RS 67

Servo SUV Brenta-C

RSV 74

XMR 73V

Self-tension Tire 205/65 205/70 205/75 205/80 215/60 215/65 215/70 215/75 215/80 225/55 225/60 225/70 225/75 225/80225235/60 235/70 245/60 255/60265/60 7.007.5027x8.5 30x9.5 30x10.5 31x10.5 31x11.5 32x11.5 135/80 145/80 145155/60 155/65 155/70 155/80 165/60 165/65 165/70 165/80 175/55 175/60 175/65 175/70 175/80 185/50 185/55 185/60 185/65 185/70 185/80 190/65 195/45 195/50 195/55 195/60 195/65 195/70 195/75

Rim Snox 14 SXP 530 14 SXP 540 14 14 SXP 560 14 SXP 530 14 SXP 540 14 14 SXP 560 14 SXP 560 14 14 SXP 540 14 14 14 14 14 14 SXP 570 14 14 SXP 570 14 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 SXP 520 15 15 15 15 SXP 530 15 15 15 SXP 520 15 SXP 520 15 SXP 540 15 15 15 SXP 520 15 SXP 530 15 SXP 530 15 15 15 15 15 15 SXP 530 15 SXP 540 15 SXP 540 15 SXP 550

Manual

Snox SUV

Servo RS 68 RS 73

Servo SUV Brenta-C

XMR 73V

SXV 570

SXV 570 SXV 570

RS 75 RS 69 RS 73 RS 74 RS 75 RS 76 RS 69 RS 73 RS 75 RS 76 RS 77 RS 74 RS 77 RS 75 RS 76 RS 77 RS 77

RS 60 RS 62 RS 62 RS 60 RS 60 RS 62 RS 64 RS 60 RS 62 RS 64 RS 67 RS 62 RS 62 RS 64 RS 67 RS 69 RS 60 RS 64 RS 64 RS 67 RS 68 RS 73 RS 69 RS 60 RS 64 RS 64 RS 67 RS 69 RS 73 RS 74

RSV 76

RSV 75

XMR 77V

RSV 77

XMR 77V XMR 77V XMR 77V

RSV 76 RSV 77

XMR 77V XMR 77V XMR 79V XMR 81V XMR 80V XMR 80V XMR 81V XMR 82V XMR 82V

RSV 73

XMR 73V

RSV 74

XMR 73V

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

Rim Snox 15 SXP 560 15 SXP 520 15 SXP 530 15 SXP 540 15 SXP 540 15 SXP 550 15 SXP 560 15 SXP 560 15 SXP 530 15 SXP 540 15 SXP 550 15 SXP 560 15 SXP 570 15 15 15 SXP 530 15 15 SXP 540 15 SXP 550 15 SXP 560 15 SXP 570 15 15 15 15 15 SXP 560 15 15 15 SXP 570 15 15 15 15 15 15 15 15 SXP 570 15 15 15 15 15 15 16 16 16 16 16 16 SXP 540 16 SXP 520 16 SXP 520 16 SXP 530 16 SXP 550 16 16 16 SXP 520 16 SXP 530 16 SXP 540

Manual

Snox SUV

SXV 570 SXV 570

Servo RS 75 RS 64 RS 68 RS 69 RS 73 RS 74 RS 75 RS 76 RS 68 RS 73 RS 74 RS 75 RS 76 RS 77

Servo SUV Brenta-C RSV 75 XMR 74V

RSV 76 RSV 77

XMR 77V XMR 79V XMR 77V

RS 67 RS 69 RS 73 RS 75 RS 75 SXV 570 SXV 580 SXV 580

RS 79

SXV 580 SXV 580 SXV 570

RS 74 RS 75 RS 79 RS 79 RS 76

SXV 580 SXV 580 SXV 600

RS 73 RS 77 RS80

RSV 76 RSV 77 RSV 79

XMR 76V XMR 77V XMR 79V XMR 79V

RSV 79 RSV 79 RSV 76 RSV 79

XMR 79V XMR 79V XMR 79V XMR 79V XMR 81V

RSV 77 RSV 80 RSV 81 RSV 81A

XMR 77V XMR 80V XMR 81V XMR 81V

RSV 80A RSV 81A

XMR 81V XMR 81V

RSV 80

XMR 80V XMR 81V XMR 81V

RS 76 SXV 590 SXV 600 RS 77 SXV 590

RS 75 RS 76

RS 64 RS 73 RS 64 RS 67 RS 67 RS 74 RS 75 RS 64 RS 67 RS 68 RS 69

RSV 81A RSV 75 RSV 76 RSV 80 RSV 80A

XMR 77V XMR 80V XMR 81V

Self-tension Tire 195/65 195/80 195/85 205/40 205/45 205/50 205/55 205/60 205/65 205/70 205/75 205/80 215/40 215/45 215/50 215/55 215/60 215/65 215/70 215/75 215/80 215/85 220/60 225/45 225/50 225/55 225/60 225/65 225/70 225/75 235/50 235/60 235/65 235/70 235/75 235/80 235/85 245/45 245/50 245/55 245/60 245/70 245/75 255/50 255/65 255/70 265/60 265/65 265/70 265/75 275/70 205/40 205/45 205/50 205/55 215/40 215/45 215/50

Rim Snox 16 SXP 550 16 SXP 560 16 SXP 570 16 16 SXP 520 16 SXP 530 16 SXP 540 16 SXP 540 16 SXP 550 16 SXP 560 16 SXP 570 16 16 SXP 520 16 16 SXP 540 16 SXP 550 16 SXP 560 16 SXP 560 16 SXP 570 16 16 16 16 16 16 SXP 550 16 SXP 560 16 SXP 560 16 SXP 570 16 16 16 SXP 560 16 SXP 570 16 16 16 16 16 16 SXP 550 16 SXP 560 16 SXP 570 16 16 16 16 SXP 570 16 16 16 16 16 16 16 17 SXP 530 17 SXP 530 17 SXP 540 17 SXP 550 17 SXP 530 17 SXP 540 17 SXP 550

Manual

Snox SUV

SXV 570

Servo RS 73 RS 76 RS 77 RS 64 RS 64 RS 68 RS 73 RS 74 RS 75 RS 75 RS 76 RS 77 RS 64 RS 67 RS 73 RS 74 RS 75 RS 76 RS 77 RS 77 RS 79 RS80 RS 75 RS 69 RS 74 RS 75 RS 76 RS 76 RS 79 RS 79 RS 75 RS 77

Servo SUV Brenta-C

RSV 77

XMR 77V

RSV 76 RSV 77

XMR 77V XMR 77V

RSV 77 RSV 77 RSV 79

XMR 77V XMR 79V XMR 80V

RSV 79 RSV 79

XMR 79V XMR 77V

RSV 77 RSV 79 RSV 79 RSV 80 RSV 81 RSV 81A

XMR 77V XMR 79V XMR 80V XMR 82V XMR 82V XMR 81V

RSV 79 RSV 80 RSV 81

XMR 79V XMR 80V XMR 81V

SXV 590 SXV 600

RSV 80 RSV 81

SXV 600 SXV 600 SXV 600 SXV 600

RSV 81 RSV 81A RSV 82 RSV 82

XMR 80V XMR 81V XMR 80V XMR 80V XMR 82V XMR 82V XMR 82V

SXV 570 SXV 570

SXV 570 SXV 580 SXV 580

SXV 580 SXV 580

SXV 580 SXV 580 SXV 600 SXV 600

passenger class “S”

Self-tension Tire 195/80 205/50 205/55 205/60 205/65 205/70 205/75 205/80 215/50 215/60 215/65 215/70 215/75 215/80 215225/45 225/50 225/55 225/60 225/65 225/70 225/75 225/80 225235/55 235/60 235/70 235/75 245/60 245/70 255/45 255/55 255/60 255/70 255/75 255/80 265/50 265/70 265/75 275/50 275/60 275/65 275/70 6.006.507.007.50175/60 175/75 185/50 185/55 185/60 185/75 185/80 195/45 195/50 195/55 195/60

RS 74 RS 76 RS 77 SXV 590 SXV 590 RS 77

RS 67 RS 68 RS 73 RS 74 RS 68 RS 69 RS 74

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

33

passenger class “S” 34

Self-tension Tire 215/55 215/60 215/65 225/40 225/45 225/50 225/55 225/60 225/65 225/70 235/40 235/45 235/50 235/55 235/60 235/65 235/70 245/40 245/45 245/50 245/55 245/65 245/75 255/40 255/45 255/50 255/60 255/75 265/40 265/70 275/55 275/60 8.008.50205/65 205/70 205/75 215/55 215/75 225/55 225/75 235/75 245/70 255/40 255/55 265/60 6.00215/45 225/40 225/45 225/55 235/40 235/50 235/55 235/60 245/40 245/45 245/50

Rim Snox 17 SXP 560 17 SXP 560 17 17 SXP 540 17 SXP 550 17 SXP 560 17 SXP 560 17 SXP 570 17 17 17 SXP 540 17 SXP 550 17 SXP 560 17 SXP 570 17 17 17 17 SXP 550 17 SXP 560 17 17 17 17 17 SXP 560 17 SXP 570 17 17 17 17 SXP 570 17 17 17 17.5 17.5 17.5 17.5 17.5 17.5 17.5 17.5 17.5 17.5 17.5 17.5 17.5 17.5 18 18 SXP 550 18 SXP 550 18 SXP 560 18 SXP 570 18 SXP 560 18 18 18 18 SXP 560 18 SXP 570 18

Manual

Snox SUV

SXV 570 SXV 580 SXV 580

Servo RS 75 RS 77 RS 78 RS 69 RS 74 RS 75 RS 76 RS 77 RS 79

Servo SUV Brenta-C

RSV 77 RSV 79 RSV 79

XMR 79V XMR 80V

RSV 79 RSV 80

XMR 79V XMR 80V

RS 74 RS 74 RS 76 RS 77 SXV 580 SXV 580

SXV 590

SXV 580 SXV 590

RS80 RS80 RS 74 RS 75 RS 77 RS 79 RS80 RS 75 RS 76 RS 79

RSV 80A RSV 81A

XMR 80V XMR 82V

RSV 79 RSV 80A

XMR 79V XMR 80V XMR 82V

RSV 82 RSV 81 RSV 81A RSV 80 RSV 81 RSV 76 RSV 77 RSV 79

XMR 82V XMR 80AV XMR 81V XMR 80V XMR 81V XMR 76V XMR 79V XMR 79V

RSV 76 RSV 80A RSV 81A

XMR 77V XMR 81V XMR 82V XMR 82V XMR 77V XMR 81V XMR 82V XMR 79V

Self-tension Tire 245/60 255/40 255/45 255/55 255/60 265/35 225/40 235/50 235/55 255/50 265/50

Rim Snox 18 18 SXP 570 18 18 18 18 SXP 570 19 SXP 560 19 19 19 19

Manual

Snox SUV

Servo RS80 RS 76 RS 78

SXV 590 SXV 590

Servo SUV Brenta-C

RSV 80A RSV 81A

XMR 80AV XMR 81V

RSV 79 RSV 80A RSV 81 RSV 81A

XMR 79V XMR 80V XMR 80AV XMR 80AV

RS 76 RS 75

SXV 600

product reference images Class “S”

Class “S”

Class “S”

Snox

Servo

Brenta-C

RS 76 SXV 600 SXV 600

SXV 580

SXV 580 SXV 580 SXV 580

RS 76 RS 77 RS 79 RS 76 RS80 RS 76

RS 74 RS 74 RS 75 RS 77 RS 74 RS 77 RS 79 RS80 RS 75 RS 77 RS 79

RSV 77 RSV 79 RSV 80

XMR 80V

vehicle clearance class

SAE Class

"A" Above Tire Tread

"C" Sidew all

Class "S"

1.46'' / 37mm

.59'' / 15mm

Class "U"

1.97'' / 50mm

.91'' / 23mm

Class "W"

2.50'' / 63.5mm

1.50'' / 38mm

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

Rim Singles 13 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14.5 14.5 14.5 14.5 15 15 USAZZ3237 15 15 15 15 15 15 USAZZ3227 15 USAZZ3229 15 15 15 15 15 15 15 USAZZ3227 15 USAZZ3227 15 15 15 15 USAZZ3227 15 USAZZ3227 15 USAZZ3227 15 USAZZ3227 15 USAZZ3229 15 USAZZ3237 15 USAZZ3227 15 USAZZ3227 15 USAZZ3229 15 USAZZ3227 15 USAZZ3229

Ladder Singles USA2201 USA2201 USA2209 USA2211 USA2216 USA2209 USA2216 USA2201 USA2201 USA2209 USA2209 USA2209 USA2209 USA2216 USA2209 USA2216 USA2219 USA2229 USA2229 USA2229 USA2229 USA2229 USA2209 USA2209 USA2216 USA2216 USA2216 USA2216 USA2219 USA2216 USA2219 USA2237 USA2237 USA2239 USA2228

Duals

Ladder WB

Ladder Mud Service

Ladder Studded

Singles

Singles

Singles

USA4211 USA4216

USA2433 USA2433 USA2433 USA2433

USA4216

Duals

USA4412 USA4412 USA4412 USA4412

USA4216 USA4216 USA4219 USA4229 USA4229 USA4229 USA4229 USA4229

USA4216 USA4216 USA4216 USA4216 USA4216 USA4216 USA4219 USA4237 USA4237 USA4239 USA4228

USA2433

USA4412

USA2433 USA2435 USA2433

USA4412

USA2433 USA3237

USA3227 USA3229 USA3255

USA4412

USA4412

USA2437

Duals

USA2216 ST

USA4216 ST

USA2216 ST

USA4216 ST

USA2216 ST

USA4216 ST

USA2216 ST USA2219 ST USA2229 ST USA2229 ST USA2229 ST USA2229 ST USA2229 ST

USA4216 ST USA4219 ST USA4229 ST USA4229 ST USA4229 ST USA4229 ST USA4229 ST

USA2216 ST USA2216 ST USA2216 ST USA2216 ST USA2219 ST USA2216 ST USA2219 ST

USA4216 ST USA4216 ST USA4216 ST USA4216 ST USA4219 ST USA4216 ST USA4219 ST

USA2435 USA2441

USA4435

USA2441 USA2441

USA4435 USA4435

USA2228 ST

USA4228 ST

USA2229 USA3210 USA2229 USA2229 USA3210 USA3210

USA4229

USA2433

USA4412

USA2229 ST

USA4229 ST

USA4229 USA4229

USA2433

USA4412

USA2229 ST USA2229 ST

USA4229 ST USA4229 ST

USA2229 USA2229 USA3210

USA4229 USA4229

USA2435 USA2437 USA2437 USA2437 USA2437 USA2439 USA2439

USA2229 ST USA2229 ST

USA4229 ST USA4229 ST

USA2228 ST

USA4228 ST

USA2439

USA2228 ST

USA4228 ST

USA2228 ST

USA4228 ST

light truck, SUV & 4WD

Zig-Zag WB Tire 76.007.0027x8.5 27x9.5 28x8.5 29x9.5 185/75 185195/75 205/70 205/75 215/70 215/75 225/60 225/70 225235/70 245/70 255/60 265/60 275/60 USAR7878927x8.5 6.777.17.58.2591011121427x9.5 27x10.5 28x8.5 29x9.5 29x10.5 29x11.5 29x12.5 30x7.5 30x9.5 30x10.5 31x9.5 31x10.5 31x11.5 31x12.5 31x13.5 31x15.5 32x9.5 32x11.5 32x12.5 33x9.5 33x10.5

USA3227 USA3227

USA3210 USA2228 USA3210

USA4228

USA2228

USA4228

USA2228

USA4228

USA3227 USA3227 USA3227 USA3227 USA3229 USA3237 USA3227 USA3227 USA3229 USA3227 USA3229

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

35

light truck, SUV & 4WD 36

Zig-Zag WB Tire 33x12.5 33x13.5 33x14 33x14.5 34x9.5 35x10.5 35x12.5 35x13.5 35x14 35x14.5 35x15 35x15.5 36x12.5 36x13.5 36x14 36x14.5 36x15.5 36.5x14 37x12.5 37x14.5 38x12.5 38x14.5 38x15 38.5x16 40x17 42x15 44x18.5 CR78GR78HR78LR78NR78QR78195/65 195/75 195/80 195205/75 215/70 215/75 215/80 215225/70 225/75 225/80 225235/70 235/75 235245/60 245/70 245/75 245/85 255/60 255/65 255/70 255/75 255/80

Rim Singles 15 USAZZ3229 15 USAZZ3229 15 USAZZ3229 15 USAZZ3231 15 USAZZ3227 15 USAZZ3231 15 USAZZ3235 15 USAZZ3235 15 USAZZ3235 15 15 15 USAZZ3237 15 USAZZ3235 15 USAZZ3235 15 15 15 15 15 USAZZ3235 15 15 15 15 15 15 USAZZ3269 15 USAZZ3269 15 USAZZ3269 15 15 15 15 15 15 USAZZ3235 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15

Ladder Singles

Duals

USA2226

USA4226

USA2226 USA2226 USA2226 USA2226

USA4226 USA4226 USA4226 USA4226

USA2226 USA2226

USA4226 USA4226

USA2209 USA2216 USA2216 USA2219 USA2221

Ladder WB

Ladder Mud Service

Ladder Studded

Singles USA3229 USA3229 USA3229 USA3231 USA3227 USA3231 USA3235 USA3235 USA3235 USA3251 USA3251 USA3237 USA3235 USA3235 USA3251 USA3251 USA3251 USA3255 USA3235 USA3251 USA3259 USA3259 USA3259 USA3267 USA3269 USA3269 USA3269

Singles

Singles

USA4209 USA4216 USA4216 USA4219 USA4221

Duals

USA2441 USA2441

USA4435 USA4435

USA2441 USA2441

USA4435 USA4435

USA2445 USA2445

USA4437 USA4437

USA2445 USA2445

USA4437 USA4437

USA2445

USA4437

USA2433 USA2435 USA2437

USA4412

USA2433 USA2433 USA2433 USA2433 USA2433 USA2433 USA2435 USA2433 USA2433 USA2435

USA4412 USA4412 USA4412 USA4412 USA4412 USA4412

Duals

USA2216 ST USA2216 ST USA2219 ST USA2221 ST

USA4216 ST USA4216 ST USA4219 ST USA4221 ST

USA2216 ST USA2216 ST USA2216 ST USA2216 ST USA2216 ST USA2216 ST USA2216 ST USA2216 ST USA2219 ST USA2219 ST USA2216 ST USA2219 ST USA2219 ST USA2228 ST USA2228 ST USA2229 ST USA2229 ST USA2228 ST

USA4216 ST USA4216 ST USA4216 ST USA4216 ST USA4216 ST USA4216 ST USA4216 ST USA4216 ST USA4219 ST USA4219 ST USA4216 ST USA4219 ST USA4219 ST USA4228 ST USA4229 ST USA4229 ST USA4229 ST USA4228 ST

USA3235 USA2201 USA2209 USA2209 USA2209 USA2209 USA2209 USA2216 USA2216 USA2216 USA2216 USA2216 USA2216 USA2216 USA2216 USA2219 USA2219 USA2216 USA2219 USA2219 USA2228 USA2229 USA2229 USA2229 USA2228 USA3210

USA4209

USA4216 USA4216 USA4216 USA4216 USA4216 USA4216 USA4216 USA4216 USA4219 USA4219 USA4216 USA4219 USA4219 USA4228 USA4229 USA4229 USA4229 USA4228

USA2435 USA2435 USA2437 USA2435 USA2435 USA2437 USA2441 USA2435 USA2435 USA2437 USA2439 USA2439

USA4412 USA4412

USA4435

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

Rim Singles 15 USAZZ3227 15 USAZZ3227 15 15 15 15 USAZZ3227 15 15 USAZZ3227 15 USAZZ3227 15 15 15 USAZZ3229 15 15 15 USAZZ3231 15 USAZZ3229 15 USAZZ3229 15 USAZZ3229 15.5 16 16 16 16 16 16 16 16 USAZZ3229 16 USAZZ3229 16 16 16 16 USAZZ3227 16 16 USAZZ3227 16 USAZZ3231 16 USAZZ3231 16 USAZZ3227 16 USAZZ3231 16 USAZZ3235 16 USAZZ3235 16 USAZZ3235 16 16 16 16 16 16 16 16 16 16 16 16 16 16 USAZZ3231 16 16 16

Ladder Singles USA2228 USA2228 USA2229 USA2229 USA2221 USA2221 USA2229 USA3210 USA3210 USA2228 USA2228

Duals USA4228 USA4228 USA4229 USA4229 USA4221 USA4221 USA4229

USA2229 USA2229 USA2226

USA4229 USA4229 USA4226

USA2209 USA2206 USA2216 USA2219 USA2221 USA2228 USA2237 USA2237

USA4209

Ladder WB

Ladder Mud Service

Ladder Studded

Singles USA3227 USA3227

Singles USA2439 USA2439

Singles USA2228 ST USA2228 ST USA2229 ST USA2229 ST USA2221 ST USA2221 ST USA2229 ST

Duals USA4228 ST USA4228 ST USA4229 ST USA4229 ST USA4221 ST USA4221 ST USA4229 ST

USA2228 ST USA2228 ST

USA4228 ST USA4228 ST

USA2229 ST USA2229 ST

USA4229 ST USA4229 ST

USA2435 USA2435 USA2437

USA2216 ST USA2219 ST USA2221 ST USA2228 ST

USA4216 ST USA4219 ST USA4221 ST USA4228 ST

USA2435 USA2437 USA2437 USA2439

USA2216 ST USA2229 ST

USA4216 ST USA4229 ST

USA2219 ST USA2216 ST USA2216 ST USA2219 ST USA2216 ST USA2229 ST USA2216 ST USA2216 ST USA2216 ST USA2216 ST USA2219 ST USA2219 ST

USA4219 ST USA4216 ST USA4216 ST USA4219 ST USA4216 ST USA4229 ST USA4216 ST USA4216 ST USA4216 ST USA4216 ST USA4219 ST USA4219 ST

USA2216 ST USA2219 ST

USA4216 ST USA4219 ST

USA3227 USA3227 USA3227

USA4228 USA4228

Duals

USA2439 USA2439 USA2437 USA2439 USA2439 USA2439 USA2439

USA3229

USA3231 USA3229 USA3229 USA3229

USA4216 USA4219 USA4221 USA4228 USA4237 USA4237

light truck, SUV & 4WD

Zig-Zag WB Tire 255/85 255265/60 265/65 265/70 265/75 275/60 275/65 275/70 275/75 285/70 285/75 295/50 305/50 305/75 315/70 325/60 355/65 185/70 66.577.58.258.759111229x9.5 30x9.5 31x10.5 31x11.5 31x16 32x11.5 33x12.5 33x13.5 34x9 35x12.5 35x13.5 36x13.5 36.5x14 38x15 185195/75 195/85 195205/75 205/80 205215/65 215/70 215/75 215/80 215/85 215225/50 225/70 225/75

USA3229 USA3229 USA2216 USA2229 USA3210

USA4216 USA4229

USA2226

USA4226

USA2219 USA2216 USA2216 USA2219 USA2216 USA2229 USA2216 USA2216 USA2216 USA2216 USA2219 USA2219 USA2226 USA2209 USA2216 USA2219

USA4219 USA4216 USA4216 USA4219 USA4216 USA4229 USA4216 USA4216 USA4216 USA4216 USA4219 USA4219

USA3227 USA3259 USA3227 USA3231 USA3231 USA3227 USA3231 USA3235 USA3235 USA3235 USA3265

USA3231 USA4209 USA4216 USA4219

USA2441

USA4435

USA2441 USA2441 USA2445 USA2445

USA4435 USA4435 USA4437 USA4437

USA2433 USA2435

USA4412

USA2433 USA2433 USA2435 USA2435 USA2435 USA2435 USA2435 USA2435 USA2441

USA4412 USA4412

USA2435 USA2435

USA4435

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

37

light truck, SUV & 4WD 38

Zig-Zag WB Tire 225/80 225/85 235/60 235/65 235/70 235/75 235/80 235/85 245/60 245/65 245/70 245/75 245/85 245255/60 255/65 255/70 255/75 255/85 265/50 265/55 265/60 265/65 265/70 265/75 265/85 275/55 275/60 275/65 275/70 275/85 275/75 285/60 285/65 285/70 285/75 295/65 295/75 305/70 305/85 315/70 315/75 325/80 325/85 365/65 HR78LR7888.58.759.510121430x9.5 31x10.5 31x11.5 31x13.5

Rim Singles 16 16 16 16 16 16 16 16 USAZZ3227 16 16 16 16 16 16 USAZZ3227 16 16 16 USAZZ3227 16 16 16 16 16 16 16 USAZZ3227 16 USAZZ3227 16 16 16 USAZZ3227 16 16 USAZZ3227 16 USAZZ3231 16 USAZZ3227 16 16 16 USAZZ3229 16 USAZZ3229 16 USAZZ3229 16 USAZZ3229 16 USAZZ3231 16 16 USAZZ3231 16 USAZZ3231 16 USAZZ3235 16 USAZZ3235 16 USAZZ3235 16 16 16.5 16.5 16.5 16.5 USAZZ3227 16.5 USAZZ3227 16.5 USAZZ3229 16.5 USAZZ3235 16.5 USAZZ3227 16.5 USAZZ3227 16.5 USAZZ3227 16.5 USAZZ3229

Ladder Singles USA2219 USA2228 USA2216 USA2229 USA2229 USA2219 USA2219 USA2221 USA2229 USA2229 USA2229 USA2221 USA2228

Duals USA4219 USA4228 USA4216 USA4229 USA4229 USA4219 USA4219 USA4221 USA4229 USA4229 USA4229 USA4221 USA4228

USA2229 USA2229 USA3210 USA2228 USA2228 USA2229 USA2229 USA2229 USA2229 USA2228 USA2228 USA2228 USA2229 USA3210 USA3210 USA2228

USA4229 USA4229

USA2228 USA3210 USA2228 USA2228

USA4228

Ladder WB

Ladder Mud Service

Ladder Studded

Singles

Singles USA2435 USA2437 USA2433 USA2435 USA2435 USA2435 USA2437 USA2437 USA2435 USA2435 USA2435 USA2437 USA2437

Singles USA2219 ST USA2228 ST USA2216 ST USA2229 ST USA2229 ST USA2219 ST USA2219 ST USA2221 ST USA2229 ST USA2229 ST USA2229 ST USA2221 ST USA2228 ST

Duals USA4219 ST USA4228 ST USA4216 ST USA4229 ST USA4229 ST USA4219 ST USA4219 ST USA4221 ST USA4229 ST USA4229 ST USA4229 ST USA4221 ST USA4228 ST

USA2229 ST USA2229 ST

USA4229 ST USA4229 ST

USA2228 ST USA2228 ST USA2229 ST USA2229 ST USA2229 ST USA2229 ST USA2228 ST USA2228 ST USA2228 ST USA2229 ST

USA4228 ST USA4228 ST USA4229 ST USA4229 ST USA4229 ST USA4229 ST USA4228 ST USA4228 ST USA4228 ST USA4229 ST

USA2228 ST

USA4228 ST

USA2228 ST

USA4228 ST

USA2228 ST USA2228 ST

USA4228 ST USA4228 ST

USA2226 ST

USA4226 ST

USA2226 ST USA2226 ST

USA4226 ST USA4226 ST

USA2219 ST USA2221 ST USA2216 ST USA2216 ST USA2219 ST USA2221 ST

USA4219 ST USA4221 ST USA4216 ST USA4216 ST USA4219 ST USA4221 ST

USA3227

Duals

USA4412

USA3227

USA3227 USA4228 USA4228 USA4229 USA4229 USA4229 USA4229 USA4228 USA4228 USA4228 USA4229

USA4228

USA4228 USA4228

USA2226

USA4226

USA2226 USA2226

USA4226 USA4226

USA2219 USA2221 USA2216 USA2216 USA2219 USA2221 USA3210

USA3210

USA4219 USA4221 USA4216 USA4216 USA4219 USA4221

USA2435 USA2437 USA2437 USA2437

USA3227 USA3227

USA2441 USA2439

USA3227

USA2437 USA2439 USA2439

USA3227 USA3231 USA3227

USA4435

USA2439 USA2439 USA3229 USA3229 USA3229 USA3229 USA3231 USA3259 USA3231 USA3231 USA3235 USA3235 USA3235

USA2439 USA2441 USA2445 USA2441 USA2441

USA4435 USA4437 USA4435 USA4435

USA2445

USA4437

USA2437 USA2433 USA2433 USA3227 USA3227 USA3229 USA3235 USA3227 USA3227 USA3227 USA3229

USA2437

USA4412 USA4412

USA2437 USA2439 USA2439

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

Rim Singles 16.5 USAZZ3227 16.5 USAZZ3229 16.5 USAZZ3229 16.5 USAZZ3229 16.5 USAZZ3229 16.5 USAZZ3229 16.5 USAZZ3231 16.5 USAZZ3231 16.5 USAZZ3235 16.5 USAZZ3235 16.5 USAZZ3235 16.5 16.5 USAZZ3235 16.5 16.5 USAZZ3235 16.5 USAZZ3235 16.5 16.5 16.5 16.5 USAZZ3269 17 17 17 17 17 17 17 17 17 17 17 17 USAZZ3227 17 17 17 17 17 USAZZ3227 17 17 USAZZ3229 17 17 17 USAZZ3227 17 USAZZ3227 17 USAZZ3227 17 USAZZ3227 17 17 17 USAZZ3227 17 USAZZ3227 17 USAZZ3227 17 USAZZ3227 17 USAZZ3229 17 USAZZ3231 17 17 USAZZ3227 17 USAZZ3227 17 USAZZ3227 17 USAZZ3229

Ladder Singles

USA2226 USA2226 USA2226 USA2226 USA2226

Duals

USA4226 USA4226 USA4226 USA4226 USA4226

USA2226 USA2226

USA4226 USA4226

USA2221 USA2214 USA2237 USA2221 USA2219 USA2229 USA2219 USA2229 USA2219 USA2211 USA2219 USA3210 USA2228 USA2228 USA2219 USA2229 USA3210 USA3210 USA2237 USA2229 USA2229 USA2229 USA3210 USA2228 USA2228 USA2228 USA2237 USA2228 USA3210 USA3210 USA2228 USA2228 USA2226 USA2229 USA2229 USA2228 USA2228 USA2228

USA4221 USA4214 USA4237

Ladder WB

Ladder Mud Service

Ladder Studded

Singles USA3227 USA3229 USA3229 USA3229 USA3229 USA3229 USA3231 USA3231 USA3235 USA3235 USA3235 USA3251 USA3235 USA3251 USA3235 USA3235 USA3249 USA3251 USA3251 USA3269

Singles

Singles

USA3227 USA4228 USA4228 H4219 USA4229 USA3227

USA4228 USA4228 USA4228 USA4237 USA4228

USA4228 USA4228 USA4226 USA4229 USA4229 USA4228 USA4228 USA4228

USA2445 USA2445 USA2445 USA2445

USA4437 USA4437 USA4437 USA4437

USA2445

USA4437

USA2437

USA4229 USA4219 USA4229 USA4219 USA4211 USA4219

USA4237 USA4229 USA4229 USA4229

Duals

USA2435 USA2437 USA2433 USA2435 USA2435 USA2437 USA2439 USA2439 USA2439 USA2435 USA2437 USA2437 USA2439

USA4412

Duals

USA2221 ST

USA4221 ST

USA2221 ST USA2219 ST USA2229 ST USA2219 ST USA2229 ST USA2219 ST

USA4221 ST USA4219 ST USA4229 ST USA4219 ST USA4229 ST USA4219 ST

USA2219 ST

USA4219 ST

USA2228 ST USA2228 ST USA2219 ST USA2229 ST

USA4228 ST USA4228 ST USA4219 ST USA4229 ST

USA2229 ST USA2229 ST USA2229 ST

USA4229 ST USA4229 ST USA4229 ST

USA2228 ST USA2228 ST USA2228 ST

USA4228 ST USA4228 ST USA4228 ST

USA2228 ST

USA4228 ST

USA2228 ST USA2228 ST

USA4228 ST USA4228 ST

USA2229 ST USA2229 ST USA2228 ST USA2228 ST USA2228 ST

USA4229 ST USA4229 ST USA4228 ST USA4228 ST USA4228 ST

light truck, SUV & 4WD

Zig-Zag WB Tire 32x11.5 32x12.5 33x10.5 33x12.5 33x14.5 33x15 35x12.5 35x14 36x12.5 36x13.5 36x14 36x14.5 37x12.5 37x14.5 38x15.5 38.5x15 38.5x16 39.5x15 40x17 44x18.5 77.58.25215/80 215/70 225/70 225/75 235/55 235/60 235/65 235/70 235/75 235/80 235/85 245/60 245/65 245/70 245/75 245/85 255/50 255/55 255/60 255/65 255/70 255/75 255/80 255/85 265/55 265/60 265/65 265/70 265/75 265/85 275/50 275/55 275/60 275/65 275/70

USA3229

USA3227 USA3227 USA3227 USA3227

USA2435 USA2435 USA2435 USA2437 USA2439 USA2439

USA3227 USA3227 USA3227 USA3227 USA3229 USA3231

USA2439 USA2439 USA2439 USA2441 USA2441

USA3227 USA3227 USA3227 USA3229

USA2439 USA2439 USA2439

USA4441 USA4441

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

39

light truck, SUV & 4WD 40

Zig-Zag WB Tire 275/80 285/60 285/65 285/70 285/75 295/70 305/60 305/65 305/70 315/70 325/70 325/75 345/55 31x10.5 33x12.5 35x12.5 36x13.5 37x12.5 77.588.59101114205/60 205/65 205/70 205/75 215/70 215/75 225/55 225/70 225/75 235/75 245/70 245/75 255/40 255/55 255/65 265/60 275/70 285/60 295/75 6.0077.591010.515.5/60 215/75 235/60 235/80 245/55 245/60 255/55

Rim Singles 17 17 USAZZ3231 17 USAZZ3231 17 USAZZ3229 17 USAZZ3229 17 USAZZ3229 17 USAZZ3229 17 USAZZ3231 17 USAZZ3231 17 USAZZ3231 17 USAZZ3235 17 USAZZ3235 17 USAZZ3231 17 USAZZ3227 17 USAZZ3229 17 USAZZ3235 17 USAZZ3235 17 USAZZ3235 17.5 17.5 17.5 USAZZ3249 17.5 17.5 USAZZ3227 17.5 USAZZ3227 17.5 17.5 USAZZ3235 17.5 17.5 17.5 17.5 17.5 17.5 17.5 17.5 17.5 17.5 USAZZ3227 17.5 USAZZ3229 17.5 USAZZ3229 17.5 17.5 17.5 17.5 17.5 USAZZ3229 17.5 17.5 USAZZ3231 18 18 18 18 18 18 18 USAZZ3235 18 18 18 18 18 18

Ladder Singles USA2228 USA2228 USA2228

Duals USA4228 USA4228 USA4228

USA2226 USA2226

USA4226 USA4226

USA3210

USA2211 USA2216 USA2219 USA2219 USA3210 USA2228 USA2239

USA4211 USA4216 USA4219 USA4219

USA2209 USA2216 USA2216 USA2219 USA2219 USA2219 USA2216 USA2221 USA2221 USA3210 USA2228 USA2228 USA2216 USA2229 USA2229 USA3210

USA4209 USA4216 USA4216 USA4219 USA4219 USA4219 USA4216 USA4221 USA4221

USA2228 USA2226 USA2219 USA2214 USA2233 USA2237 USA2237 USA2229

USA4228

USA4228 USA4239

Ladder WB

Ladder Mud Service

Ladder Studded

Singles

Singles

Singles USA2228 ST USA2228 ST USA2228 ST

Duals USA4228 ST USA4228 ST USA4228 ST

USA2216 ST USA2219 ST USA2219 ST

USA4216 ST USA4216 ST USA4216 ST

USA2228 ST

USA4228 ST

USA2216 ST USA2216 ST USA2219 ST USA2219 ST USA2219 ST USA2216 ST USA2221 ST USA2221 ST

USA4216 ST USA4216 ST USA4219 ST USA4219 ST USA4219 ST USA4216 ST USA4221 ST USA4221 ST

USA2228 ST USA2228 ST USA2216 ST USA2229 ST USA2229 ST

USA4228 ST USA4228 ST USA4216 ST USA4229 ST USA4229 ST

USA2228 ST

USA4228 ST

USA2219 ST

USA4219 ST

USA2229 ST

USA4229 ST

USA2219 ST USA2229 ST USA2228 ST USA2229 ST

USA4219 ST USA4229 ST USA4228 ST USA4229 ST

USA2229 ST

USA4229 ST

USA3231 USA3231 USA3229 USA3229 USA3229 USA3229 USA3231 USA3231 USA3231 USA3235 USA3235 USA3231 USA3227 USA3229 USA3235 USA3235 USA3235

Duals

USA2439

USA2441 USA2441 USA2441

USA4435 USA4435 USA4435

USA2437 USA2441

USA4435

USA2445

USA4437

USA2433

USA4412

USA2441 USA2437 USA2439

USA4435

USA2433 USA2433 USA2435 USA2433 USA2435 USA2437 USA2433 USA2437 USA2437 USA2437 USA2439 USA2439 USA2433 USA2435 USA2437 USA2439

USA4412 USA4412

USA3249 USA3227 USA3227 USA3235

USA4228 USA4228 USA4216 USA4229 USA4229

USA3227 USA3229 USA3229

USA4412

USA4412

USA4412

USA3229 USA3231 USA4219 USA4214 USA4233 USA4237 USA4237 USA4229

USA2435

USA3235 USA2219 USA2229 USA2228 USA2229 USA3210 USA2229

USA4219 USA4229 USA4228 USA4229 USA4229

USA2437 USA2435 USA2439 USA2435 USA2437 USA2437

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

Rim Singles 18 USAZZ3227 18 18 USAZZ3227 18 18 USAZZ3227 18 USAZZ3227 18 18 USAZZ3229 18 USAZZ3229 18 USAZZ3227 18 18 USAZZ3229 18 USAZZ3229 18 USAZZ3231 18 USAZZ3231 18 18 USAZZ3229 18 USAZZ3229 18 USAZZ3231 18 USAZZ3231 18 USAZZ3227 18 USAZZ3231 18 USAZZ3231 18 USAZZ3231 18 USAZZ3231 18 USAZZ3235 18 USAZZ3231 18 USAZZ3231 18 USAZZ3231 18 USAZZ3235 18 USAZZ3231 18 USAZZ3231 18 USAZZ3235 18 USAZZ3251 18.5 19 19 19 19 19 19 19 USAZZ3227 19 USAZZ3227 19 USAZZ3227 19 19 19 19 USAZZ3229 19 USAZZ3227 19 19 USAZZ3229 20 20 20 20 20 USAZZ3227 20 USAZZ3227 20

Ladder Singles USA3210 USA2229 USA2228 USA2229 USA2228 USA2228

Duals USA4229 USA4228 USA4229 USA4228 USA4228

Ladder WB

Ladder Mud Service

Ladder Studded

Singles USA3227

Singles

USA3227

Singles USA2437 USA2437 USA2439

USA3227 USA3227

USA2439 USA2439

USA3229 USA3229 USA3227 USA2228 USA2228

USA4228 USA4228

USA2226 USA2228 USA2228 USA2228

USA4226 USA4228 USA4228 USA4228

USA2226

USA4226

USA2226

USA2228 USA2216 USA2221 USA2216 USA2219 USA2229 USA2229 USA3210 USA2228 USA2228 USA2229 USA2229 USA2228 USA3210 USA2228

USA4226

USA3229 USA3229 USA3231 USA3231 USA3227 USA3231 USA3231 USA3231 USA3231 USA3235 USA3231 USA3231 USA3231 USA3235 USA3231 USA3231 USA3235 USA3251

USA4229 ST USA4228 ST USA4229 ST

USA2228 ST USA2228 ST

USA4228 ST USA4228 ST

USA2228 ST USA2228 ST

USA4228 ST USA4228 ST

USA2228 ST USA2228 ST USA2228 ST

USA4228 ST USA4228 ST USA4228 ST

USA2228 ST USA2216 ST USA2221 ST USA2216 ST USA2219 ST USA2229 ST USA2229 ST

USA4228 ST USA4216 ST USA4221 ST USA4216 ST USA4219 ST USA4229 ST USA4229 ST

USA2439

USA2228 ST USA2228 ST USA2229 ST USA2229 ST USA2228 ST

USA4228 ST USA4228 ST USA4229 ST USA4229 ST USA4228 ST

USA2439

USA2228 ST

USA4228 ST

USA2435 USA2435

USA2229 ST USA2229 ST USA2229 ST

USA4229 ST USA4229 ST USA4229 ST

USA2439

USA2228 ST

USA4228 ST

USA2439 USA2439

USA2439 USA2439

USA2441

USA4435

USA2441 USA2441

USA4435 USA4435

USA2441 USA2441 USA2441 USA2441 USA2441 USA2441 USA2441

USA4435 USA4435 USA4435 USA4435 USA4435 USA4435 USA4435

USA2439

USA3227 USA3227 USA3227

Duals

USA2229 ST USA2228 ST USA2229 ST

USA3229 USA3229 USA3231 USA3231

USA4228 USA4216 USA4221 USA4216 USA4219 USA4229 USA4229 USA4228 USA4228 USA4229 USA4229 USA4228

Duals

USA2435 USA2435 USA2435 USA2437 USA2435 USA2437 USA2439 USA2439

light truck, SUV & 4WD

Zig-Zag WB Tire 255/60 255/65 255/70 265/50 265/60 265/65 265/70 265/75 270/75 275/55 275/60 275/65 275/70 275/75 285/50 285/55 285/60 285/65 285/70 285/75 295/45 295/65 295/70 305/60 305/65 305/70 315/60 325/50 325/60 325/65 33x12.5 35x12.5 37x12.5 37x13.5 255/65 225/55 225/60 235/50 235/55 245/55 255/50 255/55 255/60 255/65 265/50 275/45 275/55 275/65 285/45 285/55 285/60 225/50 235/55 245/45 255/40 255/50 255/55 255/60

USA3229 USA3227 USA4228 USA3229

USA2229 USA2229 USA2229 USA2229 USA3210 USA2228 USA2228

USA4229 USA4229 USA4229 USA4228 USA4228

USA3227 USA3227

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

41

light truck, SUV & 4WD 42

Zig-Zag WB Tire 265/40 265/45 265/50 265/60 275/45 275/50 275/55 275/60 275/65 285/50 285/60 285/65 295/40 295/45 295/50 305/45 305/50 305/55 325/50 325/60 33x12.5 35x12.5 35x13.5 37x13.5 38x14.5 40x15.5 275/45 285/40 285/45 305/40 305/45 325/40 295/35 295/40 305/35 315/35

Rim Singles 20 20 20 USAZZ3227 20 USAZZ3229 20 USAZZ3227 20 20 USAZZ3229 20 USAZZ3231 20 USAZZ3231 20 USAZZ3229 20 USAZZ3231 20 USAZZ3231 20 20 20 USAZZ3229 20 USAZZ3229 20 USAZZ3229 20 USAZZ3231 20 USAZZ3231 20 USAZZ3235 20 USAZZ3231 20 USAZZ3231 20 USAZZ3235 20 20 20 22 USAZZ3229 22 USAZZ3227 22 USAZZ3231 22 USAZZ3231 22 USAZZ3231 22 USAZZ3231 24 USAZZ3231 24 USAZZ3231 24 USAZZ3231 24

Ladder Singles USA2229 USA2229 USA3210 USA2228 USA3210 USA2228

Duals USA4229 USA4229 USA4228

Ladder WB

Ladder Mud Service

Ladder Studded

Singles

Singles

Singles USA2229 ST USA2229 ST

Duals USA4229 ST USA4229 ST

USA3227 USA3229 USA3227

USA4228

USA2226

USA4226

USA2228

USA4228

USA2226 USA2228 USA2228 USA2228

USA4226 USA4228 USA4228

USA2228 USA2226 USA2238 USA2226 USA2226

USA4228 USA4226 USA4238 USA4226 USA4226

USA2226 USA2226 USA2226

USA4226 USA4226 USA4226

USA3229 USA3231 USA3231 USA3229 USA3231 USA3231

USA3229 USA3229 USA3229 USA3231 USA3231 USA3235 USA3231 USA3231 USA3235 USA3251 USA3265 USA3255 USA3229 USA3227 USA3231 USA3231 USA3231 USA3231 USA3231 USA3231 USA3231 USA3231

Duals

USA2439 USA2228 ST

USA4228 ST

USA2439 USA2439

USA2228 ST

USA4228 ST

USA2439

USA2228 ST

USA4228 ST

USA2439 USA2439

USA2228 ST USA2228 ST

USA4228 ST USA4228 ST

USA2228 ST

USA4228 ST

USA2439

USA2441

USA4435

USA2441 USA2441 USA2445

USA4435 USA4435 USA4437

USA2439 USA2439

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

Rim Singles 19.5 19.5 19.5 19.5 20 20 20 20 USA 91 P 20 20 USA 94 P 20 USA 97 P 20 USA 01 P 20 USA 93 7 P 20 USA 95 P 20 20 20 20 USA 02 P 20 20 20 20 USA 95 P 20 USA 02 P 20 20 USA 02 P 20 22 USA 94 P 22 22 22.5 22.5 22.5 USA 91 P 22.5 USA 94 P 22.5 USA 97 P 22.5 22.5 22.5 USA 01 P 22.5 22.5 USA 91 P 22.5 22.5 USA 93 7 P 22.5 22.5 22.5 USA 93 7 P 22.5 USA 94 P 22.5 USA 93 7 P 22.5 22.5 USA 93 7 P 22.5 USA 94 P 22.5 USA 97 P 22.5 22.5 USA 02 P 22.5 22.5 22.5 USA 160 7 P 24 24 24

Zig-Zag

CL

Singles

Singles

USAZZ2255 USAZZ2255 USAZZ2255

ASV Duals

Tite-N-Lite

CL 91 S

CL 291 S

Singles A 82 SV A 82 SV A 84 SV A 85 SV A 82 SV A 85 SV A 88 SV A 91 SV

CL 94 S CL 97 S CL 01 S CL 94 S CL 95 S

CL 294 S CL 297 S CL 201 S CL 294 S CL 295 S

A 94 SV A 97 SV A 01 SV A 94 SV A 95 SV

CL 01 S

CL 201 S

A 01 SV A 08 SV A 08 SV A 05 SV A 10 SV A 84 SV A 95 SV A 02 SV A 05 SV A 01 SV A 07 SV

USAZZ2255

CL 02 S

USAZZ2255

CL 95 S

CL 295 S

CL 01 S

CL 201 S

Duals A 282 SV A 282 SV A 284 SV A 285 SV

USAZZ2247 USAZZ2255 USAZZ2255 USAZZ2255

CL 203 S

CL 91 S CL 94 S CL 97 S

A 291 SV

A 297 SV A 201 SV

TNL 2245 TNL 2245 TNL 2249

TNL 4245 TNL 4245 TNL 4249

TNL 2249

TNL 4249

TNL 2245 TNL 2249

TNL 4245 TNL 4249

TNL 2245

TNL 4245

TNL 2249

TNL 4249

A 201 SV

A 203 SV A 287 SV

CL 294 S CL 297 S

A 03 SV A 85 SV A 88 SV A 91 SV A 94 SV A 97 SV

CL 91 S

CL 291 S

A 01 SV A 88 SV A 90 SV

A 201 SV A 288 SV A 290 SV

CL 94 S

CL 294 S

A 94 SV

A 294 SV

CL 91 S CL 94 S CL 94 S

CL 291 S CL 294 S CL 294 S

A 94 SV A 94 SV A 94 SV

A 294 SV A 294 SV

CL 97 S CL 97 S

CL 297 S CL 297 S

A 94 SV A 97 SV A 97 SV A 08 SV A 01 SV A 155 8 SV

A 294 SV A 297 SV A 297 SV

CL 01 S

Duals

A 285 SV

USAZZ2249 USAZZ2255 CL 03 S

Singles

A 294 SV A 297 SV

heavy truck & trailer (pattern)

USA P Tire 8225/70 245/70 265/70 6.57.58.25910/90 10111212/80 12.513/80 14/80 1414.514.75/80 16275/55 335/80 365/80 365/85 370/75 395/85 1011128910111212.512.7513255/70 275/70 275/75 275/80 275/85 295/70 295/75 295/80 305/70 305/85 315/70 315/75 315/80 375/90 385/65 425/65 445/50 445/65 121314-

USAZZ2247 USAZZ2249 USAZZ2247 USAZZ2247 USAZZ2247 USAZZ2255

USAZZ2255

USAZZ3269 A 160 8 SV A 06 SV A 08 SV A 10 SV

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

43

heavy truck & trailer (pattern)

USA P Tire 315/75 320/75 111212.5275/80 285/70 285/75 285/80 305/75 315/75

Rim Singles 24 24 24.5 USA 94 P 24.5 24.5 24.5 USA 94 P 24.5 24.5 USA 94 P 24.5 USA 97 P 24.5 24.5

Zig-Zag

CL

Singles USAZZ2255 USAZZ2255 USAZZ2249 USAZZ2255 USAZZ2255 USAZZ2247 USAZZ2247 USAZZ2249 USAZZ2249 USAZZ2255 USAZZ2255

Singles

ASV

CL 97 S

Duals

CL 297 S

Duals

A 10 SV A 97 SV

Singles

Duals

TNL 2249

TNL 4249

TNL 2245

TNL 4245

TNL 2245 TNL 2249

TNL 4245 TNL 4249

NEW Zig Zag Pa ern Trac on Chain Proudly Made in the USA

Reduce & Increase Starwave profile reduces weight and increases the hardened surface by 7% Be er Wear and Longer Life Increases lifespan to reduce down me and cost per mile More Grip!

Improves trac on with addi onal edges providing more grip to dig into the ground

44

Tite-N-Lite

Singles

Unique 8 Sided Design Increases stud surface area by 23% Superior Penetra ng Trac on Gets through the most extreme condi ons Advanced Engineering For the most aggressive off-road applica ons Longer Las ng!

Resul ng in less down me, less cost per mile, fewer repairs, and lower opera ng costs

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

Rim Singles 19.5 USA2214 19.5 19.5 19.5 19.5 19.5 USA2221 19.5 USA2228 19.5 USA2228 19.5 USA2228 19.5 USA2237 19.5 USA2237 19.5 USA2237 19.5 USA2237 19.5 USA2238 19.5 USA2239 19.5 USA2239 19.5 20 USA2233 20 USA2233 20 USA2237 20 USA2239 20 USA2239 20 USA2241 20 USA2245 20 USA2245 20 USA2241 20 USA2251 20 USA2251 20 USA2255 20 USA2251 20 USA2255 20 USA2255 20 USA2257 20 USA2257 20 USA2271 20 USA2255 20 USA2257 20 USA2271 20 20 20 20 20 20 USA2233 20 USA2228 20 USA2233 20 20 20 20 20 USA2255 20 20 USA2257 20 USA2271 20 20 USA2271 20 21 USA2271

Ladder WB Duals USA4214

USA4221 USA4228 USA4228 USA4228 USA4237 USA4237 USA4237 USA4237 USA4238 USA4239 USA4239

Singles

Duals

USA3265 USA3255 USA3257 USA3261 USA3227

Ladder Mud Service

Ladder Studded

Ladder Studded WB

Singles USA2439

Singles

Singles

Duals

USA2439 USA2439

USA3229

USA3231 USA3235 USA3257

USA4233 USA4233 USA4237 USA4239 USA4239 USA4241 USA4245 USA4245 USA4241 USA4251 USA4251 USA4255 USA4251 USA4255 USA4255 USA4257 USA4257

USA3267 USA3269 USA3273 USA3275 USA3277

USA2445 USA2441 USA2445 USA2437

USA4437 USA4435 USA4437

USA2441 USA2437 USA2441 USA2445 USA2448 USA2448

USA4435

USA2452 USA2452 USA2486 USA2448 USA2452 USA2486

USA4461 USA4461 USA4486 USA4448 USA4461 USA4486

USA4435 USA4437 USA4448 USA4448

USA2221 ST USA2228 ST USA2228 ST USA2228 ST USA2237 ST USA2237 ST USA2237 ST USA2237 ST USA2238 ST USA2239 ST USA2239 ST USA2233 ST USA2233 ST USA2237 ST USA2239 ST USA2239 ST USA2241 ST USA2245 ST USA2245 ST USA2241 ST USA2251 ST USA2251 ST USA2255 ST USA2251 ST USA2255 ST USA2255 ST USA2257 ST USA2257 ST USA2271 ST USA2255 ST USA2257 ST

Duals

USA3265 ST USA3255 ST USA3257 ST USA3261 ST USA4221 ST USA3227 ST USA4228 ST USA4228 ST USA4228 ST USA4237 ST USA4237 ST USA3229 ST USA4237 ST USA4237 ST USA4238 ST USA3231 ST USA4239 ST USA4239 ST USA3235 ST USA3257 ST USA4233 ST USA4233 ST USA4237 ST USA4239 ST USA4239 ST USA4241 ST USA4245 ST USA4245 ST USA4241 ST USA4251 ST USA4251 ST USA4255 ST USA4251 ST USA4255 ST USA4255 ST USA4257 ST USA4257 ST USA4271 ST USA4255 ST USA4257 ST

USA3277 USA3231 USA3235 USA3251 USA3255 USA2437

USA4255 USA4257 USA4271

USA3255 USA3271 USA3255 USA4271

USA3267 ST USA3269 ST USA3273 ST USA3275 ST USA3277 ST

USA3277 ST USA3231 ST USA3235 ST USA3251 ST USA3255 ST USA2233 ST USA4233 ST USA2228 ST USA4228 ST USA2233 ST USA4233 ST

USA4228 USA3231 USA3231 USA3231 USA3231 USA3255 USA3255 USA3261

Duals

heavy truck & trailer (ladder)

Ladder Tire 81516.51819.5225/70 225/75 245/70 245/75 255/70 265/70 265/75 275/70 285/70 285/75 305/70 445/65 6.577.588.25910/90 1010.51111.51212/80 12.513/80 1314/80 1414.514.75/80 15.5/80 1633x12.5 35x13.5 37x13.5 40x15.5 225/70 245/60 245/70 275/55 275/60 285/50 305/50 335/80 355/80 365/80 365/85 370/75 395/85 405/70 14-

USA2452 USA2452 USA2486

USA4461 USA4461 USA4486

USA2255 ST

USA2486

USA4486

USA2271 ST

USA2257 ST USA2271 ST

USA2271 ST

USA3231 ST USA3231 ST USA3231 ST USA3231 ST USA4255 ST USA3255 ST USA3255 ST USA4257 ST USA3261 ST USA4271 ST USA3255 ST USA4271 ST USA3271 ST USA3255 ST USA4271 ST

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

45

heavy truck & trailer (ladder) 46

Ladder Tire 24325/50 10111277.588.25910111212.512.75131516.51819225/70 235/75 235/80 245/70 245/75 245/80 255/70 255/75 255/80 265/65 265/75 275/70 275/75 275/80 275/85 285/60 285/70 285/75 295/60 295/70 295/75 295/80 305/60 305/70 305/80 305/85 315/60 315/70 315/75 315/80 365/70 365/80 375/90 385/65 425/55 425/65 445/50 445/55

Rim Singles 21 22 22 USA2249 22 USA2255 22 22.5 USA2233 22.5 USA2239 22.5 USA2237 22.5 USA2239 22.5 USA2239 22.5 USA2241 22.5 USA2247 22.5 USA2251 22.5 USA2255 22.5 USA2255 22.5 USA2255 22.5 22.5 22.5 22.5 22.5 USA2237 22.5 USA2237 22.5 USA2239 22.5 USA2239 22.5 USA2239 22.5 USA2239 22.5 USA2238 22.5 USA2239 22.5 USA2241 22.5 USA2237 22.5 USA2241 22.5 USA2241 22.5 USA2247 22.5 USA2245 22.5 USA2249 22.5 22.5 USA2247 22.5 USA2247 22.5 22.5 USA2247 22.5 USA2247 22.5 USA2251 22.5 22.5 USA2247 22.5 USA2251 22.5 USA2255 22.5 22.5 22.5 USA2251 22.5 USA2255 22.5 22.5 22.5 USA2273 22.5 22.5 22.5 22.5 22.5

Ladder WB Duals

Singles USA3261 USA3235

Duals

Ladder Mud Service

Ladder Studded

Singles

Singles

Duals

USA2233 ST USA2239 ST USA2237 ST USA2239 ST USA2239 ST USA2241 ST USA2247 ST USA2251 ST USA2255 ST USA2255 ST USA2255 ST

USA4233 ST USA4239 ST USA4237 ST USA4239 ST USA4239 ST USA4241 ST USA4247 ST USA4251 ST USA4255 ST USA4255 ST USA4255 ST

USA4249 USA4255

USA3277 USA3277

USA2452 USA2486

USA4233 USA4239 USA4237 USA4239 USA4239 USA4241 USA4247 USA4251 USA4255 USA4255 USA4255

USA3259

USA2439

Duals

USA4461 USA4486

USA3267 USA3269 USA3273 USA3275 USA3277 USA3277

USA2441 USA2445 USA2448 USA2452 USA2452

USA4435 USA4437 USA4448 USA4461 USA4461

Ladder Studded WB

Singles Duals USA3261 ST USA3235 ST USA2249 ST USA4229 ST USA3277 ST USA2255 ST USA4255 ST USA3277 ST USA3259 ST USA3267 ST USA3269 ST USA3273 ST USA3275 ST USA3277 ST USA3277 ST

USA3255

USA3255 ST

USA3261 USA3261

USA3261 ST USA3261 ST

USA4237 USA4237 USA4239 USA4239 USA4239 USA4239 USA4238 USA4239 USA4241 USA4237 USA4241 USA4241 USA4247 USA4245 USA4249

USA2441 USA2441 USA2441 USA2441 USA2441 USA2441 USA2441 USA2445 USA2445

USA4435 USA4435 USA4435 USA4435 USA4435 USA4435 USA4435 USA4437 USA4437

USA3277

USA2445 USA2445 USA2445 USA2445 USA2448 USA2441 USA2448 USA2448 USA2445 USA2448 USA2448 USA2448 USA2445 USA2448

USA4437 USA4437 USA4437 USA4437 USA4448 USA4435 USA4448 USA4448 USA4437 USA4448 USA4448 USA4448 USA4437 USA4448

USA3277

USA2445 USA2448 USA2452 USA2486

USA4437 USA4448 USA4461 USA4486

USA3269 USA3269 USA3269

USA3269

USA3235 USA4247 USA4247

USA3275 USA3235

USA4247 USA4247 USA4251

USA3277 USA3275 USA3273 USA3235

USA4247 USA4251 USA4255

USA4251 USA4255

USA2237 ST USA2237 ST USA2239 ST USA2239 ST USA2239 ST USA2239 ST USA2238 ST USA2239 ST USA2241 ST USA2237 ST USA2241 ST USA2241 ST USA2247 ST USA2245 ST USA2249 ST

USA4237 ST USA4237 ST USA4239 ST USA4239 ST USA4239 ST USA4239 ST USA4238 ST USA4239 ST USA4241 ST USA4237 ST USA4241 ST USA4241 ST USA4247 ST USA4245 ST USA4249 ST

USA3269 ST USA3269 ST USA3269 ST

USA3269 ST

USA3235 ST USA2247 ST USA4247 ST USA2247 ST USA4247 ST

USA3275 ST USA3235 ST

USA2247 ST USA4247 ST USA2247 ST USA4247 ST USA2251 ST USA4251 ST

USA3277 ST USA3275 ST USA3273 ST USA3235 ST

USA2247 ST USA4247 ST USA2251 ST USA4251 ST USA2255 ST USA4255 ST

USA3277 ST

USA2251 ST USA4251 ST USA2255 ST USA4255 ST

USA3255 USA3255

USA3277 ST USA3255 ST USA3255 ST

USA2273 ST USA4273 ST USA3255 USA3271 USA3271 USA3269 USA3271

USA3255 ST USA3271 ST USA3271 ST USA3269 ST USA3271 ST

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

Rim Singles 22.5 22.5 22.5 22.5 24 USA2253 24 USA2257 24 USA2271 24 USA2273 24 USA2255 24 USA2255 24 USA2273 24 24.5 USA2249 24.5 USA2255 24.5 USA2255 24.5 USA2247 24.5 USA2247 24.5 USA2249 24.5 USA2249 24.5 USA2253 24.5 USA2255 24.5 USA2255

Ladder WB Duals

Singles USA3261 USA3271 USA3271 USA3271

Duals

USA4253 USA4257 USA4271 USA4273 USA4255 USA4255 USA4273

Ladder Mud Service

Ladder Studded

Ladder Studded WB

Singles

Singles

Duals

Singles Duals USA3261 ST USA3271 ST USA3271 ST USA3271 ST

USA2253 ST USA2257 ST USA2271 ST USA2273 ST USA2255 ST USA2255 ST USA2273 ST

USA4253 ST USA4257 ST USA4271 ST USA4273 ST USA4255 ST USA4255 ST USA4273 ST

USA2249 ST USA2255 ST USA2255 ST USA2247 ST USA2247 ST USA2249 ST USA2249 ST USA2253 ST USA2255 ST USA2255 ST

USA4249 ST USA4255 ST USA4255 ST USA4247 ST USA4247 ST USA4249 ST USA4249 ST USA4253 ST USA4255 ST USA4255 ST

Duals

USA2486

USA4486

USA2452 USA2452

USA4461

USA2452 USA2486

USA4461 USA4486

USA2448 USA2448 USA2452 USA2452 USA2452 USA2452 USA2452

USA4448 USA4448 USA4461 USA4461 USA4461 USA4461 USA4461

USA3261 USA4249 USA4255 USA4255 USA4247 USA4247 USA4249 USA4249 USA4253 USA4255 USA4255

USA3261 ST USA3277

USA3275

USA3277 USA3277

USA3277 ST

USA3275 ST

USA3277 ST USA3277 ST

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

heavy truck & trailer (ladder)

Ladder Tire 445/65 445/80 455/50 455/55 11121314315/75 320/75 385/95 420/70 111212.5275/80 285/70 285/75 285/80 295/75 305/75 315/75

47

loader, grader & tractor 48

Universal (UNE) Tire 315/75 9.51111.21212.413.621.513.518.421.5L9.510.5/80 12.5/80 320/65 340/80 405/70 445/65 12.0012.513.0014.0014.51616.0017.5/65 300/70 320/85 355/80 360/70 365/80 395/80 395/85 400/70 405/70 625/70 14.0016.0015-2445/65 495/55 8.39.511.212.413.0013.614.0014.916.0016.917.517.5L18.0018.419.5L21.0021-

Rim 8.2MM 15 16 16 16 16 16 16 16 16.1 16.1 16.1 18 18 18 18 18 18 19.5 20 69162 20 4143 20 3999 20 69163 20 69164 20 73370 20 69122 20 20 20 20 20 20 45657 20 20 20 73370 20 73370 20 21 21 22.5 22.5 60197 22.5 24 24 24 24 24 69120 24 24 69121 24 24 24 24 24 24 24 24 24 24

Erzberg (ERZ) 10MM

12MM

10MM

12MM

Pattern

Ladder

USA-H USA225SL

OTR

Tractor USA0829 USA0822

USA214SL USA225SL USA0831 USA0850 USA0882 USA0838 USA0881

USA264SL USA264SL

USA2612

USA0829 USA0822 USA0834 USA0836 USA0836 USA0858 USA0858

USA2612

USA0858

USA214SL USA240SL USA240SL

69158

69160

93087

USA2624 USA2627 USA214SL USA218SL USA229SL USA218SL

USA0832 USA0838 USA0838 USA0838 USA2615

14122 USA2612 USA2612 USA2645 USA2612 USA2624

USA0858 USA0858 USA0858 USA0852

USA2612 USA214SL USA214SL USA229SL USA240SL 69156

69141

USA0858 USA2615

USA240SL 69119

USA0858 USA0822 USA0832 USA0836 USA0852

03481

USA0859 USA2627

USA262SL USA263SL USA263SL

USA0874 USA0874

USA268SL USA268SL

USA0883 USA0883

69124 69119

03481

USA2648 USA0885

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

49

Rim 8.2MM 24 24 24 24 24 24 24 24 24 24 24 69121 24 24 69164 24 24 24 24 24 24 24 24 24 24 25 69120 25 25 25 25 69122 25 25 25 25 25 25 25 25 25 69121 25 69122 25 25 25 25 25 25 25 25 25 25 25 25 25 26 26 26 26 26 26 26

Erzberg (ERZ) 10MM

12MM

10MM

12MM

Pattern

Ladder

USA-H USA275SL

OTR

USA0822 USA0832 USA0836 USA0836 USA0859 USA0856 USA0859 USA0856 USA0858

USA214SL USA214SL USA226SL USA229SL USA240SL USA242SL USA240SL USA240SL 69156

USA2615 USA240SL USA242SL USA250SL USA262SL USA240SL USA262SL USA240SL USA262SL USA262SL USA268SL USA268SL

69157 69119 69158 69124 69123

03481 69160 69112

69125

69149

69159

69150 69161

69156 69158 69119 69124 69123

69125

69159

Tractor

93087 69128 95122

USA268SL 69143 69144

69142

69145

69160 03481 69112

69149 84849 84849 69150

USA0856

USA2624

USA2615 USA2615 USA2627 USA2627 USA2615 USA2612 USA2627 USA2624 USA2636 USA2633 USA2648 USA2645 USA2660 USA2645 USA2657 USA2672 USA2615 USA2624 USA2612 USA2636 USA2633 USA2636 USA2636 USA2642 USA2645

USA0859 USA0869 USA0874 USA0859 USA0874

loader, grader & tractor

Universal (UNE) Tire 21L220/85 240/85 280/85 320/70 320/85 340/85 360/70 380/70 380/85 385/95 400/70 400/80 420/65 420/70 420/85 440/65 440/70 445/70 460/70 480/70 495/70 500/70 13.0014.0015.516.0017.518.0020.521.0023.524.0025.526.529.5385/95 445/80 445/95 505/95 525/80 550/65 555/70 600/65 605/80 625/70 650/65 685/80 705/70 750/65 755/70 13.614.916.918.0018.423.1420/70

USA0874 USA0874 USA0883 USA0883

USA0858

USA0858

USA2648 USA2657 USA2648 USA2657 USA2657 USA240SL USA250SL USA262SL

USA0858 USA0869 USA0876 USA2636

69125

69149

USA271SL USA280SL USA262SL

USA0883 USA0891 USA0876

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

49

loader, grader & tractor 50

Universal (UNE) Tire 420/85 460/85 480/70 480/80 480/85 520/70 540/65 9.51111.21212.413.614.916.918.419.5L23.1320/70 320/85 340/85 360/70 380/70 380/85 420/65 420/70 420/80 420/85 440/65 440/80 480/65 480/70 540/65 600/65 26.529.514.916.918.419.5L23.1380/85 420/70 420/85 420/90 460/85 480/70 520/70 540/65 600/70 620/75 9.51011.216.9210/95 650/75 800/65

Rim 8.2MM 26 26 26 26 26 26 26 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 28 29 29 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 32 32 32 32 32 32 32

Erzberg (ERZ) 10MM

12MM

10MM

12MM

Pattern

Ladder

USA-H USA262SL USA268SL USA262SL USA268SL USA268SL USA268SL USA262SL USA214SL USA218SL USA229SL USA242SL USA218SL USA242SL USA252SL USA262SL USA271SL USA262SL USA280SL USA229SL USA218SL USA242SL USA218SL USA242SL USA252SL USA218SL USA250SL USA250SL USA262SL USA242SL USA269SL USA250SL USA262SL USA262SL USA266SL

OTR

Tractor USA0876 USA0883 USA0876 USA0883 USA0883 USA0883 USA0876 USA0836 USA0838 USA0856 USA0859 USA0869 USA0876 USA0884 USA0876 USA0838 USA0856 USA0859 USA0856 USA0859 USA0876 USA0856

USA2612

USA0869 USA0876 USA0859 USA0884 USA0869 USA0876 USA0876 USA0877

USA2660 USA2675

69125

USA252SL USA266SL USA271SL USA266SL USA281SL USA252SL USA252SL USA266SL USA266SL USA271SL USA266SL USA271SL USA266SL

USA0876 USA0877 USA0885 USA0877 USA0893 USA0876 USA0876 USA0877 USA0877 USA0885 USA0877 USA0885 USA0877

USA281SL USA229SL USA218SL USA218SL USA266SL USA240SL USA278SL

USA0893 USA0838

69149

USA0877 USA0856 USA2657

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

Rim 8.2MM 33 33 34 34 34 34 34 34 34 34 34 34 34 34 34 34 34 34 34 34 34 35 35 36 36 36 36 36 36 36 36 36 36 36 38 38 38 38 38 38 38 38 38 38 38 38 38 38 38 38 38 38 38 38 38 38 38 38

Erzberg (ERZ) 10MM

12MM

10MM

12MM

Pattern

Ladder

USA-H

OTR USA2642 USA2678

USA224SL USA262SL USA270SL USA273SL USA272SL

Tractor

USA0846 USA0876 USA0879 USA0887 USA0890 USA0895 USA0876 USA0876 USA0876 USA0885 USA0877 USA0887 USA0879 USA0887 USA0879 USA0887 USA0885 USA0887 USA0895

USA262SL USA242SL USA262SL USA271SL USA270SL USA273SL USA270SL USA273SL USA270SL USA273SL USA270SL USA273SL USA282SL

loader, grader & tractor

Universal (UNE) Tire 18.0033.511.212.416.918.420.823.1290/95 320/85 320/95 385/85 420/85 460/85 480/70 480/85 500/70 520/70 540/65 600/65 620/75 21.0029.59.51111.21212.413.613.9210/95 270/95 320/85 340/85 9.5101111.212.413.614.915.516.918.420.8230/95 320/85 340/85 380/85 420/85 460/85 480/70 480/80 520/85 540/65 580/70 650/65 710/70

USA2654 USA2688 USA218SL USA232SL USA224SL USA246SL USA232SL USA246SL USA242SL USA218SL USA262SL USA232SL USA246SL USA218SL USA232SL USA232SL USA232SL USA232SL USA246SL USA254SL USA270SL USA270SL USA272SL USA276SL USA272SL USA271SL USA246SL USA270SL USA270SL USA272SL USA272SL USA272SL USA276SL USA272SL USA276SL USA276SL

USA0846 USA0862 USA0866 USA0866 USA0856 USA0876 USA0877 USA0866

USA0862 USA0862 USA0866 USA0871 USA0879 USA0889 USA0892 USA0880 USA0885 USA0866 USA0879

USA0880 USA0892 USA0880 USA0892 USA0892 USA2657

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

51

loader, grader & tractor 52

Universal (UNE) Tire 12.4180/95 230/95 12.418.4320/90 460/85 480/80 520/85 580/70 620/70 650/65 8.39.511.214.916.918.4380/90 420/80 460/85 480/80 9.511.212.4320/90 12.4300/95 12.4-

Rim 8.2MM 40 40 40 42 42 42 42 42 42 42 42 42 44 44 44 46 46 46 46 46 46 46 48 48 48 50 52 52 54

Erzberg (ERZ) 10MM

12MM

10MM

12MM

Pattern

Ladder

USA-H USA247SL USA252SL USA266SL USA247SL USA277SL USA272SL USA277SL USA277SL USA286SL USA286SL USA286SL USA286SL USA232SL USA227SL USA236SL USA256SL USA256SL USA277SL USA276SL USA256SL USA277SL USA277SL USA236SL USA247SL USA259SL USA255SL USA255SL USA276SL USA256SL

OTR

Tractor USA0876 USA0877 USA0894 USA0880 USA0894 USA0894

USA0892

USA0892 USA0892

THIS IS A GUIDE ONLY - ACTUAL FITMENT MAY VARY - ALWAYS PRE-FIT CHAINS BEFORE USE

52

USA2209 USA2211 USA2214 USA2216 USA2219 USA2221 USA2226 USA2228 USA2229 USA2233 USA2237 USA2238 USA2239 USA2241 USA2245 USA2247 USA2249 USA2251 USA2253 USA2255 USA2257 USA2271 USA2273 USA4211 USA4214 USA4216 USA4219 USA4221 USA4228 USA4229 USA4233 USA4237 USA4238 USA4239 USA4241 USA4245 USA4247 USA4249 USA4251 USA4253 USA4255 USA4257 USA4271 USA4273 USA3210 USA3227 USA3229 USA3231 USA3235 USA3237 USA3249 USA3251 USA3255 USA3257 USA3259

Weight Cross Chain Cross Chain Cross Chain Cross Chain Links Per Cross Chain Hook Per Pair Per 1/2 Pair Stock No. Length w/Hooks Wire Dia. Cross Chain Stock No.& Dia. pewag 2200 LT/HT Singles 21.5 11 USA6219 11.25'' 5.6 mm 9 406USA .276" 26.0 13 USA6221 13.25'' 5.6 mm 11 406USA .276" 31.0 15 USA6221 13.25'' 5.6 mm 11 406USA .276" 25.5 12 USA6221 13.25'' 5.6 mm 11 406USA .276" 27.0 13 USA6221 13.25'' 5.6 mm 11 406USA .276" 29.5 14 USA6221 13.25'' 5.6 mm 11 406USA .276" 36.0 15 USA6229 16.75'' 5.6 mm 15 406USA .276" 31.0 14 USA6225 15.00'' 5.6 mm 13 406USA .276" 27.0 12 USA6225 15.00'' 5.6 mm 13 406USA .276" 40.0 11 USA6251 13.50'' 7 mm 9 407USA .312" 44.0 12 USA6251 13.50'' 7 mm 9 407USA .312" 48.0 12 USA6253 16.25'' 7 mm 11 407USA .312" 48.0 13 USA6251 13.50'' 7 mm 9 407USA .312" 51.0 14 USA6251 13.50'' 7 mm 9 407USA .312" 56.0 15 USA6251 13.50'' 7 mm 9 407USA .312" 56.3 14 USA6253 16.25'' 7 mm 11 407USA .312" 59.0 15 USA6253 16.25'' 7 mm 11 407USA .312" 59.0 15 USA6253 16.25'' 7 mm 11 407USA .312" 63.2 16 USA6253 16.25'' 7 mm 11 407USA .312" 66.4 14 USA6263 18.50'' 7 mm 13 407USA .312" 75.1 16 USA6263 18.50'' 7 mm 13 407USA .312" 81.0 16 USA6266 20.75'' 7 mm 15 407USA .312" 90.0 18 USA6266 20.75'' 7 mm 15 407USA .312" pewag 4200 LT/HT Duals 42.0 26 USA6219 13.25'' 5.6 mm 11 406USA .276" 57.0 30 USA6221 13.25'' 5.6 mm 11 406USA .276" 44.0 24 USA6221 13.25'' 5.6 mm 11 406USA .276" 50.0 26 USA6221 13.25'' 5.6 mm 11 406USA .276" 53.0 28 USA6221 13.25'' 5.6 mm 11 406USA .276" 58.0 28 USA6225 15.00'' 5.6 mm 13 406USA .276" 47.0 24 USA6225 15.00'' 5.6 mm 13 406USA .276" 73.0 22 USA6251 13.50'' 7 mm 9 407USA .312" 82.0 24 USA6251 13.50'' 7 mm 9 407USA .312" 88.0 24 USA6253 16.25'' 7 mm 11 407USA .312'' 89.0 26 USA6251 13.50'' 7 mm 9 407USA .312" 91.0 28 USA6251 13.50'' 7 mm 9 407USA .312" 101.0 30 USA6251 13.50'' 7 mm 9 407USA .312" 103.0 28 USA6253 16.25'' 7 mm 11 407USA .312" 105.0 30 USA6253 16.25'' 7 mm 11 407USA .312" 105.0 30 USA6253 16.25'' 7 mm 11 407USA .375" 112.0 32 USA6253 16.25'' 7 mm 11 407USA .375" 117.0 28 USA6263 18.50'' 7 mm 13 407USA .375" 126.0 32 USA6263 18.50'' 7 mm 13 407USA .375" 154.0 32 USA6266 20.75'' 7 mm 15 407USA .375" 171.0 36 USA6266 20.75'' 7 mm 15 407USA .375" pewag 3200 LT/HT Wide Base 28.0 13 USA6225 15.00'' 5.6 mm 13 406USA .276" 40.0 10 USA6253 16.25'' 7 mm 11 407USA .312" 42.0 10 USA6259 18.50'' 7 mm 13 407USA .312" 47.0 11 USA6259 18.50'' 7 mm 13 407USA .312" 51.0 12 USA6259 18.50'' 7 mm 13 407USA .312" 42.0 9 USA6267 23.50'' 7 mm 17 407USA .312" 43.0 9 USA6267 23.50'' 7 mm 17 407USA .312" 48.0 10 USA6267 23.50'' 7 mm 17 407USA .312" 63.5 14 USA7213 20.75'' 7 mm 15 407USA .312" 78.0 15 USA7213 20.75'' 7 mm 15 407USA .312" 60.0 11 USA7214 23.00'' 7 mm 17 407USA .312"

Side Chain Stock Side Chain No.& Dia. Length 1004USA 1004USA 1004USA 1004USA 1004USA 1004USA 1004USA 1004USA 1004USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1007USA 1007USA 1007USA 1007USA

.219" .219" .219" .219" .219" .219" .219" .219" .219" .281" .281" .281" .281" .281" .281" .281" .281" .281" .281" .312" .312" .312" .312"

66.00" 77.75" 89.00" 74.00" 80.00" 84.50" 89.00" 84.50" 74.00" 83.50" 94.50" 94.50" 101.75" 109.00" 112.00" 109.00" 116.00" 116.00'' 126.75" 116.75" 126.75" 130.50" 145.50"

1004USA 1004USA 1004USA 1004USA 1004USA 1004USA 1004USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1007USA 1007USA 1007USA 1007USA

.219" .219" .219" .219" .219" .219" .219" .281" .281" .281" .281" .281" .281" .281" .281" .281" .281" .312" .312" .312" .312"

77.75" 89.00" 74.00" 80.00" 85.50" 83.75" 71.25" 83.50" 94.50" 94.50" 101.75" 109.00" 116.00" 109.00" 116.00" 116.00'' 126.75" 116.75" 126.75" 130.50" 145.50"

1004USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA

.219" .281" .281" .281" .281" .281" .281" .281" .281" .281" .281"

77.75" 80.00" 80.00" 87.25" 94.50" 69.00" 69.00" 76.25" 109.00" 112.25" 83.50"

chain specifications

Stock No.

53

chain specifications

Stock No.

USA3261 USA3265 USA3267 USA3269 USA3271 USA3273 USA3275 USA3277 USA2433 USA2435 USA2437 USA2439 USA2441 USA2445 USA2448 USA2452 USA2486 USA4412 USA4435 USA4437 USA4448 USA4461 USA4486 USA2612 USA2615 USA2624 USA2627 USA2633 USA2636 USA2642 USA2645 USA2648 USA2657 USA2672 USA2675 USA0822 USA0829 USA0831 USA0832 USA0834 USA0836 USA0838 USA0846 USA0850 USA0852 USA0856 USA0858 USA0859 USA0862 USA0866 USA0869 USA0871 USA0874

54

Weight Cross Chain Cross Chain Cross Chain Cross Chain Links Per Cross Chain Hook Per Pair Per 1/2 Pair Stock No. Length w/Hooks Wire Dia. Cross Chain Stock No.& Dia. pewag 3200 LT/HT Wide Base 75.0 16 USA7214 23.00'' 7 mm 17 407USA .312" 59.0 11 USA7214 23.00'' 7 mm 17 407USA .312" 60.0 12 USA7214 23.00'' 7 mm 17 407USA .312" 60.5 13 USA7214 23.00'' 7 mm 17 407USA .312" 66.0 14 USA7214 23.00'' 7 mm 17 407USA .312" 79.0 12 USA7216 32.50'' 7 mm 25 407USA .312" 86.0 13 USA7216 32.50'' 7 mm 25 407USA .312" 92.0 14 USA7216 32.50'' 7 mm 25 407USA .312" pewag 2400 Mud Singles 33.0 8 USA6256 13.50'' 7 mm 9 407USA .312" 35.0 9 USA6256 13.50'' 7 mm 9 407USA .312" 37.0 10 USA6256 13.50'' 7 mm 9 407USA .312" 39.0 10 USA6260 16.25'' 7 mm 11 407USA .312" 63.0 11 USA6434 17.50'' 8.2 mm 11 409USA .375" 71.0 12 USA6434 17.50'' 8.2 mm 11 409USA .375" 68.5 13 USA6434 17.50'' 8.2 mm 11 409USA .375" 73.5 14 USA6434 17.50'' 8.2 mm 11 409USA .375" 90.0 14 USA6445 20.50'' 8.2 mm 13 409USA .375" pewag 4400 Mud Duals 72.0 20 USA6256 13.50'' 7 mm 9 407USA .312" 118.0 22 USA6256 13.50'' 7 mm 9 407USA .312" 124.0 24 USA6434 17.50'' 8.2 mm 11 409USA .375" 136.0 26 USA6434 17.50'' 8.2 mm 11 409USA .375" 137.0 28 USA6434 17.50'' 8.2 mm 11 409USA .375" 183.0 28 USA6445 20.50'' 8.2 mm 13 409USA .375" pewag 2600 OTR 98.0 14 USA6630 25.50'' 8.2 mm 17 409USA .375" 114.0 16 USA6630 25.50'' 8.2 mm 17 409USA .375" 146.0 13 USA6640 28.00'' 10 mm 17 411USA .437" 168.0 15 USA6640 28.00'' 10 mm 17 411USA .437" 176.0 14 USA6650 33.75'' 10 mm 21 411USA .437" 188.0 15 USA6650 33.75'' 10 mm 21 411USA .437" 232.0 18 USA6650 33.75'' 10 mm 21 411USA .437" 268.0 15 USA6660 38.25'' 12 mm 19 411USA .437" 298.0 16 USA6660 38.25'' 12 mm 19 411USA .437" 375.0 17 USA6670 45.25'' 12 mm 23 411USA .437" 403.0 17 USA6680 52.25'' 12 mm 27 411USA .437" 427.0 18 USA6680 52.25'' 12 mm 27 411USA .437" pewag 0800 Tractor 79.0 11 USA6434 17.50'' 8.2 mm 11 409USA .375" 76.0 9 USA6434 17.50'' 8.2 mm 11 409USA .375" 72.0 10 USA6445 20.50'' 8.2 mm 13 409USA .375" 79.0 12 USA6434 17.50'' 8.2 mm 11 409USA .375" 78.0 11 USA6445 20.50'' 8.2 mm 13 409USA .375" 88.0 12 USA6445 20.50'' 8.2 mm 13 409USA .375" 109.0 14 USA6445 20.50'' 8.2 mm 13 409USA .375" 126.0 17 USA6445 20.50'' 8.2 mm 13 409USA .375" 86.0 10 USA7420 22.75'' 8.2 mm 15 409USA .375" 105.0 13 USA6445 20.50'' 8.2 mm 13 409USA .375" 111.0 15 USA6445 20.50'' 8.2 mm 13 409USA .375" 122.0 14 USA7420 22.75'' 8.2 mm 15 409USA .375" 124.0 15 USA7420 22.75'' 8.2 mm 15 409USA .375" 145.0 18 USA6445 20.50'' 8.2 mm 13 409USA .375" 153.0 19 USA7420 22.75'' 8.2 mm 15 409USA .375" 137.0 16 USA7420 22.75'' 8.2 mm 15 409USA .375" 163.0 20 USA7420 22.75'' 8.2 mm 15 409USA .375" 137.0 15 USA7426 28.50'' 8.2 mm 19 409USA .375"

Side Chain Stock Side Chain No.& Dia. Length 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA

.281" .281" .281" .281" .281" .281" .281" .281"

123.25" 83.50" 90.75" 101.75" 109.00" 90.75" 97.75" 105.25"

1006USA 1006USA 1006USA 1006USA 1007USA 1007USA 1007USA 1007USA 1007USA

.281" .281" .281" .281" .312" .312" .312" .312" .312"

61.75" 69.00" 80.00" 80.00" 92.75" 96.25" 108.25" 116.00" 111.25"

1006USA 1006USA 1007USA 1007USA 1007USA 1007USA

.281" .281" .312" .312" .312" .312"

61.60" 68.90" 76.10" 108.25" 117.50" 115.25"

1007USA 1007USA 1009USA 1009USA 1009USA 1009USA 1009USA 1011USA 1011USA 1011USA 1011USA 1011USA

.312" .312" .375" .375" .375" .375" .375" .437" .437" .437" .437" .437"

115.50" 126.75" 121.75" 138.50" 130.00" 134.75" 160.75" 148.00" 153.00" 163.00" 163.00" 166.50"

1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA

.312" .312" .312" .312" .312" .312" .312" .312" .312" .312" .312" .312" .312" .312" .312" .312" .312" .312"

88.50" 73.00" 80.75" 96.25" 88.50" 96.25" 111.50" 134.50" 80.75" 103.75" 119.25" 111.50" 119.25" 142.25" 149.75" 126.75" 157.50" 119.25"

USA0876 USA0877 USA0879 USA0881 USA0882 USA0883 USA0884 USA0885 USA0887 USA0889 USA0890 USA0891 USA0892 USA0893 USA0894 USA0895 USASSE10165-2 USASSE10165-4 USASSE12165-2 USASSE12165-4 USASSE14175-2 USASSE14175-4 USA2219SC 7ST USA2221SC 7ST USA2228SC 7ST USA2233SC 7ST USA2237SC 7ST USA2238SC 7ST USA2239SC 7ST USA2241SC 7ST USA2245SC 7ST USA2247SC 7ST USA2249SC 7ST USA2251SC 7ST USA2253SC 7ST USA2255SC 7ST USA2247S 7ST USA2249S 7ST USA2255S 7ST USA2233SC 8ST USA2237SC 8ST USA2238SC 8ST USA2239SC 8ST USA2241SC 8ST USA2245SC 8ST USA2247SC 8ST USA2249SC 8ST USA2251SC 8ST USA2253SC 8ST USA2255SC 8ST USA4219SC 7ST USA4221SC 7ST

Weight Cross Chain Cross Chain Cross Chain Cross Chain Links Per Cross Chain Hook Per Pair Per 1/2 Pair Stock No. Length w/Hooks Wire Dia. Cross Chain Stock No.& Dia. pewag 0800 Tractor 158.0 16 USA7426 28.50'' 8.2 mm 19 409USA .375" 164.0 17 USA7426 28.50'' 8.2 mm 19 409USA .375" 171.0 18 USA7426 28.50'' 8.2 mm 19 409USA .375" 205.0 10 USA9562 30.75'' 10 mm 19 411USA .437" 244.0 12 USA9562 30.75'' 10 mm 19 411USA .437" 268.0 13 USA9562 30.75'' 10 mm 19 411USA .437" 283.0 14 USA9562 30.75'' 10 mm 19 411USA .437" 319.0 15 USA9562 30.75'' 10 mm 19 411USA .437" 324.0 16 USA9562 30.75'' 10 mm 19 411USA .437" 364.0 17 USA9562 30.75'' 10 mm 19 411USA .437" 438.0 17 USA6650 33.75'' 10 mm 21 411USA .437" 338.0 14 USA9567 39.25'' 10 mm 25 411USA .437" 385.0 18 USA6650 33.75'' 10 mm 21 411USA .437" 384.0 16 USA9567 39.25'' 10 mm 25 411USA .437" 370.0 19 USA9562 30.75'' 10 mm 19 411USA .437" 523.0 17 USA9567 39.25'' 10 mm 25 411USA .437" pewag Skid Steer 78.0 17 USA6434 17.50'' 8.2 mm 11 409USA .375" 44.0 9 USA6434 17.50'' 8.2 mm 11 409USA .375" 88.0 19 USA6445 20.50'' 8.2 mm 13 409USA .375" 69.0 10 USA6445 20.50'' 8.2 mm 13 409USA .375" 120.0 23 USA6445 20.50'' 8.2 mm 13 409USA .375" 76.0 12 USA6445 20.50'' 8.2 mm 13 409USA .375" pewag 2200 LT/HT 7mm Studded Singles - With Cams USA 6250 7ST 35.7 9 13.75'' 7 mm 9 407USA .312" USA 6250 7ST 39.0 10 13.75'' 7 mm 9 407USA .312" USA 62517ST 42.0 10 14.75'' 7 mm 11 407USA .312" USA 62517ST 40.0 11 14.75'' 7 mm 11 407USA .312" USA 62517ST 51.3 12 14.75'' 7 mm 11 407USA .312" USA 6253 7ST 56.0 12 15.75'' 7 mm 12 407USA .312" USA 62517ST 53.8 13 14.75'' 7 mm 11 407USA .312" USA 62517ST 58.1 14 14.75'' 7 mm 11 407USA .312" USA 62517ST 62.2 15 14.75'' 7 mm 11 407USA .312" USA 6253 7ST 60.4 14 15.75'' 7 mm 12 407USA .312" USA 6253 7ST 64.0 15 15.75'' 7 mm 12 407USA .312" USA 6263 7ST --15 17.00'' 7 mm 13 407USA .312" USA 6263 7ST --17 17.00'' 7 mm 13 407USA .312" USA 6266 7ST 74.4 16 18.25'' 7 mm 14 407USA .312" pewag 2200 HT 7mm Studded Singles - Without Cams USA 6253 7ST 48.0 12 15.75'' 7 mm 12 407USA .312" USA 6253 7ST 51.4 13 15.75'' 7 mm 12 407USA .312" USA 6266 7ST 56.7 13 18.25'' 7 mm 14 407USA .312" pewag 2200 HT 8mm Studded Singles USA 62518ST --10 16.00'' 8 mm 11 409USA .375" USA 62518ST --11 16.00'' 8 mm 11 409USA .375" USA 6253 8ST 71.0 11 17.50'' 8 mm 12 409USA .375" USA 62518ST 51.7 12 16.00'' 8 mm 11 409USA .375" USA 62518ST 56.0 13 16.00'' 8 mm 11 409USA .375" USA 62518ST 64.0 14 16.00'' 8 mm 11 409USA .375" USA 6253 8ST 81.0 13 17.50'' 8 mm 12 409USA .375" USA 6253 8ST 87.1 14 17.50'' 8 mm 12 409USA .375" USA 6253 8ST 87.1 14 17.50'' 8 mm 12 409USA .375" USA 6253 8ST --16 17.50'' 8 mm 12 409USA .375" USA 6253 8ST 87.1 14 17.50'' 8 mm 12 409USA .375" pewag 4200 LT/HT 7mm Studded Duals - With Cams USA 6250 7ST 68.0 18 13.75'' 7 mm 9 407USA .312" USA 6250 7ST 70.5 20 13.75'' 7 mm 9 407USA .312"

Side Chain Stock Side Chain No.& Dia. Length 1007USA 1007USA 1007USA 1009USA 1009USA 1009USA 1009USA 1009USA 1009USA 1009USA 1009USA 1009USA 1009USA 1009USA 1009USA 1009USA

.312" .312" .312" .375" .375" .375" .375" .375" .375" .375" .375" .375" .375" .375" .375" .375"

126.75" 134.50" 142.25" 92.25" 108.50" 117.25" 126.00" 134.75" 143.25" 152.00" 152.00" 126.00" 160.75" 143.25" 169.50" 152.00"

1007USA 1007USA 1007USA 1007USA 1007USA 1007USA

.312" .312" .312" .312" .312" .312"

72.00" 72.00" 79.00" 79.00" 94.00" 94.00"

1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA

.281" .281" .281" .281" .281" .281" .281" .281" .281" .281" .281" .281" .281" .281"

75.83" 84.25" 84.25" 87.50" 95.00" 95.00" 102.25" 109.25" 116.50" 109.25" 116.50" 116.50" 131.00" 123.75"

1005USA 1005USA 1005USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA

chain specifications

Stock No.

110.63" 116.50" 118.11"

.312" .312" .312" .312" .312" .312" .312" .312" .312" .312" .312"

85.25" 92.25" 92.25" 100.50" 108.25" 117.50" 108.25" 117.50" 117.50" 131.25" 117.50"

1006USA .281" 1006USA .281"

75.83" 84.25"

55

chain specifications

Weight Cross Chain Cross Chain Cross Chain Cross Chain Links Per Cross Chain Hook Per Pair Per 1/2 Pair Stock No. Length w/Hooks Wire Dia. Cross Chain Stock No.& Dia. pewag 4200 LT/HT 7mm Studded Duals - With Cams USA 62517ST USA4228SC 7ST 77.0 20 14.75'' 7 mm 11 407USA .312" USA 62517ST USA4233SC 7ST --22 14.75'' 7 mm 11 407USA .312" USA 62517ST USA4237SC 7ST --24 14.75'' 7 mm 11 407USA .312" USA 6253 7ST USA4238SC 7ST --24 15.75'' 7 mm 12 407USA .312" USA 62517ST USA4239SC 7ST 98.8 26 14.75'' 7 mm 11 407USA .312" USA 62517ST USA4241SC 7ST 106.4 28 14.75'' 7 mm 11 407USA .312" USA 62517ST USA4245SC 7ST 114.0 30 14.75'' 7 mm 11 407USA .312" USA 6253 7ST USA4247SC 7ST 110.0 28 15.75'' 7 mm 12 407USA .312" USA 6253 7ST USA4249SC 7ST 117.0 30 15.75'' 7 mm 12 407USA .312" USA 6263 7ST USA4251SC 7ST --30 17.00'' 7 mm 13 407USA .312" USA 6263 7ST USA4253SC 7ST --34 17.00'' 7 mm 13 407USA .312" USA 6266 7ST USA4255SC 7ST 134.0 32 18.25'' 7 mm 14 407USA .312" pewag 4200 HT 7mm Studded Duals - Without Cams USA 6253 7ST USA4247S 7ST 88.4 24 15.75'' 7 mm 12 407USA .312" USA 6253 7ST USA4249S 7ST 92.0 26 15.75'' 7 mm 12 407USA .312" USA 6266 7ST USA4255S 7ST 104.3 26 18.25'' 7 mm 14 407USA .312" pewag 4200 HT 8mm Studded Duals - With Cams USA 62518ST USA4233SC 8ST --20 16.00'' 8 mm 11 409USA .375" USA 62518ST USA4237SC 8ST --22 16.00'' 8 mm 11 409USA .375" USA 6253 8ST USA4238SC 8ST --22 17.50'' 8 mm 12 409USA .375" USA 62518ST USA4239SC 8ST 115.7 24 16.00'' 8 mm 11 409USA .375" USA 62518ST USA4241SC 8ST 125.4 26 16.00'' 8 mm 11 409USA .375" USA 62518ST USA4245SC 8ST 135.0 28 16.00'' 8 mm 11 409USA .375" USA 6253 8ST USA4247SC 8ST 149.6 26 17.50'' 8 mm 12 409USA .375" USA 6253 8ST USA4249SC 8ST 159.3 28 17.50'' 8 mm 12 409USA .375" USA 6253 8ST USA4251SC 8ST 159.3 28 17.50'' 8 mm 12 409USA .375" USA 6253 8ST USA4253SC 8ST --32 17.50'' 8 mm 12 409USA .375" USA 6253 8ST USA4255SC 8ST 159.3 28 17.50'' 8 mm 12 409USA .375" pewag 3200 7mm Wide Base - With Cams USA 6253 7ST USA3227SC 7ST --10 15.75'' 7 mm 12 407USA .312" USA 6266 7ST USA3231SC 7ST --11 18.25'' 7 mm 14 407USA .312" pewag 3200 8mm Wide Base - With Cams USA 7213 8ST USA3255SC 8ST 64.0 13 20.75'' 8 mm 15 409USA .375" USA 7215 8ST USA3271SC 8ST 85.0 13 23.25'' 8 mm 17 409USA .375" USA 7214 8ST USA3261SC 8ST --15 22.00'' 8 mm 16 409USA .375" pewag 3200 8mm Wide Base - Without Cams - Double Spaced USA 7213 8ST USA3255 DS 8ST 154.1 26 20.75'' 8 mm 15 409USA .375" USA 7214 8ST USA3261 DS 8ST 185.3 30 22.00'' 8 mm 16 409USA .375" USA 7215 8ST USA3271 DS 8ST 168.1 26 23.25'' 8 mm 17 409USA .375" Stock No.

Side Chain Stock No.& Dia. 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA 1006USA

.281" .281" .281" .281" .281" .281" .281" .281" .281" .281" .281" .281"

75.83" 87.50" 95.00" 95.00" 102.25" 109.25" 116.50" 109.25" 116.50" 116.50" 131.00" 123.75"

1005USA 1005USA 1005USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA 1007USA

Side Chain Length

110.63" 116.50" 118.11"

.312" .312" .312" .312" .312" .312" .312" .312" .312" .312" .312"

85.25" 92.25" 92.25" 100.50" 108.25" 117.50" 108.25" 117.50" 117.50" 131.25" 117.50"

1006USA .281" 1006USA .281"

84.25" 87.50"

1007USA .312" 1007USA .312" 1007USA .312"

110.23" 112.21" 127.56"

1007USA .312" 1007USA .312" 1007USA .312"

112.21" 127.56" 112.21"

wire diameter & link specifications Trade Size 3.7 mm 4.5 mm 5.6 mm 7 mm 8.2 mm 10 mm 12 mm

(A) Decimal (A) Standard 0.145" 9/64" 0.177" 5/32" 0.221'' 15/64'' 0.276'' 9/32'' 0.322'' 21/64'' 0.394'' 25/64'' 0.472'' 15/32''

(A) Metric 3.7 mm 4.5 mm 5.6 mm 7 mm 8.2 mm 10 mm 12 mm

(B) Pitch 11 mm 18 mm 24 mm 30 mm 33 mm 35 mm 45 mm

Trade Size 1/0 3/0 4/0 6/0 7/0 9/0 11/0 14/0

(A) Decimal (A) Standard 0.177'' 11/64'' 0.207'' 13/64'' 0.234'' 15/64'' 0.281'' 9/32'' 0.312'' 5/16'' 0.375'' 3/8'' 0.437'' 7/16'' 0.531'' 17/32''

(A) Metric 4.5 mm 5.25 mm 5.95 mm 7.14 mm 7.92 mm 9.53 mm 11.10 mm 13.50 mm

(B) Pitch 1.180'' 0.920'' 1.000'' 1.250'' 1.390'' 1.260'' 1.562'' 1.734''

Diameter: (A) is the thickness of the steel wire material used to form the chain link. The measurement should be taken at an unbent area of the link where possible.

Pitch: (B) is the inside measurement across the length of the link.

56

A

B

notes

is Investing in America Investing In America pewag opens first North American Chain Manufacturing Plant in Pueblo, Colorado

in.com

pewagcha

5-2895

1-800-44

Ribbon cutting ceremony on May 3, 2014, at pewag’s first North American chain manufacturing plant in Pueblo, Colorado.

Wheel loader with pewag Universal “ED” tire chains displayed at the grand opening in Pueblo, Colorado.

Manufacturing Headquarters pewag Traction Chain, Inc. 190 Greenhorn Drive Pueblo, CO 81004 Toll Free: (800) 445-2895 Fax: (719) 691-1841

Distributed By:

youtube.com/pewagusa facebook.com/pewagtraction instagram.com/pewagtraction

traction@pewagchain.com

Corporate Headquarters

Canada Headquarters

pewag, Inc. 600 West Crossroads Parkway Bolingbrook, IL 60440 Toll Free: (800) 526-3924 Fax: (630) 759-0788

pewag Canada, Inc. 3600 B Laird Road Mississauga, ON L5L 6A7 Toll Free: (888) 598-0626 Fax: (289) 201-0075

Traction Chain Warehouse

Satellite Warehouses

pewag Traction, Inc. 3825 Cincinnati Avenue, Suite D Rocklin, CA 95765 Toll Free: (800) 445-2895 Fax: (916) 408-0575

• • • •

Reno, NV Portland, OR Denver, CO Edmonton, AB
