Shadow Storage Cabinet Instruction Sheet 72600 by nathanjameshome

Shadow Storage Cabinet

24-0403-VN Scan me! Free Lifetime Warranty 90 90 M I NUTE ASSE MBLY SKU 72600

Let’s build the

This should be easy, just follow our instructions and you will be back to Netflix in no time.

Estimated time for assembly

What you need

• Some bubbly or your preferred relaxant

• Use the packaging carton as a working surface to prevent product damage during assembly

• Phillips head screwdriver 90:00

Weight Limitation

Toll-free at 1-866-619-1004 Help@nathanjames.com Nathanjames.com/help

included Scan me! Free Lifetime Warranty

What’s

Ok, let’s get rolling

not

drill Top Max. Capacity: 50 lbs. Interior Top Shelf: 40 lbs. Interior Lower Shelf: 50 lbs. Description Qty A Top Panel 1 B Left Side Panel 1 C Right Side Panel 1 D Shelf Panel 1 E Bottom Panel 1 F Back Top Rail 1 G Back Panel 1 H Top Front Rail 1 I Leg Frame 2 J Right Door 1 K Left Door 1 L Back bottom Rail 1

use a

The goods

A B C D E F L H I I G J K

4 What’s included Description Qty 1 M6*35mm Cam Bolt 9 2 Magnetic Catch 2 3 M3*15mm Screw 4 4 Allen key 1 5 M8*30mm Wooden Dowel 16 6 1/4”*13mm Flat Washer 20 7 1/4”*32mm Hex Button Head Bolt 16 8 1/4”*55mm Hex Button Head Bolt 4 9 15*10mm Cam Lock 9 10 M4*35mm Screw 8 11 Hinge 4 12 M4*14mm Screw 24 13 5/32”*25mm Hex Button Head Bolt 2 14 Handle 2 15 M4*14m Screw 2 16 Plastic Bracket (for Anti-Tip) 2 17 Plastic Tether (for Anti-Tip) 1 18 Non-Drywall Anchor 2 19 Drywall Anchor 2 20 M4*55mm Screw 2 21 Leveler (Extra) 2 19 20 21

Step 1

Let’s get this thing fired up! First things first, insert the Cam Bolts (1) into the Top (A), Left (B), and Right Side Panels (C) as shown below. Tighten using a Phillips head screwdriver.

Then, attach the two Magnetic Catches (2) using four M3*15mm Screws (3).

Tip! Door Catcher can be adjusted from front to back for proper door alignment.

1 x9 2 x2 3 x4 B C 1 1 1 1 1 1 A E 3 3 2 1 1 1

FRONT

Step 2

Then connect the Shelf Panel (D) and Bottom Panel (E) to the Right Side Panel (C) using the Wooden Dowels (5), as pictured below. Slide a Flat Washer (6) onto a Hex Button Head Bolt (7) then use the Allen Key to tighten the Shelf Panel (D) and Bottom Panel (E) to the Right Side Panel (C). Repeat four times, as shown below. Tighten to 75% for now. 7 6 5

x4 x4 x4 6 7 4 7 6 5 5 5 5 7 6 7 6 C D E

Step 3 7 6 5

No this isn’t Deja Vu! Repeat Step 2 to attach the Left Side Panel (B) to the Shelf Panel (D) and Bottom Panel (E).

Don’t go Hulk-smash on the tightening just yet, aim for a gentle 75%.

x4 x4 x4 B 5 5 5 5 7 7 7 7 6 6 6 6 C D E

It’s Cam Lock time! Use the Cam Locks (9) to attach the Top Front Rail (H) to the unit, making sure the big holes are facing up.

See the following page for Cam Lock Assembly Quick Guide.

9 9 B 9

H C

Step 4 9

How to use cam locks

Did you know?

Cam locks are used to join t wo panels together, usually the edge of one to the flat side of another.

First, your cam bolt (or cam pin) will need to be properly inser ted into the flat side of the board.

Import ant Note: Only tighten the cam bolt until it is secure. Do not over-tighten.

Next, you will fit the proper hole on the edge of the associated joining panel over the cam bolt

Import ant Note: When installed properly, the head of the cam bolt will be visible through the larger hole on the side of the joining panel.

Next, you will notice the cam lock has a “C” shaped back. Commonly, an arrow on the front of the cam lock points in the same direct ion as the open sec tion on back .

Using these as your cue, insert the cam lock into the large hole so the opening of the “C” fits over the head of the cam bolt.

Using a screwdriver, you will turn the cam lock until it stops, usually between 130º or 180º. You will feel the panels pulling closer un til they are secured.

Import ant Note: Only turn the cam lock until the panels are fully engaged & feel secure. Turning too far may lead to hardware failure.

If a cam loc k seem s to be spinning in plac e or is not “catching” or pulling the panel s together as expected, first rem ove th e cam loc k & try again whil e mak in g sure that every thing is properly positoned & oriented .

If you are still having issues getting things work in g as expected, firs t rem ove the cam lock then unscre w th e cam bolt slightl y (less than 1 complete turn) to s ee if that helps with the alignment of the cam lock & bolt. Still having issues?

Repeat your Cam Lock (9) installation for the Back Top Rail (F) and Back Bottom Rail (L).

Step

Holes faceing up

9 x4 9 9 9 9 9 F L B

Big holes faceing up

Secure the Back Bottom Rail (L) using three M4*35mm Screws (10).

10 x3 B C 10 10 10 L

Step 6

Cha-cha slide in the Back Panel (G).

Step

G B C

Step 8 7 6 5

Connect the Top Panel (A) to the unit using the Wooden Dowels (5), as pictured below. Slide a Flat Washer (6) onto a Hex Button Head Bolt (7) then use the Allen Key to tighten the Top Panel (A) to the unit. Repeat four times, as shown below.

x4 x4 x4 5 5 5 5 7 6 7 6 7 6 7 6 A B C

Step 9 10 x3 9 x3

Tighten the Top Front Rail (H) using three M4*35mm Screws (10). Insert three Cam Locks (9) into the back of the unit, as well.

10 10 10 H

F C

9 9

Step 10

Connect the Leg Frame (I) to the unit with the Wooden Dowels (5).

To make sure everything stays in place, you’ll need to use the Hex Button Head Bolts (7) and (8) along with Flat Washers (6).

For each bolt, you’ll put a flat washer on first, then slide the bolt through the holes and tighten. Do this for both bolts to securely attach the Leg Frame (I) to the unit.

7 6 5 x2 x4 x2 8 x2 5 5 8 6 8 6 I B 7 6 7 6 7 6 8 6 5 5 8 6 8 6 7 6 7 6

Tighten

STEP 1

the bolts to 75% STEP 2

the all bolts to 100%

Repeat Step 10 with the other Leg Frame (I).

Step

7 6 5 x2 x4 x2 8 x2 8 6 8 6 I C 7 6 7 6 7 6 8 6 5 5 5 8 6 8 6 5 5 7 6 7 6

1 Tighten the bolts to 75%

2 Tighten the all bolts to 100%

STEP

Attach the four Hinges (11) to the doors using eight M4*14mm Screws (12).

x8 x4 12 11 x4 11 12 12 K J

Step 12

Lookin’ good! Secure the doors to the unit by the hinges using the M4*14mm Screws (12). Atttach the two Handles (14) to the door fronts using two 5/32”*25mm Hex Button Head Bolts (13). Step 13

x16 12 x2 x2 14 13 K 12 J x4 13 14 13 14

Is your cabinet door looking crooked or unevenly spaced?

Then you’ve come to the right place. Follow the illustrations below to get your cabinet door aligned and ready for action.

Is your cabinet door

looking crooked or unevenly spaced? (Cont.)

If you’re still having trouble lining everything up, your next step should be to adjust the leveling glides to square up the cabinet and doors and make sure things are level. Follow the instructions below:

If the right door appears to be hanging low, you can adjust the adjustable leveler on the front right until the door is better aligned.

If the left door appears to be hanging low, you can adjust the adjustable leveler on the front left until the door is better aligned.

Step 14

To level your unit, simply adjust the levelers found on the legs until everything is straight and even.

leveller

Safety first! Secure the Plastic Bracket (16) to the back of the unit using two M4*14mm Screws (15) and then loop the Plastic Tether (17) through the Bracket. Step 15

x1 17

15 15 17 16 15 15 16 16

16 15

Please note... Part 10 & 18 are for non-drywall applications. Part 19 & 20 are for drywall applications.

See following pages for more details.

Step

x2 x1 x2 x2 x2 19 20 16 18 10 17 16 16 18 18 16 10 10 19 19

How to use Drywall Anchors

5/16” Drill Bit

5/16” Hole

3. Begin tightening.

4. Anchor is secure when screw is tightened to 100%

1. Drill hole with 5/16” bit. 2. Pinch and insert. WALL WALL

No heartburn, when we handle the return

Give us a call 1-866-619-1004 or shoot us a message at help@nathanjames.com we will issue you a free replacement with zero hassle

Our way Their way

Give us a call

Replacement

You

Re-package item

Schedule pick up

Track package

Replacement

You

We really don’t want you to go through the hassle of re-packaging your item and sending it back, because let’s be honest…nobody has time for that.

Safety first, fun later

We want your product to last as long as possible, so we recommend that you tighten the screws 2 weeks after assembly and for added safety check the tightness of all screws every 2 months.

For proper care and treatment, please check our website at NathanJames.com/products

Safe use of this product starts with you.

Use this product responsibly with the primary concern for your safety. Follow assembly instructions carefully and inspect product upon receipt and each use.

Nathan James and its parent companies cannot be held legally responsible for any injuries or death resulted from failure to follow instructions or improper use of this product.

Do not modify the structure of this product in any way.

Our products have been tested to meet specific safety measures as they were originally intended to be sold. Any modifications will present the risk of creating significant safety issues which NJ will not be responsible for.

DO NOT use for commercial purposes

DO NOT frolic on storage unit

Proper use

DO NOT use storage unit as foot stool

DO NOT leave spilled liquid on unit

DO NOT use storage unit if damaged

DO NOT make temporary repairs

DO NOT use outdoors

We are only in business if you’re happy

For starters, thanks for being you.

Toll-free at 1-866-619-1004

Help@nathanjames.com

NathanJames.com/help

We do our best to ensure your furniture arrives without any problems, but occasionally mistakes happen—as humans we are imperfect beings. In the event that a part is damaged or missing, we will be more than happy to provide you with replacement part(s) for free.

Warranty

This product comes with a lifetime warranty from the date of purchase. Please use your phone to scan the QR code to register your product or visit https://goo.gl/i9dk3q

Brooklyn Burdon Founder, Nathan James

Did we do alright? Please spread the love!

If you are happy with your product, tell your friends and family about us or even better leave us a review online. Spreading the word gives us the opportunity to make more people happy and keep our prices low for your next purchase.
