Oil-free
Synchronous drum motors NGI A/S
NGI Italy
NGI Inc. USA
NGI GmbH (Germany)
Virkelyst 5
Via Guglielmo Jervis 4
250 S. Fairbank St.
Madrider Straße 2
DK-9400 Nørresundby
IT-10015 IVREA TO
Addison, IL 60101 USA
DE-41069 Mönchengladbach
T: +45 98 17 45 00
T: +39 077 568 7010
T: +1 (646) 201 9410
T: +45 98 17 45 00
E: ngi@ngi-global.com
E: ngi@ngi-global.com
E: sales@ngi-global.com
E: ngi@ngi-global.com
ngi-global.com
Rev 102026
Synchronous Drum Motors Drum motor series Two series. Four shared sizes. Power & torque upgrade opportunities.
MTS drum motor
The MTS and HMTS drum motors share the same proven motor technology and performance. Our two series allow you to choose the level of hygienic performance that best matches your application. Both series are available across four drum motor sizes: 62, 82, 113, and 138.
MTS drum motor Our MTS Series is built around proven drum motor technology, the MTS features a hygienic design suitable for a wide range of food processing applications, delivering reliable performance and easy cleaning.
HMTS drum motor (NEW!) Our HMTS Series builds on the same proven motor platform as the MTS, with an advanced hygienic design engineered for the most demanding environments in food production. A closed design, robust sealing and increased mechanical robustness support effective cleaning and reliable performance, even under demanding washdown conditions.
Power & Torque Upgrades Configure performance to match your application Our drum motors are available with power (P), torque (T), and combined power & torque (PT) upgrades, enabling optimized performance for demanding applications.
Power upgrades (P) increase power density and support reliable operation in demanding inverter-driven applications with high peak voltages.
HMTS drum motor
Torque upgrades (T) provide higher torque output, particularly at low and medium speeds and under heavy loads.
Combined power & torque upgrades (PT) enhance both electrical and mechanical performance for reliable operation under demanding conditions.
Sizes & Data overview Size
2
Gear ratio
Rotational Speed
Linear Speed
Torque
Power
[rpm]
[ft/s]
[lbf·ft]
[hp]
Performance indicator
Min. Shell Length MTS Series [in]
Min. Shell Length HMTS Series [in]
MTS/HMTS 62
8–80
56–563
0.6-5.9
1.5-14.3
0.17
N
9.33-10.35
11.97–12.95
MTS/HMTS 82
5–160
19–600
0.3-8.4
2.2-32.5
0.25-0.80
N/P
7.60-12.40
11.85–14.49
MTS/HMTS 113
8–160
19–375
0.4-7.2
3.4-88.5
0.25-1.50
N / P / PT / T
9.69-14.49
11.85–16.61
MTS/HMTS 138
10–160
19–300
0.4-7.0
14.9-191.8
0.90-2.10
N / P / PT
11.18-17.17
13.35–19.61
New
3
Table of content MTS62
Diameter:
in
Gear ratio: Rotational Speed:
rpm
Linear Speed: Torque:
2.4 8 - 80 0.6 - 5.9
Linear Speed:
ft/s
0.6 - 5.9
lbf·ft
1.5 - 14.3
Torque:
lbf·ft
1.5 - 14.3
0.17 9.33 - 10.4
in
3.19 5 - 160
Rotational Speed:
rpm
Linear Speed: Torque:
Power: HP
6
0.17
Performance Indicator: Min. shell length:
HMTS82
in
N
11.97–12.95
Diameter:
in
3.19
19 - 600
Rotational Speed:
rpm
19 - 600
ft/s
0.3 - 8.4
Linear Speed:
ft/s
0.3 - 8.4
lbf·ft
2.1 - 32.5
Torque:
lbf·ft
2.1 - 32.5
0.25 - 0.80 N/P 7.6 - 12.4
in
4.41
Gear ratio:
8 - 160
Power: HP
10
Performance Indicator: Min. shell length:
HMTS113
Special Features
in
0.25 - 0.80 N/P 11.85–14.49
Diameter:
in
4.41
Gear ratio:
8 - 160
rpm
19 - 375
Rotational Speed:
rpm
19 - 375
Linear Speed:
ft/s
0.4 - 7.2
Linear Speed:
ft/s
0.4 - 7.2
Torque:
lbf·ft
3.4 - 88.5
Torque:
lbf·ft
0.25 - 1.50
Power: HP
Performance Indicator: Min. shell length:
N / P / T / PT
in
9 - 14.5
in
5.35
20
HMTS138
Special Features Diameter:
3.4 - 88.5 0.25 - 1.50
Performance Indicator:
N / P / T / PT
Min. shell length:
in
11.85–16.61
in
5.35
Diameter:
10 - 160
Gear ratio:
10 - 160
Rotational Speed:
rpm
19 - 300
Rotational Speed:
rpm
19 - 300
Linear Speed:
ft/s
0.4 - 7.0
Linear Speed:
ft/s
0.4 - 7.0
Torque:
lbf·ft
14.9 - 191.8
Torque:
lbf·ft
14.9 - 191.8
0.9 - 2.1
Performance Indicator:
N / P / PT
Min. shell length:
in
11.18 - 17.17
28
48
Special Features
Gear ratio:
Power: HP
40
Special Features
Rotational Speed:
Power: HP
36
Special Features 5 - 160
in
Diameter:
56 - 563
Gear ratio:
Performance Indicator:
MTS138
N
in
Power: HP
MTS113
2.4 8 - 80
ft/s
Gear ratio:
Min. shell length:
in
Gear ratio: rpm
Special Features Diameter:
Diameter: Rotational Speed:
Performance Indicator: Min. shell length:
Special Features
56 - 563
Power: HP
MTS82
HMTS62
Special Features
Power: HP
0.9 - 2.1
Performance Indicator:
N / P / PT
Min. shell length:
in
13.35–19.61
56
Cable and Feedback systems An overview of cable and feedback options across all NGI drum motor series, sizes, and power/torque upgrades.
64 4
5
The World’s Smallest Oil-Free Drum Motor.
MTS62 Synchronous Drum motor
MTS62
Small in size. Big on performance. With a diameter of just 2.4 inches, the MTS62 is the most compact oil-free drum motor available today engineered for hygiene, precision, and space-constrained applications where traditional drives fall short. Its fully sealed, maintenance-free design integrates motor and transmission inside the drum, eliminating external components and contamination risks. Despite its slim profile, the MTS62 delivers consistent torque across all speeds thanks to advanced synchronous technology. It’s ideal for tight transfers, packaging lines, and inspection systems, offering reliable performance without compromising on control or footprint. Designed for low-load, high-precision applications, it also supports optional servo-level feedback for enhanced positioning accuracy.
MTS drum motor
MTS drum motor
Oil-free
Oil-free
Applications: Food Processing Systems: Tight transfers for small or delicate items, minimizing gaps and ensuring product integrity. Packaging Machines: Space-efficient solutions for narrow conveyors in automated packaging systems. Check Weighing & Inspection Systems: Precision-driven operations requiring compact, reliable drive solutions. Why choose MTS62: Slim size, high torque Optional servo-level feedback Maintenance-free and sealed for hygiene 130 W continuous power
Lower energy consumption Oil free - minimize the risk of oil leaks Higher motor efficiency Enhanced food safety
6
7
Drum motor - MTS62 Class
Standard variant - MTS62 Rated values refer to the drum shell. Custom gear combinations on request.
AGL = SL +1.46”
Motor Variant MTS62-0.17-N
EL = SL +0.47” FW = SL +0.28”
Power
SL
B
0.17
B
0.14” 1/3
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
8
563
355
5.9
1.5
15
9.33
[hp]
A
B
MG = 0.1”
Gear ratio
1/3
Ø0.98”
0.17
12
375
236
3.9
2.3
23
9.84
0.17
16
281
177
3.0
3.1
31
9.84
0.17
25
180
113
1.9
4.7
47
9.84
0.17
32
141
89
1.5
6.1
60
9.84
0.17
40
113
71
1.2
7.5
75
9.84
0.17
60
75
47
0.8
11.0
110
10.35
0.17
80
56
35
0.6
14.3
143
10.35
Power and Torque upgrades currently not available for MTS62
Explanations: FW = Face width MG = Distance between End Cap and Key Flat
AGL = Total length of shaft SL = Shell length (Reference length / ordering length) EL = Installation length
Crowned
Motor Data - Standard Variant (N)
ØA
ØB
Shell length max.
[in]
[in]
[in]
2.46
2.40
25.6
hp
0.17
Rated speed
rpm
4500
Rated frequency
Hz
150
Number of pole pairs
2
Wiring
Y
Insulation class
F
Supply voltage range
1 x / 3 x VAC
200…480
VDC
280…680
Cylindrical
2.40
2.40
25.6
DC Bus voltage range
Cylindrical with key
2.47
2.47
25.6
Rated voltage
3 x VAC
159
Rated torque
lbf·ft
0.20
Rated current per phase
A
0.6
Stall torque
lbf·ft
0.30
Stall current per phase
A
0.9
Peak torque
lbf·ft
0.96
Peak current
A
3.0
Voltage constant
V / 1.000 rpm
29.4
Torque constant
lbf·ft / Arms
0.32
For designs outside of these specifications, please reach out to your local NGI sales representative.
Feedback systems are options which increase the minimum shell length as shown below. Feedback unit
Minimum shell length addition [in]
Resolver
2.68
SKS36
3.43
EKS36/EDS36
2.83
ECI 1119
3.58
The MTS62 is only available with feedback systems in combination with hybrid cables.
8
Rated power
Winding resistance (2 phases)
Ω
36.9
Winding inductance (2 phases)
mH
19.6
Electrical time constant
ms
0.8
Moment of inertia rotor
lb in2
0.30
Anti condensing heating voltage
VDC
34
MTS drum motor
MTS drum motor
Type
0.87”
9
Clean. Efficient. Oil-free.
MTS82 Synchronous Drum motor
MTS82
With a diameter of just 3.19 inches, the MTS82 is a compact, oil‑free drum motor for hygienic environments and demanding conveyor applications. Its fully enclosed, maintenance‑free design integrates motor and transmission inside the drum, eliminating external components and contamination risks.
MTS drum motor
MTS drum motor
Powered by synchronous motor technology, the MTS82 delivers high torque at low speeds with minimal energy consumption. It supports multi‑speed dimensioning, sensorless precise positioning, and optional feedback systems for closed‑loop control and indexing. Digital nameplate options enable plug‑and‑play installation. The MTS82 is suitable for both standalone conveyors and high‑precision machinery, reliably handling low‑ Oil-free to mid‑range loads in food production and automation systems. MTS82 is also available in a Compact version: The Compact MTS82-0.25 is NGI’s shortest drum motor, optimized for short motor lengths and tight installations in space constrained conveyor systems. Applications: Food Production Lines: Hygienic conveyors for raw or packaged goods. Automated Sorting Lines: Compact drives for high-speed sorting and inspection stations. Check Weighing Systems: Precision-driven conveyors for compliance-critical operations. Pharmaceutical Packaging: Compact drives for blister packs and precision filling systems. Why choose MTS82: Compact size with powerful performance High torque at low speeds Maintenance-free and oil-free for hygienic environments Supports feedback and servo drive integration Energy-efficient and easy to install Power and torque upgrade variants available for demanding applications.
10
Oil-free
Lower energy consumption Oil free - minimize the risk of oil leaks Higher motor efficiency Enhanced food safety
11
Drum motor - Compact MTS82-0.25
Standard variants – Compact MTS82-0.25 Rated values refer to the drum shell.
AGL= SL+1.34” EL= SL+0.35” FW= SL+0.16” SL
Motor Variant Compact MTS82-0.25-N 1.42”
Ø2.3”
Power
Gear ratio
[hp]
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
0.25
5
600
502
8.4
2.2
16
7.60
0.25
8
375
314
5.2
3.4
26
7.60
0.25
12
250
209
3.5
5.1
38
8.11
0.25
16
188
157
2.6
6.8
51
8.11
MG= 0.1”
0.25
20
150
126
2.1
8.5
64
8.11
0.08”
0.25
25
120
100
1.7
10.5
79
8.11
0.25
32
94
79
1.3
13.5
101
8.11
0.25
40
75
63
1.0
16.6
125
8.741
1
Optional minimum shell length of 8.11 in with torque output up to 14.8 lbf·ft / 111 LBF Belt pull.
Explanations: FW = Face width MG = Distance between End Cap and Key Flat
AGL = Total length of shaft SL = Shell length (Reference length / ordering length) EL = Installation length
The Compact MTS82-0.25 drum motor is fitted with a cable box and pre-installed power cable. MTS drum motor
MTS drum motor
For custom and replaceable power cables, a standard terminal box is available, maintaining the minimum shell length.
Type
Crowned
ØA
ØB
Shell length max.
[in]
[in]
[in]
3.20
3.17
47.24
Cylindrical
3.19
3.19
47.24
Cylindrical with key
3.22
3.22
33.46
Other dimensions or shell profiles on request.
A cable gland connection and feedback systems are options which increase the minimum shell length as shown below. Feedback unit
12
Minimum shell length addition [in]
Sensorless & cable gland
1.54
EDS35 or EKS36 & cable box
1.69
13
Drum motor - MTS82 Class
Standard variants - MTS82 Rated values refer to the drum shell. Custom gear combinations on request for all models.
AGL = SL +1.5” EL = SL +0.5”
Motor Variant MTS82-0.25-N
FW = SL +0.3”
Power
SL B
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp] A
B
0.25
5
600
502
8.4
2.2
16
10.16
0.25
8
375
314
5.2
3.4
26
10.16
0.25
12
250
209
3.5
5.1
38
10.63
0.25
16
188
157
2.6
6.8
51
10.63
0.25
20
150
126
2.1
8.5
64
10.63
0.25
25
120
100
1.7
10.5
79
10.63
0.25
32
94
79
1.3
13.5
101
10.63
B MG = 0.1”
0.25
40
75
63
1
16.6
125
10.63
0.14”
0.25
160
19
16
0.3
32.5
244
11.14
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
600
502
8.4
4.3
33
11.34
1/3
1/3
Ø1.2”
1/3
Explanations: FW = Face width MG = Distance between End Cap and Key Flat
AGL = Total length of shaft SL = Shell length (Reference length / ordering length) EL = Installation length
1.0” SECTION B-B
Motor Variant MTS82-0.50-N Power
Gear ratio
[hp] 0.50 0.50
8
375
314
5.2
6.9
52
11.34
0.50
12
250
209
3.5
10.2
77
11.81
0.50
16
188
157
2.6
13.6
102
11.81
0.50
20
150
126
2.1
17.0
128
11.81
0.50
25
120
100
1.7
21.0
158
11.81
0.50
32
94
79
1.3
26.9
202
11.81
0.50
40
75
63
1
29.5
222
11.81
160
19
16
0.3
32.5
244
12.32
ØA
ØB
Shell length max.
[in]
[in]
[in]
Crowned
3.20
3.17
47.24
Cylindrical
3.19
3.19
47.24
0.50
Cylindrical with key
3.22
3.22
33.46
MTS drum motor
MTS drum motor
Type
5
For designs outside of these specifications, please reach out to your local NGI sales representative.
Feedback unit
14
Minimum shell length addition [in]
Resolver - 2 Cables
1.73
Resolver - Hybrid Cable
2.60
DBS36 - 2 Cables
3.07
DBS36 - Hybrid Cable
3.94
SKS36 - 2 Cables
2.48
SKS36 - Hybrid Cable
3.35
EKS36/EDS35 - Hybrid Cable
2.76
ECI 1119 - 2 Cables
2.64
ECI 1119 - Hybrid Cable
3.54
15
Power upgrade variants - MTS82 Rated values refer to the drum shell. Custom gear combinations on request for all models.
Motor Variant MTS82-0.34-P Power
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp] 0.34
5
600
502
8.4
2.9
22
9.69
0.34
8
375
314
5.2
4.6
34
9.69
0.34
12
250
209
3.5
6.8
51
10.20
0.34
16
188
157
2.6
9.1
68
10.20
0.34
20
150
126
2.1
11.3
85
10.20
0.34
25
120
100
1.7
14.0
105
10.20
0.34
32
94
79
1.3
17.9
135
10.20
0.34
40
75
63
1.0
22.2
167
10.20
0.34
160
19
16
0.3
32.5
244
10.71
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
600
502
8.4
5.1
38
10.67 10.67
Motor Variant MTS82-0.60-P Power
Gear ratio
[hp] 0.60
5 8
375
314
5.2
8.0
60
12
250
209
3.5
11.9
90
11.18
0.60
16
188
157
2.6
15.9
119
11.18
0.60
20
150
126
2.1
19.8
149
11.18
0.60
25
120
100
1.7
24.5
185
11.18
0.60
32
94
79
1.3
31.4
236
11.18
0.60
40
75
63
1.0
29.5
222
11.18
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
600
502
8.4
6.5
49
11.89
MTS drum motor
MTS drum motor
0.60 0.60
Motor Variant MTS82-0.80-P Power
Gear ratio
[hp] 0.80
5
0.80
8
375
314
5.2
10.3
78
11.89
0.80
12
250
209
3.5
15.3
115
12.40
0.80
16
188
157
2.6
20.4
153
12.40
0.80
20
150
126
2.1
25.5
192
12.40
0.80
25
120
100
1.7
29.5
222
12.40
0.80
32
94
79
1.3
32.5
244
12.40
Global Sales Support. Built for Execution. You don’t need more options - you need the right one. Our DriveTech Sales Team works account-based and cross-functionally to remove friction in your project: clear scope, clear configuration, clear next steps. From early dialogue to final specification, we help you get it right the first time - so implementation is easier, and performance is predictable.
16
17
Drum motor - MTS82 Class
Drum motor - MTS82 Class
Motor Data - Standard variants (N)
Motor Data - Power upgrade variants (P)
Rated power
hp
0.25
0.50
Rated power
hp
0.34
0.60
0.80
Rated speed
rpm
3.000
3.000
Rated speed
rpm
3000
3000
3000
Rated frequency
Hz
150
150
Rated frequency
Hz
250
250
250
Number of pole pairs
3
3
Number of pole pairs
5
5
5
Wiring
Y
Y
Wiring
Y
Y
Y
Insulation class
F
Insulation class
F
F
F
1 x / 3 x VAC
200 .. 480
200 .. 480
Supply voltage range
1 x / 3 x VAC
200 .. 480
380 .. 480
380 .. 480
DC Bus voltage range
VDC
280 .. 680
280 .. 680
DC Bus voltage range
VDC
280 .. 680
540 .. 680
540 .. 680
Rated voltage
3 x VAC
181
181
Rated voltage
3 x VAC
188
331
333
Rated torque
lbf·ft
0.44
0.89
Rated torque
lbf·ft
0.59
1.03
1.33
Rated current per phase
A
0.8
1.5
Rated current per phase
A
0.9
0.9
1.2
Stall torque
lbf·ft
0.52
1.11
Stall torque
lbf·ft
0.74
1.40
1.92
Stall current per phase
A
0.9
1.8
Stall current per phase
A
1.41
1.39
1.83
Peak torque
lbf·ft
2.07
4.43
Peak torque
lbf·ft
1.84
3.54
4.79
Peak current
A
3.6
7.2
Peak current
A
3.8
3.5
4.4
Voltage constant
V / 1.000 rpm
49.6
51.7
Voltage constant
V / 1.000 rpm
48.1
91.1
97.1
Torque constant
lbf·ft / Arms
0.55
0.59
Torque constant
lbf·ft / Arms
0.66
1.15
1.11
Winding resistance (2 phases)
Ω
26.4
9.8
Winding resistance (2 phases)
Ω
21
24.8
17.9
mH
25.50
37.33
27.10
Winding inductance (2 phases) identical to Ld and Lq
mH
37.6
18.6
Winding inductance (2 phases) identical to Ld and Lq
Electrical time constant
ms
1.4
1.9
Electrical time constant
ms
1.2
1.5
1.5
Moment of inertia rotor
lb in2
0.075
0.140
Moment of inertia rotor
lb in2
0.092
0.167
0.243
Anti condensing heating voltage
VDC
35
26
Anti condensing heating voltage
VDC
49
53
50
MTS drum motor
MTS drum motor 18
F
Supply voltage range
19
Compact. Clean. Efficient. Oil-free.
MTS113 Synchronous Drum motor
MTS113
The MTS113 is a versatile, oil-free drum motor designed for hygienic environments and precision-driven conveyor systems. With a diameter of 4.41 inches and shell lengths starting from 9.69 inches, it fits seamlessly into setups where space, cleanliness, and performance are critical. Its fully enclosed, maintenance-free design keeps all components protected inside the drum, eliminating contamination risks and simplifying cleaning.
Applications: Meat & Seafood Processing: Hygienic, oil-free motors for washdown areas. Bakery & Confectionery Lines: High flexibility for wide belts. Quality Control Stations: Reliable performance for weight-sensitive operations.
Why choose MTS113: Wide power range for versatile applications Compact and hygienic design High torque with low energy consumption Maintenance-free and oil-free Ideal for both standard and precision setups Power and torque upgrade variants available for demanding applications.
20
MTS drum motor
MTS drum motor
Powered by synchronous motor technology, the MTS113 delivers high torque with minimal energy consumption - supporting both sustainability and operational efficiency. Oil-free Covering a wide power range from 0.25 hp to 1.5 hp, the MTS113 is often used with rubber coatings or sprockets for various belt types. It’s suitable for standalone conveyors and precision machinery alike.
Oil-free
Lower energy consumption Oil free - minimize the risk of oil leaks Higher motor efficiency Enhanced food safety
21
Drum motor - MTS113 Class
Standard variants - MTS113 Rated values refer to the drum shell. Custom gear combinations on request for all models.
AGL = SL +1.5” EL = SL +0.5”
Motor Variant MTS113-0.25-N
FW = SL +0.3”
Power
SL B
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp] A
B
B MG = 0.1”
0.25
8
375
434
7.2
3.4
19
10.16
0.25
12
250
289
4.8
5.1
28
10.63
0.25
16
188
218
3.6
6.8
37
10.63
0.25
20
150
174
2.9
8.5
46
10.63
0.25
25
120
139
2.3
10.5
57
10.63
0.25
32
94
109
1.8
13.5
73
10.63
0.25
40
75
87
1.4
16.6
91
10.63
0.25
160
19
22
0.4
32.5
177
11.14
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
0.14” 1/3
1/3
Ø1.2”
1/3
Motor Variant MTS113-0.50-N
Explanations: FW = Face width MG = Distance between End Cap and Key Flat
AGL = Total length of shaft SL = Shell length (Reference length / ordering length) EL = Installation length
1.0” SECTION B-B
Power [hp] 0.50
Crowned
ØA
ØB
Shell length max.
[in]
[in]
[in]
4.47
4.41
51.18
Cylindrical
4.41
4.41
51.18
Cylindrical with key
4.45
4.45
33.46
For designs outside of these specifications, please reach out to your local NGI sales representative.
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
8
375
434
7.2
6.9
37
11.34
0.50
12
250
289
4.8
10.2
55
11.81
0.50
16
188
218
3.6
13.6
74
11.81
0.50
20
150
174
2.9
17.0
92
11.81
0.50
25
120
139
2.3
21.0
114
11.81
0.50
32
94
109
1.8
26.9
146
11.81
0.50
40
75
87
1.4
29.5
161
11.81
0.50
160
19
22
0.4
32.5
177
12.32
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
Motor Variant MTS113-1.00-N Power
Gear ratio
[hp]
Feedback unit
22
Minimum shell length addition [in]
Resolver - 2 Cables
1.61
Resolver - Hybrid Cable
2.52
MTS drum motor
MTS drum motor
Type
Gear ratio
1.00
8
375
434
7.2
13.2
72
11.69
1.00
12
250
289
4.8
19.5
106
12.20
1.00
16
188
218
3.6
26.1
142
12.20
1.00
20
150
174
2.9
32.5
177
12.20
1.00
25
120
139
2.3
29.5
161
12.20
1.00
32
94
109
1.8
32.5
177
12.20
1.00
40
75
87
1.4
29.5
161
12.20
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
DBS36 - 2 Cables
2.95
DBS36 - Hybrid Cable
3.86
SKS36 - 2 Cables
2.28
SKS36 - Hybrid Cable
3.19
Power
EKS36/EDS35 - Hybrid Cable
2.68
[hp]
ECI 1119 - 2 Cables
2.52
1.35
ECI 1119 - Hybrid Cable
3.43
Motor Variant MTS113-1.35-N Gear ratio
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
8
375
434
7.2
13.3
72
12.48
1.35
12
250
289
4.8
27.2
148
12.99
1.35
16
188
218
3.6
32.5
177
12.99
1.35
20
150
174
2.9
32.5
177
12.99
1.35
25
120
139
2.3
29.5
161
12.99
1.35
32
94
109
1.8
32.5
177
12.99
1.35
40
75
87
1.4
29.5
161
12.99 23
Torque upgrade variants - MTS113
Power upgrade variants - MTS113
Rated values refer to the drum shell. Custom gear combinations on request for all models.
Rated values refer to the drum shell. Custom gear combinations on request for all models.
Motor Variant MTS113-1.00-T
Motor Variant MTS113-0.34-P
Power
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
Power
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp]
[hp]
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
1.00
10
300
347
5.8
16.3
89
12.28
0.34
8
375
434
7.2
4.6
25
9.69
1.00
16
188
218
3.6
26.1
142
12.99
0.34
12
250
289
4.8
6.8
37
10.20
1.00
20
150
174
2.9
32.6
177
12.99
0.34
16
188
218
3.6
9.1
49
10.20
1.00
25
120
139
2.3
40.3
219
12.99
0.34
20
150
174
2.9
11.3
62
10.20
1.00
32
94
109
1.8
51.6
281
12.99
0.34
25
120
139
2.3
14.0
76
10.20
1.00
40
75
87
1.4
63.8
347
12.99
0.34
32
94
109
1.8
17.9
98
10.20
1.00
160
19
22
0.4
88.5
482
13.70
0.34
40
75
87
1.4
22.2
121
10.20
0.34
80
38
44
0.7
32.5
177
10.71
0.34
160
19
22
0.4
32.5
177
10.71
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
Motor Variant MTS113-1.35-T Power
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp] 10
300
347
5.8
22.7
123
13.07
1.35
16
188
218
3.6
36.3
197
13.78
1.35
20
150
174
2.9
45.3
247
13.78
1.35
25
120
139
2.3
56.1
305
13.78
1.35
32
94
109
1.8
71.8
391
13.78
1.35
40
75
87
1.4
81.1
442
13.78
1.35
160
19
22
0.4
88.5
482
14.49
Power & Torque upgrade variants - MTS113
Power
Gear ratio
[hp] 0.60
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
8
375
434
7.2
8.0
44
10.67
0.60
12
250
289
4.8
11.9
65
11.18
0.60
16
188
218
3.6
15.9
86
11.18
0.60
20
150
174
2.9
19.8
108
11.18
0.60
25
120
139
2.3
24.5
133
11.18
0.60
32
94
109
1.8
31.4
171
11.18
0.60
40
75
87
1.4
29.5
161
11.18
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
Motor Variant MTS113-0.90-P
Rated values refer to the drum shell. Custom gear combinations on request for all models.
Power
Motor Variant MTS113-0.90-PT
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
0.90
8
375
434
7.2
12.0
65
10.59
0.90
12
250
289
4.8
17.8
97
11.10
0.90
16
188
218
3.6
23.8
129
11.10
0.90
20
150
174
2.9
29.7
162
11.10
0.90
25
120
139
2.3
29.5
161
11.10
0.90
32
94
109
1.8
32.5
177
11.10
Power
Gear ratio
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp]
Gear ratio
[hp]
Rotational Speed
0.90
25
120
139
2.3
36.8
200
11.89
0.90
32
94
109
1.8
47.1
256
11.89
0.90
40
75
87
1.4
58.2
317
11.89
0.90
160
19
22
0.4
88.5
482
12.60
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
MTS drum motor
MTS drum motor
1.35
Motor Variant MTS113-0.60-P
Motor Variant MTS113-1.50-PT Power
Gear ratio
[hp]
24
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
1.50
10
300
347
5.8
24.8
135
12.36
1.50
16
188
218
3.6
39.7
216
13.07
1.50
20
150
174
2.9
49.6
270
13.07
1.50
25
120
139
2.3
61.3
334
13.07
1.50
32
94
109
1.8
78.5
427
13.07
1.50
40
75
87
1.4
81.1
442
13.07 25
Drum motor - MTS113 Class
Drum motor - MTS113 Class
Motor Data - Standard & torque variants (N / T)
Motor Data - Power upgrade variants (P / PT)
Rated power
hp
0.25
0.50
1.00
1.00
1.35
1.35
Rated power
hp
0.34
0.60
0.90
1.50
Rated speed
rpm
3.000
3.000
3.000
3.000
3.000
3.000
Rated speed
rpm
3000
3000
3000
3000
Rated frequency
Hz
150
150
150
150
150
150
Rated frequency
Hz
250
250
250
250
3
3
3
3
3
3
Number of pole pairs
5
5
5
5
Y
Y
Y
Y
Number of pole pairs Wiring
Y
Y
Y
Y
Y
F
F
F
F
F
F
Insulation class
F
F
F
F
Supply voltage range
1 x / 3 x VAC
200 .. 480
200 .. 480
200 .. 240
380 .. 480
200 .. 240
380 .. 480
Supply voltage range
1 x / 3 x VAC
200 .. 480
380 .. 480
380 .. 480
380 .. 480
DC Bus voltage range
VDC
280 .. 680
280 .. 680
280 .. 340
540 .. 680
280 .. 340
540 .. 680
DC Bus voltage range
VDC
280 .. 680
540 .. 680
540 .. 680
540 .. 680
Rated voltage
3 x VAC
181
181
181
320
181
320
Rated voltage
3 x VAC
188
331
291
330
Rated torque
lbf·ft
0.44
0.89
1.70
1.70
2.36
2.36
Rated torque
lbf·ft
0.59
1.03
1.55
2.58
Rated current per phase
A
0.8
1.5
2.6
1.6
3.7
2.1
Rated current per phase
A
0.9
0.9
1.7
2.3
lbf·ft
0.74
1.40
1.77
3.10
Insulation class
Stall torque
lbf·ft
0.52
1.11
2.07
2.07
2.58
2.58
Stall torque
Stall current per phase
A
0.9
1.8
3.1
1.8
3.9
2.2
Stall current per phase
A
1.41
1.39
2.00
2.93
Peak torque
lbf·ft
2.07
4.43
8.26
8.26
10.33
10.33
Peak torque
lbf·ft
1.84
3.54
4.43
7.74
Peak current
A
3.6
7.2
12.4
7.2
15.6
8.8
Peak current
A
3.8
3.5
5.6
7.7
Voltage constant
V / 1.000 rpm
48.1
91.1
83.5
98.0
Voltage constant
V / 1.000 rpm
49.6
51.7
54.3
95.3
55.0
97.5
Torque constant
lbf·ft / Arms
0.55
0.59
0.65
1.06
0.64
1.12
Torque constant
lbf·ft / Arms
0.66
1.15
0.91
1.12
Winding resistance (2 phases)
Ω
26.4
9.8
4.6
14.2
2.8
9.0
Winding resistance (2 phases)
Ω
21
24.8
19.8
10.1
26.0
Winding inductance (2 phases) identical to Ld and Lq
mH
25.50
37.33
45.70
29.20
Winding inductance (2 phases) identical to Ld and Lq
mH
Electrical time constant
ms
1.4
1.9
2.6
2.5
3.0
2.9
Electrical time constant
ms
1.2
1.5
2.3
2.9
Moment of inertia rotor
lb in2
0.075
0.140
0.478
0.478
0.660
0.660
Moment of inertia rotor
lb in2
0.092
0.167
0.273
0.499
Anti condensing heating voltage
VDC
35
26
23
40
19
34
Anti condensing heating voltage
VDC
49
53
57
45
37.6
18.6
11.8
36.2
8.4
MTS drum motor
MTS drum motor 26
Y
Wiring
27
Compact. Clean. Efficient. Oil-free.
MTS138 Synchronous Drum motor
MTS138
The MTS138 is a robust, oil-free drum motor designed for hygienic environments and demanding conveyor applications. With a diameter of 5.35 inches and shell lengths starting from 11.18 inches, it combines strong performance with a compact footprint - ideal for heavy-duty operations where space and cleanliness matter. Its fully enclosed, maintenance-free design eliminates external components and contamination risks, while synchronous technology ensures high torque with minimal energy consumption.
Applications: Large Conveyor Systems: High-performance drives for heavy-duty food production lines. Meat Processing Plants: Hygienic, oil-free motors for contamination-sensitive areas. Automated Packaging Lines: Powerful yet space-saving for large-scale operations.
Why choose MTS138: Compact size with powerful performance Hygienic, oil-free design High torque with energy efficiency Maintenance-free and easy to integrate Power and torque upgrade variants available for demanding applications.
MTS drum motor
MTS drum motor
The MTS138 is a reliable choice for large conveyor systems and precision-driven processes in food Oil-free production.
Oil-free
Lower energy consumption Oil free - minimize the risk of oil leaks Higher motor efficiency Enhanced food safety
28
29
Drum motor - MTS138 Class
Standard variants - MTS138 Rated values refer to the drum shell. Custom gear combinations on request for all models.
AGL = SL +1.5” EL = SL +0.5”
Motor Variant MTS138-1.00-N
FW = SL +0.3”
Power
SL B
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp] A
B
B MG = 0.1”
1.00
10
300
421
7.0
16.3
73
12.28
1.00
16
188
264
4.4
26.1
117
12.99
1.00
20
150
211
3.5
32.6
146
12.99
1.00
25
120
169
2.8
40.3
181
12.99
1.00
32
94
132
2.2
51.6
231
12.99
1.00
40
75
105
1.8
63.8
286
12.99
1.00
160
19
27
0.4
88.5
397
13.70
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
0.14” 1/3
1/3
Ø1.2”
1/3
Explanations: FW = Face width MG = Distance between End Cap and Key Flat
AGL = Total length of shaft SL = Shell length (Reference length / ordering length) EL = Installation length
Crowned
SECTION B-B
ØA
ØB
Shell length max.
[in]
[in]
[in]
5.43
5.35
59.06
Cylindrical
5.35
5.35
59.06
Cylindrical with key
5.39
5.39
33.46
Power
Gear ratio
[hp] 1.35
10
300
421
7.0
22.7
102
13.07
1.35
16
188
264
4.4
36.3
162
13.78
1.35
20
150
211
3.5
45.3
203
13.78
1.35
25
120
169
2.8
56.1
251
13.78
1.35
32
94
132
2.2
71.8
322
13.78
1.35
40
75
105
1.8
81.1
364
13.78
1.35
160
19
27
0.4
88.5
397
14.49
MTS drum motor
MTS drum motor
Type
1.0”
Motor Variant MTS138-1.35-N
For designs outside of these specifications, please reach out to your local NGI sales representative.
Feedback unit
30
Minimum shell length addition [in]
Resolver - 2 Cables
1.73
Resolver - Hybrid Cable
2.68
DBS36 - 2 Cables
2.95
DBS36 - Hybrid Cable
3.94
SKS36 - 2 Cables
2.36
SKS36 - Hybrid Cable
3.35
EKS36/EDS35 - Hybrid Cable
2.76
ECI 1119 - 2 Cables
2.64
ECI 1119 - Hybrid Cable
3.54
31
Power upgrade variants - MTS138
Power & Torque upgrade variants - MTS138
Rated values refer to the drum shell. Custom gear combinations on request for all models.
Rated values refer to the drum shell. Custom gear combinations on request for all models.
Motor Variant MTS138-0.90-P
Motor Variant MTS138-0.90-PT
Power
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
Power
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp]
[hp]
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
0.90
10
300
421
7.0
14.9
67
11.18
0.90
60
50
70
1.2
85.5
383
14.80
0.90
16
188
264
4.4
23.8
107
11.89
0.90
80
38
53
0.9
112.8
505
14.80
0.90
100
30
42
0.7
139.4
625
14.80
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length [in]
0.90
20
150
211
3.5
29.7
133
11.89
0.90
25
120
169
2.8
36.8
165
11.89
0.90
32
94
132
2.2
47.1
211
11.89
0.90
40
75
105
1.8
58.2
261
11.89
0.90
60
50
70
1.2
81.1
364
12.60
0.90
160
19
27
0.4
88.5
397
12.60
Motor Variant MTS138-2.10-PT Power
Gear ratio
[hp]
Motor Variant MTS138-1.50-P Power
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
10
300
421
7.0
24.8
111
12.36 13.07
[hp] 1.50
16
188
264
4.4
39.7
178
20
150
211
3.5
49.6
222
13.07
1.50
25
120
169
2.8
61.3
275
13.07
1.50
32
94
132
2.2
78.5
352
13.07
1.50
40
75
105
1.8
81.1
364
13.07
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
32
94
132
2.2
109.9
492
16.06
2.10
40
75
105
1.8
135.9
609
16.06
2.10
60
50
70
1.2
191.8
860
17.17
2.10
80
38
53
0.9
191.8
860
17.17
2.10
100
30
42
0.7
191.8
860
17.17
MTS drum motor
MTS drum motor
1.50 1.50
[rpm]
2.10
Motor Variant MTS138-2.10-P Power
Gear ratio
[hp]
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
10
300
421
7.0
28.0
126
13.54
2.10
16
188
264
4.4
55.5
249
14.25
2.10
20
150
211
3.5
69.4
311
14.25
2.10
25
120
169
2.8
81.1
364
14.25
2.10
32
94
132
2.2
88.5
397
14.25
2.10
32
33
Drum motor - MTS138 Class
Drum motor - MTS138 Class
Motor Data - Standard variants (N)
Motor Data - Power upgrade variants (P / PT)
Rated power
hp
1.00
1.00
1.35
1.35
Rated power
hp
0.90
1.50
2.10
Rated speed
rpm
3.000
3.000
3.000
3.000
Rated speed
rpm
3000
3000
3000
Rated frequency
Hz
150
150
150
150
Rated frequency
Hz
250
250
250
Number of pole pairs
3
3
3
3
Number of pole pairs
5
5
5
Wiring
Y
Y
Y
Y
Wiring
Y
Y
Y
Insulation class
F
F
F
Insulation class
F
F
F
1 x / 3 x VAC
200 .. 240
380 .. 480
200 .. 240
380 .. 480
Supply voltage range
1 x / 3 x VAC
380 .. 480
380 .. 480
380 .. 480
DC Bus voltage range
VDC
280 .. 340
540 .. 680
280 .. 340
540 .. 680
DC Bus voltage range
VDC
540 .. 680
540 .. 680
540 .. 680
Rated voltage
3 x VAC
181
320
181
320
Rated voltage
3 x VAC
291
330
334
Rated torque
lbf·ft
1.70
1.70
2.36
2.36
Rated torque
lbf·ft
1.55
2.58
3.61
Rated current per phase
A
2.6
1.6
3.7
2.1
Rated current per phase
A
1.7
2.3
3.1
Stall torque
lbf·ft
2.07
2.07
2.58
2.58
Stall torque
lbf·ft
1.77
3.10
4.20
Stall current per phase
A
3.1
1.8
3.9
2.2
Stall current per phase
A
2.00
2.93
3.75
Peak torque
lbf·ft
8.26
8.26
10.33
10.33
Peak torque
lbf·ft
4.43
7.74
10.55
Peak current
A
12.4
7.2
15.6
8.8
Peak current
A
5.6
7.7
9.6
Voltage constant
V / 1.000 rpm
54.3
95.3
55.0
97.5
Voltage constant
V / 1.000 rpm
83.5
98.0
103.0
Torque constant
lbf·ft / Arms
0.65
1.06
0.64
1.12
Torque constant
lbf·ft / Arms
0.91
1.12
1.17
Winding resistance (2 phases)
Ω
4.6
14.2
2.8
9.0
Winding resistance (2 phases)
Ω
19.8
10.1
6.2
26.0
Winding inductance (2 phases) identical to Ld and Lq
mH
45.70
29.20
20.70
Winding inductance (2 phases) identical to Ld and Lq
mH
Electrical time constant
ms
2.6
2.5
3.0
2.9
Electrical time constant
ms
2.3
2.9
3.3
Moment of inertia rotor
lb in2
0.48
0.48
0.66
0.66
Moment of inertia rotor
lb in2
0.273
0.499
0.724
Anti condensing heating voltage
VDC
23
40
19
34
Anti condensing heating voltage
VDC
57
45
38
11.8
36.2
8.4
MTS drum motor
MTS drum motor 34
F
Supply voltage range
35
The World’s Smallest Oil-Free Drum Motor.
HMTS62 Synchronous Drum motor
HMTS62
New
Compact performance. Advanced hygienic design. With a diameter of just 2.4 inches, the HMTS62 combines our proven synchronous motor technology with an advanced hygienic design built for demanding food production environments. Its compact dimensions make it ideal for applications where installation space is limited while hygiene and cleanability remain critical. Built on the same proven motor platform as the MTS, the HMTS62 delivers consistent torque across all speeds. Its closed design supports effective cleaning and helps reduce contamination risks in demanding washdown environments. HMTS drum motor
HMTS drum motor
Oil-free
Its compact size makes the HMTS62 particularly suited for tight transfers and applications handling small or delicate products, where precision, hygiene and limited installation space all matter. Applications: Food Processing Systems: Compact hygienic drive solution for tight transfers and applications handling small or delicate products. Packaging Machines: Space-efficient drive for hygienically designed packaging and processing equipment. Check Weighing & Inspection Systems: Compact and precise drive solution for applications requiring reliable and controlled movement. Why choose HMTS62: Advanced hygienic design Compact 2.4-inch diameter Consistent torque across all speeds Closed, maintenance-free design 130 W continuous power
36
Oil-free
Lower energy consumption Oil free - minimize the risk of oil leaks Higher motor efficiency Enhanced food safety
37
Drum motor - HMTS62 Class
Standard variant - HMTS62 Rated values refer to the drum shell. Custom gear combinations on request.
AGL = SL +1.26” EL = SL +0.28” SL = FW
Motor Variant HMTS62-0.17-N Power
ØA
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
8
563
355
5.9
1.5
15
11.97
[hp] 0.17
A
ØB
A B 1/3
MG = 0.14”
1/3
1/3
MG = 0.14”
Ø0.98”
Explanations:
Type
Crowned
SECTION B-B
ØA
ØB
Shell length max.
[in]
[in]
[in]
2.46
2.40
25.6
375
236
3.9
2.3
23
12.48
281
177
3
3.1
31
12.48
0.17
25
180
113
1.9
4.7
47
12.48
0.17
32
141
89
1.5
6.1
60
12.48
0.17
40
113
71
1.2
7.5
75
12.48
0.17
60
75
47
0.8
11.0
110
12.95
0.17
80
56
35
0.6
14.3
143
12.95
Power and Torque upgrades currently not available for HMTS62
Motor Data - Standard Variant (N) Rated power
hp
0.17
Rated speed
rpm
4500
Rated frequency
Hz
150
Number of pole pairs
2
Wiring
Y
Insulation class
F
Supply voltage range
1 x / 3 x VAC
200…480
VDC
280…680
Cylindrical
2.40
2.40
25.6
DC Bus voltage range
Cylindrical with key
2.47
2.47
25.6
Rated voltage
3 x VAC
159
Rated torque
lbf·ft
0.20
Rated current per phase
A
0.6
Stall torque
lbf·ft
0.30
Stall current per phase
A
0.9
Peak torque
lbf·ft
0.96
Peak current
A
3.0
Voltage constant
V / 1.000 rpm
29.4
Torque constant
lbf·ft / Arms
0.32
For designs outside of these specifications, please reach out to your local NGI sales representative.
Feedback systems are options which increase the minimum shell length as shown below. Feedback unit
Minimum shell length addition [in]
Resolver
2.68
SKS36
3.43
EKS36/EDS36
2.83
ECI 1119
3.58
The HMTS62 is only available with feedback systems in combination with hybrid cables.
38
12 16
0.87”
FW = Face width MG = Distance between End Cap and Key Flat
AGL = Total length of shaft SL = Shell length (Reference length / ordering length) EL = Installation length
0.17 0.17
Winding resistance (2 phases)
Ω
36.9
Winding inductance (2 phases)
mH
19.6
Electrical time constant
ms
0.8
Moment of inertia rotor
lb in2
0.30
Anti condensing heating voltage
VDC
34
39
Clean. Efficient. Advanced hygiene.
HMTS82 Synchronous Drum motor
HMTS82
New
Compact performance for demanding hygienic applications. With a diameter of just 3.19 inches, the HMTS82 combines proven synchronous motor technology with an advanced hygienic design built for demanding food production environments. Its closed, maintenance-free design integrates motor and transmission inside the drum, supporting effective cleaning and helping reduce contamination risks. The HMTS82 delivers high torque at low speeds with minimal energy consumption. It supports multispeed dimensioning, sensorless precise positioning and optional feedback systems for closed-loop control and indexing. Applications: Food Production Lines: Hygienic conveyors for raw or packaged goods. Automated Sorting Lines: Compact drives for sorting and inspection systems. Check Weighing Systems: Precision-driven conveyors for demanding operations. Packaging Systems: Compact drives for space-constrained applications. Why choose HMTS82: Advanced hygienic design Compact size with powerful performance High torque at low speeds Closed, maintenance-free and oil-free design Supports feedback and servo drive integration Power and torque upgrade variants available for demanding applications.
HMTS drum motor
HMTS drum motor
Oil-free
Oil-free
Lower energy consumption Oil free - minimize the risk of oil leaks Higher motor efficiency Enhanced food safety
40
41
Drum motor - HMTS82 Class
Standard variants - HMTS82 Rated values refer to the drum shell. Custom gear combinations on request for all models.
AGL = SL +1.26” EL = SL +0.28” SL = FW
Motor Variant HMTS82-0.25-N Power
ØA
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp] A
ØB
A B 1/3
MG = 0.14”
1/3
1/3
MG = 0.14”
0.25
5
600
502
8.4
2.2
16
12.32
0.25
8
375
314
5.2
3.4
26
12.32
0.25
12
250
209
3.5
5.1
38
12.80
0.25
16
188
157
2.6
6.8
51
12.80
0.25
20
150
126
2.1
8.5
64
12.80
0.25
25
120
100
1.7
10.5
79
12.80
0.25
32
94
79
1.3
13.5
101
12.80
0.25
40
75
63
1
16.6
125
12.80
0.25
160
19
16
0.3
32.5
244
13.31
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
600
502
8.4
4.3
33
13.50
Ø1.18”
Explanations:
0.98”
FW = Face width MG = Distance between End Cap and Key Flat
AGL = Total length of shaft SL = Shell length (Reference length / ordering length) EL = Installation length
Motor Variant HMTS82-0.50-N
SECTION B-B
Power
Gear ratio
[hp] 0.50 0.50
8
375
314
5.2
6.9
52
13.50
0.50
12
250
209
3.5
10.2
77
13.98
0.50
16
188
157
2.6
13.6
102
13.98
0.50
20
150
126
2.1
17.0
128
13.98
0.50
25
120
100
1.7
21.0
158
13.98
0.50
32
94
79
1.3
26.9
202
13.98
0.50
40
75
63
1
29.5
222
13.98
160
19
16
0.3
32.5
244
14.49
ØA
ØB
Shell length max.
[in]
[in]
[in]
Crowned
3.20
3.17
47.24
Cylindrical
3.19
3.19
47.24
0.50
Cylindrical with key
3.22
3.22
33.46
HMTS drum motor
HMTS drum motor
Type
5
For designs outside of these specifications, please reach out to your local NGI sales representative.
Feedback unit
42
Minimum shell length addition [in]
Resolver - 2 Cables
1.73
Resolver - Hybrid Cable
2.60
DBS36 - 2 Cables
3.07
DBS36 - Hybrid Cable
3.94
SKS36 - 2 Cables
2.48
SKS36 - Hybrid Cable
3.35
EKS36/EDS35 - Hybrid Cable
2.76
ECI 1119 - 2 Cables
2.64
ECI 1119 - Hybrid Cable
3.54
43
Power upgrade variants - HMTS82 Rated values refer to the drum shell. Custom gear combinations on request for all models.
Motor Variant HMTS82-0.34-P Power
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp] 0.3
5
600
502
8.4
2.9
22
11.85
0.3
8
375
314
5.2
4.6
34
11.85
0.3
12
250
209
3.5
6.8
51
12.32
0.3
16
188
157
2.6
9.1
68
12.32
0.3
20
150
126
2.1
11.3
85
12.32
0.3
25
120
100
1.7
14.0
105
12.32
0.3
32
94
79
1.3
17.9
135
12.32
0.3
40
75
63
1.0
22.2
167
12.32
0.3
160
19
16
0.3
32.5
244
12.83
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
600
502
8.4
5.1
38
10.67 10.67
Motor Variant HMTS82-0.60-P Power
Gear ratio
[hp] 0.60
5
HMTS drum motor
0.60
8
375
314
5.2
8.0
60
0.60
12
250
209
3.5
11.9
90
11.18
0.60
16
188
157
2.6
15.9
119
11.18
0.60
20
150
126
2.1
19.8
149
11.18
0.60
25
120
100
1.7
24.5
185
11.18
0.60
32
94
79
1.3
31.4
236
11.18
0.60
40
75
63
1
29.5
222
11.18
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
600
502
8.4
6.5
49
14.02
Motor Variant HMTS82-0.80-P Power
Gear ratio
[hp] 0.80
5
0.80
8
375
314
5.2
10.3
78
14.02
0.80
12
250
209
3.5
15.3
115
14.49
0.80
16
188
157
2.6
20.4
153
14.49
0.80
20
150
126
2.1
25.5
192
14.49
0.80
25
120
100
1.7
29.5
222
14.49
0.80
32
94
79
1.3
32.5
244
14.49
Global Sales Support. Built for Execution. You don’t need more options - you need the right one. Our DriveTech Sales Team works account-based and cross-functionally to remove friction in your project: clear scope, clear configuration, clear next steps. From early dialogue to final specification, we help you get it right the first time - so implementation is easier, and performance is predictable.
44
45
Drum motor - HMTS82 Class
Drum motor - HMTS82 Class
Motor Data - Standard variants (N)
Motor Data - Power upgrade variants (P)
Rated power
hp
0.25
0.50
Rated power
hp
0.34
0.60
0.80
Rated speed
rpm
3.000
3.000
Rated speed
rpm
3000
3000
3000
Rated frequency
Hz
150
150
Rated frequency
Hz
250
250
250
Number of pole pairs
3
3
Number of pole pairs
5
5
5
Wiring
Y
Y
Wiring
Y
Y
Y
Insulation class
F
Insulation class
F
F
F
1 x / 3 x VAC
200 .. 480
200 .. 480
Supply voltage range
1 x / 3 x VAC
200 .. 480
380 .. 480
380 .. 480
DC Bus voltage range
VDC
280 .. 680
280 .. 680
DC Bus voltage range
VDC
280 .. 680
540 .. 680
540 .. 680
Rated voltage
3 x VAC
181
181
Rated voltage
3 x VAC
188
331
333
Rated torque
lbf·ft
0.44
0.89
Rated torque
lbf·ft
0.59
1.03
1.33
Rated current per phase
A
0.8
1.5
Rated current per phase
A
0.9
0.9
1.2
Stall torque
lbf·ft
0.52
1.11
Stall torque
lbf·ft
0.74
1.40
1.92
Stall current per phase
A
0.9
1.8
Stall current per phase
A
1.41
1.39
1.83
Peak torque
lbf·ft
2.07
4.43
Peak torque
lbf·ft
1.84
3.54
4.79
Peak current
A
3.6
7.2
Peak current
A
3.8
3.5
4.4
Voltage constant
V / 1.000 rpm
49.6
51.7
Voltage constant
V / 1.000 rpm
48.1
91.1
97.1
Torque constant
lbf·ft / Arms
0.55
0.59
Torque constant
lbf·ft / Arms
0.66
1.15
1.11
Winding resistance (2 phases)
Ω
26.4
9.8
Winding resistance (2 phases)
Ω
21
24.8
17.9
mH
25.50
37.33
27.10
Winding inductance (2 phases) identical to Ld and Lq
mH
37.6
18.6
Winding inductance (2 phases) identical to Ld and Lq
Electrical time constant
ms
1.4
1.9
Electrical time constant
ms
1.2
1.5
1.5
Moment of inertia rotor
lb in2
0.075
0.140
Moment of inertia rotor
lb in2
0.092
0.167
0.243
Anti condensing heating voltage
VDC
35
26
Anti condensing heating voltage
VDC
49
53
50
HMTS drum motor
HMTS drum motor 46
F
Supply voltage range
47
Versatile. Hygienic. Oil-free.
HMTS113 Synchronous Drum motor
HMTS113
New
Flexible power and reliable performance for demanding food processing applications. The HMTS113 is a versatile, oil-free drum motor combining proven synchronous motor technology with an advanced hygienic design built for demanding food production environments. With a diameter of 4.41 inches, and a wide power range, it delivers the flexibility needed where hygiene, performance and efficiency are critical. Its closed, maintenance-free design protects the motor and transmission inside the drum, supporting effective cleaning and helping reduce contamination risks in demanding washdown environments. HMTS drum motor
HMTS drum motor
Powered by synchronous motor technology, the HMTS113 delivers high torque Oil-free with low energy consumption across a wide range of conveyor applications. With power ratings from 0.25 hp to 1.50 hp, the HMTS113 can be configured with rubber coatings or sprockets for different belt types, making it suitable for both standalone conveyors and precision-driven machinery. Applications: Meat & Seafood Processing: Hygienic, oil-free drive solution for demanding washdown environments. Bakery & Confectionery Lines: Flexible drive solution for a wide range of conveyor configurations. Quality Control & Inspection Systems: Reliable, precise performance for controlled conveying applications. Lower energy consumption Why choose HMTS113: Advanced hygienic design for demanding washdown environments Oil free - minimize the risk of oil leaks Wide power range for versatile applications
High torque with low energy consumption Closed, maintenance-free and oil-free design Suitable for both standard and precision-driven applications
Power and torque upgrade variants available for demanding applications.
48
Oil-free
Higher motor efficiency Enhanced food safety
49
Drum motor - HMTS113 Class
Standard variants - HMTS113 Rated values refer to the drum shell. Custom gear combinations on request for all models.
AGL = SL +1.26” EL = SL +0.28” SL = FW
Motor Variant HMTS113-0.25-N Power
ØA
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp] A
ØB
A B 1/3
MG = 0.14”
1/3
1/3
0.25
8
375
434
7.2
3.4
19
10.16
0.25
12
250
289
4.8
5.1
28
10.63
0.25
16
188
218
3.6
6.8
37
10.63
0.25
20
150
174
2.9
8.5
46
10.63
0.25
25
120
139
2.3
10.5
57
10.63
0.25
32
94
109
1.8
13.5
73
10.63
0.25
40
75
87
1.4
16.6
91
10.63
0.25
160
19
22
0.4
32.5
177
11.14
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
MG = 0.14”
Ø1.18”
Explanations: FW = Face width MG = Distance between End Cap and Key Flat
AGL = Total length of shaft SL = Shell length (Reference length / ordering length) EL = Installation length
Motor Variant HMTS113-0.50-N
0.98”
Power SECTION B-B
[hp]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
375
434
7.2
6.9
37
13.50
0.50
12
250
289
4.8
10.2
55
13.98
0.50
16
188
218
3.6
13.6
74
13.98
0.50
20
150
174
2.9
17.0
92
13.98
0.50
25
120
139
2.3
21.0
114
13.98
0.50
32
94
109
1.8
26.9
146
13.98
HMTS drum motor Crowned
ØA
ØB
Shell length max.
[in]
[in]
[in]
0.50
40
75
87
1.4
29.5
161
13.98
0.50
160
19
22
0.4
32.5
177
14.49
4.47
4.41
51.18
Cylindrical
4.41
4.41
51.18
Cylindrical with key
4.45
4.45
33.46
For designs outside of these specifications, please reach out to your local NGI sales representative.
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
Motor Variant HMTS113-1.00-N Power
Gear ratio
[hp]
Feedback unit
50
Minimum shell length addition [in]
Resolver - 2 Cables
1.61
Resolver - Hybrid Cable
2.52
HMTS drum motor
[rpm] 8
0.50
Type
Gear ratio
1.00
8
375
434
7.2
13.2
72
13.82
1.00
12
250
289
4.8
19.5
106
14.33
1.00
16
188
218
3.6
26.1
142
14.33
1.00
20
150
174
2.9
32.5
177
14.33
1.00
25
120
139
2.3
29.5
161
14.33
1.00
32
94
109
1.8
32.5
177
14.33
1.00
40
75
87
1.4
29.5
161
14.33
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
DBS36 - 2 Cables
2.95
DBS36 - Hybrid Cable
3.86
SKS36 - 2 Cables
2.28
SKS36 - Hybrid Cable
3.19
Power
EKS36/EDS35 - Hybrid Cable
2.68
[hp]
ECI 1119 - 2 Cables
2.52
1.35
ECI 1119 - Hybrid Cable
3.43
Motor Variant HMTS113-1.35-N Gear ratio
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
8
375
434
7.2
13.3
72
14.61
1.35
12
250
289
4.8
27.2
148
15.12
1.35
16
188
218
3.6
32.5
177
15.12
1.35
20
150
174
2.9
32.5
177
15.12
1.35
25
120
139
2.3
29.5
161
15.12
1.35
32
94
109
1.8
32.5
177
15.12
1.35
40
75
87
1.4
29.5
161
15.12 51
Torque upgrade variants - HMTS113
Power upgrade variants - HMTS113
Rated values refer to the drum shell. Custom gear combinations on request for all models.
Rated values refer to the drum shell. Custom gear combinations on request for all models.
Motor Variant HMTS113-1.00-T
Motor Variant HMTS113-0.34-P
Power
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
Power
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp]
[hp]
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
1.0
10
300
347
5.8
16.3
89
12.28
0.3
8
375
434
7.2
4.6
25
9.69
1.0
16
188
218
3.6
26.1
142
12.99
0.3
12
250
289
4.8
6.8
37
10.20
1.0
20
150
174
2.9
32.6
177
12.99
0.3
16
188
218
3.6
9.1
49
10.20
1.0
25
120
139
2.3
40.3
219
12.99
0.3
20
150
174
2.9
11.3
62
10.20
1.0
32
94
109
1.8
51.6
281
12.99
0.3
25
120
139
2.3
14.0
76
10.20
1.0
40
75
87
1.4
63.8
347
12.99
0.3
32
94
109
1.8
17.9
98
10.20
1.0
160
19
22
0.4
88.5
482
13.70
0.3
40
75
87
1.4
22.2
121
10.20
0.3
80
38
44
0.7
32.5
177
10.71
0.3
160
19
22
0.4
32.5
177
10.71
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
Motor Variant HMTS113-1.35-T Power
Gear ratio
[hp]
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
10
300
347
5.8
22.7
123
15.24
1.35
16
188
218
3.6
36.3
197
15.94
1.35
20
150
174
2.9
45.3
247
15.94
1.35
25
120
139
2.3
56.1
305
15.94
1.35
32
94
109
1.8
71.8
391
15.94
1.35
40
75
87
1.4
81.1
442
15.94
1.35
160
19
22
0.4
88.5
482
16.61
Power & Torque upgrade variants - HMTS113
Power
Gear ratio
[hp] 0.6
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
8
375
434
7.2
8.0
44
12.83
0.6
12
250
289
4.8
11.9
65
13.31
0.6
16
188
218
3.6
15.9
86
13.31
0.6
20
150
174
2.9
19.8
108
13.31
0.6
25
120
139
2.3
24.5
133
13.31
0.6
32
94
109
1.8
31.4
171
13.31
0.6
40
75
87
1.4
29.5
161
13.31
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
Motor Variant HMTS113-0.90-P
Rated values refer to the drum shell. Custom gear combinations on request for all models.
Power
Motor Variant HMTS113-0.90-PT
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
0.87
8
375
434
7.2
12.0
65
12.72
0.87
12
250
289
4.8
17.8
97
13.23
0.87
16
188
218
3.6
23.8
129
13.23
0.87
20
150
174
2.9
29.7
162
13.23
0.87
25
120
139
2.3
29.5
161
13.23
0.87
32
94
109
1.8
32.5
177
13.23
Power
Gear ratio
[hp]
Gear ratio
[hp]
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
0.9
25
120
139
2.3
36.8
200
11.89
0.9
32
94
109
1.8
47.1
256
11.89
0.9
40
75
87
1.4
58.2
317
11.89
0.9
160
19
22
0.4
88.5
482
12.60
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
HMTS drum motor
HMTS drum motor
1.35
Motor Variant HMTS113-0.60-P
Motor Variant HMTS113-1.50-PT Power
Gear ratio
[hp]
52
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
1.5
10
300
347
5.8
24.8
135
14.53
1.5
16
188
218
3.6
39.7
216
15.20
1.5
20
150
174
2.9
49.6
270
15.20
1.5
25
120
139
2.3
61.3
334
15.20
1.5
32
94
109
1.8
78.5
427
15.20
1.5
40
75
87
1.4
81.1
442
15.20 53
Drum motor - HMTS113 Class
Drum motor - HMTS113 Class
Motor Data - Standard & torque variants (N / T)
Motor Data - Power upgrade variants (P / PT)
Rated power
hp
0.25
0.50
1.00
1.00
1.35
1.35
Rated power
hp
0.34
0.60
0.90
1.50
Rated speed
rpm
3.000
3.000
3.000
3.000
3.000
3.000
Rated speed
rpm
3000
3000
3000
3000
Rated frequency
Hz
150
150
150
150
150
150
Rated frequency
Hz
250
250
250
250
3
3
3
3
3
3
Number of pole pairs
5
5
5
5
Y
Y
Y
Y
Number of pole pairs Wiring
Y
Y
Y
Y
Y
F
F
F
F
F
F
Insulation class
F
F
F
F
Supply voltage range
1 x / 3 x VAC
200 .. 480
200 .. 480
200 .. 240
380 .. 480
200 .. 240
380 .. 480
Supply voltage range
1 x / 3 x VAC
200 .. 480
380 .. 480
380 .. 480
380 .. 480
DC Bus voltage range
VDC
280 .. 680
280 .. 680
280 .. 340
540 .. 680
280 .. 340
540 .. 680
DC Bus voltage range
VDC
280 .. 680
540 .. 680
540 .. 680
540 .. 680
Rated voltage
3 x VAC
181
181
181
320
181
320
Rated voltage
3 x VAC
188
331
291
330
Rated torque
lbf·ft
0.44
0.89
1.70
1.70
2.36
2.36
Rated torque
lbf·ft
0.59
1.03
1.55
2.58
Rated current per phase
A
0.8
1.5
2.6
1.6
3.7
2.1
Rated current per phase
A
0.9
0.9
1.7
2.3
lbf·ft
0.74
1.40
1.77
3.10
Insulation class
Stall torque
lbf·ft
0.52
1.11
2.07
2.07
2.58
2.58
Stall torque
Stall current per phase
A
0.9
1.8
3.1
1.8
3.9
2.2
Stall current per phase
A
1.41
1.39
2.00
2.93
Peak torque
lbf·ft
2.07
4.43
8.26
8.26
10.33
10.33
Peak torque
lbf·ft
1.84
3.54
4.43
7.74
Peak current
A
3.6
7.2
12.4
7.2
15.6
8.8
Peak current
A
3.8
3.5
5.6
7.7
Voltage constant
V / 1.000 rpm
48.1
91.1
83.5
98.0
Voltage constant
V / 1.000 rpm
49.6
51.7
54.3
95.3
55.0
97.5
Torque constant
lbf·ft / Arms
0.55
0.59
0.65
1.06
0.64
1.12
Torque constant
lbf·ft / Arms
0.66
1.15
0.91
1.12
Winding resistance (2 phases)
Ω
26.4
9.8
4.6
14.2
2.8
9.0
Winding resistance (2 phases)
Ω
21
24.8
19.8
10.1
26.0
Winding inductance (2 phases) identical to Ld and Lq
mH
25.50
37.33
45.70
29.20
Winding inductance (2 phases) identical to Ld and Lq
mH
Electrical time constant
ms
1.4
1.9
2.6
2.5
3.0
2.9
Electrical time constant
ms
1.2
1.5
2.3
2.9
Moment of inertia rotor
lb in2
0.075
0.140
0.478
0.478
0.660
0.660
Moment of inertia rotor
lb in2
0.092
0.167
0.273
0.499
Anti condensing heating voltage
VDC
35
26
23
40
19
34
Anti condensing heating voltage
VDC
49
53
57
45
37.6
18.6
11.8
36.2
8.4
HMTS drum motor
HMTS drum motor 54
Y
Wiring
55
Powerful. Hygienic. Oil-free.
HMTS138 Synchronous Drum motor
HMTS138
New
Wide power range for demanding hygienic conveyor applications. The HMTS138 is a robust, oil-free drum motor combining proven synchronous motor technology with an advanced hygienic design engineered for maximum cleanability. With a diameter of 5.35 inches, it is designed for demanding food processing applications where hygiene, power, and reliable performance are critical. Its fully enclosed, maintenance-free design keeps the motor and transmission protected inside the drum, while the advanced hygienic construction helps minimize contamination risks and supports effective cleaning in demanding washdown environments.
HMTS drum motor
HMTS drum motor
Oil-free
Powered by synchronous motor technology, the HMTS138 delivers high torque with low energy consumption, making it a reliable drive solution for large conveyor systems and demanding food production processes. Applications: Large Conveyor Systems: High-performance drive solution for demanding food production lines. Meat Processing Plants: Hygienic, oil-free drive solution for demanding washdown environments. Automated Packaging Lines: Powerful and compact drive solution for large-scale operations. Why choose HMTS138: Advanced hygienic design for maximum cleanability Powerful performance in a compact design High torque with low energy consumption Maintenance-free and oil-free Designed for demanding conveyor applications Power and torque upgrade variants available for demanding applications.
56
Oil-free
Lower energy consumption Oil free - minimize the risk of oil leaks Higher motor efficiency Enhanced food safety
57
Drum motor - HMTS138 Class
Standard variants - HMTS138 Rated values refer to the drum shell. Custom gear combinations on request for all models.
AGL = SL +1.26” EL = SL +0.28” SL = FW
Motor Variant HMTS138-1.00-N Power
ØA
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp] A
ØB
A B 1/3
MG = 0.14”
1/3
1/3
Crowned
300
421
7
16.3
73
12.28
16
188
264
4.4
26.1
117
12.99
1
20
150
211
3.5
32.6
146
12.99
1
25
120
169
2.8
40.3
181
12.99
1
32
94
132
2.2
51.6
231
12.99
1
40
75
105
1.8
63.8
286
12.99
1
160
19
27
0.4
88.5
397
13.70
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
Motor Variant HMTS138-1.35-N Power
SECTION B-B
ØA
ØB
Shell length max.
[in]
[in]
[in]
5.43
5.35
59.06
Cylindrical
5.35
5.35
59.06
Cylindrical with key
5.39
5.39
33.46
Gear ratio
[hp] 1.35
10
300
421
7
22.7
102
15.24
1.35
16
188
264
4.4
36.3
162
15.94
1.35
20
150
211
3.5
45.3
203
15.94
1.35
25
120
169
2.8
56.1
251
15.94
1.35
32
94
132
2.2
71.8
322
15.94
1.35
40
75
105
1.8
81.1
364
15.94
1.35
160
19
27
0.4
88.5
397
16.61
HMTS drum motor
HMTS drum motor
Type
0.98”
FW = Face width MG = Distance between End Cap and Key Flat
AGL = Total length of shaft SL = Shell length (Reference length / ordering length) EL = Installation length
10
1
MG = 0.14”
Ø1.18”
Explanations:
1
For designs outside of these specifications, please reach out to your local NGI sales representative.
Feedback unit
58
Minimum shell length addition [in]
Resolver - 2 Cables
1.73
Resolver - Hybrid Cable
2.68
DBS36 - 2 Cables
2.95
DBS36 - Hybrid Cable
3.94
SKS36 - 2 Cables
2.36
SKS36 - Hybrid Cable
3.35
EKS36/EDS35 - Hybrid Cable
2.76
ECI 1119 - 2 Cables
2.64
ECI 1119 - Hybrid Cable
3.54
59
Power upgrade variants - HMTS138
Power & Torque upgrade variants - HMTS138
Rated values refer to the drum shell. Custom gear combinations on request for all models.
Rated values refer to the drum shell. Custom gear combinations on request for all models.
Motor Variant HMTS138-0.90-P
Motor Variant HMTS138-0.90-PT
Power
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
Power
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
[hp]
[hp]
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
0.9
10
300
421
7
14.9
67
11.18
0.9
60
50
70
1.2
85.5
383
17.24
0.9
16
188
264
4.4
23.8
107
11.89
0.9
80
38
53
0.9
112.8
505
17.24
0.9
100
30
42
0.7
139.4
625
17.24
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
0.9
20
150
211
3.5
29.7
133
11.89
0.9
25
120
169
2.8
36.8
165
11.89
0.9
32
94
132
2.2
47.1
211
11.89
0.9
40
75
105
1.8
58.2
261
11.89
0.9
60
50
70
1.2
81.1
364
12.60
0.9
160
19
27
0.4
88.5
397
12.60
Motor Variant HMTS138-2.10-PT Power
Gear ratio
[hp]
Motor Variant HMTS138-1.50-P Power
Gear ratio
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
10
300
421
7
24.8
111
14.53
1.5
16
188
264
4.4
39.7
178
15.20
1.5
20
150
211
3.5
49.6
222
15.20
[hp] 1.5
25
120
169
2.8
61.3
275
15.20
32
94
132
2.2
78.5
352
15.20
1.5
40
75
105
1.8
81.1
364
15.20
Rotational Speed
Linear Speed
Linear Speed
Torque
Belt pull
Min. Shell Length
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
32
94
132
2.2
109.9
492
18.50
2.1
40
75
105
1.8
135.9
609
18.50
2.1
60
50
70
1.2
191.8
860
19.61
2.1
80
38
53
0.9
191.8
860
19.61
2.1
100
30
42
0.7
191.8
860
19.61
HMTS drum motor
HMTS drum motor
1.5 1.5
[rpm]
2.1
Motor Variant HMTS138-2.10-P Power
Gear ratio
[hp] 2.1
60
[rpm]
[ft/min.]
[ft/s]
[lbf·ft]
[lbf]
[in]
10
300
421
7
28.0
126
15.71 16.38
2.1
16
188
264
4.4
55.5
249
2.1
20
150
211
3.5
69.4
311
16.38
2.1
25
120
169
2.8
81.1
364
16.38
2.1
32
94
132
2.2
88.5
397
16.38
61
Drum motor - HMTS138 Class
Drum motor - HMTS138 Class
Motor Data - Standard variants (N)
Motor Data - Power upgrade variants (P / PT)
Rated power
hp
1.00
1.00
1.35
1.35
Rated power
hp
0.90
1.50
2.10
Rated speed
rpm
3.000
3.000
3.000
3.000
Rated speed
rpm
3000
3000
3000
Rated frequency
Hz
150
150
150
150
Rated frequency
Hz
250
250
250
Number of pole pairs
3
3
3
3
Number of pole pairs
5
5
5
Wiring
Y
Y
Y
Y
Wiring
Y
Y
Y
Insulation class
F
F
F
Insulation class
F
F
F
1 x / 3 x VAC
200 .. 240
380 .. 480
200 .. 240
380 .. 480
Supply voltage range
1 x / 3 x VAC
380 .. 480
380 .. 480
380 .. 480
DC Bus voltage range
VDC
280 .. 340
540 .. 680
280 .. 340
540 .. 680
DC Bus voltage range
VDC
540 .. 680
540 .. 680
540 .. 680
Rated voltage
3 x VAC
181
320
181
320
Rated voltage
3 x VAC
291
330
334
Rated torque
lbf·ft
1.70
1.70
2.36
2.36
Rated torque
lbf·ft
1.55
2.58
3.61
Rated current per phase
A
2.6
1.6
3.7
2.1
Rated current per phase
A
1.7
2.3
3.1
Stall torque
lbf·ft
2.07
2.07
2.58
2.58
Stall torque
lbf·ft
1.77
3.10
4.20
Stall current per phase
A
3.1
1.8
3.9
2.2
Stall current per phase
A
2.00
2.93
3.75
Peak torque
lbf·ft
8.26
8.26
10.33
10.33
Peak torque
lbf·ft
4.43
7.74
10.55
Peak current
A
12.4
7.2
15.6
8.8
Peak current
A
5.6
7.7
9.6
Voltage constant
V / 1.000 rpm
54.3
95.3
55.0
97.5
Voltage constant
V / 1.000 rpm
83.5
98.0
103.0
Torque constant
lbf·ft / Arms
0.65
1.06
0.64
1.12
Torque constant
lbf·ft / Arms
0.91
1.12
1.17
Winding resistance (2 phases)
Ω
4.6
14.2
2.8
9.0
Winding resistance (2 phases)
Ω
19.8
10.1
6.2
26.0
Winding inductance (2 phases) identical to Ld and Lq
mH
45.70
29.20
20.70
Winding inductance (2 phases) identical to Ld and Lq
mH
Electrical time constant
ms
2.6
2.5
3.0
2.9
Electrical time constant
ms
2.3
2.9
3.3
Moment of inertia rotor
lb in2
0.48
0.48
0.66
0.66
Moment of inertia rotor
lb in2
0.273
0.499
0.724
Anti condensing heating voltage
VDC
23
40
19
34
Anti condensing heating voltage
VDC
57
45
38
11.8
36.2
8.4
HMTS drum motor
HMTS drum motor 62
F
Supply voltage range
63
Flexible options across series, sizes, and configurations.
Cable and feedback systems
NGI drum motors are available with different cable and feedback configurations to meet specific installation and application requirements. The options in this section apply across drum motor series, sizes, and available power/torque upgrades. This makes it easy to identify the relevant cable and feedback solution for the selected drum motor configuration. Available options include: Cable configurations Feedback systems Options across multiple series and sizes Configurations for standard and power/torque upgrade variants
64
65
Cable specifications
Option - Feedback system NGI drum motors can be supplied with various forms of feedback systems, including resolver, incremental- or absolute encoders.
Cable specifications
Resolver
Power cable < 16.40 ft.
Resolver
Construction
4 x AWG21 + (2 x AWG 24)C shielded
Number of poles
2
Voltage
600 V (AWG21)
Input frequency
10 kHz
Sheath material
PUR (TPE-U)
Input voltage
7 Vrms
Outer diameter (D)
0.3 in (max. 0.31)
Connection
Signal cable 6 AWG26, shielded
Sheath colour
orange (similar to RAL 2003)
Temperature range (fixed in place)
-58°F to 221°F
Cable specifications / Resolver cable
Minimum bending radius (fixed in place)
7.5 x D
Construction
3 x 2 x AWG26 shielded
Flame retardant
Yes
Sheath material
PVC
Halogen free
Yes
Outer diameter (D)
0.22 in
Oil resistant
Yes
Sheath colour
Grey (RAL 7032)
UL
Yes
Temperature range (fixed in place)
- 40 °F to + 176 °F
Minimum bending radius (fixed in place)
6xD
Flame retardant
Yes
Power cable ≥ 16.40 ft.
Halogen free
Yes
4 x AWG19 + (2 x AWG22)C shielded
Oil resistant
Yes
Voltage
600V(AWG19)
UL
No
Sheath material
PUR (TPE-U)
Colour assignment resolver cable
Signal / Function
Outer diameter (D)
0.3 in (max. 0.31)
Sheath colour
orange (similar to RAL 2003)
White
REF +
Temperature range (fixed in place)
-58°F to 221°F
Brown
REF -
Minimum bending radius (fixed in place)
7.5 x D
Green
SIN +
Flame retardant
Yes
Yellow
SIN -
Halogen free
Yes
Pink
COS +
Oil resistant
Yes
Grey
COS -
UL
Yes
Construction
66
Cable specifications / Resolver / hybrid cable Construction
Power (4 x AWG21) + Signal (2 x AWG21+3x(2x)AWG26 + 2 x AWG22)
Voltage
1000V peak
Colour assignment power
Signal / Function
Sheath material
PUR
Black / 1
U
Outer diameter (D)
0.44 in
Black / 2
V
Sheath colour
Grey (similar to RAL 7001)
Black / 3
W
Temperature range (fixed in place)
- 22 °F to + 194 °F
Green-yellow
PE
Minimum bending radius (fixed in place)
5xD
Brown
PT1000 or PTC
Flame retardant
Yes
White
PT1000 or PTC
Halogen free
Yes
Oil resistant
Yes
UL
Yes
Pin assignment Power / Option: Terminal Box
Signal / Function
Colour assignment / Resolver / hybrid cable
Signal / Function
L1
U
Black / 1
U
L2
V
Black / 2
V
L3
W
Black / 3
W
M5x8 Screw
PE
Green-yellow
PE
PT1000 + / 5
PT1000 or PTC
Black / 7
PT1000 or PTC
PT1000 - / 6
PT1000 or PTC
Black / 8
PT1000 or PTC
White
REF +
Brown
REF -
Green
SIN +
Yellow
SIN -
Pink
COS +
Grey
COS -
67
Option - Feedback system
Option - Feedback system
Incremental Encoder - DBS36
EKS36 / EDS35
DBS36
EKS36 / EDS35
Number of pulses
100 - 2048
Resolution per turn
18 / 24 bit
Communication interface
Incremental (ABZ)
Number of absolute detectable turns
1
Communication interface
TTL (RS422) / HTL
Measuring step per turn
262.177 / 16.777.216
Supply voltage (TTL)
5V / 7-30V
Communication interface
HIPERFACE DSL
Supply voltage (HTL)
7-30V
Connection
Hybrid cable, Terminal Box
Connection
2-Cable solution, Hybrid cable
Cable specifications / DBS36 cable / 2-cable solution
Cable specifications / EKS36 / EDS35 / Hybrid cable
Construction
4 x 2 x AWG26 shielded
Sheath material
PUR (TPE-U)
Outer diameter (D)
0.21 in
Sheath colour
Black
Temperature range (fixed in place)
- 22 °F to + 194 °F
Minimum bending radius (fixed in place)
5xD
Colour assignment DBS36
Signal / Function
White
A
Brown
A-
Pink
B
Grey
B-
Green
Z
Yellow
Z-
Red
Us (5V / 7-30V)
Blue
GND (0V)
Cable specifications / DBS36 cable / Hybrid cable
68
Note: Motor data plate storage on EKS36 for Schneider PacDrive 3 and EKS36 / EDS35 for Beckhoff AX8000 on request.
Construction
((2xAWG26)C + 4 x AWG17)C
Voltage
1000V
Sheath material
PUR
Outer diameter (D)
0.35 in (max. 0.37 in)
Sheath colour
orange
Temperature range (fixed in place)
- 122 °F to + 221 °F
Minimum bending radius (fixed in place)
7.5 x D
Flame retardant
Yes
Halogen free
Yes
Oil resistant
Yes
UL
Yes
Colour assignment / Cable specifications / EKS36 / EDS35 / Hybrid cable
Signal / Function
Black / 1
U
Black / 2
V
Black / 3
W
Construction
Power (4 x AWG21) + Signal (2 x AWG21+3x(2x)AWG26 + 2 x AWG22)
Green-yellow
PE
Voltage
1000V
Blue
GND / DSL
Sheath material
PUR
White
+US / DSL+
Outer diameter (D)
0.44 in
Sheath colour
Grey (similar to RAL 7001)
Temperature range (fixed in place)
- 22 °F to + 194 °F
Minimum bending radius (fixed in place)
5xD
Flame retardant
Yes
Halogen free
Yes
Oil resistant
Yes
UL
Yes
Colour assignment / DBS36 / Hybrid cable
Signal / Function
Black / 1
U
Black / 2
V
Black / 3
W
Green-yellow
PE
Black / 7
PT1000 or PTC
Black / 8
PT1000 or PTC
White
A
Brown
A-
Pink
B
Grey
B-
Green
Z
Yellow
Z-
Red
Us (5V / 7-30V)
Blue
GND (0V) 69
Option - Feedback system
Option - Feedback system
SKS36
ECI 1119
SKS36
ECI 1119
Number of Sin / Cos Periods per revolution
128
Resolution per turn
19 bit
Number of absolute revolutions
1 (single turn)
Number of absolute detectable turns
1
Resolution
4096
Measuring step per turn
524.288
Communication interface
HIPERFACE
Communication interface
EnDat 2.2
Supply voltage
7 to 12 V DC
Connection
Hybrid cable
Connection
2-Cable solution, Hybrid cable
Note: Motor data plate storage on ECI 1119 for B&R ACOPOS on request.
Note: Motor data plate storage on SKS36 for PacDrive 3 on request. Cable specifications / ECI 1119 / Hybrid cable
Cable specifications / SKS36 cable / 2-Cable solution
Construction
Power (4 x AWG21) + Signal (2 x AWG21+3x(2x)AWG26 + 2 x AWG22)
Voltage
1000V peak
Sheath material
PUR
Outer diameter (D)
0.44 in
Sheath colour
Grey (similar to RAL 7001)
Temperature range (fixed in place)
- 77 °F to + 176 °F
Minimum bending radius (fixed in place)
5xD
Flame retardant
Yes
DATA +
Halogen free
Yes
DATA -
Oil resistant
Yes
White
SIN +
UL
Yes
Brown
REF SIN
Pink
COS +
Colour assignment / ECI 1119 / Hybrid cable
Signal / Function
Black
REF COS
Black / 1
U
Red
US (8 V DC)
Black / 2
V
Blue
GND (0 V DC)
Black / 3
W
Green-yellow
PE
brown Sensor
UP
White Sensor
0V
Grey
DATA
Pink
DATA
Green
CLOCK
Yellow
CLOCK
Construction
4 x 2 x AWG26 shielded
Sheath material
PUR (TPE-U)
Outer diameter (D)
0.21 in
Sheath colour
Black
Temperature range (fixed in place)
- 22 °F to + 194 °F
Minimum bending radius (fixed in place)
5xD
Colour assignment SKS36
Signal / Function
Grey Green
Cable specifications / SKS36 cable / Hybrid cable
70
Construction
Power (4 x AWG21) + Signal (2 x AWG21+3x(2x)AWG26 + 2 x AWG22)
Voltage
1000V peak
Sheath material
PUR
Outer diameter (D)
0.44 in
Sheath colour
Grey (similar to RAL 7001)
Temperature range (fixed in place)
- 22 °F to + 194 °F
Minimum bending radius (fixed in place)
5xD
Flame retardant
Yes
Halogen free
Yes
Oil resistant
Yes
UL
Yes
Colour assignment / SKS36 / Hybrid cable
Signal / Function
Black / 1
U
Black / 2
V
Black / 3
W
Green-yellow
PE
Black / 7
PT1000 or PTC
Black / 8
PT1000 or PTC
Yellow
DATA +
Green
DATA -
White
SIN +
Brown
REF SIN
Pink
COS +
Grey
REF COS
Red
US (8 V DC)
Blue
GND (0 V DC)
For feedback systems not listed, please contact your local NGI sales representative. 71
Thermal protection & material variants
Frequency converters and servo drives
Thermal protection NGI drum motors are fitted with a PT1000 thermal sensor. If necessary, we can also offer a PTC thermal sensor. The temperature sensor must be monitored by an external circuit, such as a frequency converter which switches off the
NGI drum motors are synchronous permanent magnet motors and must be operated using a frequency converter or servo drive between the mains supply and the motor.
power supply to the motor, if the maximum temperature is exceeded.
PT1000, technical data According to standard
IEC 60751
Measuring range
–58°F to +572°F
Nominal resistance
1000 Ohm @ 32 °F
Tolerance
+/- 0.6K @ 32°F (IEC 60751 F0.6)
Measurement current
0.3 mA
Inverter
PTC, technical data Operating voltage range
2.5 to 24 V DC
Maximum permissible operating voltage
30 V DC
NGI drum motors have been tested and verified with a wide range of frequency converters and servo drives. Application specific guidance is available on request.
Resistance at switching temperature - 4 °F to TREF −36 °F
< 250 Ω
TREF −9 °F
≤ 550 Ω
TREF +9 °F
≥ 1.330 Ω
TREF +27 °F
≥ 4.000 Ω
Possible speed adjustment ranges:
1
Sensorless operation with suitable frequency inverter
1 : 7 to 1 : 300 - (depending on Inverter type)
Servo drive and feedback
up to 1 : 10.000
Actual performance depends on drive type, control mode, and application.
Material variants Component
Shell [Other materials on request]
Variants
Standard MTS
Standard HMTS
Crowned
Stainless steel 1.4301
Cylindrical
Stainless steel 1.4301
Cylindrical with key
Stainless steel 1.4301
Variants: Any profiled drum shell design, knurling (length depending) Flat rubber lagging
NBR, shore 50A - 90A. Colour: blue or white
Profiled rubber lagging
NBR, shore 50A - 90A. Colour: blue or white
Flat rubber lagging
PUR, shore 70A - 90A. Colour: blue or white
Profiled rubber lagging
PUR, shore 70A - 90A. Colour: blue or white
Shaft
Alternative design on request
Stainless steel 1.4305
Stainless steel 1.4301
Cover
Laser engraved nameplate
Stainless steel 1.4305
Stainless steel 1.4301
Terminal box
Stainless steel 1.4305
Stainless steel 1.4301
Straight cable gland
Stainless steel 1.4305
Electrical connection
Contact your local NGI sales representative for detailed compatibility and application support.
Elbow cable gland
Stainless steel 1.4301 Stainless steel 1.4305
Cable with connection plugs on request
Operating temperature range of our drum motor
72
Standard when operating with belt
+41 °F to +104 °F
Optional low temperature range
to -13 °F lower temperature on request
73
Technical data
Technical data
Cable connection, dimensions cable connection and constructions/material variants are the same for all MTS drum motor classes.
Cable connection, dimensions cable connection and constructions/material variants are the same for all HMTS drum motor classes.
Cable Connection MTS
Cable Connection HMTS Option TB hygienic: Terminal box 1.97”
Option EG: Elbow gland Elbow Gland only available for sensorless and the solution is IP66. 0.98”
Ø1.18”
Option CG: Cable gland, straight Cable lengths > 10 m on request. Hybrid cable is possible. 0.95”
74
1.97”
1.42”
Ø3.74”
Option EG: Elbow gland Elbow Gland only available for sensorless and the solution is IP66.
Option CBX: Cable box
0.98”
Ø2.34”
Ø1.18”
Option CG hygienic: Cable gland, straight Cable lengths > 10 m on request. Hybrid cable is possible.
Option CG2: Cable gland, straight, for 2 cables 0.83”
1.06”
1.22”
Ø3.15”
0.95”
1.08”
Option CBX hygienic: Cable box 1.63”
Ø2.34”
Option CG2: Cable gland, straight, for 2 cables 0.83”
0.95”
1.06”
Ø3.74”
1.06”
1.97”
0.95”
1.06”
Option TB: Terminal box
75
Item descriptions for Drum Motors This decoder explains how NGI Drum Motor item descriptions are structured and how each element in the name corresponds to a specific technical attribute. Optional elements are included only when applicable. If an option is not specified, it is omitted from the item description without placeholders.
MTS 113 - 0,65 - P - 250 - 291 - N - 500 - CY, Blue PUR - 1.4301 - CG Nominal diameter [mm] Product type
Rated Voltage [V] Rated power [kW]
Material
Shell length [mm]
Rated rpm
Optional Rubber material
PerformanceIndicator
E connection
N = Standard P = Upgraded stator T = Upgraded gear box
CG = Cable gland EG = Elbow gland TB = Terminal box CBX = Cable box
PT = Upgraded stator and gear box
Feedback system N = Sensorless FR = Resolver FK = SKS36 FD = EKS36 FE = EDS35 FL = HES2-001 FH = HES3-001 FG = ECI1118 FB = ECI1119 FQ = EQI1131 FS = DBS36/100 HTL 30V FT = DBS36/200 HTL 30V FF = DBS36/500 TTL 5V FM = DBS36/1024 HTL 30V FC = DBS36/1024-TTL 5V FN = DBS36/2048 TTL 5V FJ = DBS36/2048 TTL 30V
Drive shape CY = Cylindrical CR = Crowned KY = Key KS = Key slot PR = Profiled CYKN = Cylindrical knurling CRKN = Crowned knurling CYGR = Cylindrical grooved CRGR = Crowned grooved CYDR = Cylindrical diamond CYRI = Cylindrical ridges/spikes CRRI = Crowned ridges/spikes CM = Custom
This decoder applies to all NGI Drum Motors using the updated naming structure from May 11, 2026.
76
Local expertise. Stronger solutions. Our DACH Sales Team combines local market knowledge with strong application understanding to help customers find the right drum motor solution. Close to our customers and their applications, we turn requirements into the right configuration and keep projects moving from first dialogue to final solution.
MTS drum motors
Drum Motor Shell and Surface Our drum motors are available with a wide range of shell designs to meet functional, hygienic, and application‑specific requirements. All drum shell profiles can be supplied with integrated sprockets as well as rubber lagging. Available configurations include:
Cylindrical or crowned steel drum shells surfaces Rubber‑lagged drum shells: cylindrical, crowned, or profiled Knurled surfaces: cylindrical or crowned, for increased friction Keyed drum shell designs, available as welded keys or snap‑on keys Stainless steel profiled drum shell surfaces for specialised applications
Additional designs and special configurations are available to support specific conveyor layouts, belt types, and performance requirements. Below are selected examples.
Support That Stands Out. Our Application Engineering Team works with you to ensure the drum motor is configured for your exact machine, application, and production flow. While others only ask for specs like power and width, we dig deeper—tension, load, usage patterns—because the right setup starts with the right understanding. And we make the process easy. You’ll save time, prevent costly missteps, and get a tailored drive solution that just works.
78
79
Reliable and inventive supplier Our extensive experience and technical understanding let us, and our customers, navigate complex challenges with clarity and wisdom. We are always thinking ahead and investing in innovation to ensure that clients have access to the best and most forward-thinking technologies available.
Contact us to learn how you can maximize space without sacrificing a thing!
Thanks for your interest Go to ngi-global.com/us/drivetech-division/
