This should be easy, just follow our instruc tions and you will be back to Net flix in no time.
What you need
• Some bubbly or your preferred relaxant
• Use the packaging car ton as a working sur face to prevent produc t damage during assembly
• Phillips Screwdriver
• Drill
•
•
1. Do not tighten bolts / screws completely until all bolts / screws are lined up and inser ted into holes.
2 . Do not over tighten screws and bolts to avoid stripping.
Your highly anticipated dresser has arrived! Let ’s get this thing star ted. First, lay out the Top Panel (A), the Lef t Side Panel (C ), the Right Side Panel (D), Base - Front panel (L), and Drawer Front Panel (M) on a sof t sur face or towel in front of you. Inser t the Cam Bolts (1) into the designated holes following the image below
Step 2
Now inser t the Wooden Dowels (2) into the Top Back Panel (E), then push Bot tom Back Panel (F ) together as shown.
Cam lock time! Push the Lef t Side Panel (C ) and Right Side Panel (D) into the sides of the pieces you assembled in Step 2 . Secure in place using the Cam Locks (3). See the nex t page for instruc tions on using Cam Locks.
First, your cam bolt (or cam pin) will need to be properly inser ted into the flat side of the board.
Did you know?
Cam locks are used to join t wo panels together, usually the edge of one to the flat side of another.
Impor tant Note: Only tighten the cam bolt until it is secure. Do not over-tighten.
Nex t, you will fit the proper hole on the edge of the associated joining panel over the cam bolt.
Impor tant Note: When installed properly, the head of the cam bolt will be visible through the larger hole on the side of the joining panel.
Nex t, you will notice the cam lock has a “C ” shaped back Commonly, an arrow on the front of the cam lock points in the same direc tion as the open sec tion on back
Using these as your cue, inser t the cam lock into the large hole so the opening of the “C ” fits over the head of the cam bolt
Using a screwdriver, you will turn the cam lock until it stops, usually bet ween 130º or 180º You will feel the panels pulling closer until they are secured
Impor tant Note: Only turn the cam lock until the panels are fully engaged & feel secure. Turning too far may lead to hardware failure
Still having issues?
Now at tach the Top Panel (A) to the pieces you assembled in Step 3. Secure in place using the Wooden Dowels (2), using the Cam Locks (3).
At tach the Bot tom Front Rail (H) to the dresser and secure into place using the Cam Locks (3). Step 5
Locate the Top Front Rail (B) and make sure the large hole is facing upwards. Secure the unit with the Cam Locks (3) and Screws (8).
Nex t, locate the Wooden Dowels (2) and place it into the corresponding holes. Then grab the Bot tom Panel (G) and at tach it to the what you’ve assembled so far using the Cam Locks (3) and Screws (8). Step 7
8
Okay, time to at tach the Base Frame!
First, inser t the Cam Bolts (1) into the Bot tom Panel (G).
Nex t, at tach the Base - Lef t Side Panel ( J) and the Base - Right Side Panel (K) to the Base - Front Panel (L). Secure in place using the Wooden Dowels (2), using the Cam Locks (3).
At tach the pieces you assembled in Step 9 to the dresser and secure into place using the Cam Locks (3).
We’re about half way through! Now would be the per fec t time to stretch or have a snack break. We’re going to
Now, at tach the Base - Back Panel (I) using the Screw (13) and the Cam Locks (3).
This may be our favorite step of all (and we have a feeling it ’s going to be yours, too). Stick the Foam Pad (12) onto the four corners of the Base Frame as shown.
Step 13
Now that we’ve got the frame so far along, it ’s time to move onto the drawers. Locate the Drawer Front Panel (M) and at tach the Drawer Suppor t Rail (O) using the Wooden Dowels (4) and the Cam Locks (3).
Then at tach the Drawer Right Side Panel (Q) using the Wooden Dowels (4), the Screws (8), and the Barrel Nuts (7 ). Make sure the barrel nuts are facing the correc t direc tion, checking the image below. Tighten to 80% .
Helpful Tip:
If the Screw (8) isn’t lining up with the Barrel Nut (7 ), use a screwdriver to slightly turn the Barrel Nut (7 ) into place.
14
Slide the Drawer Bot tom Panel (R) into place, then secure the Drawer Back Panel (N) with the Wooden Dowels (4), the Screws (8), and the Barrel Nuts (7 ). Repeat for all three drawers.
G rab the Drawer Side Panel (Left) (P) and at tach it to the other side of the drawer using the Wooden Dowels (4), the Screws (8), and the Barrel Nuts (7 ).
NOTE: The drawer side panels with the labels are to be used for and installed as the top drawer
We want your produc ts to last as long as possible, so we recommend that you re -tighten the bolts 2 weeks af ter assembly.
It ’s time to get your furniture on its feet! Flip over your dresser to make sure it is right side up Then check to make sure the device at the end of the side rail is correc t, referencing the figure below
NOTE:
B efore installing the drawer, ple ase che ck that the device at the end of the slide rail is corre c t according to the figure below
If the device is not in the right position, Ple ase adjust the device to the corre c t position by hand. Refer to the nex t page.
17
If your slide rail needs to be correc ted, refer to the “Note” to the right. If not, go ahead and move on to the nex t step.
NOTE:
Refer to the image below to corre c t the device at the end of the slide,just nee d to gently move the c ylinder with your hand
Step 18
Pull out the inner ball bearing slides on each side all the way out until it stops. Only one drawer can be opened at a time.
Note: Only one drawer can be opened at a time.
Note: pull the inner ball be aring slides on e ach side all the way out until it stops (may be slightly gre asy)
incorr ect
19
G rab your first drawer (and a friend). Slide the drawer into place at the bot tom of the dresser. Both sides must be installed at the same time, so you will need t wo people for this par t.
NOTE: You’ll need t wo people to assemble the drawers so grab a friend! During installation, both sides must be installed at the same time.
Step 1: Hold the inner ball with your hand. Do not let it move during installation.
Step 2: Align the grooves on the rails. The inner ball must stay close to the track.
Step 3: Hold the inner ball and inser t the track until close to the drawer panel.
Step 4: Push the drawer in slowly and simultaneously with both hands.
Note:
Install the other drawers by referring to the previous installation method.
Note: Only one drawer can be opened at a time.
NOTE: When installing the middle drawer, you need to close the bot tom drawer.
NOTE:When installing the top drawer, you need to close the bot tom and middle drawer.
Safet y first! Secure the Plastic Bracket (for Anti-Tip) (10) to the back of the unit using the Screws (9) and then loop the Plastic Tether (6) through the Bracket.
IMPORTANT NOTE:
Young children (and/or pets) can be seriously injured by tipping furniture units. You must install the provided anti-tip kit hardware solution, as instruc ted, to prevent the furniture units) from tipping over - which could possibly lead to injuries or damage.
The provided anti-tip kit hardware solution is intended only as an additional safet y measure & deterrent; it is not a substitute for proper adult super vision.
The provided anti-tip kit hardware solution is not an ear thquake restraint. If you wish to add the ex tra securit y of ear thquake restraints, they must be purchased & installed separately.
5 / 1 6 ” D
5 / 1 6 ” H
2. Pinch and insert.
3 Begin tightening. is 4. Anchor is secure when screw tightened to 100%/
Find where you want your dresser to live and then mount the Plastic Bracket (for Anti-Tip) (10) to the wall using the provided Wall Anchors (5) and the Screws (11). We recommend using a drill bit to drill a pilot hole first. Last, but not least, loop the Plastic Tether (6) through both brackets to safely secure the unit to the wall.
You did it! Time for a celebrator y pizza? The answer to that is always yes!
Non- Dry wall Anchor (5) requires a 1/4” Drill Bit
Dry wall Anchor (14) requires a 5/16” Drill Bit.
To Remove Drawer, If Needed
• Pull the drawer fully open so levers are visible .
• Push up on lef t side lever and down on right side lever.
• Holding levers in place, pull drawer toward you.
Note: O nly one drawer can be opened at a time.
Warning: Risk of injur y to persons - do not place a television on this furniture. This furniture is not approved for use with a television .
Give us a call 1- 866 -619-1004 or shoot us a message at help@nathanjames.com we will issue you a free replacement with zero hassle.
Our way Their way
Give us a call
Replacement
You
Re-package item
Schedule pick up Track package
Replacement
You
We really don’t want you to go through the hassle of re -packaging your item and sending it back , because let ’s be honest…nobody has time for that.
We want your Iris Dresser to last as long as possible, so we recommend that you tighten the screws 2 weeks af ter assembly and for added safet y check the tightness of all screws ever y 2 months.
For proper care and treatment of wood and metal please check our website at NathanJames.com/products
Safe use of this produc t star ts with you.
Use this Dresser responsibly with the primar y concern for your safet y. Follow assembly instruc tions carefully and inspec t produc t upon receipt and each use.
Nathan James and its parent companies cannot be held legally responsible for any injuries or death resulted from failure to follow instruc tions or improper use of this produc t
Do not modif y the struc ture of this produc t in any way.
Our produc ts have been tested to meet specific safet y measures as they were originally intended to be sold. Any modifications will present the risk of creating significant safet y issues which NJ will not be responsible for.
DO NOT use for commercial purposes
DO NOT climb on dresser
DO NOT exceed weight limit
DO NOT leave spilled liquid on dresser
DO NOT use if dresser is damaged or broken
DO NOT make temporar y repairs
DO NOT use outdoors
