English version - Luxury ll Series Material

1

Luxury ll English version

Series Material

2

Luxury ll Series Material

3

Luxury ll Series Material : The materials in this series are designed to reduce external heat, featuring 20 cm thick autoclaved concrete and 6-inch thermal insulation, which help keep the home cool and save on electricity costs. The entire house is also equipped with the PD Fresh Airflow- air ventilation system, model Fresh Plus, which provides fresh air, prevents mold, and filters out PM2.5 dust.

High-quality materials are used throughout, focusing on modern, luxurious designs that cater to a luxury lifestyle.

4

5

01

Materials and equipment for the elderly and health

6

Luxury ll Section 1 Materials and equipment for the elderly and health

Lift

By ARITCO : S15 or as drawing specified Feature : Beautiful, easy to install, and space-efficient with a unique structure.

Saves up to 95% on electricity and is made from recyclable materials. www.aritco.co.th

Air ventilation equipment

PM2.5 prevention and clean air ventilation equipment by PD Fresh Airflow model Fresh Plus – Spiral duct installed over the ceiling as engineer specified.

Feature : The heat recovery ventilation (ERV) system includes a humidity sensor in the air intake and exhaust diffuser, helping to balance air quality for optimal living conditions, improving indoor air quality by over 100%, and can recover up to 86% of cooling air.

Luxury ll Section 1 Materials and equipment for the elderly and health

Elder room floor

Shock absorb Safety Floor – PVC type,

by KRONOTEX with PVC floor skirt Feature : Anti-slip surface reduces the risk of slipping and minimizes the impact severity in case of falls. www.thaigermandecor.com

House entrance ramp

Coarse polished cement, as drawing specified Feature : For wheelchair accessibility

7

Luxury ll Section 1 Materials and equipment for the elderly and health

8

Door for elder bathroom

Hung type sliding, Anodized aluminum door

by TOSTEM : ATIS or as manufacturer specified, 1.00 m. wide with 8 mm. frosted glass or as drawing specified.

Feature : Sliding door for easy access of the elderly, made from waterproof WPC material that resists warping. www.tostemthailand.com

Elder Bathroom

“AMERICAN STANDARD” or COTTO” (White color) Feature : Special designed sanitaryware and equipment for elderly, complemented by additional safety features to prevent accidents in the bathroom. www.americanstandard.co.th/th - www.cotto.com/

Water closet

AMERICAN STANDARD : Cygnet Hygiene Rim 2626SC-WT-0 with toilet seat model Armorlid, 2 function rinsing spray by COTTO : CT980H#WH (HM) and stop valve model CT179N (HM)

Wash basin

Wall hung type by COTTO : For All SC00537

Luxury ll Section� 11วั​ัMaterials and equipment หมวดที่​่ สดุ​ุเพื่​่�อผู้​้�สู​ูงวั​ั ยและสุ​ุ ขภาพ for the elderly and health

Wash basin mixer faucet

COTTO : CT300A (with hot water pipe)

Wall mounted mixer faucet for shower

AMERICAN STANDARD : SIGNATURE A-1712-300 with shower head model RAINCLICK F40017-CHADY (with water pipe)

Wall mounted faucet

AMERICAN STANDARD : WINSTON FFAST6020T0500BT0

9

Luxury ll Section 1 Materials and equipment for the elderly and health

10

Towel bar

AMERICAN STANDARD : ACACIA E K-1393-46N chromium color

Soap holder

AMERICAN STANDARD : ACACIA E K-1382-42N chromium color

Tissue holder

AMERICAN STANDARD : ACACIA E K-1387-55-N chromium color

Mirror

COTTO : MZ901#BS with shelf and cloth hook

Luxury ll Section 1 Materials and equipment for the elderly and health

11

Bathroom floor drain

COTTO : CT654Z2P (size 100 cm.)

Safety equipment for Elder bathroom Foldable support arm by COTTO : CT0164

Safety equipment for Elder bathroom L shape handrail by COTTO : CT0162

Safety equipment for Elder bathroom Foldable wall mounted shower seat

by COTTO : CT0169

12

Luxury ll Section 1 Materials and equipment for the elderly and health

Swimming Pool

Feature : Convenient and safe for the elderly to exercise for strong and healthy well-being.

Wall structure

Polypropylene wall with concrete structure depth does not exceed 1.20 m. or as drawing specified.

Floor-wall system

1.1 mm. thick, anti-slip, blue liner, no pattern. Pool edge tile with polished sandstone size 30x60 cm.

Installation equipment

Electrical system, pipe, drainage and filter system size follow the manufacturer recommendation

Pool pavement (if any)

Reinforced concrete with porcelain tile (price does not exceed 500 baht/sq.m)

Luxury ll Section� 11วั​ัMaterials and equipment หมวดที่​่ สดุ​ุเพื่​่�อผู้​้�สู​ูงวั​ั ยและสุ​ุ ขภาพ for the elderly and health

13

14

15

02

Materials and equipment for Energy-Efficiency and Heat Insulation

16

Luxury ll Section 2 Materials and equipment for Energy-Efficiency and Heat Insulation

Solar water heater

Capacity 200 litres with hot water piping (Pimaflex) to every bathroom for wash basin, bath tub and shower. (except maid bathroom) Feature : Uses solar energy to help reduce electricity costs.

Heat prevention beneath the roof

6 inches thick insulator by “STAY COOL”: Premium placed on ceiling beneath upper and lower roof level (except garage, upper, lower terrace area external ceiling and Insulated Roof).

Feature : Prevent the heat from the roof to enter the living space. www.scgsmartliving.com

Luxury ll Section 2 Materials and equipment for Energy-Efficiency and Heat Insulation

17

Sanitary ware (Water saving)

“AMERICAN STANDARD” or COTTO” (White color) Feature : Water conservation with water saving funtion www.americanstandard.co.th/th - www.cotto.com

Water Closet for general bathroom

AMERICAN STANDARD : ACACIA EVOLUTION 2307SC-WT-0 with stainless steel rinsing spray model SMART A-4900-S

Roof tile (Excella)

“SCG” Ceramic roof tile model Excella Classic (Crystal blue, White pearl, Green peridot, Red sapphire, Red garnet, Carnelian brown, Yellow sapphire) or Excella Grace (Navy blue, Burgundy) or Excella Modern (Coco brown, Obsidian grey, Silver grey, Platinum) with “Dry ridge system”, stainless #24 for valley rafter.

Feature : Reduces heat entering the building, effectively absorbs rain noise. www.scghome.com

18

Luxury ll Section 2 Materials and equipment for Energy-Efficiency and Heat Insulation

Exterior/ interior wall material

Exterior wall - 20 (10+10) cm. thick, or as thick as the structural column thickness, Autoclave concrete with plastering and skim coat.

Feature : Heat insulation and fire resistant.

Reduce te disturbing noise from outside

General wall

10 cm. thick Autoclave concrete with plastering and skim coat.

Feature : Heat insulation and fire resistant.

Reduce te disturbing noise from outside

Luxury ll Section� 12วั​ัMaterials and equipment หมวดที่​่ สดุ​ุเพื่​่�อผู้​้�สู​ูงวั​ั ยและสุ​ุ ขภาพ for Energy-Efficiency and Heat Insulation

19

20

21

03

Eco-Friendly Materials and Equipment

Luxury ll Section 3 Eco-Friendly Materials and Equipment

22

General first floor and upper floor materials

7.5 mm. thick waterproof wood floor by “KRONOTEX” : Corepel or 12 mm. thick laminated floor by “KRONOTEX”: Robusto or equal with PVC floor skirt Feature : Designed to resemble natural wood, offering superior moisture resistance and scratch durability. www.thaigermandecor.com

Wooden stair set

A set of Engineered Wood by ACON or MUKU color coated from the factory Feature : Strong, warp-resistant, insect and mold-proof, and environmental friendly as it is made from plantation-grown rubberwood. www.facebook.com/AconThailand - www.facebook.com/Mukuthailand

Stair tread

l

Size 300x30 mm.

l

Stair tread

Riser

Riser

Size 200x20 mm.

Luxury ll Section 3 Eco-Friendly Materials and Equipment

23

Baluster

l

Baluster

Size 50x50 mm. l

Landing

Landing

30 mm. thick, 2 pieces (V groove connect)

l

Post Post

Size 125x125 mm.

Handrail

Wrought Iron as drawing specified topped with Engineered wood size 50x100 mm.

l

Handrail

24

Luxury ll Section 3 Eco-Friendly Materials and Equipment

Exterior ceiling (Balcony/Garage/Eaves)

Wood Plastic Composite (WPC) by PD WOOD

by Maxis Wood model QB-003 Teak color or equal with Zinc galvanized studs#26 and insect prevention screen.

Feature : Durable in all weather conditions, resistant to termites, non-flammable, with a naturally beautiful appearance.

Decorated wall (If any)

In case of fiber cement decorated wall, use “SCG” or “CONWOOD” or Wood Plastic Composite (WPC) - PD WOOD by Maxis Wood model CX-002 teak color or as drawing specified

Feature : Durable in all weather conditions, resistant to termites, non-flammable, with a naturally beautiful appearance.

Luxury ll Section 3 Eco-Friendly Materials and Equipment

25

Interior Doors General interior door/ Bedroom/ Storage room (if any)

Wood Plastic Composite (WPC) door with steel structure by “PD WOOD” model C1-WPC-001-006 color New Pine, Burma teak or Vintage wenge (choose later). And white wood pattern film coated Wood Plastic Composite (WPC) door frame model Ultra series 3 by “PD WOOD”.

Feature : Strong and water-resistant (can be submerged or exposed to water), termite-proof, and fire-retardant, with customizable door colors to suit preferences.

Door for maid room and maid bathroom

White Wood Plastic Composite (WPC) door model C-WPC-001-003, 008, 011, 012 and white wood pattern film coated Wood Plastic Composite (WPC) door frame model Ultra series 3 by “PD WOOD”

26

Luxury ll Section 3 Eco-Friendly Materials and Equipment

Door for kitchen/ open to garage/ maid room/ maid bathroom (open to exterior)

White Wood Plastic Composite (WPC) door with steel structure by “PD WOOD” model C1-WPC-008, 011, 012. White wood pattern film coated Wood Plastic Composite (WPC) door frame model Ultra series 3 by “PD WOOD”.

Facia

Fiber - cement board by “SCG”: 6”, 8” primer paint coated type or Synthetic wood “Eave Plus” or equal Feature : Highly durable, resistant to warping or shrinking, and maintains its straight, flawless form throughout its lifespan. www.scgsmartliving.com

Luxury ll Section 3 Eco-Friendly Materials and Equipment

27

Treatment Tank

Fiberglass tank by “DOS” model ST-21/GY or “PP” : Ecotank or equal (put underground).

Feature : Strong and durable, meets wastewater treatment standards, ideal for residential use. www.dos.co.th - www.premier-products.co.th

Grease trap Tank

Fiberglass tank by “DOS”: GT-09/BK-40 “PP”: GT-30UG (put underground).

Feature : Eco-friendly, odor-free from water and food waste. www.dos.co.th - www.premier-products.co.th

28

29

30

31

04

Construction technology and innovative materials and equipment

32

Luxury ll Section 4 Construction technology and innovative materials and equipment

Concrete Structure Footing/Column /Beam/ Staircase/ Bathroom tray

Prefabrication structure with Multi Joint Lock System. Some parts of structure are cast-in-place as engineer specified.

Feature : Strong and durable, with every component quality-checked before installation. Speeds up construction, reduces dust and noise, and can be installed during the rainy season.

General concrete plank

Prestressed planks by D-CON or PCM or equal. Some parts of structure are cast-in-place as engineer specified.

Luxury ll

Section 4 Construction technology and innovative materials and equipment

33

Exterior Door/Window

by TOSTEM Feature : Anodized aluminum panels are manufactured and quality-controlled to meet production standards in a factory using Japanese technology. www.tostemthailand.com

General Window

Anodized aluminum window by “TOSTEM”: ATIS or as manufacturer specific with 8 mm. thick clear green glass.

Bathroom window

Anodized aluminum window by “TOSTEM”: ATIS or as manufacturer specific with 8 mm. thick frosted glass.

Door to Terrace / Balcony/ main entrance Anodized aluminum door by “TOSTEM”: ATIS or as manufacturer specific with 8 mm. thick clear green glass.

34

Luxury ll Section 4 Construction technology and innovative materials and equipment

Hung type sliding door (if any)

Anodized aluminum door by TOSTEM : ATIS or as manufacturer specific with 8 mm. thick clear green glass.

Door for Bathroom

Anodized aluminum window by “TOSTEM”: ATIS or as manufacturer specific with 8 mm. thick frosted glass.

Door for storage room under stair (if any) /Door for electric control unit panel Aluminum door by “TOSTEM”: ATIS or as manufacturer specific www.tostemthailand.com

Plastering Material

Mortar cement by “SCG”, “INSEE”, “TPI”, “SINGHA MORTAR” or equal with skim coat. For exterior wall, protective formula mortar “PD Mortar Plus”+ Fiberglass mesh is used.

Feature : Crack-resistant plaster is designed to minimize exterior wall cracks caused by changing weather conditions.

Luxury ll

Section 4 Construction technology and innovative materials and equipment

35

Roof Truss

Alu-zinc (AZ-150) or SuperDyma coated high strength steel structure with screw and nut system as engineer specified.

Feature : Made from high-tensile steel, lightweight, rust-resistant coating.

Water pipe

Pimaflex Mutipipe by PIMATEC 25x2.5 mm. (20 mm.) for main pipe from building to meter, length not exceed 40.00 m. with ball valve, metal handle, separating for each floor. 20x2.25 mm. (15.5 mm.) for branch pipe. 16x2.0 mm. (12 mm.) for hot water pipe.

Feature : Made from high-quality materials, flexible, durable, resistant to breakage, and effectively prevent leaks. The pipe is well-suited for use under high temperatures and pressure. www.pimatec.com/th

Handrail

Wrought Iron, tempered glass or as drawing specified Feature : High quality steel work, durable and elegance

36

37

38

39

05

General Construction Materials and Equipment

40

Luxury ll Section 5 General Construction Materials and Equipment

Piling

Bangkok area and surrounding area

pre-stressed concrete pile I-26 not exceed 21.00 m. long (2 piles welded connection) In case driven pile cannot be used, bored pile as engineer specified is used (extra cost) Provincial area (stiff soil), pre-stressed concrete solid square pile 26 x 26 cm is used.

One storey house, the length does not exceed 10.00 m.

2-3 storey house, the length does not exceed 12.00 m.

In the area where pile can not be driven, soil bearing foundation as engineer specified is used.

Floor of washing area

Reinforced concrete slab on ground as engineer specified. Piling work size I-12, 2.00 m. long every 0.80 m. interval

(except stiff soil where pile cannot be driven)

Luxury ll Section 5 General Construction Materials and Equipment

41

Entrance pavement

Reinforced concrete slab on ground with 0.12 m. thickness or as engineer specified. Total area not exceed 40 sq.m.

Concrete

Ready mixed concrete by SCG, INSEE, TPI

Floor Level

First floor level

0.80 m. high from the ground or as specified in the drawing (In case of multilevel floor).

Second floor level

3.80 m. approximately high from the first-floor level or as specified in the drawing

Luxury ll Section 5 General Construction Materials and Equipment

42 Flooring Materials

Feature : Highly durable and strong, reducing the risk of breakage, moisture issues, and mold growth.

Master bathroom floor

Porcelain tile (price does not exceed 1,000 bath/sq.m.)

General bathroom floor

Porcelain tile (price does not exceed 500 bath/sq.m.)

Elder bathroom floor

Porcelain tile (price does not exceed 500 bath/sq.m.)

Maid bathroom floor

Porcelain tile (price does not exceed 300 bath/sq.m.)

Luxury ll Section 5 General Construction Materials and Equipment

Kitchen floor/ Laundry floor (if any)

43

Porcelain tile (price does not exceed 500 bath/sq.m.) with PVC floor skirt or equal

Maid room floor/ storage room floor

Porcelain tile (price does not exceed 300 bath/sq.m.) with PVC floor skirt or equal

Main entrance terrace

Porcelain tile (price does not exceed 1,000 bath/ sq.m.) with aluminum stair nose

General terrace floor

Porcelain tile (price does not exceed 500 bath/sq.m.) with aluminum stair nose

44

Luxury ll Section 5 General Construction Materials and Equipment

Waterproofing system for terrace/balcony/toilet floor

the paint type waterproofing system, TOA Cement Waterproof with fiberglass mesh or equal will be applied.

Feature : Flexible waterproof cement ensures 100% leak protection, ideal for waterproofing and protecting concrete surfaces. www.toagroup.com/th

Parking floor / Entrance/ Footpath

Ceramic tile by “Bezen”: Rome Street Nano size 4”x4”

Washing area

Porcelain tile (price does not exceed 300 bath/sq.m.) with aluminum stair nose (If any)

Luxury ll Section 5 General Construction Materials and Equipment

45

Wall Decoration Materials

Feature : Highly durable and strong, reducing the risk of breakage, moisture issues, and mold growth.

Master bathroom wall

Porcelain tile (price does not exceed 1,000 bath/sq.m.) height does not exceed 2.80 m. with stainless steel or aluminum tile trim or 45-degree mitered tile corners

Elder bathroom wall

Porcelain tile (price does not exceed 500 bath/sq.m.) height does not exceed 2.80 m. with stainless steel or aluminum tile trim or 45-degree mitered tile corners

Maid bathroom wall

Porcelain tile (price does not exceed 300 bath/sq.m.) height does not exceed 2.40 m. with PVC tile trim

Decorated wall (If any)

Natural color granite “BEZEN” or “KENZAI” model as drawing specified (price does not exceed 2,500 baht/ sq.m.) or equal, spaced grooves Feature : Homogeneous porcelain ceramic tiles - quartz stone strength comparable. Scratch-resistant, long-lasting, and easy to clean. www.bezenceramictiles.com

Luxury ll Section 5 General Construction Materials and Equipment

46

Ceiling General interior ceiling

Height not exceed 3.00 m. Beveled edge gypsum board 9 mm. thick by “SCG” with galvanized metal studs#26. 2 set of 60x60 cm. instant service access on the second-floor ceiling.

Feature : Fire-resistant with a smooth, even surface that is visually appealing. www.scgsmartliving.com

Maid room/ Storage room ceiling

Beveled edge gypsum board 9 mm. thick by “SCG” with galvanized metal studs#26

Ceiling for bathroom

Beveled edge gypsum board, moisture resistant type, 9 mm. thick by “SCG” with galvanized metal studs #26

Roof tile

Concrete roof tile model Adamas Tile, chalet shake or smooth tile model with Metallic color (Shining sapphire, Shining emerald) or Platinum color (Sunny red, Brightly brown) the color chosen later with “Dry ridge system”, stainless #24 for valley rafter.

In case of polished concrete roof, the paint type waterproofing system, TOA PU Waterproof with fiberglass mesh or equal will be applied. feature : Flat concrete tiles with triple water-blocking layer Feature : that effectively prevents rainwater backflow. Wet on Wet color coat system, ensuring deep color absorption and long-lasting durability. www.dbp.co.th

Luxury ll Section 5 General Construction Materials and Equipment

47

Door and window accessories Handle / Lock set for general interior doors/ kitchen door/ garage door

Stainless steel mortise lock set by “HAFELE”: 902.92.044 with dead lock key model 911.02.153 or equal with stainless steel door stopper

Maid room door

Stainless steel mortise lock set by “MATURE”: MTL-001-C or equal with stainless steel door stopper model MDH-006 or equal.

Maid bathroom door

Stainless steel knob by “MATURE”: MK-012-B SS (eco) or equal with stainless steel door stopper model MDH-006 or equal.

Hinge for general doors/ Maid bathroom door

Stainless steel butterfly hinge by “HAFELE”:926.96.100 or equal, 4 pieces/door

Bathroom door

Hinge and lockset by “TOSTEM” or equal

48

Luxury ll Section 5 General Construction Materials and Equipment

Hung type sliding door (if any) by “TOSTEM” or equal

SANTARY WARE

“AMERICAN STANDARD” or COTTO” (White color) or equal (as specified by company) Feature : Efficient flushing system for thorough cleaning without residue, along with advanced surface coating innovation that ensures it looks as good as new even after 100 years

Water closet

Master bathroom by AMERICAN STANDARD : PLAT Smart Toilet Music & Auto Seat 2021-WT-9 with 2 function rinsing spray model DuoSTiX A-4800CH-WT chromium color

Water closet Maid bathroom by AMERICAN STANDARD : NEW WINSPLUS 2698SCW-WT-0 with rinsing spray model A-4800-WT, white color

Urinal

AMERICAN STANDARD : LYNBROOK CCAS6519-3120410F0 with automatic electronic flush valve (in 1 bathroom downstairs)

Luxury ll Section 5 General Construction Materials and Equipment

49

Bathtub

For Master bathroom only, AMERICAN STANDARD : PLAZA TF-8190-WT with wall mount mixer faucet and shower set model SIGNATURE A-1712-300 (with hot water pipe)

Wash basin

For master bathroom, AMERICAN STANDARD: FECILITY DOUBLE WP-F521H-WT, over the counter type For general bathroom AMERICAN STANDARD : ACACIA SUPASLEEK WP-F420-WT, over the counter type For maid bathroom, AMERICAN STANDARD : LOVEN 0262-WT-0, wall hung type

Wash basin mixer faucet

For master bathroom, AMERICAN STANDARD : ACACIA EVOLUTION A-1305-100 For general bathroom AMERICAN STANDARD : ACACIA EVOLUTION A-1301-100

50

Luxury ll Section 5 General Construction Materials and Equipment

Wash basin faucet

For maid bathroom AMERICAN STANDARD : ARC A-J55-10

Bathroom counter

For general bathroom counter topped with African black color granite stone, counter edge topped with porcelain tile same as the wall.

Wall mounted mixer faucet for shower

For master bathroom, AMERICAN STANDARD : ACACIA EVOLUTION MONO A-1312-300B with rain shower set model MOONSHADOW H20S A-6110-978-906 For general bathroom AMERICAN STANDARD : SIGNATURE A-1712-300 with shower head set

Luxury ll Section 5 General Construction Materials and Equipment

Wall mounted faucet for shower

For maid bathroom AMERICAN STANDARD : WINSTON FFAST6047T1500BT0

Wall mounted faucet

For master bathroom, general bathroom and maid bathroom AMERICAN STANDARD : WINSTON FFAST602-0T0500BT0 (1 for each bathroom)

Towel bar

For master bathroom and general bathroom AMERICAN STANDARD : ACACIA EVOLUTION K-1393-46-N For maid bathroom AMERICAN STANDARD : CONCEPT ROUND K-2801-46-N

Soap holder

For master bathroom and general bathroom AMERICAN STANDARD : ACACIA EVOLUTION K-1382-42-N For maid bathroom RASLAND : RA-BENZ-9894

51

Luxury ll Section 5 General Construction Materials and Equipment

52

Tissue holder

For maid bathroom AMERICAN STANDARD : ACACIA EVOLUTION K-1387-55-N chromium color For maid bathroom RASLAND : RA-822626

Shelf

For maid bathroom RASLAND : RA-B30044

Mirror

For master bathroom and general bathroom AMERICAN STANDARD : GRACE LQ-04 For maid bathroom COTTO : MM006

Bathroom floor drain

For master bathroom and general bathroom, odor trap chrome plated brass floor drain by AMERICAN STANDARD : A-8204-N, 2 for each bathroom

Luxury ll Section 5 General Construction Materials and Equipment

53

WATER

PVC pipes by SCG or THAI PIPE

Waste water/ Drain

4” dia. PVC pipe (class 8.5) for sewage pipe. 2” dia.

PVC (class 8.5) for drainage pipe and 3” dia. for main pipe (class 8.5)

Ventilation pipe

1” dia. PVC pipe (class 5.0)

Rain-water drainage

2” dia. PVC pipe for branch rainwater pipe and 3” dia. for main water pipe (class 8.5). 2” Skull shape stainless steel floor drain for balcony or concrete slap roof.

Luxury ll Section 5 General Construction Materials and Equipment

54

SANITARY SYSTEM

Drainage pipe

Asbestos cement pipe dia. 8” to public drain (Not exceed 40.00 m. long from the house).

Manhole

30x40 cm. precast manhole every 6.00 m. interval and every bends or corners.

Luxury ll Section 5 General Construction Materials and Equipment

55

ELECTRICITY SYSTEM

Electric cables and equipment comply with the Standard of Metropolitan Electricity or Provincial Electricity Authority. Electricity cable by THAI YASAKI or equal.

Main income wiring

PVC insulated single copper wiring (KV-CV#50 sq.mm.) The length from wall to meter not exceed 40.00 m (put in PE conduit dia. 2” underground).

Feature : Durable electrical wires, flame resistance withstand higher temperatures compared to standard wires. www.thaiyazaki.com

Main income telephone wiring

Four cores wiring not exceed 40.00 m. from meter to the house put in PE conduit ½” underground.

Internal wiring

Single copper wiring with PVC insulated with yellow PVC conduit in wall or on ceiling.

Air condition wiring

Maximum 6 points wiring

56

Luxury ll Section 5 General Construction Materials and Equipment

Control panel

32 Amps. 36 circuit breaker by “HACO”: HLC-100/36 with main breaker model HM3-100S32 or equal with Residual Current Device (RCBO).

Lighting switch

Flat wall mounted lighting switch by “HACO” switch cover Qx W1931 / W1932, 1 way switch model W2711 (ST-MSB-SBL-STP) install 2 switches for 1 room, 3 switches for master bedroom, 1 switch for kitchen, maid room, storage room, bathroom, laundry. 2-way switch model W2711 (ST-MSB-SBL-STP) only at stair hall. Select 1 color from White, Matt Black (ST), Matt Grey (MSB), Matt Dark (SBL), Taupe (STP)

Luxury ll Section 5 General Construction Materials and Equipment

57

Receptacle

Flat wall mounted receptacle by “HACO” 3 slots cover model Qx W1933 and 3 pin receptable model W8416V2 (ST-MSB-SBL-STP), install 3 for master bedroom, living room and kitchen, 2 outlets for general bedroom, 1 for bathroom, laundry, upper hall (except storage room). Select 1 color from White, Matt Black (ST), Matt Grey (MSB), Matt Dark (SBL), Taupe (STP)

Exterior receptacle

2 sets of flat wall mounted receptacle by “HACO” 3 slots cover model Qx W1933 and 3 pin receptable model W8416V2 (ST-MSB-SBL-STP) with soft rubber waterproof case model IPW553-WH / IPW553-ST. Select 1 color from White, Matt Black (ST)

Telephone outlet

2 sets of flat wall mounted telephone outlet by “HACO” cover model Qx W1931 (ST-MSB-SBL-STP) and 6 core telephone outlet RJ12 model PR-P024 W8201TU. Select 1 color from White, Matt Black (ST), Matt Grey (MSB), Matt Dark (SBL), Taupe (STP)

T.V. outlet

2 sets of Flat wall mounted T.V. outlet by “HACO” cover model Qx W1931 (ST-MSB-SBL-STP) and 75 ohm T.V. outlet model W8201TV. Select 1 color from White, Matt Black (ST), Matt Grey (MSB), Matt Dark (SBL), Taupe (STP)

Luxury ll Section 5 General Construction Materials and Equipment

58

LAN outlet

5 sets of Flat wall mounted LAN outlet by “HACO” cover model Qx W1931 (ST-MSB-SBL-STP) and CAT6 LAN outlet model W8211PC. Select 1 color from White, Matt Black (ST), Matt Grey (MSB), Matt Dark (SBL), Taupe (STP)

Emergency light

2 sets of twin LED lamp head emergency light at stair hall or as drawing specified.

Luminaire

Total budget not over 80,000 Baht

Luxury ll Section 5 General Construction Materials and Equipment

59

ELECTRICITY AND WATER METER

Permanent electric meter

30 Amps 3 phases meter. Fee and meter deposit covered by company. (Exclude the service area extension fee) Feature : Ideal for large home with high-power electrical appliances. Help prevent phase overloads.

Permanent water meter

3/4” Diameter meter, Fee and meter deposit covered by company.

(Exclude the service area extension fee)

Luxury ll Section 5 General Construction Materials and Equipment

60 PAINTING

BY TOA

External wall

External acrylic paint “TOA”: Supershield or equal, 1 primer and 2 final coated Feature : Resistant to mold, algae, salt stains, and cement marks also protects against corrosion from pollutants, peeling, and powdering. www.toagroup.com/th

Internal wall

Internal acrylic paint “TOA”: Supershield Duraclean A+ or equal,1 primer and 2 final coated Feature :Washable paint, bacteria-free and odorless, promoting fresh air. Safe from harmful fumes, it inhibits 99.99% of bacteria and mold growth. www.toagroup.com/th

Steel surface/HDF panel

Emulsion paint “TOA”: Glipton or equal 1 primer and 2 final coated

Facia/Fiber Cement Board

External acrylic paint “TOA”: Supershield or equal,1 primer and 2 final coated

Luxury ll Section 5 General Construction Materials and Equipment

OTHER WORK

Termite protection system

“BYER” : Agenda termite chemical or equal spray on ground and 1 meter around the building. Springer system and PVC tube piping for termite protection chemical is installed beneath the first floor structure for termite protection chemical.

Tile adhesive

Glue cement by SCG, WEBER, CROCODILE or equal

61

62

63

64

65

06 Warranty

66

Luxury ll Section 6 Warranty

Structure

20 year warranty

General work

2 year warranty exclude natural depreciation of materials due to long used and misused Remarks : The company reserves the right to change the list if needed but the price of the materials is not less than that stated above. The cost of the construction does not include: Old building demolition Interior decoration and garden Air conditioner system.

Water drainage outside the construction site. Mosquito net, door and window steel bars, rain gutter.

Smart ll หมวดที่​่� 6 การรั​ับประกั​ัน

68
