How to use cam locks
Did you know?
Cam locks are used to join t wo panels together, usually the edge of one to the flat side of another.
First, your cam bolt (or cam pin) will need to be properly inser ted into the flat side of the board.
Import ant Note: Only tighten the cam bolt until it is secure. Do not over-tighten.
Next, you will fit the proper hole on the edge of the associated joining panel over the cam bolt.
Import ant Note: When installed properly, the head of the cam bolt will be visible through the larger hole on the side of the joining panel.
Next, you will notice the cam lock has a “C” shaped back. Commonly, an arrow on the front of the cam lock points in the same direct ion as the open sec tion on back
Using these as your cue, insert the cam lock into the large hole so the opening of the “C” fits over the head of the cam bolt.
Using a screwdriver, you will turn the cam lock until it stops, usually between 130º or 180º. You will feel the panels pulling closer until they are secured.
Import ant Note: Only turn the cam lock until the panels are fully engaged & feel secure. Turning too far may lead to hardware failure
Still having issues?
If a cam lock seem s to be spinning in place or is not “catching” or pulling the panel s together as expected , first remo ve the cam loc k & tr y agai n whil e ma ki ng sure that every thin g is properly positoned & oriented.
If you are still having issues getting things worki ng as expected, firs t re move the cam lock then unscr ew th e cam bolt slightl y (les s than 1 complete turn) to see if that helps with the alignment of the cam lock & bolt
Insert the 8*30mm Wooden Dowels (9) into the designated holes. Next, slide the Left Back Panel (H) and the Right Back Panel (I) into place and push down to connect the pieces. Grab the 15*10mm Cam Locks (18) and insert them into their corresponding holes. Use your screwdriver to twist the cam locks into place. The panels with pull closer until they are secured. Step 2
Step 3
Things are moving along quickly! Take your connected parts from the previous step - the Left Side Panel (A) and the Left Back Panel (H) and attach them to the Top Panel (G) using the 8*30mm Wooden Dowels (9) and the 15*10mm Cam Locks (18). You will also slip the 1/4”*16mm Flat Washers (4) onto the 1/4”*32mm Hex Button Head Bolts (1) and insert these parts into their designated holes to make sure everything is nice and secure!
Step 4
We can’t forget about the Right Side Panel (B) and the Right Back Panel (I). Grab those connected panels and secure them into place on the other half of the Top Panel (G), repeating the same methods from the pervious step.
1 4
Step 5
Locate the Top Front Rail (C) and make sure the large hole is facing upwards. Grab the 1/4”*45mm Hex Button Head Bolts (2) and the 1/4”*13mm Flat Washers (5) to secure it into its spot. Next, use the Crescent Spacers (6), the 1/4”*55mm Hex Button Head Bolts (3), and the Allen Key (8) to lock the Top Front Rail (C) into place following the image below.
The large hole faces upward
Step 6
Our dresser is starting to take form! Locate the 8*30mm Wooden Dowels (9) and place it into its corresponding holes. Then grab the Bottom Panel (D) and attach it to the assembly you have been working on using the 1/4”*55mm Hex Button Head Bolts (3), the 1/4”*13mm Flat Washers (5), and the 1/4”*15MM Barrel Nuts (7). Make sure the Barrel Nuts are facing upwards. We need the bolts to line up with the barrel nuts.
Extra attention now will help ensure this dresser stands the test of time!
Step 7 18 x2
Grab those 15*10mm Cam Locks (18) and twist them into place using your screwdriver to tighten the panels into place.
x2
18 9 9
Step 8
Find both of (F) and make sure you can see holes on each, paying attention to the image below. Use (3) and (5) to secure these parts into place along the long edges of your assembly. Tighten to 75%.
Time to give your furniture a leg up (or two)! Take both of the Side Leg Frames (E) and secure them onto your assembly using the 1/4”*55mm Hex Button Head Bolts (3) and the 1/4”*13mm Flat Washers (5). At this point, only tighten to 75%. Step 9 3
We’re about halfway through! Now would be the perfect time to stretch or have a snack break. We’re going to need to be energized to finish off these last couple of steps. Next we’re going to make sure the bottom of your dresser is secure. Use the Crescent Spacers (6), the 1/4”*55mm Hex Button Head Bolts (3) and the Allen Key (8) in all four corners to properly connect them to each other. Tighten to 75%. Step 10
Now that we’ve got the frame so far along, it’s time to move onto the drawers. Locate the Drawer Front Panel (J) and attach the Drawer Bottom Stretcher (O) using the 15*10mm Cam Locks (18).
Then attach the Drawer Right Side Panel (L) using the 8*30mm Wooden Dowels (9), the 3/16”*35mm Hex Button Head Bolts (19), and the 3/16”*8mm Barrel Nuts (20). Make sure the barrel nuts are facing the correct direction, checking with the image below. Tighten to 75%. Step 11
Slide the Drawer Bottom Panel (N) into place, then secure it with the 8*30mm Wooden Dowels (9), the 3/16”*35mm Hex Button Head Bolts (19), and the 3/16”*8mm Barrel Nuts (20). Repeat for all three drawers.
Grab the Drawer Left Side Panel (K) attach it to the other side of the drawer using the 8*30mm Wooden Dowels (9), the 3/16”*35mm Hex Button Head Bolts (19), and the 3/16”*8mm Barrel Nuts (20). Then attach the Handle (10) using the M3.5*14mm Screws (11). Repeat this for all three drawers.
NOTE:Drawers with warning labels are installed on the top drawer
Step 14
It’s time to get your furniture on its feet! Flip over your dresser to make sure it is right side up. Then check to make sure the device at the end of the side rail is correct referencing the figure below.
Note
Before installing the drawer, please check that the device at the end of the slide rail is correct according to the figure below If the device is not in the right position, Please adiust the device to the correct position by hand. Refer to the next page
Left Side Panel
Right Side Panel
Step 15
If your slide rail needs to be corrected refer to the “Note” to the right. If not, go ahead and move on to Step 16.
Left Side Panel
Note
Refer to the image below to correct the device at the end of the slide gently move the cylinder with your hand
Right Side Panel
Step 16
Pull out the inner ball bearing slides on each side all the way out until it stops. Only one drawer can be opened at a time.
Note Only one drawer can be opened at a time.
Step 17
Grab your first drawer (and a friend). Slide the drawer into place at the bottom of the dresser. Both sides must be installed at the same time, so you will need two people for this part.
Note: Only one drawer can be opened at a time
Note You’ll need two people to assemble the drawers,so grab a friend, During installation, both sides must be installed at the same time.
Step 1: Hold the inner ball with your hand, Do not let it move during installation,
Step 2: Align the grooves on the rails, the inner ball must stay close to the track,
Step 3: Hold the inner ball and insert the track, Until close to the drawer panel
Step 4: Push drawer,push the drawer in slowly and simultaneously with both hands
Note Install the other drawers by referring to the previous installation method,
Note: Only one drawer can be opened at a time.
NOTE: When installing the middle drawer, you need to close the bottom drawer
Note: Only one drawer can be opened at a time.
NOTE: When installing the top drawer, you need to close the bottom drawer and middle drawer,
We can finally see just how beautiful this dresser really is! Adjust the footpads to make sure it is both sturdy and stunning! Step 18
Safety first! Secure the Plastic Bracket(for Anti-Tip) (12) to the back of the unit using the M3.5*14mm Screws (13) and then loop the Plastic Tether (14) through the Bracket.
IMPORTANT NOTE:
Young children (and/or pets) can be seriously injured by tipping furniture units. You must install the provided anti-tip kit hardware solution, as instructed, to prevent the furniture units) from tipping over - which could possibly lead to injuries or damage.
The provided anti-tip kit hardware solution is intended only as an additional safety measure & deterrent; it is not a substitute for proper adult supervision.
The provided anti-tip kit hardware solution is not an earthquake restraint. If you wish to add the extra security of earthquake restraints, they must be purchased & installed separately.
Find where you want your dresser to live and then mount the Plastic Bracket(for Anti-Tip) (12) to the wall using the provided Wall Anchors (16) and the M4*50mm Screws (15).
We recommend using a 1/4” drill bit. Last, but not least, loop the Plastic Tether (14) through both brackets to safely secure the unit to thewall.
You did it! Time for a celebratory pizza? The answer to that is always yes!
Prepare your wall for Anti-Tip Kit Installation
Recommended Drill Bit : 1/4” Drill Bit
pull through to secure
Note: Only one drawer can be opened at a time.
To Remove Drawer, If Needed
• Pull the drawer fully open so levers are visible.
• Push up on left side lever and down on right side lever.
• Holding levers in place, pull drawer toward you.
Warning: Risk of injur y to persons - do not place a television on this furniture. This furniture is not approved for use with a television.
