PROJECT 2 | INEX

a captivating art gallery for a captivated audience nicole rodriguez | fall 2018

Table of Contents interactions

01 - 03

project info

04 - 10

artist | client

11 - 13

concept formulation

14 - 16

component study

17 - 23

design proposal

24 - 36

interactions

01

interactions | Body Studies 02

This study looked at an analysis of the posture of the human body in two spaces: an art gallery and a cafe.

It was concluded that there can be a categorization of two parties in these spaces, the captive audience and the active audience.

From this, it was understood the various head movements and body movements that dictated whether the subject is an active audience member or a captive audience member.

The captive audience tends to be more secluded and involved with just the art and nothing else, essentially being captivated by the art. Similarily, in the cafe setting the captive audience generally waited for their drinks while being on their cellphones, again captivated by their cellphone The active audience was not necesseraily uninterested in the art itself, but was more expressive of how they observed the art. For example, reaching out to point at something or discussing art with another active audience member.

03

project info

04

project info | program 05

Mixed-use artist studio and gallery General Requirements: > 1500 SF Artist Studio—workspace (not living) > 1500 SF Gallery > 1800 SF footprint, maximum, for a 2-story facility

exhibition/gallery

gallery office

Mechanical room: > 2 Entries/Exits from all levels > All levels accessible > Delivery / Receiving Area for transportation of materials and art > 2 Parking Spaces

studio public unisex restrooms (1st & 2nd lvl.)

Artist Studio area includes: > Studio workspace > Unisex Toilet > Work Room with utility sinks and cabinets > Storage as appropriate for the artist’s work process and media

Food prep/small kitchen studio storage/gallery storage Program Distribution Diagram

Gallery area includes: > Multiple exhibition areas > Gallery Storage > Public Unisex Toilet > Utility Closet > Small Gallery Office > Small food storage and prep area

delivery/receiving

studio storage/gallery storage mechanical room elevator utility closet

06

77 north park square, marietta, ga

N

Site Plan 1/16” = 1’0”

project info | site 07

Site Context Analysis Diagram

08

Identifying the Captive Audience Study 01 indicates the pattern of use on the site of the captive audience vs the pattern of use of the active public. Essentially identifying their frequent commute around the site and how consist these patterns are.

The captive public is characterized as single people or pairs that are generally isolated from their environment in terms of being consciously in the space. Study 02 highlights moments when a person becomes aware that they are in a space and when a person is no longer “captivated�.

project info | site study 09

Study 01

Study 02

10

artist

11

http://tomi.crewpulse.co/ai-weiwei-works/

artist | ai wei wei 12

http://tomi.crewpulse.co/ai-weiwei-works/

The Artist | The Client

The Art in Context to the Site Study

Ai Wei Wei is a contemporary artist and activist. As an activist, he brings attention to human rights violation on a massive scale; as an artist, he expands the concept of art to include new forms of social engagement.

In context to Wei Wei’s work -- he has large scale captivating art and sculptures that bring the attention of people to the art through thought provoking themes, this idea of captivating art is the driving factor for the study conducted and the formation of the concept for the art gallery as a means to captivate the people of Marietta.

Wei Wei creates massive works of art that reflect the human scale and allow for people to reflect on the human rights violation he is bringing awareness to.

13

concept formulation

14

Subverting Interior and Exterior Spaces As an initial push to the design process, the concept collage questioned “what if the outside was brought inside?�

The collage essentially became the catalyst for the overall concept of the art gallery, the idea of subverting the relationship between interior and exterior spaces.

In order to generate some type of experiential or spatial condition with this idea in mind, the component was developed.

concept formulation | concept collage 15

16

component study

17

Initial Component Diagram

Materiality Sketches

component study | conceptual diagrams 18

Connectivity and Component as a System

Spatial Explorations of Component

19

component study | component model 20

21

Mobility of Component through Track System

component study | component development 22

Structural Detail Connection of Component

23

design proposal

24

design proposal | program 25

exhibition/gallery

gallery office studio public unisex restrooms (1st & 2nd lvl.) delivery/receiving Food prep/small kitchen studio storage/gallery storage studio storage/gallery storage mechanical room elevator utility closet

26

mech. closet bath

office

food prep storage

delivery

exhibition 2

exhibition 2

restroom restroom

studio

exhibition 1

studio

N

Site Plan 1/8”=1’0”

design proposal | Plans and material analysis 27

First Floor Plan 1/4”=1’0”

Second Floor Plan 1/4”=1’0”

Facade Material Diagram

glass

white panel mirror frosted glass

28

Longitudinal Section

design proposal | sections and elevations 29

Cross Section

30

Concept Statement The designed art gallery subverts the relationship between interior and exterior spaces, through a series of moveable panels, the art gallery generates opportunites of varying spatial conditions.

With a facade that essentially erodes into the art gallery, this blurred line between what is perceived as “outside” and “inside” is the core of the gallery itself.

design proposal | inex 31
