WEIGHING & EID

Electronic Weighing and EID

Weighing livestock gives you the ability to monitor average daily liveweight gain and body condition, measure feed allocation and input costs, administer animal health products correctly, identify poor performing animals early on, as well as making better management and breeding decisions.

Iconix Weighing Systems

Iconix weighing equipment, manufactured in New Zealand since 1982 and proven globally, provides an accurate, cost effective and easy to use weighing solution for livestock. Pasturetec are proud to have been appointed as the distributor for Iconix weighing equipment for the UK and Ireland.

FX1 Indicator

The FX1 is the entry level electronic weighing system. Simplicity itselfjust turn it on and “you’re weighing”.

Features:

• Auto zero at switch-on

• Intelligent zero-tracking. Dirt build-up while weighing is automatically zero-tracked out.

• Tough, weatherproof case rated to IP65

• Mounting bracket is included

• Powered by external 12V battery - battery lead supplied

• Optional AC adaptor for mains

FX15+ Indicator

operation

• Low battery indicator

• Auto ‘low voltage’ shut down

• Weighs up to 2000kg with standard loadbars

Specifications:

• Supply voltage = 11.5V to 19V DC

• Low battery indication = 11.4V DC

• Automatic scale base selection

• Accuracy: +/- 0.5% of displayed reading +/- 1 division where 1

The Iconix FX15+ is the new generation livestock weighing system that follows on from the very popular FX15. It provides significantly upgraded features, while retaining excellent ease of use.

Simple one-step weighing: on pressing WEIGH, the animal is accurately weighed and the result locked on the display. A new weight record is added to memory and statistics are updated.

Features:

• Large LCD display with 5 digits 30mm high

• Internal rechargeable battery giving 10 to 12 hours of portable weighing

• Bluetooth – allows connection to EID readers and smartphones division = 0.2kg, 0.5kg etc depending on weight range

• Temperature range = -5°C to +50°C

• A DRAFT limit can be set to allow sorting of animals into high or low weight ranges

• STATS key allows easy scrolling through statistics at any tiem during the weighing session

• Dimensions – 280 x 186 x 90mm (excluding bracket)
