Leah Bookshelf Instruction Sheet 68222

Let’s build the

0

SEMBL

Y

A

S

MINU

TE

9

SKU 68222

Bookshelf

Scan me!

Free Lifetime Warranty 24-11-14 -VN

Ok, let’s get rolling This should be easy, just follow our instructions and you will be back to Netflix in no time.

What’s included Description

Qty

A

Arched Top

2

B

Middle Side Frame

2

C

Open Shelf

3

D

Bottom Side Panel (Left)

1

E

Bottom Side Panel (Right)

1

F

Top Cabinet Panel

1

G

Bottom Cabinet Panel

1

H

Back Stretcher

2

I

Back Panel

1

J

Adjustable Shelf

1

K

Door (Left)

1

L

Door (Right)

1

Estimated time for assembly

90:00 What you need •

Some of your favourite bubbly or your preferred relaxant

•

Use the packaging carton as a working surface to prevent product damage during assembly

•

Phillips head screwdriver

•

Drill (not included)

•

1/4” Drill bit (not included)

•

5/16” Drill bit (not included)

Weight Limitation

165

max. capacity

Scan me!

Free Lifetime Warranty Toll-free at 1-866-619-1004 Help@nathanjames.com Nathanjames.com/help

Toll-free at 1-866-619-1004 Help@nathanjames.com Nathanjames.com/help 2

The goods

IMPORTANT 1. Do not tighten bolts / screws completely until all bolts / screws are lined up and inserted into holes.

2. Do not over tighten screws and bolts to avoid stripping.

3. Please use hand tools to assemble this product.

3

What’s included Description

Qty

1

Ø1/4” x 30mm Hex Button Head Bolt

24

2

Ø1/4” x 45mm Hex Button Head Bolt

4

3

Ø1/4” x 65mm Hex Button Head Bolt

4

4

Ø1/4” x 10mm Spring Washer

32

5

Ø1/4” x 13mm Flat Washer

32

6

Allen Key

1

7

Cam Bolt

4

8

Cam Lock

4

9

Ø8 x 30mm Wooden Dowel

40

10

Leveler (Extra)

11

M3.5 x 15mm Screw

4

12

Shelf Pin

4

13

Magnetic Catch

2

14 M3.5x15mm Screw (for Anti-Tip) 15

Drywall Anchor (for Anti-Tip)

2

16

Plastic Bracket (for Anti-Tip)

2

17

Non-Drywall Anchor (for Anti-Tip)

2

18

M4x50mm Screw (for Anti-Tip)

2

19

Plastic Tether (for Anti-Tip)

1

4

The goods

Step 1

1

x 4pcs

4

x 4pcs

5

Let’s get this thing fired up! Begin by attaching the Arched Tops (A) to the Middle Side Frames (B). First, insert the Wooden Dowels (9) into the designated holes. Then, use a Hex Button Head Bolt (1) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly.

A

A

B

B

9 9 100%

x4

5 4

6

1

6

x4pcs

9

x8pcs

Step 2

1

x6pcs

x6pcs

4

5

x 6pcs

Attach the Open Shelves (C) to one of the Side Frames (B).

First, insert the Wooden Dowels (9) into the designated holes.

Then, use a Hex Button Head Bolt (1) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly.

C C

6 1 4 5

9

9

C

B

100%

x

7

9

x6pcs

Step 3

x6pcs

1

4

x6pcs

5

x6pcs

You should be a pro by now!

Repeat Step 2 with the other Side Frame (B).

B

100%

9 9

1

4

6

5

x

8

9

x6pcs

Step 4 Secure the Magnetic Door Catch (13) to the Top Cabinet Panel (F) usig two M3 x15mm Screws (1 ). Then, attach the Back Stretcher (H) to the Top Cabinet Panel (F) by inserting the Wooden Dowels (9) into the designated holes. Then, use a Hex Button Head Bolt (3) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly.

3

x2pcs

4

x2pcs

5

x2pcs

9

x2pcs

13

x1pc

1

x2pcs

6 3 4 5 x2

100%

9

H F

1

13 Front

Helpful Tip! Magnetic Door Catch can be adjusted front to back to solve for proper door alignment.

9

Step 5

3

x2pcs

4

x2pcs

5

x2pcs

No, this isn’t Deja Vu! Repeat Step 4 with the Bottom Cabinet Panel (G).

9

x2pcs

13

x1pc

1

x2pcs

6 3 4 5 x2

100%

9

H 1

G

13 Front

Helpful Tip! Magnetic Door Catch can be adjusted front to back to solve for proper door alignment.

10

Step 6

7

Twist four of the Cam Lock Bolts (7) into the designated holes on the Bottom Side Panel (Right)(E) and Bottom Side Panel (Left)(D).

Be sure the Cam Lock Bolts are tightened all the way.

x

11

x4pcs

Step 7

1

x 4pcs

4

x 4pcs

5

x 4pcs

Attach the Top Cabinet Panel (F) and Bottom Cabinet Panel (G) to the Bottom Side Panel (Right) by inserting the Wooden Dowels (9) into the designated holes.

Then, use a Hex Button Head Bolt (1) with a Spring Washer (4) and a Flat Washer (5) to tighten everything to 100%.

100%

x2

x2

12

9

x 4pcs

Step 8

8

Insert the Back Panel (I) vertically into the groove in the side panel. Secure with two Cam Locks (8).

See the following page for a quick guide on cam locks!

I

8

13

x2pcs

How to use cam locks

Did you know?

Cam locks are used to join two panels together, usually the edge of one to the flat side of another.

First, your cam bolt (or cam pin) will need to be properly inserted into the flat side of the board.

Important Note: Only tighten the cam bolt until it is secure. Do not over-tighten.

Next, you will fit the proper hole on the edge of the associated joining panel over the cam bolt.

Important Note: When installed properly, the head of the cam bolt will be visible through the larger hole on the side of the joining panel.

Next, you will notice the cam lock has a “C” shaped back. Commonly, an arrow on the front of the cam lock points in the same direction as the open section on back.

Using these as your cue, insert the cam lock into the large hole so the opening of the “C” fits over the head of the cam bolt.

Using a screwdriver, you will turn the cam lock until it stops, usually between 130º or 180º.

You will feel the panels pulling closer until they are secured.

Important Note: Only turn the cam lock until the panels are fully engaged & feel secure.

Turning too far may lead to hardware failure.

Still having issues?

If a cam lock seems to be spinning in place or is not “catching” or pulling the panels together as expected , first remove the cam lock & try again while making sure that everything is properly positoned & oriented.

If you are still having issues getting things worki ng as expected, first remove the cam lock then unscrew the cam bolt slightly (less than 1 complete turn) to see if that helps with the alignment of the cam lock & bolt .

14

Step 9

x4pcs

1

4

x4pcs

5

x4pcs

Secure the Bottom Side Panel (Left)(D) to what you’ve assembled so far from Step 8. Be sure that the back panel is inserted in the groove in the side panel.

D

x2

9 9 100%

5 4 1 6

15

9

x4pcs

Step 10

8

Secure with two Cam Locks (8).

Would you believe us if we told you you’re over halfway finished?!

x2

8

16

x2pcs

Step 11

x4pcs

2

4

x4pcs

5

x4pcs

Time to bring it all together!

Secure the Arched Top section with the bottom section by insterting the Wooden Dowels (9) into the designated holes. Then, use a Hex Button Head Bolt (2) with a Spring Washer (4) and a Flat Washer (5) to secure them tightly.

x2

100%

17

9

x8pcs

Step 12

12

Insert four Shelf Pins (12) at the height you want the shelf to be. Then, place the Shelf (J) on top of the pins.

100%

18

x4pcs

Step 13

HELPFUL TIP: Adjust feet to balance cabinet.

19

Is your cabinet door looking crooked or unevenly spaced? (Cont.)

If you’re still having trouble lining everything up, your next step should be to try to adjust the feet slightly to square up the cabinet & doors. Follow the illustrations below: If the right door appears to be hanging low, you can adjust the adjustable leveler on the front right until the door is better aligned.

If the left door appears to be hanging low, you can adjust the adjustable leveler on the front left until the door is better aligned.

2

1. Drill hole with 5/16” bit.

ALL 5/16” HoleW

5/16” Drill Bit

WALL

How to use Drywall Anchors

2. Pinch and insert.

4. Anchor is secure when screw is tightened to 100%

3. Begin tightening.

2

Step

x2pcs

x1pc

17

x2pcs

x2pcs

WAL

L

17 16

17

IMPORTANT NOTE: Non-Drywall Anchor (17) requires 1/4” Drill Bit

2

Step Secure the other Plastic Bracket (16) to the back of the bookshelf using the M3.5*15MM Screws (1 ) and then secure the bookshelf to the wall by looping the Plastic Tether (19) through both brackets.

16

1

x1pc

19

x2pcs

x1pc

IMPORTANT NOTE Young children (and/or pets) can be seriously injured by tipping furniture units.

You must install the provided anti-tip kit hardware solution, as instructed, to prevent the furniture unit(s) from tipping over which could possibly lead to injuries or damage.

The provided anti-tip kit hardware solution is intended only as an additional safety measure & deterrent; it is not a substitute for proper adult supervision.

The provided anti-tip kit hardware solution is not an earthquake restraint. If you wish to add the extra security of earthquake restraints, they must be purchased & installed separately.

16 1 1

17

wall

19 shelf

16

17

16

1 16 16

Tether to the wall.

19

2

No heartburn, when we handle the return Give us a call 1-866-619-1004 or shoot us a message at help@nathanjames.com we will issue you a free replacement with zero hassle.

Our way

Their way

Give us a call

Re-package item

Replacement

Schedule pick up

You

Track package Replacement You

We really don’t want you to go through the hassle of re-packaging your item and sending it back, because let’s be honest…nobody has time for that.

2

Safety first, fun later We want your product to last as long as possible, so we recommend that you tighten the screws 2 weeks after assembly and for added safety check the tightness of all screws every 2 months.

For proper care and treatment, please check our website at NathanJames.com/products

Safe use of this product starts with you.

Do not modify the structure of this product in any way.

Use this product responsibly with the primary concern for your safety. Follow assembly instructions carefully and inspect product upon receipt and each use.

Our products have been tested to meet specific safety measures as they were originally intended to be sold. Any modifications will present the risk of creating significant safety issues which NJ will not be responsible for.

Nathan James and its parent companies cannot be held legally responsible for any injuries or death resulted from failure to follow instructions or improper use of this product.

Proper use

DO NOT

use for commercial purposes

DO NOT

frolic on bookshelf

DO NOT

use bookshelf as foot stool

DO NOT

leave spilled liquid on shelves

DO NOT

use bookshelf if damaged

DO NOT

make temporary repairs

DO NOT

use outdoors

2

We are only in business if you’re happy For starters, thanks for being you.

Toll-free at 1-866-619-1004 Help@nathanjames.com NathanJames.com/help

We do our best to ensure your furniture arrives without any problems, but occasionally mistakes happen—as humans we are imperfect beings. In the event that a part is damaged or missing, we will be more than happy to provide you with replacement part(s) for free.

Warranty This product comes with a lifetime warranty from the date of purchase. Please use your phone to scan the QR code to register your product or visit https://goo.gl/i9dk3q

Did we do alright? Please spread the love!

If you are happy with your product, tell your friends and family about us or even better leave us a review online. Spreading the word gives us the opportunity to make more people happy and keep our prices low for your next purchase.
